WAGNER ProSpray 3.21 0558009 User manual

®
Edition 3 / 2010 0558 936A
ProSpray 3.21
GB
Operating manual
ProSpray 3.21
Airless high-pressure spraying unit
Models:
0558009
0558026
0558095
Original operating manual
Uncontrolled Copy

24 ProSpray 3.21
Spare parts list
ProSpray 3.21
26 28
27
29
30
31
32
33
1
17
16
23
4
24
41
19
20
21
22
18
43
44
45 46
5
3
7
8
9
6 25
42
2
35
34
38
36
37
39
40
12
13
14
15
10
11
Main Assembly
AS-311 2
0558 467
220V~240V
6 m
GB-1002-1
GB-2099-1
0558 434
220V~240V
6 m
IRAM-2073
0558 435
220V~240V
6 m
AS-311 2
0558 467
220V~240V
6 m
GB-1002-1
GB-2099-1
0558 434
220V~240V
6 m
IRAM-2073
0558 435
220V~240V
6 m
Uncontrolled Copy

ProSpray 3.21 25
Item Part No. Description
1 0290 230 Motor shroud
2 9800 340 Ground screw
3 9800 319 Screw(2)
4 9822 627 Washer(2)
5 0558 311A Bellypanassembly(includesitems26-31)
6 9802 266 Screw(2)
7 0558 408 Dust cover
8 0509 218 Screw(2)
9 0290 222 Door
10 0558 460 Plug*
11 -------- Strap*
12 9805 317 Screw(2)
13 0290 212 Handle cover, back
14 0290 213 Handle cover, front
15 ------- Drive assembly
16 0509 218 Screw(4)
17 0290 278 Face plate / oiler assembly
18 0558 305A Controlpanelassembly,completeincludesitems33-39)
19 0509 218 Screw(4)
20 9805 348 Screw(4)
21 0509 636 Plug(2)
22 0558 298A Fluid section assembly
23 0290 205 Pusher assembly
24 0508 553 Screw(2)
25 9800 319 Screw
26 0551 757 Transducer jumper
27 9822 624 Washer(2)
28 9800 607 Screw(5)
29 54054 Washer
30 0290 221 PC board assembly
31 9800 340 Screw
32 0290 231 Belly pan
33 0508 655 Circuit breaker
34 0290 227 Control panel cover
35 0507 749 Nutwithseal
36 0290 202 Set screw
37 0290 218 Knob
38 9850 936 Switch
39 0508 579 Potentiometer
40 0522 007 LED assembly
41 0551 705 Siphon assembly
42 0508 239 Manometer
43 0509 218 Screw(4)*
44 0522 424 EMIlter,20A*
45 9800 340 Groundscrew(2)*
46 0558 452 Bracketcover*
 * Australiaonly
Uncontrolled Copy

26 ProSpray 3.21
Spare parts list
ProSpray 3.21
24
23
25
26
27
28
29
30
31
32
33
34
1
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
2
3
4
5
7
6
Fluid section
Uncontrolled Copy

ProSpray 3.21 27
Item Part No. Description
1 0509 594 Retainer
2 0509 584 Piston guide
3 ------- Upperpacking
4 0551 756 Transducer assembly
5 0507 517 Pipe plug
6 0290 209 Pump manifold
7 0509 873 Fitting
8 ------- Lower packing
9 0552 489 Bushing
10 0290 277 Piston rod
11 0551 262 Uppercage
12 0551 263 Crush washer
13 50164 Outlet valve ball
14 0551 620 Outlet valve seat
15 13481 Outlet valve retainer
16 0509 591 Lower ball guide
17 0509 583 Inlet valve ball
18 0551 534 Inlet valve seat
19 0509 582 O-ring,Teon
20 0509 581 Inlet valve seal
21 0290 216 Inlet valve housing
22 9871 160 O-ring
23 0508 748 Filter
24 0508 603 Bearing ring
25 0508 601 Filter housing
26 0508 602 Conical spring
27 0508 749 Bearing spring
28 0508 604 O-ring
29 0507 745 Gasket
30 0507 690 Bypass valve assembly
31 0507 931 Cam base
32 0508 744 Relief valve knob
33 5006 543 Groove pin
34 9885 612 Returntubetting
0509 151 Pistonassembly(includesitems10-15)
0290 201 Repackingkit(includesitems2-3,8,11-14and16-20).
47266 Reliefvalvekit(includesitems29-33).
Uncontrolled Copy

28 ProSpray 3.21
Spare parts list
ProSpray 3.21
3
4
2
1
5
6
7
8
9
10
11 8
12
Drive Assembly
Item Part No. Description
1 0524 637A Housing assembly
2 0509 121 2nd stage gear
3 0558 375 Motorassembly,230V
4 9800 319 Screw(4)
5 0551 967 Capacitor assembly
6 0290 217 Bafeassembly
7 0512 340 Fan
8 0551 714 Cordgrip(2)*
9 0558 449 Bracket*
10 0551 980 Locknut*
11 0509 218 Screw(3)*
12 0558 475 Powercordjumper*
------- Doublesidedtape(notshown)
0551 543 Tiewrap(notshown)
 * Australiaonly
Uncontrolled Copy

ProSpray 3.21 29
ProSpray 3.21
1
4
56 7
8
9
2
3
10
Stand
Spare parts list
Item Part No. Description
1 9805 367 Screw(3)
2 0290 215 Drip cup
3 0290 211 Leg, right
4 0294 635 Plug
5 0290 214 Foot
6 0508 660 Screw(2)
7 0294 635 Plug
8 0290 219 Cord holder
9 0290 214 Foot
10 0290 210 Leg, left
0290 203 Leftlegassembly(includesitems6-10)
0290 204 Rightlegassembly(includesitems1-5)
Uncontrolled Copy

30 ProSpray 3.21
1
3
2
4
Item Part No. Description
1 0551 706 Siphon hose
2 9850 638 Tiewrap(2)
3 0551 707 Retun tube
4 0279 459 Clip
0551 705 Siphontubeassembly(includesitems1-4)
Suction system
Spare parts list
ProSpray 3.21
