Dramm Autofog MLVH-10A User manual

AUTOFOG™
MLVH-10A
Owners Manual

Dramm Autofog MLVH-10A Manual 3
Table of Contents
MLVH-MAN3
Printed in the U.S.A. Revised 10/2016
Warranty ..........................................................................................................................................................................................................................4
Warning ..........................................................................................................................................................................................................................5
How Does My Autofog Work? ............................................................................................................................................................................7
Assembly Instructions ..............................................................................................................................................................................................8
Pre-Operation Checklist..........................................................................................................................................................................................8
Chemical Mixture and Application ..................................................................................................................................................................9
Low Rate Calculations ............................................................................................................................................................................................10
High Rate Calculations............................................................................................................................................................................................11
Spraying Procedure/Timer Settings ................................................................................................................................................................12
Cleaning & Maintenance. ......................................................................................................................................................................................13
Assembly Diagram ....................................................................................................................................................................................................14
Assembly Parts List....................................................................................................................................................................................................15
Compressor Plumbing Diagram ........................................................................................................................................................................16
Compressor Plumbing Parts List........................................................................................................................................................................17
Compressor Diagram ..............................................................................................................................................................................................18
Compressor Parts List..............................................................................................................................................................................................19
Nozzle Assembly Parts List....................................................................................................................................................................................20
Troubleshooting......................................................................................................................................................................................................21-22
Notes ................................................................................................................................................................................................................................23

Dramm Autofog MLVH-10A Manual 5
WARNING
• The Dramm Autofog MLVH-10A is a low-volume
application machine that applies Hazardous
Chemicals in concentrated solutions. Care
and Logic must be adhered to. The solution
particle size is very small (0.5 microns to 10.0
microns). Beware of inhalation.
• Follow EPA Guidleines for application of
chemicals.
• Wear Protective Clothing, gas mask, hood
gloves and boots when mixing chemicals, pouring
chemicals into the tank and when applying
chemicals.
• Ensure area to be treated is securely
closed - with no vents open.
• Ensure That No humans or Pets Are In
The Area To Be Treated - death from
chemicals could occur!
• After the machine has been turned on, chemical
application begins. Exit the area immediately.
Secure or lock the enclosure. Post “Do Not
Enter” hazard signs. The Deadly Chemical
Vapor Will Not be Visible! It is your
responsibility to ensure no one can enter the
enclosure for at least 6 hours after the machine has
stopped applying chemical.
•Before Re-Entry, Air Must Be Changed
By Venting. Follow all EPA Guidelines for re-
entry periods.
•Do Not Use This Machine In An
Enclosure Where Vapors Can Enter
Any Type Of Air Vents. Care should be
taken to ensure vapors can not reach buildings or
homes in close proximity to the enclosure being
treated.
• After Use, Double Rinse The Chemical
Tank and dispose of rinse water according to EPA
Guidelines. Clean the nozzle and suction line
thoroughly. Store the unit in a safe location away
from children and unauthorized personnel.
• Mix Only The Amount of Chemical
Which Will Be Used to treat the area.
Never - Keep - Store - Or Hold Over
Unused Chemical Solution.
• Your machine is labeled 110 volt - single phase, 220
volt - single phase or 220 volt - 3 phase. Be Sure
To Connect Your Machine To The
Correct Voltage Receptacle. Contact
your electrician for accurate voltage/phase
readings if necessary.
• Exercise Accepted Saftey Procedures
when using electricity.
The Dramm Mini Autofog MLVH-10A sprays dangerous toxic chemicals. Please read and
understand the following safety precautions before operating your Autofog. Failure to follow these
instructions may result in serious injury or death.

Dramm Autofog MLVH-10A Manual 6
1. Attach handle to side of machine opposite control
panel using four 1/4- 20 x 3/4 hex bolts. Tighten.
2. Place lower nozzle stand over studs showing through
red compressor unit cover. Adjusting knob should face
control panel. Place lockwashers and nuts on studs and
tighten.
3. Insert the nozzle stand into the nozzle stand tube with
the nozzle bracket facing away from the control panel
end. Adjust the height of the nozzle stand as necessary.
Tighten the black height adjustment knob.
4. Place the solution tank into the circular tank holder.
Rotate the tank so that the small suction hole faces the
front of the machine (the control panel end is the back
of the machine).
5. Secure the nozzle onto the nozzle stand. Insert the
suction tube into the solution tank. Check that the
suction tube reaches the bottom of the tank (there is a
slight depression in the bottom of the tank where the
suction tube should rest). Place the agitator back into
the solution tank and secure with the turn tabs.
6. On the control panel, insert air hose into the press-fit
connection marked AIR TO NOZZLE. On the nozzle,
insert air hose the same way.\
7. Plug the agitator power cord into the control panel and
connect the main power cord into a 110 volt power
source.
8. The unit is ready to spray. But before you start
spraying, read this manual thoroughly and follow all
E.P.A. Guidelines.
9. Before you spray for the first time, test the MLVH-10A
with water. Pour a small amount of clear water (about
1 liter) into the solution tank. Rotate the timer
clockwise. Spraying begins immediately. Observe the
quality of the spray pattern and pressure gauge
readings. If you have any questions, contact the Dramm
Corporation Service Department at 800-258-0848 or
920-684-0227.
List of tools needed:
• 7/16" Wrench
• 1/2" Open End Wrench
• 9/16" Open End Wrench
• Straight Blade Screwdriver
• MLVH-10A Assembly Diagram
• 1/2" Socket Wrench
Autofog MLVH-10A Assembly Instructions
Nozzle Cap
Checkmark Checkmark
Suction Tube
Securing Nut
x

The Dramm Autofog applys chemicals under the
low-volume (LV) principle. This means that the same
amount of active chemical is applied to a given area,
but the chemical is diluted into reduced amounts of
water. Because LV application is very efficient, many
users have found that lower volumes of chemical can
be used with the same results.
The Mini Autofog MLVH-10A will require a
minimum of 2 liters of water and the chemical to treat
5,000 square feet. If less than 5,000 square feet is
treated, a minimum of 2 liters of water is still used.
The specially designed solution tank and agitator
prevents concentrated chemicals from precipitating.
According to conventional high-volume (HV) spraying
methods, approximately 20 gallons of water (diluent)
plus the chemical is needed to treat 5,000 square feet.
LV application is only possible when extremely fine
particles are produced. The patented nozzle design of
the Mini Autofog MLVH-10A produces particles which
will range in size from .5 to 10 microns in diameter. Air
enters the nozzle from the oil-less compressor and
then exits the nozzle at super sonic speeds. This
movement of air creates a venturi that draws solution
from the chemical tank. As the solution exits the
nozzle it is micronized into billions of tiny particles.
The micronized chemical particles stay suspended for
up to 6 hours and are distributed by horizontal airflow
fans (HAF) and natural air currents.
The Mini Autofog MLVH-10A features manual
starting and a timer for automatic shut-down. Other
features include a safety valve on the compressor to
release any abnormal pressure build-up. The motor
which drives the compressor is supplied with a
grounded electrical cord set and is protected from
overheating with a thermal fuse that disconnects
power to the entire sprayer. The Mini Autofog MLVH-
10A now has a redesigned frame and handle to ease in
its transportation in small greenhouses and storage
facilities.
How Does My Autofog MLVH-10A Work?
7 Dramm Autofog MLVH-10A Manual
Note: Dramm offers an instructional video on our website. Please watch this before using your machine.

Precautions / Pre-Operation Checklist
D. Cold weather operation: When the temperature falls
below 32°F run the compressor in a warm environment
before placing the MLVH-10A assembly in the area to
be treated. The bearing grease may harden in very cold
temperatures causing the compressor to not preform
properly. Unless absolutely necessary, do not operate
the MLVH-10A in sub 25°F weather.
E. You will get an accurate output volume if
the nozzle cap is closed completely and
then returned to match the red check
marks. See diagram below.
NOTE:
Output volume will vary 2.5 - 3.0 cc/min. for each
notch in the nozzle cap.
•Clockwise: Output INCREASES
•Counterclockwise: Output DECREASES
NOTE:
Check the O-ring located inside the nozzle cap for wear
or damage. Replace if necessary
Dramm Autofog MLVH-10A Manual 8
A. For the most effective performance, the treatment area
must be air tight. Take time to repair any broken glass,
torn poly and gaps or openings in vents and door
frames.
B. The entire treatment area should be vacant. No
humans or pets should be present.
C. It is recommended that the application process take
place at the end of the day. Secure the treatment area
and post hazard signs before spraying.
D. Avoid spraying when the temperature is over 85°F in
the treatment area or when relative humidity exceeds
85%.
E. When utilizing horizontal airflow fans (HAF), run them
for 1/2 hour longer than actual spraying time.
F. Follow all EPA Guidelines regarding the application of
chemicals.
A. Test run the MLVH-10A with clear water for 1-2
minutes. Observe the spray quality.
B. The discharge volume rate of clean water is
approximately 45 cc / minute. When testing the
unit, pull the suction hose out of the solution tank
and place it in a graduated cylinder (fill it with 90
cc of clean water). The cylinder should be empty
after a 2 minute test run. Be sure to check the
discharge volume rate regularly to assure best
results.
C. Observe the operating pressure. The gauge will
read 14-23 PSI.
NOTE
: Check for leaks in the
piping when the pressure is too low. Eliminate
clogs if the pressure is too high. Pressure readings
may vary from location to location. Small
differences are inconsequential.
Compressor/Sprayer
Treatment Area
WARNING: The standard model Autofog uses a
nozzle that is manufactured with brass components.
The use of oxidizers will damage this nozzle
within several applications.
If you plan to use oxidizers in your Autofog,
CONTACT DRAMM BEFORE THE FIRST USE OF YOUR
MACHINE to purchase a stainless steel nozzle at a
reduced cost. After your machine has been used,
Dramm cannot accept the original nozzle
back for credit.

1. Determine the treatment area size in square feet.
NOTE:
A minimum of 2 liters of water should be added to the
active chemical when treating less than 5,000 square
feet. More water should be added to dilute larger
volumes of chemical (to a 15 to 1 ratio).
2. Calculate the chemical amount.
Example: Labeled chemical rate per 100 gallons is 16
ounces. We will first calculate a rate for 10,000 square
feet.
Low Rate: 16oz. X 0.20 = 3.2oz.
(for 10,000 square feet)
High Rate: 16oz. X 0.35 = 5.6oz.
(for 10,000 square feet)
NOTE:
Divide the rate per 10,000 square feet by
2 for the rate per 5,000 square feet. If you are treating
areas less than 5,000 square feet, make the rate
calculation for 5,000 square feet and reduce that
amount proportionately. Contact the Dramm Service
Department at 800-258-0848 or 920-684-0227 if you
have any questions.
3. Calculate the water volume for at least a 15 to 1 ratio
for wettable powder and flowable formulations. Mix
water with chemical in the mixing pitcher. Pour the
mixture into the solution tank through the strainer.
Eliminate dirt and globs of chemical that may clog the
nozzle. When using wettable powders, make a lump-
free slurry of the powder to wet it completely and then
add the remaining portion of water. For ECs use a 10:1
dilution ratio.
4. Position the MLVH-10A for spraying.
5. Install the solution tank on the sprayer and insert the
nozzle suction tube. Make sure the suction tube
reaches the bottom of the tank. When a full chemical
tank is loaded onto the MLVH-10A, do not move the
machine to avoid spilling the chemical solution.
6. Connect the MLVH-10A to a 120V 60HZ power source
and set the timer by rotating past and then returned to
the desired spraying time. The spraying process
begins immediately – vacate the
treatment area.
NOTE:
Always wear protective clothing, gas mask, hood, gloves
and boots when mixing chemicals and using the MLVH-
10A.
1. WARNING: All EPA Guidelines on the handling,
application and re-entry periods for chemicals must be
adhered to. Only crops which are listed on the
chemical label should be treated.
2. Labeled chemical rates are stated in amounts of
chemical to be diluted into 100 gallons of water. Most
chemical labels do not advise how much of the spray
concentrate should be applied to a given area.
3. Greenhouse growers apply from 25 to 300 gallons of
spray concentrate per 10,000 square feet, the average
high volume application is 40 - 50 gallons per 10,000
square feet.
4. The MLVH-10A is a low-volume applicator. Low
volume means application of chemical in a very
concentrated solution. The same amount of chemical
is applied to a given area as conventional spraying, but
in greatly reduced quantities of water. This is possible
since low volume equipment produces very small
particle sizes (0.5 to 10.0 microns) versus conventional
spray particles of 100 to 400 microns.
5. If you would normally spray 25 gallons of solution into
10,000 square feet of area you are applying 25% of the
chemical mixed in 100 gallons of water. (Per labeled
rate per 100 gallons).
6. The charts starting on the following page will help you
calculate the proper chemical amounts and water
volumes.
Preparation of Chemical Mixture and Application
Application of Chemicals
9 Dramm Autofog MLVH-10A Manual

16 oz X .20 = 3.2 oz
12 oz X .20 = 2.4 oz
CHEMICAL LABELED RATE
PER 100 GALLONS
CHEMICAL LABELED RATE
PER 100 GALLONS
LOW RATE
MULTIPLIER
.20
RATE FOR 10,000 SQUARE
FEET
RATE FOR 5,000 SQUARE
FEET
CHEMICAL REQUIRED
IN 10,000 SQ.FT.
MINIMUM AMOUNT OF
WATER FOR 5,000 SQ. FT.
If you spray 25 gallons per 10,000 square feet you will need...
LOW RATE
The following chart carries out the multiplication for you and reduces the chemical by 5% to
compensate for run-off.
Make Your LOW RATE Calculations Below.
E.C. W.P. OR F
Note: 1 Liter = 33.6 Ounces. We do not
recommend concentrations stronger than a ratio
of 15 to 1 for Wettable Powders and Flowables.
A ratio of 10 to 1 for Emulsifiable Concentrates.
Note: New chemicals or chemicals which have
been re-labeled may recommend how many
ounces should be applied per acre. If this is a
chemical you intend to use, the labeled rate
should be followed.
E.C. = Emulsifiable Concentrate F. = Flowable W.P. = Wettable Powder
4 oz X .20 = 0.8 oz ÷ 2 = 0.4 oz 2 liters 3 liters
6 oz X .20 = 1.2 oz ÷ 2 = 0.6 oz 2 liters 3 liters
8 oz X .20 = 1.6 oz ÷ 2 = 0.8 oz 2 liters 3 liters
10 oz X .20 = 2.0 oz ÷ 2 = 1.0 oz 2 liters 3 liters
12 oz X .20 = 2.4 oz ÷ 2 = 1.2 oz 3 liters 4 liters
14 oz X .20 = 2.8 oz ÷ 2 = 1.4 oz 3 liters 4 liters
16 oz X .20 = 3.2 oz ÷ 2 = 1.6 oz 3 liters 4 liters
18 oz X .20 = 3.6 oz ÷ 2 = 1.8 oz 3 liters 4 liters
20 oz X .20 = 4.0 oz ÷ 2 = 2.0 oz 3 liters 4 liters
Dramm Autofog MLVH-10A Manual 10

E.C. W.P. OR F
If you spray 40 gallons per 10,000 square feet you will need...
The following chart carries out the multiplication for you and reduces the chemical by 5% to
compensate for run-off.
4 oz X .35 = 1.4 oz ÷ 2 = 0.7 oz 2 liters 3 liters
6 oz X .35 = 2.1 oz ÷ 2 = 1.0 oz 2 liters 3 liters
8 oz X .35 = 2.8 oz ÷ 2 = 1.4 oz 3 liters 4 liters
10 oz X .35 = 3.5 oz ÷ 2 = 1.7 oz 3 liters 4 liters
12 oz X .35 = 4.2 oz ÷ 2 = 2.1 oz 3 liters 4 liters
14 oz X .35 = 4.9 oz ÷ 2 = 2.4 oz 4 liters 5 liters
16 oz X .35 = 5.6 oz ÷ 2 = 2.8 oz 4 liters 5 liters
18 oz X .35 = 6.3 oz ÷ 2 = 3.1 oz 4 liters 5 liters
20 oz X .35 = 7.0 oz ÷ 2 = 3.5 oz 4 liters 5 liters
Make Your HIGH RATE Calculations Below.
CHEMICAL LABELED RATE
PER 100 GALLONS RATE FOR 10,000 SQUARE
FEET
RATE FOR 5,000 SQUARE
FEET
MINIMUM AMOUNT OF WATER
FOR 5,000 SQ. FT.
16 oz X .35 = 6.4 oz
12 oz X .35 = 4.8 oz
CHEMICAL LABELED RATE
PER 100 GALLONS
HIGH RATE
MULTIPLIER
.35
CHEMICAL REQUIRED
IN 10,000 SQ.FT.
HIGH RATE
Note: 1 Liter = 33.6 Ounces. We do not
recommend concentrations stronger than a
ratio of 15 to 1 for Wettable Powders and
Flowables. A ratio of 10 to 1 for Emulsifiable
Concentrates.
Note: New chemicals or chemicals which have
been re-labeled may recommend how many
ounces should be applied per acre. If this is a
chemical you intend to use, the labeled rate
should be followed.
E.C. = Emulsifiable Concentrate F. = Flowable W.P. = Wettable Powder
11 Dramm Autofog MLVH-10A Manual

The MLVH-10A should be allowed to run for a half
hour after all chemical has been expelled into the
air. See the chart below for approximate amount
of time it takes to expel chemicals. These times
were compiled with clear water - the expulsion
time time may exceed these guidelines when
mixed with chemicals.
Times may vary due to the consistency of solution
being sprayed. Thicker solutions
may take longer to discharge.
1. Plug the AutoFog into the appropriate power
source.
2. Set the clock to the correct time. The timer is a 24
hour timer for accuracy between day and night.
3. Determine the spray starting time and stopping
time.
4. Flip ALL of the pins between the starting and
stopping time to the OUTSIDE. (see photo below)
5. The AutoFog will run only during the time that the
pins are flipped to the outside of the clock. DO
NOT FLIP THE START TIME AND STOP TIME
ONLY. Each pin represents 15 minutes of time.
6. The AutoFog is now ready and will begin fogging at
the appropriate time. Make sure the treatment
area is secure and will be empty of all personnel at
that time.
NOTE:
Remember to add a half hour to the spraying time
when setting the timer.
1. Vacate the treatment area, secure all entry ways
and post hazard signs.
2. Prepare the chemical solution. See page 10 for
dilution rate details. Be sure that the solution is
free of clumps of chemical that may clog the
nozzle. Use a whisk or blender to make a smooth
paste of wettable powder solutions. Check that
the suction tube screen is in place in the tank.
Pour the solution through the large solution
strainer/ funnel assembly to eliminate any unmixed
chemical or debris.
3. Plug in the main power cord. Notice the power
lamp illuminated on the control panel.
4. Set the timer. Turn the dial past, then return to
the desired operation time. The MLVH-10A will
begin to spray, vacate the treatment area
immediately.
5. If horizontal airflow fans are used, allow them to
run a half hour longer than the predetermined
spray time.
6. In order to allow all of the spray particles to settle,
do not re-enter the treatment area for a minimum
of 6 hours after the MLVH-10A has completed its
operation. Keep the structure airtight. However, if
it is necessary to enter the treatment area during
application, only do so in a full spray suit, boots,
gloves, hood and respirator.
7. After spraying, ventilate the treatment area with
fresh air and clean the MLVH-10A thoroughly.
Follow all EPA Guidelines for re-entry.
DISCHARGE TIMES FOR MLVH-10A
Clear Water Time
1.0 liter 30 minutes
2.0 liters 1 hour
3.0 liters 1.5 hours
4.0 liters 2.0 hours
5.0 liters 2.5 hours
6.0 liters 3.0 hours
7.0 liters 3.5 hours
Dramm Autofog MLVH-10A Manual 12
Spraying Procedure Timer Settings
How To Set The Timer
A video on programming
your timer is available on
our website.

The key to successful results with the MLVH-10A is
keeping the machine clean. There are only a few
steps involved, so it will be very easy. Be sure to
clean the machine after every use.
1. Using warm water and a soft cloth wash:
A. The Solution tank
B. The Solution tank cover
C. The Agitator blades
D. The Suction tube
E. Spray clear water through nozzle
F. Wipe off the machine
2. Remove the nozzle from the MLVH-10A by
unscrewing the securing nut. Remove the nozzle
cap and wipe off any chemical residue. Always
handle the nozzle and cap with care, especially the
nozzle tip (see diagram below). Inspect the nozzle
cap O-ring for damage or wear.
NOTE:
This procedure is necessary after every application
of wettable powder solutions. Be sure to remove
the nozzle cap and clean the nozzle.
3. After every 25 hours of use, be sure to clean the air
filter (Located under the compressor housing, on
top of the compressor). Brush any excess debris off
the filter and then rinse with warm water. Use a
mild detergent if necessary. ALWAYS let the filter
air dry completely before reinstalling.
NOTE:
The air filter will contain particles of the chemicals
you have been applying. When cleaning the filter
follow all EPA Guidelines for the handling and
disposal of chemicals.
4. Store the MLVH-10A where it is away from
excessive moisture, children and unauthorized
personnel. If you are storing the MLVH-10A for a
long period of time, cover the equipment with a
plastic sheet.
Compressor Air Filter
Air Filter
Air Filter Housing
REPLACE FILTER ONCE A YEAR OR AFTER
500 HOURS OF USE.
Cleaning & Maintenance
O-Ring
Nozzle Tip
Nozzle Cap
Nozzle
13 Dramm Autofog MLVH-10A Manual
A video showing the
cleaning procedure for
the MLVH is available on
our website.
Drammoffers anAnnualMaintenanceKit(AMK) tokeepyour
AutoFOGintopshape. Contactus annuallytoorder thiskit.
A video showing the maintenance involved in the AMK is
available on our website.

Dramm Autofog MLVH-10A Manual 14
MLVH-10A Assembly Diagram

15 Dramm Autofog MLVH-10A Manual
MLVH-10A Assembly Parts List
MLVH-10A Accessories
Part # Description Qty.
500926M Graduated Cylindar 1
Funnel LVM100 Funnel 1
153582 Strainer 1
these items do not appear in the diagram.

Dramm Autofog MLVH-10A Manual 16
MLVH-10A Compressor Plumbing

MLVH-10A Compressor Plumbing Parts List
17 Dramm Autofog MLVH-10A Manual

MLVH-10A Compressor Diagram
Dramm Autofog MLVH-10A Manual 18

MLVH-10A Compressor Parts List
19 Dramm Autofog MLVH-10A Manual

Dramm Autofog MLVH-10A Manual 20
MLVH-10A Nozzle Assembly
Item # Part # Component # Description Qty.
- - D7513670000A Nozzle Assembly 1
1 7010 Nozzle Base 1
2 7020 Cap 1
3 7030 Lock Nut 1
5 7100 Extension Pipe 1
7 D10151 Stainless Suction Tube 1
7460 Fits
Inside 741A 741A
7010
7040
7020
7030
7100
7450
7440
7460

21 Dramm Autofog MLVH-10A Manual
1. The spray pattern exits the nozzle in short bursts – it
should exit as a steady stream.
A. The nozzle cap is not secure or properly lined up.
Screw it on completely and then turn the cap
counter clockwise so the two check marks on the
nozzle line up. Check the nozzle calibration for
45cc/minute output rate. See diagram below.
B. The nozzle cap has an O-Ring inside which may
be damaged. Replace the O-Ring if it is cracked,
broken or in some way damaged.
C. Inspect the suction tube for clogging or damage.
To remove the suction tube from the nozzle first
loosen the nut that holds the tube to the nozzle.
Now, pull the tube out of the nozzle. Notice
the metal sleeve on the tube, inspect it carefully.
In most cases the sleeve must be replaced if it is
damaged, dented, bent or cracked.
DO NOT OVER TIGHTEN NUT
D. The nozzle and/or solution tank may be clogged
with chemical residue. Soak the nozzle
overnight, then clean the inside of the nozzle.
E. The suction tube may be clogged or damaged. With a
gloved hand, cover the nozzle tip. This reverses the
flow of air and blows the suction tube clean of any
debris. Remove and clean the tube or replace it if
necessary. See the diagram below.
F. The suction tube is above the surface of the solution in
the tank. Make sure the suction tube is pushed down
completely.
G. The filter at the bottom of the stainless steel suction
tube is clogged and needs cleaning. Inspect the entire
suction tube for clogging.
Continued on the next page...
Suction Tube Nut Sleeve
Troubleshooting
NOTE:
ALWAYS wear a glove when covering the nozzle.
Nozzle Cap
Checkmark Checkmark
Suction Tube

Dramm Autofog MLVH-10A Manual 22
2. No spray exits the nozzle.
A. Insufficient air flow from the compressor may
be caused by clogged piping or a dirty air filter.
Check the piping and clean dirty filters.
B. The suction tube is not connected properly or
is damaged and is leaking air into the nozzle
which disrupts the venturi effect. Replace the
suction tube and its connector.
C. The air hose may be loose and leaking air.
Tighten the air hose connection at the nozzle
and at the compressor.
3. Pressure gauge reads too low.
A. Air is leaking from the nozzle. Inspect the
nozzle cap for proper installation.
B. Air is leaking from the suction tube. Replace the
defective suction tube.
C. The piston and piston ring in the compressor is
worn out. Replace both.
D. The pressure gauge may be defective or
broken.
Replace it.
4. Pressure gauge reads too high.
A. Piping is clogged. Check the entire piping for
obstructions and replace any defective or
clogged sections.
B. A clogged nozzle or nozzle cap will cause
pressure to rise. Clean thoroughly.
5. Abnormal noise or vibration.
A. The compressor anchor bolts are loose causing
vibration. Re-tighten nuts and bolts.
B. The compressor set-up vibrates due to
unstable position. Set the compressor on
stable ground when operating.
6. Chemical flocculation (clumping) in the
chemical tank.
A. Few chemicals will be subject to this
phenomenon due to over agitation. For these
chemicals use distilled water or
discontinue use.
7. Machine runs for a short time and then stops.
A. Use a 12 gauge extension cord no longer than
50 feet.
B. Check power source for appropriate voltage
and amperage (120 volt - 15amp).
C. Check fuse on control panel.
D. Clean the compressor air filter. When it is
clogged it will cause the motor to overheat.
Troubleshooting continued...
