DS Select-640 User manual

Instructions for Use
Ref: 28.1 640 SSDIP 020413
640-86
PO Box 103, Saffron Walden, CB11 3GD, UK
Tel: +44 (0) 1799 551199
Contents
Page
2 Quick-fit instructions
2 Changing pump tubes
3 Pump tube life
3 Safety
3 Accuracy
3 Electrical supply
3 Operation – screen controls
4 Constant pumping
5 Rotor Adjustment
5 Encoding
5 Installation
5 Problems / errors
5 Maintenance
5 Power Resumption
6 Spare parts and accessories
Select-640 Timed SSDIP

2
2
Remove the cover
from the pump head
(3 thumb screws).
The pump is supplied
(normally) with a
beige coloured pump
tube with a grey
band, and also a
spare pump tube for
replacement.
3m of PVC delivery
tubing are also
supplied with the
pump.
Cut the delivery tube
to the desired lengths
for inlet and outlet.
Connect the delivery
tube to the pump
tube using the tube
connectors provided.
Place the tube clip in
the pump head as
shown. This is
important. The clip
should be in the
housing above a
mounting screw as
shown.
Turn the rotor by
hand to load the tube
– ensure the tube is
fully inserted.
CARE – MIND
YOUR FINGERS
Replace the pump
cover (3 thumb
screws).
Connect the pump to
the 12V DC 5A
transformer
(supplied).
The doser is ready to
operate.
See operation details
below.
Description
The Select-640 Timed SSDIP is a dosing pump designed to give an initial dose of product, and then
give subsequent doses of either the same or a different dosed at timed intervals. The size of the initial
dose, the size of the timed dosages and the timed interval (in minutes) are all selected from the on-
screen controls. The components are; themain pump unit, delivery tube, and power supply (12V DC,
5A). There are no user serviceable parts inside the Select-640 SSDIP doser.
The doser will also give the initial dose on power-up.
Changing Pump Tubes
ENSURE THE POWER SUPPLY IS DISCONNECTED BEFORE CHANGING THE PUMP TUBE.
OTHERWISE ROTOR TURNING IS POSSIBLE
Removal of pump tube – Remove the black pump cover (3 screws). Unclip the pump tube at the inlet.
Lift out the pump tube whilst rotating the pump rotor by hand in a clockwise direction. When the pump
tube is clear of the rotors, completely remove the tube. Pull the old (soft) pump tube from the tube
connectors.
Push the new pump tube onto the tube connectors WITH THE TUBE RESTRAINT (ZIP TIE) ON THE
INLET SIDE. See instructions (above) to install new tube in the pump-head.
Ensure that all connectors between the pump tube and delivery tubes are securely fitted. If necessary
warm the delivery tube with warm air or water to soften it to make fitting more easy.
Pump Tube Life
The life of the pump tube will depend on many factors including the product being dosed, the back
pressures under which the pump is working, and the amount of time the pump needs to run to perform
correctly. It is suggested that, in order to maintain dosing accuracy, the pump tube is replaced on a BI-
MONTHLY BASIS or sooner if wear or disfiguration of the tube is apparent. Spare tubes are available

3
3
from your pump supplier. Note: Only tubes supplied by Dosing Solutions Ltd are recommended for use
in the Select-640 SSDIP dosing system to ensure accuracy of operation.
Safety
The Select-640 SSDIP Doser is an extremely safe unit. However, the following points should be
observed:
Normal electrical safety precautions apply. Avoid water contact with any pump parts apart from the
pump tube in normal working. Do not immerse the Select-640 SSDIP Doser.
Take precautions to ensure the Select-640 SSDIP doser can not fall into the stock solution. Consider
extra tethering if necessary. Cover stock solution at all times. If immersion does happen accidentally,
isolate the Select-640 SSDIP Doser from the electrical supply immediately.
The use of safety circuit breakers is recommended. If in doubt seek advice from a qualified electrician.
Accuracy
The Select-640 SSDIP doser is factory set to give accurate dosing. If, during normal operation, the
output needs to be increased or decreased slightly, this can be achieved via the screen command
“Adjust %”.
Electrical Supply
The Select-640 SSDIP doser uses a 12V DC power supply. This can either be supplied from a 12V
battery or via a transformer power supply from the mains electricity supply.
A 5A maximum current power supply is recommended. The Select-640 SSDIP doser normally runs
below 2A although starting currents are larger and dependant on the pumping conditions encountered.
Operation
When the electric supply is first connected, theversion of the programming will be shown.
This is the Welcome Screen
Press Adjust to start the set-up procedure.
If an Initial dose is required to be given immediately the doser is
started in operation press Yes (Set), otherwise press No.
To select the Initial Dose that will be given immediately the
doser starts operation, press adjust repeatedly until the desired
Initial Dose is shown. Then press Set.
The dosed amount is normally shown in ml. If you require a
dose amount that is not listed, please contact your Supplier.
On this screen you can select (by pressing Adjust repeatedly)
the dose (ml) that will be produced at the chosen time intervals.
With the cursor under each digit in turn, press Adjust until the
correct time is shown. Then press Set for each digit. Ensure all
leading zeros are in place. The time shown on the example
(right) is 25 minutes. 25000 would be 25,000 minutes (17.36
days).
The first timed dose will occur at the timed interval (25 mins in
this example) starting at the end on the Initial Dose.
Timed SSDIP Mins.
Press Adjust
Initial dose?
No
Yes
Initial amount?
12000
Dose amount?
1000
Time in Minutes?
00025

4
4
Press Set to get to the next screen.
This screen shows that the Timed dose is 1000ml, and the Grey
pump tube should be used.
Press set.
A Tube Adjust % figure will be shown on the packet that the
pump tube was supplied in. Use the Adjust button to scroll
through (-20% to +20%) until the correct figure is shown
This feature can also be used to trim the output of the pump.
Then press set.
The Select-640 SSDIP SSDIP will display the number of timed
doses that have been produced. This figure can be reduced to
zero on this screen.
Then press Set.
If you need to fill up the delivery tube with product, press Yes,
the pump will turn continuously and show Priming… on the
screen. Press Stop when required.
As soon as the priming phase is ended, the initial dose is made
showing the screen on the right.
Once this dose is completed, the following screen is shown:
This is the normal dosing screen. The timed doseis 1000ml,
the Grey tube should be installed, a Tube adjust of +6% has
been entered, there no timed doses recorded yet, and the timer
has 25 minutes remaining until the next timed dose.
The timer will run down to 00000 at which point the next timed
dose will be given.
To make any adjustments to settings, return to theWelcome Screen and progress through the options.
To return to the Welcome Screen, press and hold Adjust from the Operational Screen.
On the Operational Screen, the following colour abbreviations are used for pump tubes:
Grey Gry
Purple Ppl
Brown Brn
Constant Pumping
If the priming option is selected from the menu on the control screen (see above) the pump rotor will turn
continuously regardless of the flow in the drinking line. This can be useful for filling the suction and
delivery lines prior to proportional dosing. It can also be used if a particular product needs to be dosed
quickly within a given period. The following pumping rates will be achieved when the Select-640 SSDIP
doser is set to “prime”:
1000
Use Grey tube
Zero dose count?
No
Yes
Adjust %
+6
Prime pump?
No
Yes
Dosing…
Int dose 12000
1000Gry+6
0N 00025

5
5
Pump Tube Colour
Priming pump rate
Grey 72 litres / hour
Purple 36 litres / hour
Brown 4.92 litres / hour
It is not recommended to use the Select-640 SSDIP doser for more than 2 hours at a time in the priming
mode, as tube and motor life will be reduced.
Rotor Adjustment
The rotors in the Select-640 SSDIP pump-head are not adjustable.
Encoding
Under the rotor assembly, there is a magnet holder plate that turns with the rotor on the drive shaft.
This plate should be fitted so that the magnets are uppermost. The translucent washer should be under
the magnet holder plate.
Installation
The Select-640 SSDIP doser can be powered from a 12V DC battery or via a transformer from the
mains electricity supply. Position the dosing point so as to be convenient for a power source if power is
to be taken via a transformer from the mains. Ensure that the Select-640 SSDIP doser is properly
secured to prevent it becoming immersed in water or stock solution.
Connect the Select-640 SSDIP doser to either battery or transformer. Choose program options from
the control screen. Ensure pump tube fitted and connected to inlet and outlet delivery tubes. Place inlet
tube weight into additive liquid. Position the outlet tube to dose in the desired location.
Note: The pump will self prime. The pump can also be run dry without damaging any parts although it
is not recommended to run the pump dry for extended periods.
Power Resumption
On resuming power connection, the doser will continue at the point where electrical power was lost. The
timer will continue as from the point where power was lost.
Pumping Problems / Errors
If the Select-640 SSDIP doser fails to operate correctly, check the following: (If the problem can not be
resolved – contact your Distributor)
Problem
Solution
Incorrect dosing. 1. Check for low battery power If external battery is in
use)
2. Pump tube should be replaced regularly. Replace if
necessary
3. Is correct dosing amount selected?
4. Water pressure in the drinking water line should not
exceed 2 bar. Fit pressure reduction device if
necessary.
5. Incorrect Tube Adjust Factor entered on the control
screen. Check and re-enter.
6. Incorrect pump tube fitted. Are screen details
correct?
Product not being pumped from stock container. 1. Check all tube connections are firmly in place.
2. Inlet tube could be blocked. Clear as necessary.
3. If a knife has been used to free a tube connector on
the inlet side of the pump, the connector could be
damaged and letting air into the suction line.
Sudden loss of pumping pressure (with possible
return of fluid into stock container) 1 Check if there is any lateral movement in the rotor.
It is possible the rotor shaft bearings may have
worn. Consult Distributor.
2 Check for physical damage to pump head fixing
screws.

6
6
Maintenance
Weekly
Inspect the pump tube for signs of wear.
Check doser output. Adjust as necessary via the control screen.
Monthly
Replace pump tube monthly or sooner if any of the following occur:
Sharply increased rate of dosing
Split tube
Each 6 Months
After disconnecting from electric supply, remove cover from Select-640 SSDIP doser and inspect interior
of pump enclosure. Ensure no ingress of moisture or other contaminant. In case of difficulty, contact
your supplier.
Spare Parts and Accessories
Item
Code
Select-640 SSDIP Single Shot doser Unit 010CA92
Replacement pump tube pack – 5 tubes Grey 011CA63/REP
Replacement pump tube pack – 5 tubes Purple 011CA48/REP
Replacement pump tube pack – 5 tubes Brown 011CA16/REP
Delivery tube (low pressure) 6.0mm i.d. 30m 155CA60
Delivery tube (low pressure) 4.8mm i.d. 30m 155CA48
Delivery tube (3m) plus end weight unit 152CA05
Quick-fit male/female connector unit 153CA02
Power supply 12V-DC 5A UK style unit 019CA00
Power supply 12V-DC 5A EU style unit 019CA10
