DSE 335 User manual

057-233 ISSUE: 1
DEEP SEA ELECTRONICS PLC
DSE335 Operator Manual
(Applicable to module version 4.2 and upwards)
Document Number: 057-233
Author: Fady Atallah

DSE335 Operator Manual
057-233 ISSUE: 1 Page 2 of 90
DEEP SEA ELECTRONICS PLC
Highfield House
Hunmanby
North Yorkshire
YO14 0PH
ENGLAND
Sales Tel: [phone]
Sales Fax: [phone]
E-mail: [e-mail]
Website: www.deepseaplc.com
DSE335 Operator Manual
© Deep Sea Electronics Plc
All rights reserved. No part of this publication may be reproduced in any material form (including
photocopying or storing in any medium by electronic means or other) without the written permission of
the copyright holder except in accordance with the provisions of the Copyright, Designs and Patents
Act 1988.
Applications for the copyright holder’s written permission to reproduce any part of this publication
must be addressed to Deep Sea Electronics Plc at the address above.
The DSE logo is a UK registered trademarks of Deep Sea Electronics PLC.
Any reference to trademarked product names used within this publication is owned by their respective
companies.
Deep Sea Electronics Plc reserves the right to change the contents of this document without prior
notice.
Amendments List
Issue Comments Minimum Module
Version Required
Minimum
Configuration Suite
Version Required
1 Initial release V4.2.22 2014.101 V1.212.3
Typeface: The typeface used in this document is Arial. Care must be taken not to mistake the upper
case letter I with the numeral 1. The numeral 1 has a top serif to avoid this confusion.
Clarification of notation used within this publication.
NOTE Highlights an essential element of a procedure to ensure correctness.
CAUTION! Indicates a procedure or practice, which, if not strictly observed, results in
damage or destruction of equipment.
WARNING! Indicates a procedure or practice, which results in injury to personnel or
loss of life if not followed correctly.

DSE335 Operator Manual
Page 3 of 90 057-233 ISSUE: 1
TABLE OF CONTENTS
SECTION
PAGE
1 INTRODUCTION..................................................................................................6
1.1 BIBLIOGRAPHY................................................................................................................. 7
1.1.1 INSTALLATION INSTRUCTIONS................................................................................. 7
1.1.2 TRAINING GUIDES...................................................................................................... 7
1.1.3 MANUALS.................................................................................................................... 7
1.1.4 THIRD PARTY DOCUMENTS...................................................................................... 7
2 SPECIFICATIONS ...............................................................................................8
2.1 SHORT NAMES.................................................................................................................. 8
2.2 REQUIREMENTS FOR UL CERTIFICATION...................................................................... 8
2.3 TERMINAL SPECIFICATION.............................................................................................. 9
2.4 POWER SUPPLY REQUIREMENTS................................................................................... 9
2.4.1 MODULE SUPPLY INSTRUMENTATION DISPLAY..................................................... 9
2.5 S1 & S2 VOLTAGE / FREQUENCY SENSING................................................................. 10
2.6 GENERATOR CURRENT SENSING................................................................................. 10
2.6.1 V A RATING OF THE CTS......................................................................................... 11
2.6.2 CT POLARITY............................................................................................................ 12
2.6.3 CT PHASING............................................................................................................. 12
2.6.4 CT CLASS.................................................................................................................. 12
2.7 INPUTS............................................................................................................................. 13
2.7.1 DIGITAL INPUTS ....................................................................................................... 13
2.8 OUTPUTS......................................................................................................................... 13
2.8.1 CONFIGURABLE OUTPUTS A & E............................................................................ 13
2.8.2 CONFIGURABLE OUTPUTS B & F............................................................................ 13
2.8.3 CONFIGURABLE OUTPUTS B & F............................................................................ 13
2.8.4 CONFIGURABLE OUTPUTS G, H, I, J, K & L............................................................. 13
2.9 COMMUNICATION PORTS .............................................................................................. 14
2.9.1 COMMUNICATION PORT USAGE............................................................................ 15
2.9.1.1 USB CONNECTION............................................................................................ 15
2.9.1.2 RS232................................................................................................................. 16
2.9.1.3 RECOMMENDED PC RS232 SERIAL PORT ADD-ONS ..................................... 16
2.9.1.4 RECOMMENDED EXTERNAL MODEMS............................................................ 17
2.9.1.5 RS485................................................................................................................. 18
2.9.1.6 RECOMMENDED PC RS485 SERIAL PORT ADD-ONS ..................................... 18
2.9.2 DSENET® FOR EXPANSION MODULES................................................................. 19
2.10 ADDING AN EXTERNAL SOUNDER TO THE APPLICATION...................................... 19
2.11 DIMENSIONS AND MOUNTING.................................................................................... 20
2.11.1 DIMENSIONS............................................................................................................. 20
2.11.2 PANEL CUTOUT........................................................................................................ 20
2.11.3 WEIGHT..................................................................................................................... 20
2.11.4 FIXING CLIPS............................................................................................................ 21
2.11.5 CABLE TIE FIXING POINTS ...................................................................................... 22
2.11.6 SILICON SEALING GASKET...................................................................................... 22
2.11.8 APPLICABLE STANDARDS....................................................................................... 23
2.11.9 ENCLOSURE CLASSIFICATIONS............................................................................. 25
2.11.9.1 IP CLASSIFICATIONS......................................................................................... 25
2.11.9.2 NEMA CLASSIFICATIONS.................................................................................. 26
3 INSTALLATION.................................................................................................27
3.1 TERMINAL DESCRIPTION............................................................................................... 27
3.1.1 DC SUPPLY, OUTPUTS G-L...................................................................................... 28
3.1.2 CONFIGURABLE DIGITAL INPUTS A-I...................................................................... 28
3.1.3 CONFIGURABLE DIGITAL INPUTS J-L, DSENET..................................................... 29
3.1.4 CONFIGURABLE VOLT-FREE OUTPUTS E & F........................................................ 29
3.1.5 LOAD SWITCHING AND S2 VOLTAGE SENSING..................................................... 29
3.1.6 S1 VOLTAGE SENSING ............................................................................................ 30

DSE335 Operator Manual
057-233 ISSUE: 1 Page 4 of 90
3.1.7 LOAD CURRENT TRANSFORMERS......................................................................... 30
3.1.7.1 CONNECTION TO TERMINALS 45 & 46/47........................................................ 31
3.1.7.2 CT CONNECTIONS ............................................................................................ 31
3.1.8 CONFIGURABLE VOLT-FREE CHANGEOVER OUTPUTS C & D............................. 32
3.1.9 PC CONFIGURATION INTERFACE CONNECTOR.................................................... 32
3.1.10 RS485 CONNECTOR................................................................................................. 33
3.1.11 RS232 CONNECTOR................................................................................................. 33
3.2 TYPICAL WIRING DIAGRAM........................................................................................... 34
3.2.1 DSE335 3 PHASE, 4 WIRE WITH RESTRICTED EARTH FAULT PROTECTION....... 35
3.3 ALTERNATIVE TOPOLOGIES......................................................................................... 36
3.3.1 3 PHASE, 4 WIRE WITHOUT EARTH FAULT PROTECTION .................................... 36
3.3.2 SINGLE PHASE WITH RESTRICTED EARTH FAULT ............................................... 37
3.3.3 SINGLE PHASE WITHOUT EARTH FAULT............................................................... 37
3.3.4 2 PHASE (L1 & L2) 3 WIRE WITH RESTRICTED EARTH FAULT.............................. 38
3.3.5 2 PHASE (L1 & L2) 3 WIRE WITHOUT EARTH FAULT.............................................. 38
3.3.6 2 PHASE (L1 & L3) 3 WIRE WITH RESTRICTED EARTH FAULT.............................. 39
3.3.7 2 PHASE (L1 & L3) 3 WIRE WITHOUT EARTH FAULT MEASURING........................ 40
3.3.8 3 PHASE 4 WIRE WITH UNRESTRICTED EARTH FAULT MEASURING.................. 41
3.4 EARTH SYSTEMS............................................................................................................ 42
3.4.1 NEGATIVE EARTH.................................................................................................... 42
3.4.2 POSITIVE EARTH...................................................................................................... 42
3.4.3 FLOATING EARTH .................................................................................................... 42
3.5 TYPICAL ARRANGEMENT OF DSENET®....................................................................... 42
4 DESCRIPTION OF CONTROLS........................................................................43
4.1 CONTROL PUSH-BUTTONS............................................................................................ 45
4.2 VIEWING THE INSTRUMENT PAGES.............................................................................. 47
4.2.1 STATUS..................................................................................................................... 48
4.2.2 S1.............................................................................................................................. 49
4.2.3 S2.............................................................................................................................. 49
4.2.4 MODULE.................................................................................................................... 49
4.2.5 EXPANSION.............................................................................................................. 50
4.2.6 ALARMS.................................................................................................................... 50
4.2.7 EVENT LOG............................................................................................................... 50
4.2.8 SERIAL PORT............................................................................................................ 51
4.2.8.1 RS232 SERIAL PORT......................................................................................... 51
4.2.8.2 RS485 SERIAL PORT......................................................................................... 55
4.2.9 SCHEDULER............................................................................................................. 56
4.2.10 ABOUT....................................................................................................................... 56
4.3 VIEWING LATEST TRANSFER INFORMATION PAGE.................................................... 57
4.4 USER CONFIGURABLE INDICATORS............................................................................ 58
4.5 OPERATION..................................................................................................................... 59
4.6 QUICKSTART GUIDE....................................................................................................... 59
4.6.1 STARTING S2............................................................................................................ 59
4.6.2 STOPPING S2 ........................................................................................................... 60
4.7 STOP/RESET ................................................................................................................... 61
4.8 MANUAL MODE............................................................................................................... 62
4.8.1 STARTING SEQUENCE............................................................................................. 62
4.8.2 S2 AVAILABLE........................................................................................................... 62
4.8.3 STOPPING SEQUENCE............................................................................................ 63
4.9 AUTOMATIC MODE......................................................................................................... 64
4.9.1 WAITING IN AUTO MODE......................................................................................... 64
4.9.2 STARTING SEQUENCE............................................................................................. 64
4.9.3 S2 AVAILABLE........................................................................................................... 65
4.9.4 STOPPING SEQUENCE............................................................................................ 65
4.10 MODE SELECTION....................................................................................................... 66
4.10.1 TEST ON LOAD......................................................................................................... 66
4.10.1.1 STARTING SEQUENCE...................................................................................... 66
4.10.1.2 S2 AVAILABLE.................................................................................................... 66
4.10.1.3 STOPPING SEQUENCE..................................................................................... 66

DSE335 Operator Manual
Page 5 of 90 057-233 ISSUE: 1
4.10.2 TEST OFF LOAD ....................................................................................................... 67
4.10.2.1 STARTING SEQUENCE...................................................................................... 67
4.10.2.2 S2 AVAILABLE.................................................................................................... 67
4.10.2.3 STOPPING SEQUENCE..................................................................................... 67
4.10.3 PROHIBIT RETURN................................................................................................... 68
4.10.3.1 WAITING IN PROHIBIT RETURN........................................................................ 68
4.10.3.2 STARTING SEQUENCE...................................................................................... 68
4.10.3.3 S2 AVAILABLE.................................................................................................... 69
4.10.3.4 STOPPING SEQUENCE..................................................................................... 69
4.11 SCHEDULER ................................................................................................................ 70
4.11.1 STOP MODE.............................................................................................................. 70
4.11.2 MANUAL MODE......................................................................................................... 70
4.11.3 AUTO MODE.............................................................................................................. 70
4.12 LOAD SHEDDING CONTROL....................................................................................... 71
4.12.1 LOAD SHEDDING CONTROL.................................................................................... 71
5 PROTECTIONS..................................................................................................72
5.1 INDICATIONS................................................................................................................... 73
5.2 WARNINGS...................................................................................................................... 74
5.3 ELECTRICAL TRIPS........................................................................................................ 75
6 FRONT PANEL CONFIGURATION...................................................................76
6.1 ACCESSING THE MAIN FRONT PANEL CONFIGURATION EDITOR............................. 77
6.1.1 EDITING A PARAMETER........................................................................................... 78
6.2 ADJUSTABLE PARAMETERS......................................................................................... 79
7 COMMISSIONING..............................................................................................82
8 FAULT FINDING................................................................................................83
8.1 STARTING........................................................................................................................ 83
8.2 LOADING ......................................................................................................................... 83
8.3 ALARMS........................................................................................................................... 83
8.4 COMMUNICATIONS......................................................................................................... 84
8.5 INSTRUMENTS ................................................................................................................ 84
8.6 MISCELLANEOUS ........................................................................................................... 85
9 MAINTENANCE, SPARES, REPAIR AND SERVICING ...................................86
9.1 PURCHASING ADDITIONAL CONNECTOR PLUGS FROM DSE.................................... 86
9.1.1 PACK OF PLUGS....................................................................................................... 86
9.1.2 INDIVIDUAL PLUGS.................................................................................................. 86
9.2 PURCHASING ADDITIONAL FIXING CLIPS FROM DSE................................................. 86
9.3 PURCHASING ADDITIONAL SEALING GASKET FROM DSE......................................... 86
9.4 DSENET EXPANSION MODULES.................................................................................... 87
10 WARRANTY ...................................................................................................88
11 DISPOSAL......................................................................................................88
11.1 WEEE (WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT)............................... 88

Introduction
057-233 ISSUE: 1 Page 6 of 90
1 INTRODUCTION
This document details the installation and operation requirements of the DSE335 module version 4.2
and later, part of the DSEATS® range of products.
A separate document covers the DSE335 modules with firmware version prior to version 4.2.
The manual forms part of the product and must be kept for the entire life of the product. If the product
is passed or supplied to another party, ensure that this document is passed to them for reference
purposes.
This is not a controlled document. Updates are not automatically informed. Any future updates of this
document are included on the DSE website at www.deepseaplc.com
The module is designed to provide differing levels of functionality across a common platform. This
allows the OEM greater flexibility in the choice of controller to use for a specific application.
The module has been designed to allow the operator to control the transfer of the load from Source 1
(S1) to Source 2 (S2), typically the mains supply and a standby generator either manually (via fascia
mounted push-buttons) or automatically upon S1 failure. Additionally if configured too, the module
automatically starts and stops the generator set (S2) depending upon the status of S1.
The user also has the facility to view the system operating parameters via the LCD display to monitor
the supplies and indicating the operational status and fault conditions of the module.
The powerful ARM microprocessor contained within the module allows for incorporation of a range of
complex features:
•Text based LCD display (supporting multiple languages)
•True RMS Voltage, Current and Power monitoring
•Communications capability (RS485 or RS232)
•Multiple AC supply monitoring
•Fully configurable inputs for use as alarms or a range of different functions.
Using a PC and the DSE Configuration Suite software allows alteration of selected operational
sequences, timers, alarms and operational sequences. Additionally, the module’s integral front panel
configuration editor allows adjustment of this information.
A robust plastic case designed for front panel mounting houses the module. Connections are via
locking plug and sockets.
Access to critical operational sequences and timers for use by qualified engineers, can be protected
by a security code. Module access can also be protected by PIN code. Selected parameters can be
changed from the module’s front panel.
The module is housed in a robust plastic case suitable for panel mounting. Connections to the module
are via locking plug and sockets.

Introduction
Page 7 of 90 057-233 ISSUE: 1
1.1 BIBLIOGRAPHY
This document refers to and is referred to by the following DSE publications are obtained from the
DSE website: www.deepseaplc.com
1.1.1 INSTALLATION INSTRUCTIONS
Installation instructions are supplied with the product in the box and are intended as a ‘quick start’
guide only.
DSE
Part
Description
053-135 DSE335 Installation Instructions
053-032 DSE2548 LED Expansion Annunciator Installation Instructions
053-033 DSE2130 Input Expansion Installation Instructions
053-034 DSE2157 Output Expansion Installation Instructions
1.1.2 TRAINING GUIDES
Training Guides are produced to give ‘handout’ sheets on specific subjects during training sessions.
D
SE
Part
Description
056-005 Using CTs With DSE Products
056-022 Breaker Control
056-024 GSM Modem
056-030 Module PIN Codes
1.1.3 MANUALS
Product manuals are are downloaded from the DSE website: www.deepseaplc.com.
D
SE
Part
Description
057-237 DSE335 Configuration Suite PC Software Manual
057-082 DSE2130 Input Expansion Manual
057-083 DSE2157 Output Expansion Manual
057-084 DSE2548 Annunciator Expansion Manual
057-158 DSE335 Operators Manual – prior to v4.2
1.1.4 THIRD PARTY DOCUMENTS
The following third party documents are also referred to:
Reference
Description
ISBN 1-55937-879-4 IEEE Std C37.2-1996 IEEE Standard Electrical Power System Device Function Numbers and Contact Designations. Institute of Electrical and
Electronics Engineers Inc
ISBN 0-7506-1147-2 Diesel generator handbook. L.L.J.Mahon
ISBN 0-9625949-3-8 On-Site Power Generation. EGSA Education Committee.

Specifications
057-233 ISSUE: 1 Page 8 of 90
2 SPECIFICATIONS
2.1 SHORT NAMES
Short
N
ame
Description
DSE3xx All modules/controllers in the DSEATS range
DSE335 DSE335 module/controller
2.2 REQUIREMENTS FOR UL CERTIFICATION
Description
Specification
Screw Terminal
Tightening Torque •4.5 lb-in (0.5 Nm)
Conductors
•
Terminals suitable for connection of conductor size 12 AWG to 26 AWG
(0.5 mm² to 2.0 mm²).
•Conductor protection must be provided in accordance with NFPA 70,
Article 240
•Low voltage circuits (35 V or less) must be supplied from the engine
starting battery or an isolated secondary circuit.
•The communication, sensor, and/or battery derived circuit conductors
shall be separated and secured to maintain at least ¼ ” (6 mm) separation
from the generator and mains connected circuit conductors unless all
conductors are rated 600 V or greater.
Current Inputs
•
Must be connected through UL Listed or Recognized isolating current
transformers with the secondary rating of 5 A maximum.
Communication
Circuits •Must be connected to communication circuits of UL Listed equipment
Output Pilot Duty
•
0.5 A
Mounting
•
Suitable for use in type 1 Enclosure Type rating with surrounding air
temperature -22 ºF to +158 ºF (-30 ºC to +70 ºC)
•Suitable for pollution degree 3 environments when voltage sensing inputs
do not exceed 300 V. When used to monitor voltages over 300 V, a
device is to be installed in an unventilated or filtered ventilation enclosure
to maintain a pollution degree 2 environment.
Operating
Temperature •-22 ºF to +158 ºF (-30 ºC to +70 ºC)
Storage Temperature
•
-40 ºF to +176 ºF (-40 ºC to +80 ºC)

Specifications
Page 9 of 90 057-233 ISSUE: 1
2.3 TERMINAL SPECIFICATION
NOTE: For purchasing additional connector plugs from DSE, see the section entitled
Maintenance, Spares, Repair and Servicing elsewhere in this document.
Description
Specification
Connection Type
Two part connector.
•Male part fitted to
module
•Female part supplied in
module packing case -
Screw terminal, rising
clamp, no internal
spring.
Example showing cable entry and screw
terminals of a 10 way connector
Minimum Cable Size 0.5 mm² (AWG 24)
Maximum Cable Size 2.5 mm² (AWG 10)
2.4 POWER SUPPLY REQUIREMENTS
Description
Specification
Minimum supply voltage 8V continuous
Cranking dropouts Able to survive 0V for 50mS providing the supply was at least 10V
before the dropout and recovers to 5V afterwards.
Maximum supply voltage 35V continuous (60V protection)
Reverse polarity protection -35V continuous
Maximum operating current 360mA at 24V
480mA at 12V
Maximum standby current 96mA at 24V
126mA at 12V
2.4.1 MODULE SUPPLY INSTRUMENTATION DISPLAY
Description
Specification
Range 0 V to 70 V DC
Maximum continuous operating voltage of 35 V DC
Resolution 0.1 V
Accuracy 1% full scale (±0.7 V)

Specifications
057-233 ISSUE: 1 Page 10 of 90
2.5 S1 & S2 VOLTAGE / FREQUENCY SENSING
Description
Specification
Measurement type True RMS conversion
Sample Rate 5KHz or better
Harmonics Up to 10
th
or better
Input Impedance 300K Ωph-N
Phase to Neutral 15V (minimum required for sensing frequency) to 333V AC (absolute
maximum)
Suitable for 110V to 277V nominal
(±20% for under/overvoltage detection)
Phase to Phase 26V (minimum required for sensing frequency) to 576V AC (absolute
maximum)
Suitable for 190V ph-ph to 479V ph-ph nominal
(±20% for under/overvoltage detection)
Common mode offset from
Earth 100V AC (max)
Resolution 1V AC phase to neutral
2V AC phase to phase
Accuracy ±1% of full scale phase to neutral
±2% of full scale phase to phase
Minimum frequency 3.5Hz
Maximum frequency 75.0Hz
Frequency resolution 0.1Hz
Frequency accuracy ±0.2Hz
2.6 CURRENT SENSING
Description
Specification
Measurement type True RMS conversion
Sample Rate 5KHz or better
Harmonics Up to 10
th
or better
Nominal CT secondary
rating 5A
Maximum continuous current 5A
Overload Measurement 15A for 100ms
Absolute maximum overload 50A for 1 second
Burden 0.5VA (0.02Ωcurrent shunts)
common mode offset ±2V peak plant ground to CT common terminal
Resolution 25ma
Accuracy ±1% of Nominal (5A) (excluding CT error)
