Zephyr Operating Instructions
i m p o r t a n t s a f e g u a r d s
Zephyr by Dry & Store®is for household use. When using electrical products, especially when children
are present, basic safety precautions should always be followed, including:
r e a d a l l i n s t r u c t i o n s b e f o r e u s i n g
d a n g e r -To reduce the risk of electrocution:
• Donotusewhilebathing.
• Donotplaceorstoreproductwhereitcanfallorbepulledintoatuborsink.
• Donotplaceinordropintowaterorotherliquid.
• Donotreachforthisdeviceifithasfallenintowater.Unplugimmediately.
w a r n i n g -Toreducetheriskofburns,electrocution,re,orinjurytopersons:
• Closelysuperviseuseby,onornearchildrenorinvalids.
• Usethisproductonlyforitsintendeduseasdescribedinthismanual.
• Neveroperatethisproductifithasadamagedcordorplug,ifitisnotworkingproperly,if
ithasbeendroppedordamaged,ordroppedintowater.Returnittotheplaceofpurchaseor
servicecenterforexaminationandrepair.
• Neverplacetheproductonasoftsurfacesuchasacouchorbed.Keepanyairopeningsfree
of lint, hair, and the like.
• Donotuseoutdoorsoroperatewhereaerosol(spray)productsarebeingusedorwhere
oxygenisbeingadministered.
• TheACadapterincludedwithyourunitismadespecicallyforthisproduct.Donotuse
itwithanotherappliance,anddonotuseanadapterfromanyotherelectricaldeviceinits
place.
n o t e -Zephyrisnotdesignedtodiagnose,prevent,monitor,treat,oralleviatedisease.
o p e r a t i n g c o n d i t i o n s
Zephyroperatesatatemperaturerangeof36°to40°C(97°to104°F).Itwillfunctionproperly
atindoorambienttemperaturesfrom18°to27°C(65°to80°F).
s a v e t h e s e i n s t r u c t i o n s
4Group 4, Rev F
Introduction
Used daily, Zephyr removes damaging moisture accumulation, dries earwax and removes
odors.Zephyrcanmakehearinginstrumentssoundbetter,anditcanextendzinc-airbattery
lifeinhighhumiditylocations.
Preparation for Use (Important)
1. Activate the desiccant: A disposable Dry-Brik®, which must be
replaced every two months, is included. The Dry-Brik performs
two important functions: (1) to permanently remove the moisture
moleculesthatarereleasedfromthedevicesduringthedryingcycle,
and(2)todrivetherelativehumidityinsidetheboxtoamuchlower
levelthanispossiblewithjustaheater,thusmaximizingthedrying
capability.
ToactivatetheDry-Brik,removethefoilcover(Figure 1). Do not
remove the foil until you are ready to use the Dry-Brik, because
onceitisremovedtheDry-Brikwillbeginadsorbingmoisture.
2. Record the activation date: To alert you when it is time for
replacement,acardisattachedtoeachDry-Brik.Writethedatethat
theDry-Brikwasplacedinserviceonthiscard(Figure 2).
3. Place the activated Dry-Brik in Zephyr (Figure 3).
4. Connect the AC adapter:PlugtheACadapterintoanelectrical
outlet,thentthesmallcircularplugintotherearoftheunit.
NOTE:Instructionsfortheoptionalrechargeablemetalcanisterdesiccantcanbefoundon
page18.
Operating Your Zephyr
1. Wipeexcessmoistureandearwaxfromyourhearingaidsbeforeplacingtheminthedrying
tray.Youmayleavethebatteriesin,butopenthebatterycovertoallowforaircirculation.
2. Closethelidandpresstheo n /o f f button on the right side of the unit. The green indicator
abovetheo n /o f f buttonwillilluminateforthedurationoftheeight-hourcycle,afterwhich
theunitwillturnoffautomatically.Zephyrcanalsobeturnedoffbypressingtheo n /o f f
1
2
3
5Group 4, Rev F
buttonasecondtime.BestresultscomefromanentireZephyrcycle,butdryingwilloccur
fromperiodsasshortasonehour.
Using Zephyr with Cochlear Implant Equipment
Behind-the-earprocessorsandotherimplanthardwaremustbekeptdrytofunctionproperly.
RegularZephyrusecanalsomakeasignicantdifferenceinzinc-airbatterylife,especiallyin
humidweather.(Individualresultsmayvary.)Leavezinc-airbatteriesintheprocessor(where
applicable)butremovethebatterycover.Placetheprocessor,headpieceandcableinthefront
compartmentandfollowtheinstructionsforuse,above.
General Product Care
DonotoperateZephyrinhigh-humiditylocationssuchasabathroom.Keepthelidclosedat
alltimes,becausetheeffectivenessoftheDry-Brikwillbereducedduetomoistureadsorption
fromthesurroundingair.Cleansurfaceswithasoftcloth.Neverusestrongcleaningagentsor
abrasives.Donotsprayanyliquidintothetray.
Troubleshooting Zephyr Problems
Unit will not start (no green light)• : Make sure that the o n /o f f buttonhasbeenrmlypushed.
Verifythat theACadapteris securelyconnected.Istheoutlet/mainscontrolledbyawall
switch?Ifstillnosuccess,tryanotherAC adapter (available from the placeofpurchase,
at www.dryandstore.com, or from a service center). Replace it only with anAC adapter
providedbythemanufacturer.
Green light is on, but unit is not drying properly• :HastheDry-Brikbeenreplacedregularly?
Itisimportantthatitbereplacedeverytwomonthsaccordingtotheinstructions.Checkfor
fanmovement.Ifnofansoundcanbeheard,contacttheplaceofpurchaseoraservicecenter
forevaluation.
If none of the above solves the problem:
InNorthAmerica,call1-888-327-1299orvisitwww.dryandstore.com
OutsideNorthAmerica,contacttheplaceofpurchaseoraservicecenterforevaluation.
18 Group 4, Rev F
Physical Properties
• Outsidedimensionsare150mmx92mmx72mm(5.9"x3.6"x2.8").
• Thedryingtrayhastwocompartments:theforwarddryingareameasures80mmx65mmx24mm
(3.2"x2.6"x1.0"),andasmallDry-Brik®compartmentisintherearofthetray.
• Weightasshippedisapproximately582g(1lb,4oz).
Power Supply
Input:100-240voltsAC,50/60Hz,1.0Amax.Output:24VDCat15Wmax.Zephyrpowersuppliesare
interchangeable with Dry & Store®GlobalandareCEMarked.TheyarecertiedtoETL,UL,andCSA
standards,andcarryGS(Germany),PSE/JET(Japan),C-Tick(Australia/NewZealand),KC(Korea),and
SABS(SouthAfrica)certications.
Operating Features
• Aball-bearingfancontinuouslycirculateswarm,dryairfortheentireoperatingcycle,causingmoisture
tomoveoutofthehearinginstrumentsbydiffusion.Adesiccantintheairowpathstripsthemoisture
out of the air, ensuring continuous dry operation.
• Zephyrwilldrycerumen,makingiteasiertoremovefromthehearinginstrument.
• Zephyrturnsoffautomaticallyafter8hoursunlesstheo n /o f f button on the side is pressed.
• Batteriesdonothavetoberemovedfromhearingdevices.
• Zephyrisnotdesignedtodiagnose,prevent,monitor,treat,oralleviatedisease.
Rechargeable Canister Desiccant (optional)
A small number of international configurations are shipped with an optional metal canister desiccant
insteadofaDry-Brik.Theprotectivelabelshouldberemovedfrombothsidesbeforeuse.Asmoistureis
adsorbedbythedesiccant,theindicatorwillchangefromorange(good)togreen(bad).Thecolorchange
signalsthatthedesiccantcannolongeradsorbmoisture.Torestorefunction,placethemetalcanina
conventionalovenforaminimumof3hoursatatemperatureof105°-150°C(225°-300°F).Thecolorwill
change back to orange. Warning: Never place metal in a microwave oven! After recharging, allow
the hot metal can to cool before use. Best results will occur if the can is covered by a glass during the
cooling period.
Zephyrby Dry & Store®
Zephyr by Dry & Store®is protected by U.S. Patents D536,491 and 5,852,879.
EarTechnologyCorporation
P.O.Box1017
JohnsonCity,TN37605-1017
USA
www.dryandstore.com
© Ear Technology Corporation, 2010
Group 4, REV F 11/10
