DS18 6XL600-8 User manual

6XL600-8
’
ENGLISH | ESPAÑOL
MANUAL DE USUARIO
OWNER'S MANUAL
6.5" MID-RANGE LOUDSPEAKER
ALTAVOZ DE RANGO MEDIO DE 6.5"

6XL600-8
SPECIFICATIONS / ESPECIFICACIONES:
Nominal Diameter / Diámetro Nominal............................................................................................ 6.5" / 165 mm
Nominal Impedance / Impedancia Nominal .................................................................................................8 OHMS
RMS Power Handling / Manejo de Potencia RMS.................................................................................. 300 Watts
MAX Power Handling / Manejo de Potencia MAX.................................................................................. 600 Watts
Sensitivity (1w/1m) / Sensibilidad (1w /1m) ..................................................................................................97 dB
Frequency Response / Respuesta de Frecuencia............................................................................60Hz-12.5KHz
Recommended Hi Pass Crossover / Corte Paso Alto Recomendado..........................................................100 Hz
Sold as Pair or Single / Vendido en Par o Unidad ........................................................................... Single / Unidad
MOTOR / MOTOR:
Voice Coil Diameter / Diámetro de la Bobina de Voz..........................................................................2" / 50.8 mm
VC Former Material / Material Interior de Bobina de Voz............................................................................ Kapton
Winding Material / Material del Embobinado ................................................................................................. CCAW
Cone Material / Material del Cono ....................................................... Non-pressed Paper / Papel No Prensado
Dust Cap Material / Material de la Tapa Antipolvo............................................................................ Paper / Papel
Surround Material / Material de la Suspensión .....................................................................................Cloth / Tela
Basket Material / Material de la Canasta...............................................................................Aluminum / Aluminio
Basket Color/ Color de la Canasta...................................................................................Satin Black / Satén Negro
Magnet Material / Material del Imán ...............................................................................................Ferrite / Ferrita
Magnet Weight / Peso del Imán ........................................................................................................................ 34 Oz
Displacement Volume / Volumen de Desplazamiento ................................................................0.45L / 0.015ft3
THIELE & SMALL PARAMETERS / PARÁMETROS T/S:
Equivalent Volume / Volumen Equivalente..........................Vas.......................................................4.9L / 0.17ft3
Excursion / Excursión ..............................................................Xmax ..............................................................3.7 mm
Free Air Resonance / Resonancia al Aire Libre.....................Fs ....................................................................105 Hz
Mechanical Factor / Factor Mecánico ...................................Qms ..................................................................... 4.72
Electrical Factor / Factor Eléctrico.........................................Qes ...................................................................... 0.55
Total Factor / Factor Total ......................................................Qts .....................................................................0.493
Mechanical Mass / Masa Mecánica.......................................Mms ................................................................12.244
Mechanical Compliance / Cumplimiento Mecánico.............Cms ...................................................... 0.184 mm/N
BL Factor / Factor Bl ...............................................................Bl........................................................................9.027
Voice Coil Inductance / Inductancia de Bobina de Voz........Le ............................................................. 0.1647 mH
Cone Area / Área del Cono ......................................................Sd............................................................. 136.85 cm²
DC Resistance / Resistencia DC .............................................Re...................................................................5.8 ohm
Mechanical Mass w/o air / Mechanical Mass w/o air.........Mmd............................................................ 11.323 g
MEASUREMENT / MEDIDAS:
Overall Diameter / Diámetro Total .................................................................................................... 6.7" / 170 mm
Overall Depth / Profundidad Total........................................................................................................3.5" / 89 mm
Front Mount Baffle Cutout
/ Corte del Orificio de Montaje............................................................ 5.9" / 150 mm
Mounting Depth / Profundidad de Montaje ..................................................................................... 3.14" / 80 mm
Motor Diameter / Diámetro del Motor............................................................................................4.96" / 126 mm

20 Hz 50 100 200 500 1K 2K 5K 10K 20K
dBSPL
30
40
50
60
70
80
90
100
110
SPL vs Freq
Please visit our website DS18.com for more information
on our warranty policy.
We reserve the right to change products and specifications
at any time without notice.
Images may or may not include optional equipment.
Visita nuestra página web DS18.com para obtener más
información sobre nuestra garantía.
Nos reservamos el derecho de cambiar productos y
especificaciones en cualquier momento sin previo aviso. Las
imágenes pueden incluir o no equipo opcional.
WARRANTY GARANTÍA
WARNING:
Cancer and Reproductive Harm.
www.P65Warning.ca.gov
ADVERTENCIA:
Cáncer y Daño Reproductivo.
www.P65Warning.ca.gov
MEASUREMENTS / MEDIDAS:
4-5.5*6.5
6.3”/ 160 mm
6.7”/ 170 mm
0.78”/ 20 mm
3.5”/ 89 mm
3.14”/ 80 mm
4.96”/ 126 mm
5.9”/ 150 mm
SPECIFICATIONS / ESPECIFICACIONES:
Nominal Diameter / Diámetro Nominal............................................................................................ 6.5" / 165 mm
Nominal Impedance / Impedancia Nominal .................................................................................................8 OHMS
RMS Power Handling / Manejo de Potencia RMS.................................................................................. 300 Watts
MAX Power Handling / Manejo de Potencia MAX.................................................................................. 600 Watts
Sensitivity (1w/1m) / Sensibilidad (1w /1m) ..................................................................................................97 dB
Frequency Response / Respuesta de Frecuencia............................................................................60Hz-12.5KHz
Recommended Hi Pass Crossover / Corte Paso Alto Recomendado..........................................................100 Hz
Sold as Pair or Single / Vendido en Par o Unidad ........................................................................... Single / Unidad
MOTOR / MOTOR:
Voice Coil Diameter / Diámetro de la Bobina de Voz..........................................................................2" / 50.8 mm
VC Former Material / Material Interior de Bobina de Voz............................................................................ Kapton
Winding Material / Material del Embobinado ................................................................................................. CCAW
Cone Material / Material del Cono ....................................................... Non-pressed Paper / Papel No Prensado
Dust Cap Material / Material de la Tapa Antipolvo............................................................................ Paper / Papel
Surround Material / Material de la Suspensión .....................................................................................Cloth / Tela
Basket Material / Material de la Canasta...............................................................................Aluminum / Aluminio
Basket Color/ Color de la Canasta...................................................................................Satin Black / Satén Negro
Magnet Material / Material del Imán ...............................................................................................Ferrite / Ferrita
Magnet Weight / Peso del Imán ........................................................................................................................ 34 Oz
Displacement Volume / Volumen de Desplazamiento ................................................................0.45L / 0.015ft3
THIELE & SMALL PARAMETERS / PARÁMETROS T/S:
Equivalent Volume / Volumen Equivalente..........................Vas.......................................................4.9L / 0.17ft3
Excursion / Excursión ..............................................................Xmax ..............................................................3.7 mm
Free Air Resonance / Resonancia al Aire Libre.....................Fs ....................................................................105 Hz
Mechanical Factor / Factor Mecánico ...................................Qms ..................................................................... 4.72
Electrical Factor / Factor Eléctrico.........................................Qes ...................................................................... 0.55
Total Factor / Factor Total ......................................................Qts .....................................................................0.493
Mechanical Mass / Masa Mecánica.......................................Mms ................................................................12.244
Mechanical Compliance / Cumplimiento Mecánico.............Cms ...................................................... 0.184 mm/N
BL Factor / Factor Bl ...............................................................Bl........................................................................9.027
Voice Coil Inductance / Inductancia de Bobina de Voz........Le ............................................................. 0.1647 mH
Cone Area / Área del Cono ......................................................Sd............................................................. 136.85 cm²
DC Resistance / Resistencia DC .............................................Re...................................................................5.8 ohm
Mechanical Mass w/o air / Mechanical Mass w/o air.........Mmd............................................................ 11.323 g
MEASUREMENT / MEDIDAS:
Overall Diameter / Diámetro Total .................................................................................................... 6.7" / 170 mm
Overall Depth / Profundidad Total........................................................................................................3.5" / 89 mm
Front Mount Baffle Cutout
/ Corte del Orificio de Montaje............................................................ 5.9" / 150 mm
Mounting Depth / Profundidad de Montaje ..................................................................................... 3.14" / 80 mm
Motor Diameter / Diámetro del Motor............................................................................................4.96" / 126 mm
6
X
L
6
0
0

FOR MORE INFORMATION
PLEASE VISIT
DS18.COM
We LIKE IT LOUD
V1
