Dramm Hydra SprayTrax User manual

Owners Manual
Model HYDRA-ST50
Model HYDRAG-ST50
Model HYDRAG-ST100
Hydra SprayTrax

Warranty..............................................................................................4
Warning ..............................................................................................5
Introduction ........................................................................................6
Assembly and Preparation ................................................................6
Operation ........................................................................................6-7
Start-Up ....................................................................................6
Spray Operation ......................................................................7
Shut-Down ................................................................................7
Chemcial Mixing Procedure ..............................................................8
Maintenance & Cleaning ..................................................................8
Hydra SprayTrax Cart Parts and Assembly Diagram ........................9
Hydra SprayTrax Cart Parts List ..........................................................9
Plumbing, Hose Reel, and Gun Parts and Assembly Diagram ......10
Plumbing, Hose Reel, and Gun Parts List ........................................11
Spray Gun Parts and Assembly Diagram ........................................12
Spray Gun Parts List ..........................................................................13
Crank Case and Inlet Valve Parts and Assembly Diagram ............14
Crank Case and Inlet Valve Parts List ..............................................15
Pressure Regulator Valve Parts and Assembly Diagram ................16
Pressure Regulator Valve Parts List ..................................................17
Troubleshooting ..........................................................................18-19
Notes ................................................................................................20
Hydra Sprayer Manual 3
Table of Contents
Printed in the USA 9-2010

1.5 HP ElectricMotor
5.5 HP Honda Gasoline Motor
_________________________________________________________________
Serial Number
Hydra SprayTrax™Hydraulic Sprayer
Limited Warranty
Dramm Corporation warrants, to the extent of the purchase price, that the Hydra
SprayTrax™ will be free from defects in materials and workmanship to the original purchaser
for a period of six months. Parts subject to wear are not covered under this limited warranty.
Defects or damages due to the misuse, non-observance of safety standards, or non-
observance of EPA chemical guidelines are not covered under this limited warranty. Please
read and follow the instructions and heed warnings stated in the operating manual and on
the Hydra SprayTrax™.
The Honda Motor is covered by a 2 year warranty by Honda Motor Corp. A copy of this
warranty is included in the enclosed Emission Control sheet in the motor manual.
Dramm Corporation makes no other further warranty, expressed or implied, and all other
or further warranties, including any warranties of merchantability or fitness for a particular
purpose are expressly excluded.
In no event shall the manufacturer(s) or Dramm Corporation be liable for loss of product,
profit or any other special, incidental or consequential damages including, but not limited to,
plant damage, property, or persons.
Dramm Corporation makes no warranty, expressed or implied, in regard to the efficacy of
any pesticide or other chemical which may be applied using the Hydra Sprayer.
This warranty begins on the date of original purchase. This warranty is void if there is no
proof of purchase or warranty registration on file. Mail the warranty registration card to the
Dramm Corporation and keep the bill of sale or invoice. If warranty service is required,
please include a written description of the equipment malfunction, a return address and
telephone number. The Hydra SprayTrax™ must be thoroughly cleaned of all chemical
residue and sent prepaid to:
Hydra Sprayer Service
c/o Dramm Corporation
2000 North 18th Street
Manitowoc, WI 54220
920.684.0227
[email protected] • www.dramm.com
Hydra Sprayer Manual 4

• Store in a clean, dry location– away
from children and unauthorized
personnel.
• Remove all hoses and drain the
pump prior to storage.
• Do not drag the hoses over sharp
objects or bend excessively.
• Repair or replace all damaged or
broken hoses before using the
Hydra SprayTrax.
• Before servicing the unit, disconnect
the Hydra SprayTrax from the power
source.
• Do not store mixed chemicals. Use
all of the chemical mixture
immediately.
• Do not adjust the Pressure Regulator
Valve past its stop.
WARNING
Hydra SprayTrax
Model: HYDRA - ST150 HYDRAG-ST50/ST100
• Clean after every use with warm
soapy water and then rinse with
clean water.
• Wear protective clothing; respirator,
hood, gloves and boots when
mixing and spraying chemicals.
• Do not spray into the wind. Avoid
the drift of solution sprays.
• Do not direct the spray or spray gun
at yourself or anyone else.
• Be certain all hoses and
connections are secure prior to
using the Hydra.
• Avoid dry operation, since the spray
solution acts as a pump lubrication.
• Relieve the pressure before
removing the hoses or spray gun.
• Apply all chemicals according to
EPA Guidelines.
Hydra Sprayer Manual 5

Your Spraytrax comes to you ready to spray. After removing the sprayer from the crate, check
the tank for any additional parts and accessories. Connect the spray gun to the hose using
the quick disconnect. Your machine is now ready for use.
The Dramm Hydra SprayTrax™ is a hydraulic sprayer that offers a variety of flow rates with
a variety of pressures to allow for maximum flexibility. The Hydra can apply all formulations
of chemicals including insecticides, fungicides, Insect growth regulators, plant growth
regulators, and disinfectants. The Hydra can output all formulations without damage or
corrosion to the pump.
The Dramm Hydra SprayTrax includes either a 1.5 HP electric motor or a 5.5 HP Honda
gasoline motor and a
close-coupled pump capable of 4gpm electric or 8 gpm gas and 550psi, 50 or 100 gallon
tank, maneuv erable SprayTrax™ cart with self-tracking axle design, a convex reel with a
separate lock and variable drag system, 250 feet of high pressure spray hose, and a
variable pattern trigger spray gun.
START UP
1. Either switch on the electric motor or Pull-
start the Honda motor by setting the motor
speed to fast & engaging the choke. for
more on motor operation see the motor manual
pg 15.
2. Fill the sprayer to the desired level. Do Not
operate the sprayer empty for more than a
few seconds. The water acts as a coolant
and lubricant for the pump and damage
may occur.
3. Start the sprayer with the pressure control
knob in the START position. (A). Do Not
attempt to start the sprayer under pressure
as this will stall the motor and cause an
overload condition.
4. After starting the sprayer allow it to run with
the pressure control knob in the start
position. This will remove any air from the
system, which can harm the pump.
5. Engine speed should not exceed 3,500
RPM. Maximum speed should be set using
the adjusting screw located directly above
the throttle lever of engine.
A.
Hydra SprayTrax Manual 6
Introduction
Assembly & reparation
NOTE
Always start and shutdown your sprayer
with the pressure regulator in the START
(priming) position.
Keep inlet filter clean.
Always rinse the tank and flush the pump
with clean water after each use.

SPRAY OPERATION
1. After following the start up, to increase the
spray pressure, turn the pressure control
knob to the desired setting. (B) You may
use any of these settings for spraying, as
the unit will operate properly at all settings.
2. To begin spraying, pull the lever to the gun.
A latch is provided to hold the level open
to reduce operator fatigue. (C)
CAUTION :Do not direct the spray at
yourself or others, as injury may occur. On
higher pressure settings, the spray stream
may cut or inject spray under your skin.
Always wear proper personal protective
gear when spraying.
3. Spray Pattern: Adjustment of the spray
pattern is made using the lever on the side
of the gun. The pattern will adjust from a
straight stream to a fine cone mist. (D)
4. Hose Reel: The Hydra MultiSpray comes
standard with a variable drag lockable
hose reel. The reel may be locked in
position to prevent the hose from
unwinding further than wanted. (E) The
variable drag on the reel places variable
tension on the reel to prevent freewheeling
of the reel during unwinding. The drag has
a lever to activate it. A nut allows for
tension adjustment. (F)
B.
Hydra Sprayer 7
Operation
SHUT?DOWN
1. After spraying until the tank is empty, turn
the unit off.
2. Add clear water to the tank. Start the
machine and spray until empty flushing
out the pump hose and gun.
3. Clean any residue from the unit.
4. Return the regulator to the START position.
5. Store the unit in a clean dry place.
6. Do Not allow the unit to freeze as any
water left in the unit will expand and
damage the machine.
C.
E.
F.
D.

Hydra SprayTrax Manual 8
Chemical Mixing rocedure
Maintenance & Cleaning
1. Periodically check the pump oil level(G)
If it is below the indication, add oil though
the filler (H). Oil should be changed after
the first 50 hours of operation. Use 10 w 30
oil, preferrably non-detergent.
2. Periodically lubricate the grease fittings
on the wheels with a good grade of
bearing grease to extend the wheel
bearing life.
3. Replace the spray gun tip every season.
As the hole in the tip gets larger the spray
pressure drops and degrades the quality
of the spray. ( )
4. Thoroughly clean the in?line filter, tank
and machine on a weekly basis.
5. To drain tank, rotate the drain valve (L.)
90° allowing flow from the drain hose. To
completely drain tank, remove the lower
housing of the in-line filter (M). *After
draining, clean the filter, replace the
housing and close the drain valve (L) to
ensure that upon refilling the tank? the
chemical will not drain out of the unit.
H.
G.
K.
L.
M.
1. Fill the sprayer tank at least 3/4 full with water ONLY.
2. Dilute (mixing to dissolve) chemicals with water in a 5 gallon bucket. Never put
concentrated chemical formulations directly into the tank without diluting with water.
3. Start sprayer with pressure regulator in START (priming) position to beginagitation process
prior to adding chemical to sprayer tank.
4. Pour chemical and water mixture (slurry) into the sprayer tank, filled 3/4 full of water, after
agitation has begun.
5. Fill remainder of sprayer tank with water.

Hydra SprayTrax Cart Assembly
ITEM #PART #DESCRIPTION QUANTITY
Hydra SprayTrax Manual 9
1 1353B970 Turf Wheel 4
2 4916 Hose Reel 1
3 90619A410 1/2” Lock Nut 2
4 91259A119 5/8 X 5/8 Shoulder Screw 2
5 97245A712 1/2 X 1 3/4 Pin 2
6 98306A417 1/2 X 6” Pin 1
7 D11338 Front Axle 1
8 D11341 Trailer Frame 1
9 D11343 Pivot Plate 2
10 D11346 Reel Support 1
11 D11355 Tie Bar 1
12 D11357 Rear Axle 1
13 D11364 Tank Strap 2
14 D11391 Tongue 1
15 H33086 1/2 Washer 2
16 PCO 050-19S 50 Gal Tank 1

Hydra SprayTrax Manual 10
SprayTrax lumbing, Hose Reel, and Spray Gun Assembly
Motor not shown

SprayTrax lumbing, Hose Reel, and Spray Gun arts List
Hydra SprayTrax Manual 11
1 127-B-04 1/4” Male Run Tee 1
2 1407-005 Elbow 1/2 MNPT X 1/2 Barb 1
3 1435-005 1/2 FPT to 1/2 Barb 1
4 1501-08-04 1/2 X 1/4 Elbow 1
5 24SA 08X04 Reducing Nipple 1
6 2621-007 SPEARS 3/4 Ball Valve 1
7 2T05R0812 1/2” Tube 1
8 41277 3/8 X 1/4 Bushing 1
9 42060 Bushing 1/2 MPT X 1/4 FPT 1
10 42068 1/4 Elbow 1
11 42070 1/2 Elbow 2
12 42780 1/4 X 3/8 Hose Barb 4
13 42800 Fitting 1/2 Barb X 1/2 MPT 1
14 46969 3/4 Brass Elbow 1
15 46971 Nipple 1/2 Brass Close 1
16 46991 2 1/2 LG Brass Nipple 1
17 478-3/8 3/8 I.D. Hose 1
18 478-3/8 3/8 I.D. Hose 1
19 48335 115 3/4 Elbow 2
20 48335 133 3/4 Tee 1
21 48335 174 3/4 Hex Nipple 3
22 4916 Hose Reel 1
23 5372 133 3/4 MPT X 3/4 Barb 3
24 546849 Unloading Valve 1
25 60UA04X04 1/4 X 1/4 Male Swivel Elbow 1
26 7211 Gauge -0-1000 PSI 1
27 7FB-675L Ferrule 4
28 8278005 Spray Tip 1
29 82840002 Geo 400 Spray Gun 1
30 98775 36 3/4 T-Strainer 1
31 FD45-1004-0404 MQD Quick Disconncect Male 1
32 FD45-1005-0404 FQD Female Quick Disconnect 1
33 H62004 Gear Clamp 5
34 7130-12 3/4 Suction Hose 2
35 MSD 40 MSD 40 Pump 1
36 TEE 1
ITEM #PART #DESCRIPTION QUANTITY

Hydra SprayTrax Manual 12
SprayTrax Spray Gun

Hydra SprayTrax Manual 13
PART #DESCRIPTION QUANTITY
23.1003.16 Trigger Spring 1
23.1304.29 Push Pin 1
23.1310.8 Plug 1
23.1603.36 Flow Regulator Body 1
23.602.34 O-Ring 2
23.602.36 O-Ring 1
23.602.37 O-Ring 1
26.1304.33 Directional Switch 1
26.1506.14 Spacer 1
26.1617.10 Complete Flow Tube Assembly 1
26.1701.10 Nozzle 1
26.1703.55 Narrow Pattern Tube 1
26.1703.69 Flow Tube 1
26.1707.2 Spray Shield 1
26.1902.20 Screw 1
26.305.3 Spray Pattern Control Body 1
26.605.50 Wing Nut 1
26.801.5 Spacer 1
26.902.6 Spray Pattern Control Valve 1
29.1003.24 Spring 1
29.1101.1 Nipple 1
29.1607.3 Trigger Pin 1
29.1702.26 Plug 1
29.1903.9 Complete Trigger Valve Assembly 1
29.208.131 Valve Body 1
29.507.10 Trigger Locking Clip 1
29.801.40 Stopper 1
29.902.8 Trigger 1
71.602.6 O-Ring 1
Spray Gun arts List Model MSO40

Hydra SprayTrax Manual 14
MSO40E Crank Case and Inlet Valve

8/2/06 #
Hydra SprayTrax Manual 15
1-1 354040 MSD40(5/8IN) 1
1-2 546000 Label 1
1-3 546041 Crankcase 1
1-4 044839 Oil Filler Cap 1
1-5 014179 O-Ring 1
1-6 044842 Plug 1
1-7 014179 O-Ring 1
1-8 546772 Crankshaft 1
1-9 044857 Bearing Case 1
1-10 014488 Bearing 1
1-11 044859 OIl Seal 1
1-12 014044 O-Ring 1
1-13 089551 Bolt 3
1-14 150810 Seal Washer 3
1-15 015710 Bearing 1
1-16 012385 Snap Ring 1
1-17 092241 Oil Gauge Assembly 1
1-18 044428 Packing 1
1-19 541811 Cylinder Pipe 3
1-20 045876 Connecting Rod 3
1-21 016948 Piston Pin 3
1-22 541809 Piston Pin 3
1-23 020017 Washer 3
1-24 025461 Oil Seal 3
1-25 044869 Seal Retail 3
1-26 011402 Oil Wick 3
1-27 545944 Inlet Manifold 1
1-28 540670 U-Packing13 3
1-29 639503 Inlet Valve Assembly 3
1-30 014122 Inlet Valve Seat 3
1-31 116121 Piston Packing 3
1-32 027348 Spacer 3
1-33 119917 Retainer, Piston 3
1-34 015849 Spring Washer 3
1-35 046365 Nylon Nut 3
1-36 023172 O-Ring 6
1-37 546860 Pipe Receiver 6
1-38 015862 O-Ring 6
1-39 544499 Discharge Manifold 1
1-40 044881 Valve Seat 3
1-41 044565 Retainer 3
1-42 043723 Discharge Valve 3
1-43 541062 Spring 3
1-44 544090 Cap Screw 6
ITEM #PART #DESCRIPTION QUANTITY
Crank Case and Inlet Valve arts List

Hydra SprayTrax Manual 16
MSO40E ressure Regulator Valve

ressure Regulator Valve arts List
Hydra SprayTrax Manual 17
2-1 546849 Pressure Regulator Valve 1
2-2 540936 Grip 1
2-3 088913 Cap Screw 1
2-4 081039 Nut 1
2-5 087483 Screw 2
2-6 088912 Cap Screw 1
2-7 106495 Guide 1
2-8 106499 Washer 1
2-9 541769 Retainer 1
2-10 109298 Spring 1
2-11 546500 Body 1
2-12 107221 Spring 1
2-13 106498 Ball 1
2-14 543591 Piston Assembly 1
2-15 103306 Sleeve 1
2-16 019261 O-Ring 1
2-17 543507 Valve Seat 1
2-18 019261 O-Ring 1
2-19 542258 Tee 1
2-20 541796 Cock Assembly 1
ITEM #PART #DESCRIPTION QUANTITY

CAUSE
• Suction strainer is blocked
with debris
• Suction hose is damaged or
crooked
• Suction hose connector
gasket is bad
• Connection is bad
• Debris is stuck in inlet or
discharge valve
• Inlet or discharge valve is
assembled improperly
• Inlet or discharge valve is
damaged or worn
• Discharge valve spring is
damaged
• Piston packing is damaged
• O-ring is damaged
• Seal & packing are
damaged
• Pressure regulator valve
lever in is RUN position
• Pressure regulator is stuck
• Insufficient liquid supplied to
intake
• Pressure regulator valve ball
or valve seat damaged
• Pressure regulator valve rod
is bad
• Pressure regulator valve
spring bad
• Pressure regulator valve
spring is damaged or weak
REMEDY
• Clear and clean
• Repair or replace
• Repair or replace
• Connect properly
• Clean
• Assemble properly
• Repair or replace
• Replace
• Replace
• Replace
• Replace
• Return lever to START position
• Disassemble & clean
• Diagnose under (1)
• Replace
• Adjust or replace
• Repair or replace
• Replace
ROBLEM
• Suction is Low or Absent
–Up to Suction Port
–Suction & Pressure
Parts (Cylinder Part)
–Pressure Regulator
Part
• Pressure Will Not Increase
–Suction & Pressure
Part
–Pressure Regulator
Part
Troubleshooting
Hydra SprayTrax Manual 18
This power sprayer troubleshooting section shows how to diagnose and resolve problems that
may occur in the course of normal operation. If you experience a problem, take the steps
indicated for the applicable diagnosis. When you can't determine the cause of a problem or
if you have any difficulty, please feel free to contact your nearest dealer or this company's
sales office. Please have the following information ready: 1. Model designation 2. Serial
number 3. Description of problem (What happened? What were you doing when it
happened? What were the conditions when it happened?) For items marked with *, please
request adjustment or repair from your nearest dealer or from this company's sales office.
WARNING: Do not change the setting of the screw that is under the cap on the top of the
pressure regulator knob. This screw absolutely must not be changed, since that will raise the
pressure above rated specifications, damage the machine, and possibly cause injury.

CAUSE
• Nozzle is worn
•Nozzle sprays too much
liquid
• Intake liquid amount is too
small
• Pressure regulator valve
works poorly
• Faults in intake or pressure
assemblies (stopped up,
slack)
• Loose or worn key
• Conrod bolt or other bolt is
loose
• Bearings are damage
• Pressure regulator valve is
assembled wrong
• Air is being drawn in
• O-rings are damaged
• Seal & packing are
damaged
• Oil seal is damaged
• Clamping or assembly are
incorrect
REMEDY
• Replace
•Replace with suitable nozzle
• Diagnose under (1)
• Disassemble or adjust
• Clean
• Tighten or replace
• Tighten
• Replace
• Adjust
• Inspect
• Replace
• Replace
• Replace
• Disassemble or adjust
ROBLEM
• Pressure Falls When Spray
Gun is Opened
–Nozzle
–Power Spray
• Sprayer Hose Vibrates
• Noise
• Liquid or Oil Leak
Troubleshooting
Hydra SprayTrax Manual 19

Notes
Hydra SprayTrax Manual 20

8/2014
2000 North 18th Street
P.O. Box 1960
Manitowoc, WI 54221-1960 USA
dramm.com
920.684.0227
Order Fax: [phone]
Parts & Service Fax: [phone]
in [email protected]
800-258-0848
Hydra SprayTrax Manual 21
The warranty begins on the date of original purchase. The warranty is void if there is no proof
of purchase or warranty registration on file. Mail the warranty registration card to the Dramm
Corporation and keep the bill of sale or invoice. If warranty service is required, please include
a written description of the equipment malfunction, a return address and telephone number.
The Hydra Spraytrax, must be thoroughly cleaned of all chemical residue and sent prepaid
to:
Hydra Sprayer Service
c/o Dramm Corporation
2000 North 18th Street
Manitowoc, WI 54220
800-258-0848
Fax: [phone]
Service
