Dranetz-BMI POWER XPLORER Series User manual

Quick Reference Guide for PowerXplorer / Power Guide / Power Visa pg 1
QUICK REFERENCE GUIDE
POWER XPLORER / POWER GUIDE / POWER VISA
A quick reference guide for the PowerXplorer/ Power
Guide/ Power Visa product family. It is recommended
that the user still be familiar with the complete User’s
Guides for the respective products, as it contains more
detailed information about all of the functions, as well as
the specifications and accessories.

Quick Reference Guide for PowerXplorer / Power Guide / Power Visa pg 2
WARNING
Death, serious injury, or fire hazard could result from improper connection of this instrument.
Read and understand this manual before connecting this instrument. Follow all installation and
operating instructions while using this instrument.
Connection of this instrument must be performed in compliance with the National Electrical
Code (ANSI/ NFPA 70-2005) of USA and any additional safety requirements applicable to your
installation.
Installation, operation, and maintenance of this instrument must be performed by qualified
personnel only. The National Electrical Code defines a qualified person as “one who has the
skills and knowledge related to the construction and operation of the electrical equipment and
installations, and who has received safety training on the hazards involved.”
Qualified personnel who work on or near exposed energized electrical conductors must follow
applicable safety related work practices and procedures including appropriate personal
protective equipment in compliance with the Standard for Electrical Safety Requirements for
Employee Workplaces (ANSI/NFPA 70E-2004) of USA and any additional workplace safety
requirements applicable to your installation.
Published by Dranetz-BMI
1000 New Durham Road
Edison, NJ 08818-4019 USA
Telephone: [phone] or 732-287-3680
Fax: [phone]
Web site: www.dranetz-bmi.com
Copyright© 2003, 2004, 2005, 2007 Dranetz-BMI
All rights reserved.
No part of this book may be reproduced, stored in a retrieval system, or transcribed in any form
or by any means—electronic, mechanical, photocopying, recording, or otherwise—without prior
written permission from the publisher, Dranetz-BMI, Edison, NJ 08818-4019.
Printed in the United States of America.
P/N QR-PXF Rev. A

Quick Reference Guide for PowerXplorer / Power Guide / Power Visa pg 3
ADVERTENCIA
Una conexión incorrecta de este instrumento puede producir la muerte, lesiones graves y riesgo
de incendio. Lea y entienda este manual antes de conectar. Observe todas las instrucciones de
instalación y operación durante el uso de este instrumento.
La conexión de este instrumento a un sistema eléctrico se debe realizar en conformidad con el
Código Eléctrico Nacional (ANSI/NFPA 70-2005) de los E.E.U.U., además de cualquier otra
norma de seguridad correspondiente a su establecimiento.
La instalación, operación y mantenimiento de este instrumento debe ser realizada por personal
calificado solamente.
El Código Eléctrico Nacional define a una persona calificada como "una que esté familiarizada
con la construcción y operación del equipo y con los riesgos involucrados."
El personal cualificado que trabaja encendido o acerca a los conductores eléctricos
energizados expuestos debe seguir prácticas y procedimientos relacionados seguridad
aplicable del trabajo incluyendo el equipo protector personal apropiado en conformidad con el
estándar para los requisitos de seguridad eléctricos para los lugares de trabajo del empleado
(ANSI/NFPA 70E-2004) de los E.E.U.U. y cualquier requisito de seguridad adicional del lugar
de trabajo aplicable a su instalación.
AVERTISSEMENT
Si l'instrument est mal connecté, la mort, des blessures graves, ou un danger d'incendie peuvent s'en
suivre. Lisez attentivement ce manuel avant de connecter l'instrument. Lorsque vous utilisez l'instrument,
suivez toutes les instructions d'installation et de service.
Cet instrument doit être connecté conformément au National Electrical Code (ANSI/NFPA 70-2005) des
Etats-Unis et à toutes les exigences de sécurité applicables à votre installation.
Cet instrument doit être installé, utilisé et entretenu uniquement par un personnel qualifié. Selon le
National
Electrical Code, une personne est qualifiée si "elle connaît bien la construction et l'utilisation de
l'équipement, ainsi que les dangers que cela implique".
Le personnel qualifié qui travaillent dessus ou s'approchent des conducteurs électriques activés exposés
doit suivre des pratiques en matière et des procédures reliées par sûreté applicable de travail
comprenant le matériel de protection personnel approprié conformément à la norme pour des conditions
de sûreté électriques pour les lieux de travail des employés (ANSI/NFPA 70E-2004) des Etats-Unis et
toutes les conditions de sûreté additionnelles de lieu de travail applicables à votre installation.
WARNUNG
Der falsche Anschluß dieses Gerätes kann Tod, schwere Verletzungen oder Feuer verursachen. Bevor
Sie dieses Instrument anschließen, müssen Sie die Anleitung lesen und verstanden haben. Bei der
Verwendung dieses Instruments müssen alle Installation- und Betriebsanweisungen beachtet werden.
Der Anschluß dieses Instruments muß in Übereinstimmung mit den nationalen Bestimmungen für
Elektrizität (ANSI/NFPA 70-2005) der Vereinigten Staaten, sowie allen weiteren, in Ihrem Fall
anwendbaren Sicherheitsbestimmungen, vorgenommen werden. Installation, Betrieb und Wartung dieses
Instruments dürfen nur von Fachpersonal durchgeführt werden. In dem nationalen Bestimmungen für
Elektrizität wird ein Fachmann als eine Person bezeichnet, welche "mit der Bauweise und dem Betrieb
des Gerätes sowie den dazugehörigen Gefahren vertraut ist."
Qualifiziertes Personal, das an bearbeiten oder herausgestellte angezogene elektrische Leiter sich
nähern, muß anwendbare Sicherheit bezogener Arbeit Praxis und Verfahren einschließlich passende
persönliche schützende Ausrüstung gemäß dem Standard für elektrische Sicherheitsauflagen für
Angestellt-Arbeitsplätze (ANSI/NFPA 70E-2004) der Vereinigten Staaten und alle
zusätzlichenArbeitsplatzsicherheitsauflagen folgen, die auf Ihre Installation anwendbar sind.

Quick Reference Guide for PowerXplorer / Power Guide / Power Visa pg 4
Safety Summary
----------------------------------------------------------------------------------------
Definitions WARNING statements inform the user that certain conditions
or practices could result in loss of life or physical harm.
CAUTION statements identify conditions or practices that could
harm the instrument, its data, other equipment or property.
NOTE statements call attention to specific information
-------------------------------------------------------------------------------------------------------
Symbols The following International Electrotechnical Commission
(IEC) symbols are marked on the top and rear panel in the
immediate vicinity of the referenced terminal or device:
Caution, refer to accompanying documents (this reference
guide and complete Users Guide
Direct current (DC) operation of the terminal or device
Power Switch
Safety Precautions
The following safety precautions must be followed whenever any type of voltage
or current connection is being made to the PX5:
• Wear proper Personal Protective Equipment, including safety glasses and
insulated gloves when making connections to power circuits.
• Hands, shoes and floor must be dry when making any connection to a power
line.
• Before each use, inspect all cables for breaks or cracks in the insulation.
Replace immediately if defective.
• Set the PX5 power switch to Off.
• Before connecting to electric circuits to be monitored, open their related circuit
breakers or disconnects. DO NOT install any connection of the PX5 to live
power lines.
• Connections must be made to the PX5 first, then connect to the circuit to be
monitored.

Quick Reference Guide for PowerXplorer / Power Guide / Power Visa pg 5
TABLE OF CONTENTS
INTRODUCTION.................................................................................................. 6
MAKING CONNECTIONS.................................................................................... 8
Connecting Voltage Measurement Cables ....................................................... 9
3 Phase, Four Wire Wye............................................................................. 10
3 Phase (Floating or Grounded) Delta ........................................................ 11
Split Phase and Open Delta........................................................................ 12
USER INTERFACE............................................................................................ 13
OTHER INSTRUMENT SETUP...................................................................... 14
REAL TIME METER MODES......................................................................... 14
Scope mode................................................................................................ 14
Meter mode................................................................................................. 15
Harmonics................................................................................................... 15
Phasor diagram........................................................................................... 16
STORED DATA FUNCTIONS and DISPLAYS............................................... 16
Trend........................................................................................................... 16
Events......................................................................................................... 17
REPORTS ...................................................................................................... 19
EN50160..................................................................................................... 19
ANNUNCIATOR.......................................................................................... 20
SETUPS......................................................................................................... 20
MEASUREMENT CONNECTIONS............................................................. 20
AUTOMATIC SETUP.................................................................................. 21
MONITORING MENU................................................................................. 21
WIZARD SETUP......................................................................................... 22
Example of Power Quality setup using the Wizard............................................. 28
Example of Energy/Demand setup using the Wizard......................................... 28
Statements and Notices..................................................................................... 29

Quick Reference Guide for PowerXplorer / Power Guide / Power Visa pg 6
INTRODUCTION
The Dranetz-BMI PowerXplorer® PX5, Power Guide 4400, and the Power Visa are three
portable, hand-held, eight-channel power quality meter/monitors, very similar in operation
though the PX5 and 4400 have some additional parameters not in the Power Visa, and the PX5
has a high speed sampling board for capturing the details of very fast transients. The common
features are covered in this document, and the PX5 name will be used to represent all three
instruments. These cutting-edge power quality instruments are designed with a
color liquid crystal display (LCD) 1/4 VGA, using touch screen technology. They can
monitor, record and display data on four voltage channels and four current channels
simultaneously.
PX5 is designed to meet both the IEEE 1159 and IEC 61000-4-30 Class A standards for
accuracy and measurement requirements. It can do PQ-optimized acquisition of power
quality related disturbances and events. It is designed with a statistical package called
Quality of Supply (QOS), with monitoring and setup protocols set to determine voltage
measurement compliance required for EN50160 monitoring. European standard
EN50160 requires that measurement parameters must be within a specified percentage
for 95% of the time.
The PX5 firmware can monitor power quality phenomena for troubleshooting and/or
compliance purposes. It can record inrush conditions, carry out long-term statistical
studies to establish performance baselines, and perform field-based equipment testing
and evaluation for commissioning and maintenance. The firmware integrates an
intuitive instrument setup procedure to ensure the capture of all relevant data for
additional post process analysis, report writing, and data archiving using other
compatible Dranetz-BMI software applications such as NodeLink® and DranView®.

Quick Reference Guide for PowerXplorer / Power Guide / Power Visa pg 7
1. Voltage and Current Connections – there are four differential voltage and four differential
current channels, which can be wired to measure a variety of circuit configurations. Use
only Dranetz-BMI voltage leads and current probes for proper operation. Do not exceed
marked ratings.
2. Graphic Color LCD with Touch Screen – the color LCD has an integral touch screen that
is used to select functions for setups, real time meters, and viewing stored data. Either a
clean finger or a PDA-type stylus can be used and the screen should be calibrated with
whichever you are going to use by selecting Preferences; Display Preferences, then
Calibrate Touch screen when first turned on. Clean only with soft cloth.
3. Field Replaceable Battery Pack – the internal UPS feature requires that the internal
batteries be properly charged and maintained. If the battery pack is in need of
replacement, de-energize the connections and power to the unit before opening the
battery door and replacing the pack only with the Dranetz-BMI battery pack PN# BP-
PX5. A spare battery pack may be useful to have.
4. Memory Card slots for data and firmware updates – the Dranetz-BMI supplied Compact
Flash memory cards are used for data storage, as well as to upload new firmware
versions when available. Use only Dranetz-BMI supplied memory cards, as the speed

Quick Reference Guide for PowerXplorer / Power Guide / Power Visa pg 8
requirements of the instrument can not be satisfied by many off-the-shelf memory cards.
Do not remove the memory card while monitoring. Only one slot is active at a time.
5. There are three status LEDs and the ON/OFF switch (push for on, push for off) are
located on the bottom of the instrument. AC power connection for charging the battery
and powering the unit with AC Adapter 117029-G1 is located on the right side of the
instrument. From left to right, the LEDs are:
•3 Battery Charge Indicator. LED will light steadily while battery is fast charging
and blink when fully charged.
•4 Status Indicator. LED will light steadily when abnormal condition is detected.
The unit is operating normally when light is off.
•5 Power Indicator. LED will blink in a heartbeat fashion (once per second) when
the unit is operating normally.
MAKING CONNECTIONS
WARNING
Death, serious injury, or fire hazard could result from improper connection of this
instrument. Read and understand the warnings in the beginning of this manual
before connecting this instrument.
ADVERTENCIA
Una conexión incorrecta de este instrumento puede producir la muerte, lesiones
graves y riesgo de incendio. Lea y entienda este manual antes de conectar.
Observe todas las instrucciones de instalación y operación durante el uso de este
instrumento.
AVERTISSEMENT
Si l'instrument est mal connecté, la mort, des blessures graves, ou un danger
d'incendie peuvent s'en suivre. Lisez attentivement ce manuel avant de connecter
l'instrument. Lorsque vous utilisez l'instrument, suivez toutes les instructions
d'installation et de service.
WARNUNG
Der falsche Anschluß dieses Gerätes kann Tod, schwere Verletzungen oder Feuer
verursachen. Bevor Sie dieses Instrument anschließen, müssen Sie die Anleitung
lesen und verstanden haben. Bei der Verwendung dieses Instruments müssen alle
Installation- und Betriebsanweisungen beachtet werden.

Quick Reference Guide for PowerXplorer / Power Guide / Power Visa pg 9
Connecting Voltage Measurement Cables
Measurement cable set
Description: Voltage measurement cables are provided as standard accessories and are
stored in a cable pouch as part of the measurement cable set, P/N 116042-G3. Each
cable set consists of a cable and alligator clip.
Voltage Rating: Direct connection of all voltage measurement cables are rated at 600
Vrms max. For measuring voltages greater than 600 Vrms, potential transformers (PTs)
must be used.
Optional fused voltage adapter
There are two optional fuse accessory kits available for use with the measurement
cables for PX5. One kit (P/N FVA-1) contains one fused voltage adapter and one
measurement connecting Red cable 50 cm in length. The other kit (P/N FVA-4) contains
four voltage adapters and four measurement connecting cables 50 cm in length (one
Red, one Yellow, one Blue, and one Grey).
•WARNING: To avoid the risk of electric shock or burns, always connect the safety (or
earth) ground before making any other connections.
•WARNING: To reduce the risk of fire, electrical shock, or physical injury it is strongly
recommended to fuse the voltage measurement inputs. Fuses must be located as close
to the load as possible to maximize protection.
•WARNING: For continued protection against risk of fire or shock hazard replace only
with same type and rating of recommended fuse. Use only fast blow type fuse which is
rated 600V. Recommended fuse type is Littelfuse, part number KLKD0.30 rated 600V
AC/DC, 0.3A fast blow.
•WARNING: Do not replace fuse again if failure is repeated. Repeated failure indicates a
defective condition that will not clear with replacement of the fuse. Refer condition to a
qualified technician.
-------------------------------------------------------------------------------------------------
PX5 can monitor the following power configurations:
•Single phase
•Split phase
•3 Phase Delta
•3 Phase Wye
•3 Phase 2-Wattmeter Delta
•Generic
•2 ½ Element without Vb
•2 ½ Element without Vc
3 Phase Wye and 3 Phase Delta are described in this Quick Reference version of the User’s
Guide. For other configurations, please consult the complete Users’ Guide, UG-PX5.

Quick Reference Guide for PowerXplorer / Power Guide / Power Visa pg 10
3 Phase, Four Wire Wye
Channels A, B, and C are connected to voltage and current probes. The neutral is
connected to common and is the reference for the three channels. The figure also shows
voltage connection using channel D as a differential input for measuring neutral to
ground voltage. Neutral to ground measurements are important but optional.

Quick Reference Guide for PowerXplorer / Power Guide / Power Visa pg 11
3 Phase (Floating or Grounded) Delta
In this power connection, the PX5 uses voltage channels A, B, and C as differential
inputs with channel A using source voltage A-B, channel B using B-C, and channel C
using C-A as the reference. Current probes are connected to channels A, B, and C.
Neutral to ground measurements are important but optional.
--------------------------------------------------------------------------------------

Quick Reference Guide for PowerXplorer / Power Guide / Power Visa pg 12
Split Phase and Open Delta
For either of these two power connections, the PX5 uses only two voltage channels A
and B as differential inputs with channel A using source voltage A-N or A-C and, channel
B using B-N or B-C. Current probes are connected to channels A and B. Neutral to
ground measurements are important for split phase but optional.
Split Phase (above)
Open Delta (below)

Quick Reference Guide for PowerXplorer / Power Guide / Power Visa pg 13
USER INTERFACE
The instrument powers up with the Home Page screen, shown above. The top portion of the
screen is for status information, including: monitoring status (on, off, or armed); what type of
circuit is being monitored; the memory card status (not inserted or percentage full); the data file
name; the number of waveform cycles saved (indication of event activity); number of journal
records saved (periodic timed storage of parameters); and, the real time clock display.
The first row of icons are referred to as Real-Time-Meters, showing the instantaneous values of
the parameters. The second row of icons are for display of stored data, either through trend
plots, event waveforms and rms plots, and reports of either EN50160 data or an annunciator
panel of user selectable parameters and their state (normal, out of limits). Also in this second
row is the icon for setting up instrument parameters, such as time/date, memory, language,
LCD, and touch screen.
In the bottom of the screen is a button for Start menu, which allows for starting to monitor from
either the existing setup, recalling a stored setup from the memory card, or going through the
setup process again, either in automatic setup mode, or the step-by-step wizard.

Quick Reference Guide for PowerXplorer / Power Guide / Power Visa pg 14
OTHER INSTRUMENT SETUP
Functions, such as the time/date, which language, communication port setups, and LCD
settings can be changed from the Instrument Settings menu, as well are formatting a memory
card. This screen is activated from the PREFERENCES icon on the Home page.
------------------------------------------------------------------------------------------------------------------
REAL TIME METER MODES
Scope mode
Scope mode functions as an oscilloscope, displaying real-time waveforms of voltage and
current for up to eight channels simultaneously, with one second update rate. The colors
of waveform display are user programmable. Scope mode also provides a textual
display of rms values, division for axis values, and frequency.

Quick Reference Guide for PowerXplorer / Power Guide / Power Visa pg 15
Meter mode
Meter mode functions as a true rms voltmeter and a true rms clamp-on ammeter.
Voltage and current measurements, along with other calculated and advanced power
parameters, are displayed on the Meter mode screens in both textual and graphical
format.
Harmonics
Harmonics display the amplitude and phase of each harmonic to the 63rd harmonic in
both graphical and textual format. User can select which parameter to show the
harmonics for (V,I,W), which channel (A,B,C,D), zoom in a the 5Hz components, set
options such as showing harmonics and/or interharmonics and displaying in Hz or
harmonic number, scaling to the fundamental or absolute value, and a list of the
harmonic magnitudes and phase angles in tabular fashion.

Quick Reference Guide for PowerXplorer / Power Guide / Power Visa pg 16
Phasor diagram
The phasor screen displays a graph that indicates phase relations between voltage and
current based upon the angles at the fundamental frequency, as determined by Fourier
analysis. Phasor diagram displays voltage and current phasors for all channels.
Functioning as a phase angle meter, the unit can display system imbalance conditions
and provides such information in textual form also. The phase angle display can also
verify if monitoring connections have been made correctly. Animated phasor demo
rotations demonstrating resistive, inductive and capacitive loads can be displayed.
-----------------------------------------------------------------------------------------
STORED DATA FUNCTIONS and DISPLAYS
Trend
Users can generate plots for all journalled data combined with min/max recordings of
that parameter. Most journal parameters have multiple channels to plot.

Quick Reference Guide for PowerXplorer / Power Guide / Power Visa pg 17
Events An event occurs when a programmed threshold limit is crossed. An event
consists of the pre-trigger cycle(s), trigger cycle(s), and post-trigger cycles(s)
The event data for all of the captured channels can be displayed in time plots of
the rms values or waveforms, event details such as trigger conditions,
characterization of the event according to PQ standards, and min/max values, or
the time-stamped event list.
Trend of rms voltage and current
Waveforms from transient event capture

Quick Reference Guide for PowerXplorer / Power Guide / Power Visa pg 18
Detailed information of transient event capture
List of events with characteristics
-----------------------------------------------------------------------------------------------

Quick Reference Guide for PowerXplorer / Power Guide / Power Visa pg 19
REPORTS
There are two types of reports – EN50160 for Quality of Supply reporting, and the
Annunciator panel, which the user can select to display the present state of 4-16
parameters
EN50160
If a parameter is below the 95% limit for EN50160, then the bar graph will turn red.
Some of the parameters have more detailed information about them, which can be
displayed by pressing on the parameter name. History of prior measurement weeks can
be displayed, along with the magnitude and duration distribution table (DISDIP), and the
min/max values during monitoring interval.

Quick Reference Guide for PowerXplorer / Power Guide / Power Visa pg 20
ANNUNCIATOR
If the parameter is outside of the normal), it will either turn yellow limits (low or high) or
flashing red (very high or very low) until the user clears the annunciator to reset them all
to green. Pressing the parameter button itself will show time plots and other detailed
information about the parameter.
---------------------------------------------------------------------------------------------------------------
SETUPS
Setup is a configuration of parameter thresholds that control the data recorded by PX5.
Users may perform instrument setup in three ways: via Automatic Setup which utilizes
auto-configured settings and allows users to proceed directly with data monitoring; via
Wizard Setup which follows a step-by-step sequence where users go through a series of
circuit setup screens; or via Advanced Options setup which allows users to modify
trigger parameters and intervals or tweak threshold settings.
MEASUREMENT CONNECTIONS
PX5 can monitor the following power configurations:
•Single phase
•Split phase
•3 Phase Delta
•3 Phase Wye
•3 Phase 2-Wattmeter Delta
•Generic
•2 ½ Element without Vb
•2 ½ Element without Vc
While monitoring any of the above configurations, the PX5 can also be connected to
monitor neutral to ground voltage and neutral or ground current.
