Draper 65985 User manual

These instructions accompanying the product are the original instructions. This document is part of the product,
keep it for the life of the product passing it on to any subsequent holder of the product. Read all these
instructions before assembling, operating or maintaining this product.
This manual has been compiled by Draper Tools describing the purpose for which the product has been
designed, and contains all the necessary information to ensure its correct and safe use. By following all the
general safety instructions contained in this manual, it will ensure both product and operator safety, together
with longer life of the product itself.
AlI photographs and drawings in this manual are supplied by Draper Tools to help illustrate the operation of the
product.
Whilst every effort has been made to ensure the accuracy of information contained in this manual, the Draper
Tools policy of continuous improvement determines the right to make modifications without prior warning.
65985/66012/66013
RECHARGEABLE
SPOTLIGHT

1. TITLE PAGE
1.1 INTRODUCTION
User manual for Rechargeable Spotlight
Stock No: 65985, 66012, 66013
Part No’s: RHL3W/LE/B, RHL3W/LE/G, RHL3W/LE/O
1.2 REVISIONS
As our user manuals are continually updated, users should make sure that they use the
very latest version.
Downloads are available from: http://www.drapertools.com/manuals
Draper Tools Limited, Hursley Road, Chandler’s Ford, Eastleigh, Hampshire.
SO53 1YF. UK.
Website: drapertools.com
Product Helpline: [phone]
General Fax: [phone]
1.3 UNDERSTANDING THIS MANUALS SAFETY CONTENT:
Warning! – Information that draws attention to the risk of injury or death.
Caution! – Information that draws attention to the risk of damage to the product or
surroundings.
1.4 COPYRIGHT © NOTICE:
Copyright © Draper Tools Limited.
Permission is granted to reproduce this publication for personal and educational use
only. Commercial copying, redistribution, hiring or lending is prohibited.
No part of this publication may be stored in a retrieval system or transmitted in any
other form or means without written permission from Draper Tools Limited.
In all cases this copyright notice must remain intact.
Date first published March 2017
2

1. TITLE PAGE
1.1 INTRODUCTION.............................................................................................................1
1.2 REVISION HISTORY ......................................................................................................2
1.3 UNDERSTANDING THIS MANUAL ...............................................................................2
1.4 COPYRIGHT NOTICE ....................................................................................................2
2. CONTENTS
2.1 CONTENTS.....................................................................................................................3
3. GUARANTEE
3.1 GUARANTEE..................................................................................................................5
4. INTRODUCTION
4.1 SCOPE............................................................................................................................6
4.2 SPECIFICATION .............................................................................................................6
4.3 HANDLING AND STORAGE ..........................................................................................6
5. HEALTH AND SAFETY INFORMATION
5.1 GENERAL SAFETY INSTRUCTIONS FOR POWER TOOL USE .................................7
– Electrical safety .........................................................................................................7
– Personal safety..........................................................................................................7
– Battery tool use and care..........................................................................................7
– Service........................................................................................................................8
5.2 ADDITIONAL SAFETY INFORMATION .........................................................................8
5.3 CONNECTION TO THE POWER SUPPLY (CHARGER)...............................................8
6. IDENTIFICATION
6.1 TECHNICAL IDENTIFICATION ......................................................................................9
7. UNPACKING AND CHECKING
7.1 PACKAGING ................................................................................................................10
7.2 WHAT’S IN THE BOX?.................................................................................................10
8. OPERATION AND USE
8.1 POWER SUPPLY .........................................................................................................11
8.2 CHARGING...................................................................................................................11
8.3 SPOTLIGHT OPERATION ...........................................................................................12
9. MAINTENANCE
9.1 DISPOSAL ....................................................................................................................13
2. CONTENTS
3

10. EXPLANATION OF SYMBOLS
10.1 EXPLANATION OF SYMBOLS ..................................................................................14
11. DISPOSAL
11.1 DISPOSAL ..................................................................................................................15
11.2 HEALTH AND SAFETY FOR BATTERIES.................................................................15
DECLARATION OF CONFORMITY
............................................................................................................................ENCLOSED
2. CONTENTS
4

3.1 GUARANTEE
Draper tools have been carefully tested and inspected before shipment and are
guaranteed to be free from defective materials and workmanship.
Should the tool develop a fault, please return the complete tool to your nearest
distributor or contact:
Draper Tools Limited, Chandler's Ford, Eastleigh, Hampshire, SO53 1YF. England.
Telephone Sales Desk: [phone] or: Product Helpline [phone].
A proof of purchase must be provided with the tool.
If upon inspection it is found that the fault occurring is due to defective materials or
workmanship, repairs will be carried out free of charge. This guarantee period covering
parts/labour is 12 months from the date of purchase except where tools are hired out
when the guarantee period is 90 days from the date of purchase. The guarantee is
extended to 24 months for parts only. This guarantee does not apply to normal wear
and tear, nor does it cover any damage caused by misuse, careless or unsafe handling,
alterations, accidents, or repairs attempted or made by any personnel other than the
authorised Draper warranty repair agent.
Note: If the tool is found not to be within the terms of warranty, repairs and carriage
charges will be quoted and made accordingly.
This guarantee applies in lieu of any other guarantee expressed or implied and
variations of its terms are not authorised.
Your Draper guarantee is not effective unless you can produce upon request a dated
receipt or invoice to verify your proof of purchase within the guarantee period.
Please note that this guarantee is an additional benefit and does not affect your
statutory rights.
Draper Tools Limited.
3. GUARANTEE
5

4. INTRODUCTION
6
4.1 SCOPE
Plastic bodied 3W LED hand spotlight. Suitable for use in industrial, domestic and
leisure environments. Supplied with rechargeable Li-Ion battery, 230V A.C charger.
4.2 SPECIFICATION
Stock No’s............................................................................................ 65985, 66012, 66013
Part No’s ......................................................... RHL3W/LE/B, RHL3W/LE/G, RHL3W/LE/O
LED.................................................................................................................................... 3W
LED temperature ......................................................................................................... 6000K
Lumens output ......................................................................................................................
High ............................................................................................................................ 200
Low............................................................................................................................... 80
Beam distance.............................................................................................................. 150M
Battery:
Type ......................................................................................................................... Li-Ion
Rated voltage............................................................................................................ 3.7V
Rating ...................................................................................................................... 1.2Ah
Charging time............................................................................................................ 4hrs
Continuous spotlight operating time (on one full charge):
High ...........................................................................................................................2hrs
Low............................................................................................................................ 7hrs
Charger:
Rated voltage......................................................................................................... 230V~
Rated frequency ...................................................................................................... 50Hz
Rated power input ................................................................................................... 3.7W
Rated D.C. output voltage........................................................................................... 5V
Rated D.C. output current ....................................................................................500mA
Construction .............................................................................................................. Class II
Dimensions: .............................................................................................160
× 102 × 122mm
Weight (spotlight only): ............................................................................................ 0.236kg
4.3 HANDLING AND STORAGE
Store in a dry location out of the reach of children.

5.1 GENERAL SAFETY INSTRUCTIONS FOR POWER TOOL USE
Warning: Read all safety warnings and all instructions. Failure to follow the warnings
and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains operated (corded) power
tool or battery-operated (cordless) power tool.
Electrical safety
a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not
use any adapter plugs with earthed (grounded) power tools. Unmodified plugs and
matching outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces such as pipes, radiators,
ranges and refrigerators. There is an increased risk of electric shock if your body is
earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a power tool
will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the
power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged
or entangled cords increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension cord suitable for outdoor
use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
f) If operating a power tool in a damp location is unavoidable, use a residual current
device (RCD) protected supply. Use of an RCD reduces the risk of electric shock.
Personal safety
a) Stay alert, watch what you are doing and use common sense when operating a
power tool. Do not use a power tool while you are tired or under the influence of
drugs, alcohol or medication. A moment of inattention while operating power tools
may result in serious personal injury.
b) Use personal protective equipment. Always wear eye protection. Protective
equipment such as dust mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off position before
connecting to power source and/or battery pack, picking up or carrying the tool.
Carrying power tools with your finger on the switch or energising power tools that
have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool on. A wrench or
a key left attached to a rotating part of the power tool may result in personal injury.
Battery tool use and care
a) Recharge only with the charger specified by the manufacturer. A charger that is
suitable for one type of battery pack may create a risk of fire when used with
another battery pack.
b) Use power tools only with specifically designated battery packs. Use of any other
battery packs may create a risk of injury and fire.
5. HEALTH AND SAFETY INFORMATION
7

5. HEALTH AND SAFETY INFORMATION
c) When battery pack is not in use, keep it away from other metal objects, like paper
clips, coins, keys, nails, screws or other small metal objects, that can make a
connection from one terminal to another. Shorting the battery terminals together
may cause burns or a fire.
d) Un der abusive conditions, liquid may be ejected from the battery; avoid contact. If
contact accidentally occurs, flush with water. If liquid contacts eyes, additionally
seek medical help. Liquid ejected from the battery may cause irritation or burns.
Service
a) Have your power tool serviced by a qualified repair person using only identical
replacement parts. This will ensure that the safety of the power tool is maintained.
5.2 ADDITIONAL SAFETY INFORMATION
– Do not point (shine) the light into any persons or animals eyes.
– Do not use near children.
– Store out of the reach of children.
– Do not put this unit into a fire or use near any flammable object.
– Do not use in explosive atmospheres or environments.
– Do not use excessive force on this product as it can permanently damage the
spotlight.
– Only use the charger in a standard environment.
– Do not use the charger to charge any other product and only use the supplied
charger to charge this spotlight.
5.3 CONNECTION TO THE POWER SUPPLY (CHARGER)
This spotlight comes supplied with a UK standard 3 pin charger. It is designed for
connection to a domestic power supply rated at 230V AC.
It is Class 2 (double insulated); is designed for connection to a power supply matching
that detailed on the rating label and compatible with the plug fitted.
If an extension lead is required, use an approved and compatible lead rated for this
appliance. Follow all the instructions supplied with the extension lead.
This product requires no earth connection as supplementary insulation is applied to the
basic insulation to protect against electric shock in the event of failure of the basic
insulation.
8

9
6. IDENTIFICATION

 Handle.
 ON/OFF/ beam settings switch.
 Lens.
 Power input charging point.




7. UNPACKING AND CHECKING
7.1 PACKAGING
Carefully remove the spotlight from the packaging and examine it for any sign of
damage that may have happened during shipping. Lay the contents out and check
them against the parts shown below. If any part is damaged or missing; please contact
the Draper Helpline (the telephone number appears on the Title page) and do not
attempt to use the spotlight.
The packaging material should be retained at least during the guarantee period: in
case the spotlight needs to be returned for repair.
Warning! Some of the packaging materials used may be harmful to children. Do not
leave any of these materials in the reach of children.
If any of the packaging is to be thrown away, make sure they are disposed of correctly;
according to local regulations.
7.2 WHAT´S IN THE BOX?
As well as the spotlight; there are parts not fitted or attached to it.

10
 230V AC mains charging adaptor.

8. OPERATION AND USE
11
8.1 POWER SUPPLY – FIG. 1
Before you connect the equipment to the power supply make sure that the data on the
rating plate is identical to the supply voltage.
Warning! Always pull out the power plug before making adjustments to the equipment.
FIG.1
FIG.2
8.2 CHARGING – FIG. 2
Note: Before using the spotlight, charge
the battery for 10 continuous hours.
The table below highlights the
approximate hours of continuous
useage available when fully
charged:
As the charge diminishes, the light intensity will begin to reduce. The battery should be
recharged before it is drained completely.
– Before charging, ensure the ON/OFF button is in the OFF position.
– Insert the 230V AC mains charging adaptor into the charging input point .
– The spotlight’s LED indicator light will illuminate.
– Charge the unit for 4 – 5 hours then disconnect from the power supply.
Note: Do not completely discharge the battery before recharging.
Note: if stored for emergencies, ensure it is fully charged and recharge every three
months regardless of use.
– Lithium-ion cells prefer small charges often.
– Lithium-ion technology is lightweight and compact due to increased capacity in
comparison to other battery chemistries.

High: 2 hours
Low: 7 hours


12
8. OPERATION AND USE
8.3 SPOTLIGHT OPERATION – FIG. 3
The spotlight is operated via the ON/OFF/ beam setting switch .
Press once for the lower powered beam.
Press twice for full powered beam.
Press again to switch off the spotlight.
Warning! This spotlight is extremely bright. Do not shine directly into any person’s or
animal’s eyes.
FIG.3
1
2
3

× 31
2
3
– Lithium-ion cells have no ‘memory effect’ and a long cycle life with outstanding
discharge performance.
– Lithium-ion cells suffer from a loss in capacity or thermal runway if over charged
and will degrade if allowed to enter deep discharge, however all of these situations
are negated due to the complex circuitry incorporated within this product.
– Charging must be carried out in an environment with an ambient air temperature
between 5to 45with the transformer supplied.
– To prevent overheating, do not cover the transformer.
Warning! If the cable is damaged or the non-self resetting protective device is
activated due to short circuit/overload, the transformer shall be scrapped. A
replacement of identical specification, design and application shall be obtained.

9.1 MAINTENANCE – FIG. 5
Use only mild soap and a damp cloth to clean this spotlight. Do not submerge into liquid.
13
9. MAINTENANCE
FIG.4

14
10. EXPLANATION OF SYMBOLS
Lithium-ion product.
Refer to your local authority for advice
on disposal and recycling.
For indoor use only.
Do not expose to rain.
WEEE
Do not dispose of Waste Electrical &
Electronic Equipment in with domestic
rubbish.
Class II construction (Double insulated).
Short-circuit-proof safety isolating
transformer.
Rated voltage.
Warning! Read the instruction manual.
230V charger adaptor
Do not incinerate or throw onto fire.
Warning! Do not aim beam at bystanders
or look directly into light source.
Polarity indication.

15
11. DISPOSAL
10.1 DISPOSAL
At the end of the machine’s working life, or when it can no longer be repaired, ensure
that it is disposed of according to national regulations.
Contact your local authority for details of collection schemes in your area.
In all circumstances:
– Do not dispose of power tools with domestic waste.
– Do not incinerate.
– Do not abandon in the environment.
– Do not dispose of WEEE* as unsorted municipal waste.
10.2 HEALTH AND SAFETY FOR BATTERIES
Warning! Do not put in fire or mutilate – cells may burst of release toxic materials.
– Do not short circuit cells, may cause burns.
– The battery must be removed from the appliance before it is scrapped.
– The battery is to be disposed of safely.
– Do not mutilate batteries, corrosive electrolyte will be released.
– Do not incinerate – danger of explosion and release of toxic fumes.
– Do not dispose of batteries or cells in a charged condition.
Expired lithium-ion batteries must be recycled/disposed of in accordance with the
appropriate regulation or legislation. They should be returned to your local warranty
agent/stockist.
* Waste Electrical & Electronic Equipment.

Draper Tools Limited, Hursley Road,
Chandler's Ford, Eastleigh, Hampshire. SO53 1YF. U.K.
Helpline: [phone]
Sales Desk: [phone]
Internet: www.drapertools.com
E-mail: [email protected]
General Enquiries: [phone]
Service/Warranty Repair Agent:
For aftersales servicing or warranty repairs, please contact the
Draper Tools Helpline for details of an agent in your local area.
©Published by Draper Tools Limited.
No part of this publication may be reproduced, stored in a retrieval system or transmitted in any form or by any means,
electronic, mechanical photocopying, recording or otherwise without prior permission in writing from Draper Tools Ltd.
CONTACT US
YOUR DRAPER STOCKIST
RDCH0317
