Dreamland N3903 User manual

INTELLIHEAT
EASY FIT HEATED
UNDERBLANKET
TYPE N3901
N3903
N3907
MI002683_N39.indd 1 30/03/17 16:04

ILLUSTRATIVE GUIDE
I
8 7 6
3 4 5
Cord C
Cord B
Cord A
9
8 7
5 4
Elasticated corner strap
10. LED DISPLAY
11. 1 – 5 ALL NIGHT USE TEMPERATURE SETTINGS
12. FAST PRE-HEAT SETTING, READY FOR BED IN 5 MINUTES
13. TIMER DISPLAY 1 HOUR OR 9 HOURS
14. TIMER/STANDBY BUTTON
15. READY FOR BED FAST PRE-HEAT BUTTON
16. TEMPERATURE BUTTON
17. STANDBY DISPLAY
18. ON/OFF SWITCH
B
B
Elasticated strap
A
6
8 7
1 2 [B]
[C]
[D]
[A]
Fitting your underblanket to the mattress
Fitting the elasticated straps
Attaching the connector
Fast pre heat
1-5 • Select your temperature
for all night use.
19 20 21
[E]
1213
14
Check for wear on the
blanket and do not
use if frayed
Check control for
wear + tear
Do not use if rucked
or creased
10
11
12
13
14
15
18
16
17
MI002683_N39.indd 2 30/03/17 16:04

EN
1
INTRODUCTION
Dear customer, thank you for choosing our product. We feel certain you will appreciate its
quality and reliability as it was designed and manufactured with customer satisfaction in
mind.These instructions for use comply with the European Standard EN 82079.
IMPORTANT INSTRUCTIONS.
RETAIN FOR FUTURE USE.
ATTENTION! Instructions and warnings for a safe use.
Before using this appliance, carefully read the
instructions for use and in particular the safety notes
and warnings, which must be complied with. Keep
this manual together with its illustrative guide for
future consultation. Should you transfer the appliance
to another user, make sure you hand over this
documentation as well.
NOTE: should any part of this manual be difficult to understand
or any doubt arise, contact the company at the address indicated
on the last page before using the product.
NOTE: Partially sighted persons can consult the digital version of
these instructions for use on the website www.dreamlanduk.co.uk
INDEX
Introduction ..................Page 1
Safety nots...................Page 1
Symbols .....................Page 4
Description of the appliance ....Page 4
Positioning and fitting instructions . Page 4
Using your blanket ............Page 5
Cleaning and Maintenance .....Page 6
Storing the electric blanket .....Page 7
Trouble shooting ..............Page 7
Disposal .....................Page 7
Warranty.....................Page 8
Illustrative guide ................... I
Technical data .....................II
SAFETY NOTES
• After unpacking, make sure the appliance is intact, complete with
all its parts as shown in the illustrative guide and with no sign of
damage due to transportation. In doubt, do not use the appliance
and contact an authorised service centre.
MI002683_N39.indd 1 30/03/17 16:04

2
EN
WARNING! Risk of suffocation.
Children shall not play with the packaging. Keep the plastic
bag out of the reach of children.
• This appliance must be used only for the purpose for which it was
designed, as a mattress protector for home use. Any other use
is considered not compliant with the intended use and therefore
dangerous.
• Before connecting the appliance to the mains supply, make sure
that the voltage and frequency indicated on the technical data of
the appliance correspond to those of the mains supply.The rating is
on the appliance or on the power supply unit, if any (see illustrative
guide).
• If the appliance is provided with a voltage/frequency selector, set the
selector correctly to comply with the mains supply parameters.
• This appliance is only to be used with the types of detachable
control unit that are marked on the appliance.
Children under the age of three are not to use this appliance
due to their inability to react to overheating.
• This appliance can be used by children older than 3 years and
younger than 8 years under supervision and with the control always
set to minimum temperature.
• This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in
a safe way and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance shall not
be made by children without supervision.
• This appliance must not be used by persons insensitive to heat
and other very vulnerable persons who are unable to react to
overheating.
• DO NOT use the appliance with wet hands or damp feet.
• DO NOT pull the supply cord or the appliance itself to remove the
plug from the socket.
• DO NOT pull or lift the appliance by the supply cord.
MI002683_N39.indd 2 30/03/17 16:04

EN
3
• The cable and control unit of the appliance can give rise to risks
of entanglement, strangulation, tripping or treading if not correctly
arranged. The user shall make sure that electric cords shall be
arranged in a safe way.
• DO NOT expose the appliance to humidity or atmospheric agents
(rain, sun, etc.) or extreme temperatures.
• Always disconnect the appliance from the mains supply before
cleaning or performing maintenance and when the appliance is
not in use.
• Examine the appliance frequently for signs of wear or damage. lf
there are such signs, if the appliance has been misused or does
not work, contact an authorised technical service centre before
switching it on again.
• If the appliance is faulty or malfunctions, switch it off and do not
tamper with it. Contact an authorised technical service centre for
any repairs.
• If the supply cord is damaged, take the whole appliance to an
authorised technical service centre for the replacement of the
control unit , so as to prevent all risks.
• DO NOT use this appliance to warm animals.
• DO NOT place the control unit under the pillow or between the
sheets or blankets.
• If the appliance is used on an adjustable bed, check that the blanket
and cord do not become trapped or rucked, for example in hinges.
• DO NOT tuck in.
• This appliance is not intended for medical use in hospitals.
• DO NOT use if wet.
DO NOT USE FOLDED OR CREASED.
DO NOT INSERT PINS OR NEEDLES.
• For the features of the appliance, refer to the external packaging.
• Use the appliance only with the supplied accessories that are an
essential part of the appliance.
MI002683_N39.indd 3 30/03/17 16:04

4
EN SYMBOLS
Protection class II Prohibited actions
Carefully read the operating
instructions Important note
Warning Children under 3 years old not
allowed
Do not use folded or creased Do not insert pins or needles
Wash at maximum 40° C on a
wool programme
Do not bleach
Tumble drying possibile at low
temperature Do not dry clean
Do not iron
DESCRIPTION OF THE APPLIANCE
Refer to the illustrative drawing at the beginning of this instructions booklet to verify your appliance
equipment.
1. Blanket connector
2. Control connector
3. Bottom sheet
4. Top sheet
5. Duvet/Cover
6. Label
7. Underblanket
8. Mattress
9. Mains socket
10. Led display
11. 1-5 All night use
temperature settings
12. Fast pre-heat setting -
Ready for Bed in 5 minutes
13. Timer display 1 hour or 9
hours
14. Timer/standby button
15. Ready for bed fast pre-heat
button
16. Temperature button
17. Standby display
18. On/off switch
POSITIONING AND FITTING INSTRUCTIONS
WARNING! The underblanket must only be placed on top of
the mattress. Do not use as an Overblanket.
POSITIONING THE UNDERBLANKET (Refer to Diagram B and C on page I)
Open the folded blanket and place on your mattress, leaving room for pillows. Smooth out any packing
folds. Lay the electric underblanket (7) on the mattress (8) without putting it underneath the pillows. Make
sure that it is smoothly spread out (Diagram B). Secure your blanket to the mattress with the mains lead at
the pillow end. Pull the elasticated strap (A) (Diagram C) over and under the top of the mattress, as shown
in Diagram C. Attach the elasticated corner straps (B) over the bottom corners of the mattress. Ensure
that the blanket is smooth and secured to the mattress.
To finish dressing the bed (Diagram B). Place the bottom /fitted sheet on top of the electric blanket, then
finish making the bed as normal with a top sheet (4) and duvet (5).
Frequently check to see that your blanket is properly secured to the mattress.
MI002683_N39.indd 4 30/03/17 16:04

EN
5
USING YOUR BLANKET
WARNING! DO NOT use this appliance if there are visible
signs of damage.
WARNING! NOT suitable for children under the age of 3.
Your Dreamland Intelliheat underblanket is designed to FAST PREHEAT your bed and it also responds
to temperature changes while you sleep.
The digital intelliheat control has 6 temperature settings (Diagram [D] page I).
IMPORTANT: The time required to heat the electric blanket may vary depending on the room
temperature. To judge the temperature accurately, lie in the bed with the covers draped over
you. Do not rely on a hand placed on the bed.
WARNING! This appliance is only to be used with the control
unit supplied with it.The reference of the control unit is specified
on the label sewn onto the appliance. Diagram [B] (6).
WARNING! DO NOT place the control unit under the pillow or
under the sheets when in use.
Connect the control connector into the blanket socket then plug into the mains socket.
Switch on your Intelliheat blanket from the back of the control (18) Diagram [D], by positioning the switch
ON (I). The temperature setting (11) Diagram [D] will default to the last one used, providing it has been set
to that number for a period longer than 5 minutes.
TO HEAT UP YOUR INTELLIHEAT UNDERBLANKET, YOU MUST ALWAYS PRESS THE READY FOR
BED FAST PREHEAT BUTTON. DO NOT GET INTO BED WITH YOUR BLANKET ON THE READY
FOR BED FAST PREHEAT TEMPERATURE SETTING.
READY FOR BED FAST PREHEAT: Press the Ready for Bed, fast pre-heat button on the front of the
control (15) Diagram [D]. The setting (12) (Diagram D) will be illuminated in red on your LED Display (10)
(Diagram D).Your blanket will be lovely and warm in just 5 minutes.
TO SET FOR ALL NIGHT USE: RELEASE the Ready for Bed fast pre-heat button, and press
temperature button (16) Diagram [D] to select your preferred all night temperature setting from 1 (min) to
5 (max). The higher the number, the higher the temperature. This will be illuminated in orange on the (10)
LED display (11) (Diagram D).
1 OR 9 HOURS AUTO SHUT OFF TIMER: The Intelliheat control has an AUTOMATIC SHUT OFF TIMER.
To set the timer, press the timer button (14) Diagram [D] and select either 1h or 9h. This will be illuminated
in green on the (10) LED Display (13) Diagram [D].
TIMER OFF/STANDBY: When the set time period has elapsed, the blanket will automatically switch off
and the standby light will be illuminated in blue on the (10) LED display (17) Diagram [D]. If you wish to
switch your blanket back on again, press the timer button (14) Diagram [D] selecting either 1 or 9 hours.
MANUAL SWITCH OFF BOTH BLANKET AND CONTROL: Switch off the back of your Intelliheat control
(18) Diagram [D] to off (O) position.
MEMORY FUNCTION: After using your blanket for more than 5 minutes, the Intelliheat control will
remember your last temperature setting.
MI002683_N39.indd 5 30/03/17 16:04

6
EN
DISCONNECT: To disconnect your electric blanket from the mains socket, switch the control to OFF
position on the back of your Intelliheat control (O) (18) (Diagram [D]), and then safely disconnect the plug
from the mains socket (9) (Diagram [B]).
CLEANING AND MAINTENANCE
Your electric blanket is suitable for washing. Check the washing instructions on the label of your
underblanket to wash it correctly.
WARNING! Always disconnect the appliance from the mains
supply before cleaning or performing maintenance.
BEFORE WASHING OR STORING YOUR BLANKET:
1. Disconnect the control from the mains socket.
2. Disconnect the connector (2) from the blanket by pressing the push buttons at the sides of the control
connector (1).
3. Ensure that the controls are not connected and none of the wires have worn through the fabric.
4. It is important to measure the underblanket before washing and check that the dimensions are
approximately the same before drying.
MACHINE WASHING
• The underblanket can be machine washed at 40°C on a wool programme.
• Only the gentle spin cycle is to be used. DO NOT use an extra spin cycle.
TUMBLE DRYING
• Tumble dry at a low temperature.
• DO NOT use the underblanket until it is completely dry.
HANGING THE ELECTRIC BLANKET OUTSIDE TO DRY
• The underblanket must be stretched back to approximately its original size during the drying
process.This is best done whilst damp, working from side to side, stretching a piece at a time. This
procedure may need to be repeated a few times until fully dry.
• Make sure the wires are not kinked or twisted. It is easier to check the wires by placing the electric
blanket against the light.
• If problems arise with the wires after having dryed the electric blanket or if it does not return to its
original size, return it to our authorised Service Centre for a safety check.
WARNING! Examine the appliance against the light to make
sure the cables are not bent or twisted.
WARNING! If the appliance does not resume its original size or
if problems arise with the internal cables contact an authorised
service centre for a safety check.
WARNING! Hang the appliance without applying pegs so as not
to damage it.
MI002683_N39.indd 6 30/03/17 16:04

EN
7
STORING THE ELECTRIC BLANKET
When not in use, store as follows:
When storing the appliance, allow it to cool down before folding .
• Make sure your underblanket is dry if it has been washed.
• Fold your underblanket as a normal blanket.
• It is recommeded to store the blanket in the bag it was purchased in.
• Store the underblanket in a dry place.
WARNING! DO NOT crease the appliance by placing items
on top of it during storage
The fabric may take on a natural yellow colour over time. This does not compromise the safety and/or
performance of the product in any way.
Examine the appliance and its supply cord frequently for signs of wear or
damage. lf there are such signs or in the case of malfunction, contact our
authorised technical service centre.
TROUBLE SHOOTING
This appliance is built to the very highest of standards.Follow the trouble shooting guide if the unit fails
to operate. If you don’t find any solution, discontinue use and return it to our Service Centre for a
Safety inspection.
Problem Solution
You feel a tingling sensation while in use.
This can be quite common and is completely
harmless. Contact the after sales service for
further information.
Damage to the control unit Diagram [E] 19 Page I.
Discontinue use and return it to our Service Centre
for a safety inspection.
Fabric rucking or creasing Diagram [E] 20 Page I.
Wear or tear on the fabric Diagram [E] 21 Page I.
Heat discoloration of fabric.
The product has been misused or accidentally damaged.
DISPOSAL
The packaging of the appliance is made of recyclable materials.Dispose of it in accordance
with the environmental protection regulations.
Pursuant to Directive 2012/19/EU on waste electrical and electronic equipment (WEEE),
the crossed bin symbol on the appliance or its packaging indicates that the appliance
must be disposed of separately from other waste at the end of its useful life.
The user must therefore take the appliance to an appropriate recycling centre for electrical
and electronic equipment.Alternatively, instead of handling the disposal, the user can hand
MI002683_N39.indd 7 30/03/17 16:04

8
EN
over the appliance to the retailer when a new, equivalent one is purchased. The user can hand
over electronic products measuring less than 25 cm to retailers of electronic products having a
sales area of at least 400 m2free of charge and with no obligation to buy. Appropriate separate
collection for the subsequent procedure for the decommissioned appliance for recycling, which
includes treatment and environmentally friendly disposal helps prevent adverse effects on the
environment and health and promotes reusing and/or recycling materials that the appliance
consists of.
WARRANTY
This product is guaranteed for a period of 3 years from the date of purchase against material, mechanical
and electrical defects. The warranty is binding if it is accompanied by a valid receipt of payment. This
guarantee is only valid if the appliance is used solely for domestic purposes in accordance with the
instructions provided that is not connected to an unsuitable electricity supply, dismantled, interfered
with in any way damaged, through misuse, fair wear and tear. Under this guarantee we undertake to
repair or replace free of charge any parts found to be defective.
PLEASE NOTE, THE COST OF A SAFETY INSPECTION IS NOT COVERED BY THIS
GUARANTEE. A CHARGE WILL BE MADE IN RESPECT OF ANY PRODUCT RETURNED UNDER
THIS GUARANTEE, WHERE NO FAULT IS FOUND.
This guarantee is offered as an extra benefit and does not affect your statutory rights as a consumer.
This guarantee does not confer any rights other than those expressly set out above and in particular
we shall not be liable for any indirect or consequential loss or damage. Nothing in this guarantee or
the instructions relating to the product excludes, restricts or otherwise affects your statutory rights. In
line with our policy of continuous development, we reserve the right to change this product, packaging
and documentation without notice. If a defect appears and after checking that the blanket is being
used properly in accordance with the instructions, return it with a valid proof of purchase, as soon as
possible to the manufacturer’s Service Centre.This guarantee is valid in the UK only.
SERVICE CENTRE
PO Box 166 – Middlewich – Cheshire – CW 10 0ZU - Tel: [phone]
E-mail: [email protected]
www.dreamlanduk.co.uk
MI002683_N39.indd 8 30/03/17 16:04

II
TECHNICAL DATA (6)
TYPE N3903 220-240 V 50 /60 Hz 100 W
UNDERBLANKET
TYPE N3901 220-240 V 50 /60 Hz 2x85 W
UNDERBLANKET
TYPE N3907 220-240 V 50 /60 Hz 140 W
UNDERBLANKET
MI002683_N39.indd 9 30/03/17 16:04

MI002683
100317
MI002683_N39.indd 10 30/03/17 16:04
