This Digital Terrestrial Receiver (DTR) will take you to the new and exciting
world of Digital Television. A world of crystal clear widescreen pictures, digital
sound, more information and new services. All this and more on "Free to Air"
Digital Television.
To make full use of your new DTR please take the time to familiarize yourself
with the extensivefeatures of theunit detailed inthis User's Guide.
If you need help in setting up please call your dealer or a customer service
adviser.
1

Main Features
MPEG-2 digital &fully DVB-T compliant
1000 channels TVand Radio programmable
8 different favoritegroups selection
On Screen Displaywith 12 languages
Fully support to7 days ElectronicProgram Guide(EPG)
Picture in Graphics(PIG)support
256 colors OnScreen Display
Channel search inautomatic and manual
Various channelediting function(favorite, move and lock)
Parental control forchannels
Plug and Playinstallation, with anease to use Menu System
Software upgrades throughRS232 port
2

1 sleep timer
Subtitle support DVBEN300743 and EBU
Teletextsupport DVB EN300472by OSD
Support Logic ChannelNumber(LCN)
Active AntennaPower supply control
Display the detailinformation of theactive channel with signal level &
quality indication
Support 16:9 and4:3 TV aspectratios, by Pan& Scan andLetter Box
conversion
NTSC/PALConverting Automaticallyand Manually
Game
Main Features
3

GENERAL INFORMATION
GENERAL INFORMATION
RCU
4
ASPECT
SIGNAL BAR
DISPLAY

GENERAL INFORMATION
GENERAL INFORMATION
Key Function
Turns power ON/OFF ofthe DTR
When watching a program, mute the sound
Switches between TV and Radiomode
0~9
MENU
Enter number of the requiredmenu item
or select a program numberto watch
Press this key one timeto run menu on
screen, and call command box
TV/RADIO
PR
Switches back to previous program
Display the favorite program list
Shows information of the currentprogram
Moves up/down a page inthe listprogram
FAV
INFO
AUDIO Choose audio mode
EXIT
OK, LIST
PR+, PR-
Returns to the previous menuon the menu
screen or escape from themenu
Press once to pause thescreen picture, press
once again to go tothe normal mode
Switches to subtitle mode
No function
Executes the selected item inthe menu screen
or enters the desired valuein any input mode
When watching a , change s or
move to the next higheror lower item in themenu
program program
When watching a , adjust the volume or
move to the left orright item in the menu
program
Calls up the EPG (Electronic Program Guide)
Selects the different audio modes
Switches between TV and AV modes
EPG
L
R
TV/AV
PAUSE
UHF
Key Function
5
Switches to teletext mode
TXT
PAL/NTSC Switcher between PALand NTSC mode
Enter into nine-pictures mode displayon the
screen

GENERAL INFORMATION
GENERAL INFORMATION
Rear Panel
CONNECT TOA PC FORS/W UPGRADE
CONNECT TOAUDIO R/L OR
TV OR RADIO TUNER
ANT IN: CONNECTTO ANTENNA
CONNECT TO
THE POWER SUPPLY
CONNECT TO INFRAREDRECEIVER
6

GENERAL INFORMATION
GENERAL INFORMATION
Connecting to TVusing SCART support
DTR
Antenna
CONNECT TO
THE POWER SUPPLY
TV
CONNECT TO TV
USING SCART CABLE
7

INSTALLATION
INSTALLATION
Connecting to DigitalAudio
DTR
Antenna
DIGITAL AUDIO
8

WELCOME PAGE
WELCOME PAGE
When power onfirst time, itwill show welcome page as below.
Press [Up/Down] key to move highlight to
choose your choice.
Press [Left/Right] key to move highlight to
select Region and OSD language.
Press [EXIT] keyto exit thismenu.
Move highlight to [OK] option and press
[enter] key tobegin to autoscan.
9

MAIN MENU
MAIN MENU
This menu consistsof 4 majorsub-menus as
below.
-Channel -Installation
-Setup -Tools
1. Channel
When you press[MENU] key,you can enterMain Menu
Move highlight on Channel item and press [OK]
key to enterChannel menu asbelow.
This menu hasfive sub-menus suchas: TV
Channel list, Radio Channel List, Delete All
Favorites, Delete All,Group Rename.
10

MAIN MENU
MAIN MENU
1.1 TV Channel List
When you enter“Channel List” menu, the screen will display as below.
You can move highlight by press [Up/Down]
key and preview the highlighted program in
preview window besidethe channel list.
You canpress [Page Up/Page Down] key to
implement the Pageup or Pagedown function.
You canpress [OK] keyor [EXIT] keyto enter full screen mode.
Press number keys[0]~[4] to carryout the corresponding functions that
show you atthe bottom of screen.
11

MAIN MENU
MAIN MENU
12
Pressing number key [1] can
Pressing [Up/Down] key to move the cursor up
and down.You can choose between Group1-
Group8.
Pressing [OK] key will pop up a dialogue to ask
whether assign channelto the groupor not.
pop up the Sort
drop-down list.
1.1.1 Edit
Press [OK] key at the Yes button to assign the selected channel, or press
[EXIT] key to cancelthe operation.

MAIN MENU
MAIN MENU
13
1.1.2 Find
Pressing number key[2] will enterFind window.
Pressing [Up/Down] key or [Left/Right]
key to choosethe letter inright window.
Move cursor to [OK] button and press,you can
find the channelyou want.
1.1.3 Sort
Pressing number key[3] will popup the Sort drop-down list.
Name(A-Z): The ascending order, omitting the $ character, the number
is ahead, thenthe capital letter, at lastthe lowercase.
Name (Z-A): The opposite orderof the aboveName (A-Z).

Free/Scrabmle: All FTA programs are listed
ahead, while all scrambled programs are
listed last.
Lock: all locked programsare listed atthe last.
MAIN MENU
MAIN MENU
14
1.1.4 Move
Pressing number key [4], there will be a
moving mark on the right of the selected
channel.
Then, you can move the selected channel to
the position where you want to place it by
press [Up/Down] key . And press [OK] key to
confirm your decision.

MAIN MENU
MAIN MENU
1.2 Radio Channel List
Basically, theoperation of “Radio Channel List”is same as “TV Channel
List”. But there is only one different: In “Radio Channel List”mode,
there is no video information, so it always display Radio’s logo in the
preview window.
11
15
1.3 Delete All Favorites
When you move highlight on this option and
press [OK] key, a message box will appear
and ask youto choose.
If you choose yes, it will remove all the
favorite channels (include TV and Radio
favorite channels) fromfavorite list.

MAIN MENU
MAIN MENU
1.4 Delete All
This operation is same as 1.3,but it willdelete
all the channels including TV channels and
Radio channels.
11
11
16
1.5 Group Rename
When you enter“Group Rename” menu,the screen willdisplay as below.
Press Keys to movethe cursor up
and down.
Press [OK] Key to enter GroupRename
window.
The operation is the same as1.1.2 Find, here
we don't explainany more.
[Up/Down]

2. Installation
MAIN MENU
MAIN MENU
In this menu, you can press [Up/Down] key to
select sub-menus and press [OK] key to enter
the menu whichis chosen.
When you enter Installation menu, the screen
will display onthe right.
2.1 Auto Scan
When you enter Auto Scan menu, the screen
will display onthe right.
In Scan Mode item, press [Left/Right] key to
choose scans all the channels or just scans
free channels.
11
11
17

MAIN MENU
MAIN MENU
Move the highlight on the search option, and press [OK] key to start
scanning.
Press [EXIT] keyto exit thismenu.
2.2 Channel Scan
When you enterChannel Scan, the screen will
display as beside.
There are two scan modes for you. You can
choose to scanby channel orby frequency.
When scan band is UHF and region is “China”, the range of Ch Number
is from 13 to 61. When scan band is VHF and region is “China”, the
range of ChNumber is from1 to 12. (It’s according toregion.)
11
11
