Draper 65958 User manual

12V MINI AIR
COMPRESSOR
■STOCK No.65958 ■PART No.DA12/250A
• INSTRUCTIONS •
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY TO ENSURE THE
SAFE AND EFFECTIVE USE OF THIS TOOL.
GENERAL INFORMATION
This manual has been compiled by Draper Tools and is an integrated part of the power tool equipment, which
should be kept with the machine.
This manual describes the purpose for which this tool has been designed and contains all the necessary
information to ensure its correct and safe use.We recommend that this manual is read before any operation of
the machine, before performing any kind of adjustment to the machine, and prior to any maintenance tasks. By
following all the general safety instructions contained in this manual, it will ensure both machine and operator
safety, together with longer life of the tool itself.
All photographs and drawings in this manual are supplied by Draper Tools to help illustrate the operation of the
machine.
Whilst every effort has been made to ensure accuracy of information contained in this manual, the Draper Tool
policy of continuous improvement determines the right to make modifications without prior warning.
08/2001

12V MINI AIR
COMPRESSOR
■STOCK No.65958 ■PART No.DA12/250A
CONTENTS: Page No.
Contents/Declaration .......................................................................................1
Specification/Guarantee...................................................................................2
General Safety Instructions ..............................................................................3
Getting To Know Your Mini Air Compressor .....................................................4
Operation & Use............................................................................................5-6
Troubleshooting ...............................................................................................7
We
Draper Tools Ltd. Hursley Road, Chandler’s Ford, Eastleigh, Hampshire.
SO53 1YF. England.
Declare under our sole responsibility that the product:
Stock Nos:- 65958.
Part Nos:- DA12/250A.
Description:- Mini Air Compressor 12 Volt.
To which this declaration relates is in conformity with the following directive(s)
89/336/EEC.
With reference to: EN55014-1 & EN55014-2.
JOHN DRAPER
Managing Director 14/06/2001
DECLARATION OF CONFORMITY
- 1 -

- 2 -
The Draper Tools policy of continuous improvement determines the right to change specification
without notice.
Part No. .......................................................................................................... DA12/250A
Stock No. ................................................................................................................ 65958
Power................................................................................................ 12V/D.C. 9A (MAX.)
Max. Pressure ........................................................................................................ 250PSI
Power Cable Length ................................................................................................ 2.9M
SPECIFICATION
Draper tools have been carefully tested and inspected before shipment and are
guaranteed to be free from defective materials and workmanship for a period of 12
months from the date of purchase except where tools are hired out when the guarantee
period is ninety days from the date of purchase.
Should the machine develop any fault, please return the complete tool to your nearest
authorized warranty repair agent or contact Draper Tools Limited, Chandler's Ford,
Eastleigh, Hampshire, SO53 1YF. England. Telephone: [phone].
If upon inspection it is found that the fault occurring is due to defective materials or
workmanship, repairs will be carried out free of charge. This guarantee does not apply
to normal wear and tear, nor does it cover any damage caused by misuse, careless or
unsafe handling, alterations, accident, or repairs attempted or made by any personnel
other than the authorised Draper warranty repair agent.
This guarantee applies in lieu of any other guarantee expressed or implied and
variations of its terms are not authorised.
Your Draper guarantee is not effective unless you can produce upon request a dated
receipt or invoice to verify your proof of purchase within the 12 month period.
Please note that this guarantee is an additional benefit and does not affect your
statutory rights.
Draper Tools Limited
GUARANTEE

- 3 -
SAFETY WARNING
WARNING:
Please read the following instructions carefully failure to do so could lead to serious
personal injury.
IMPORTANT:
Draper Tools recommends that this compressor should not be modified or used for any
application other than that for which it was designed. If you are unsure of it’s relative
applications do not hesitate to contact us in writing and we will advise you.
GENERAL SAFETY RULES FOR
AIR COMPRESSORS
1. KNOW YOUR COMPRESSOR
Before operating the compressor,
read and fully understand the
starting, operating and stopping
sections in this manual. Read all
labels affixed to the compressor.
Learn it’s applications and
limitations.
2. SERVICING AND MAINTENANCE
Do not service or maintain this
compressor until you have read and
understood the maintenance section
of this manual.
3. CHECK DAMAGED PARTS
Before further use of this
compressor, parts that are damaged
should be carefully checked to
ensure that it will operate correctly
and perform its intended function.
Check for alignment of moving
parts, breakage of parts and any
other conditions that may effect its
operation. A guard or other part that
is damaged should be properly
repaired or replaced.
4. DISCONNECT FROM POWER
SUPPLY
Before servicing, maintaining or
replacing damaged parts ALWAYS
disconnect the compressor from the
power supply.
5. AVOID DANGEROUS
ENVIRONMENTS
Do not use the compressor in damp
or wet locations or expose it to rain.
Keep the work area well lit. Provide
adequate surrounding work space.
6. AVOID ACCIDENTAL STARTING
Make sure the power supply is off
before connecting to the power
supply.
7. NEVER LEAVE THE
COMPRESSOR RUNNING
UNATTENDED
Turn the power supply off. Do not
leave the compressor until it comes
to a complete stop.
8. USE RECOMMENDED
ACCESSORIES
Only use the recommended
adaptors as supplied.
9. OVERHEATING.
Operation over an extended period
of time will overheat the unit and
damage the compressor. When this
occurs stop the unit immediately
and do not restart until cool,
approximately 30 minutes.
10. KEEP CHILDREN AWAY
Ensure the compressor is stored out
of reach of small children.
11. TYRE PRESSURE
The gauge on the compressor is
intended as a guide only. Tyre
pressures should be regularly
checked against a tyre pressure
gauge manufactured to BS 4613,
such as Draper Stock No.26443.

- 4 -
GETTING TO KNOW YOUR
MINI AIR COMPRESSOR
Fig.1.
1. Compressor on/off switch.
2. Light on/off switch.
3. Pressure gauge.
4. Light.
5. Cigar lighter adaptor.
6. Amber lens.
7. Metal needle adaptor.
8. Plastic adaptor.
9. Metal inflating adaptor.
10. Valve connector.
11. Cigar lighter adaptor housing.
✕✌
✖✌ ✗✌
✘✌
✕✔✌
✚✌ ✛✌ ✜✌ ✢✌ ✙✌
✕✕✌
Fig.1.

- 5 -
OPERATION & USE
INFLATING TYRES (Fig.2 - 6):
Push the connector ✪✌ onto the tyre valve with
the locking lever ✫✌ in the released position.
With the connector on the valve, lock it in place
by folding down the locking lever ✬✌.
NOTE: Listen to ensure no air loss can be heard.
With the ON/OFF switch ✭✌ in the ‘OFF’
position, plug the cigar lighter adaptor ✮✌ in to
the vehicles cigar lighter socket.
NOTE: Some vehicles may require the ignition
to be switched to the ‘ON’ position to power the
cigar lighter socket.
Fig.2.
✪✌
✫✌
Fig.3.
✬✌
Fig.4.
✭✌
Fig.4.
✭✌
Fig.5.
✮✌

- 6 -
OPERATION & USE
Referring to the vehicle data check the correct
pressure for tyres.
Turn ‘ON’ the compressor with switch ✰✌ and
check the pressure in the tyre with gauge ✯✌.
When the pressure is correct. Turn ‘OFF’ the
compressor with switch ✰✌, unplug the cigar
lighter.
Loosen and remove the valve connector as
quickly as possible to avoid any air lose.
NOTE:When the compressor is being stored
ensure the valve connector lock is in the
release position.
TORCH/WARNING LIGHT (Fig.7):
To turn the light ‘ON’ press switch ✱✌ to the ‘|’
position.
To turn the emergency light ‘ON’, press switch
✱✌ to the ‘||’ position.
The amber lens is fitted, by removing the
holder ✲✌.
FOR INFLATABLES (Fig.8):
Select the suitable adaptor and secure in the
valve connector.
Insert the adaptor into the item to be inflated,
and begin to inflate.
NOTE: Do not over inflate.
Fig.6.
✯✌
✰✌
Fig.7.
✱✌
✲✌
Fig.4.Fig.8.

TROUBLESHOOTING
TROUBLE PROBABLE CAUSE REMEDY
Will not operate. 1. Poor connection 1a. Gently turn plug in
between plug and cigarette lighter socket
socket. until contact is made.
1b. Check plug and socket
for tobacco or other
obstruction.
2. Power supply fuse 2. Check cigarette lighter
blown. power supply fuse.
Runs but does not inflate. 1. Poor connection onto 1. Ensure the adaptor is
the valve. pushed firmly onto the
valve before locking
into place.
2. Air escaping. 2a. Check the item for
leaks.
2b. Ensure hose has no
breaks or leaks at the
fitting.
Runs slowly. 1. Overheating. 1. Unplug from power
supply and leave to
cool for approx. 30
minutes.
2. Voltage too low. 2. Check condition of
battery.
IMPORTANT: PLEASE NOTE ALL REPAIRS/ADJUSTMENTS SHOULD
BE CARRIED OUT BY A QUALIFIED PERSON.
DRAPER HELPLINE:
023 8049 4344
- 7 -
