Drive DeVilbiss Healthcare 12490ADJ User manual

adjustable
swivel bather
www.drivedevilbiss.co.uk
Drive DeVilbiss Healthcare Ltd
Heathfield Lane, Birkenshaw
West Yorkshire, GB BD11 2HW
www.drivedevilbiss.co.uk
Document code: 12490ADJ_Hangtag
Product code: 12490ADJ
Issued 09/16
warranty details
Your Drive branded product is warranted to be free
of defects in materials and workmanship for one
year from date of purchase.
This device was built to exacting standards and
carefully inspected prior to shipment. This warranty
is an expression of our confidence in the materials
and workmanship of our products and our
assurance to the customer.
In the event of a defect covered by this warranty,
we will at our option supply parts or replace the
device.
This warranty does not cover device failure due to
owner misuse or negligence, or normal wear and
tear. The warranty does not extend to non-durable
components which are subject to normal wear and
need periodic replacement.
If you have any queries or require full warranty
conditions, please contact your Drive stockist.
specification
The swivel bather is constructed from aluminium
tubing and a PE-HD white plastic seat
Overall width 66cm - 71cm (26” - 28”)
Seat dimensions:
40cm (D) x 41cm (W) x 8cm (H from top of bath)
16” (D) x 17”(W) x 3” (H from top of bath)
Weight Capacity: 25 stone (160kg)
care and maintenance
! To maintain the quality of the finish, we
recommend that the swivel bather is wiped
down or showered and dried after each use.
! Periodically clean the bath bench with a
damp cloth and mild detergent or
disinfectant. Do not use abrasive detergents
as these can damage the plastic parts.
! Check that the device swivels easily, smoothly
and locks in to place. If the locking mechanism
does not feel positive or there is excessive
movement in the device, remove from use and
contact your dealer.
! Check for cracks and damage to bather, in
particular the plastic seat and tubing. Check
that the nut underneath the seat is present
and secure.
! Do not use in environments over 60ºC
(saunas, for example)

safety precautions
Apply the following precautions before use:
!Inspect all parts for shipping damage before
assembly. If there is shipping damage - DO NOT
USE. Contact your dealer for further instructions.
!Ensure that all four ‘E’ clips are fully installed on the
traverse arms.
!Check all four corners of the swivel bather are
resting on the top edge of the bath by at least 5cm
(2”). Check that the setscrews are lightly touching
the inside of the bath. Do not overtighten the
setscrews.
!Always sit in the centre of the swivel bather, and do
not lean on the edges of the bather as this can
cause instability. DO NOT stand on the bather.
!Do not exceed the weight limit of 160kg (25 st).
assembly instructions
operation
safety precautions
safety precautions
contents
‘E’ Clips x 4
Traverse Arms x 2
Swivel Seat Unit x 1
1. Insert the traverse arms in the base
plate until the required hole is seen in the
base plate.
2. Insert the ‘E’ clips into each of the
traverse arm tubing to secure.
3. Repeat the process for the other
arm, ensuring all four ‘E’-clips are used
4. Adjust the setscrews so they lightly
touch the edge of the bath.
Lift the lever arrowed, and swivel the
seat around until it locks in position and
is facing the user.
The user should sit on the seat and then
lift the lever and swivel the seat whilst
lifting their legs to they can use the bath.
