DRAKE PSM125 User manual

1
PSM125 Power Supply
GENERAL
Power Requirements: 100 VAC to 250 VAC
Frequency: 50/60 Hz
Operang Temperature Range: 0 to +50 °C
Output Voltages: +5 VDC @ 7 Amps max.;
+12 VDC @ 4.5 Amps max.
MECHANICAL
Dimensions (WxHxD): 4.2 in x 3.5 in x 7.5 in
107mm x 89mm x 191mm
Weight: 2.6 lbs. (1.2 Kg)
CONNECTORS
AC Input: IEC
DC Output: 37-pin D
ACCESSORY SUPPLIED
AC Power Cord: 6 Ft., IEC, USA
PSM 125 Rear Panel Connecons
Both the AC input receptacle and DC output
connector are located on the rear panel of the
power supply module.
1. AC Input - The power supply accepts standard
100 to 250 VAC, 50/60 Hz inputs.
2. DC Output - The polarized D connector
provides 12 sets of +12 VDC, +5 VDC, and Ground
connecon cables for the compable modular rack
units.
© Copyright 2015 R.L. Drake Holdings LLC. P/N: 651239500A Printed in Taiwan
Rev: 20150309
1001507
® is a registered trademark of the R.L. Drake Holdings LLC
DATE CODE: XXXX
P/N: XXXX
Serial No: XXXX
Purchase from: www.multicominc.com 800-423-2594
®
407-331-7779
