For technical support or help with any questions not covered in the manual,
contract.
DSPM Inc.
1921 S. Quaker Ridge Place
Ontario, CA 91761
Work Hours: 8 a.m. – 5 p.m. Pacific Standard Time
Phone:1(877) DSPM POWER
1(877) 377-6769
After Hours: 5 p.m. – 1 a.m. Pacific Standard Time
1(951) 840-0811
Fax: [phone]
Email: [e-mail]
Internet: http://www.DSPManufacturing.com
To expedite assistance if required, Please have the following information from your unit’s System Label
(found on the right side and inside door panel) available:







Thank you for selecting this Three Phase Frequency Converter. It provides you with perfect protection for con-
nected loads and equipment.
It includes important safety and instructions for
operating the Three Phase Frequency Converter. If you should have any problems with this Three Phase Fre-
quency Converter, please refer to this manual and/or call technical support.
While every precaution has been made to ensure accuracy and completeness in this manual,
DSPM assumes no responsibility and disclaims all liability for damages resulting from the use of this information
or for any errors or omissions.


1.877.377.6769
Fax: [phone]
Three Phase Frequency Converter
018-5000-00  --
User’s Manual 
a risk of electric shock, personal inju-
ry, or death to
 A Caution notice icon conveys to the user or service personnel information mak-
ing them aware that there is a possibility of equipment damage.

A Note notice icon indicates when the user should make a reference of infor-
mation regarding the Frequency Converter operation, load status and display sta-
tus. Such information is essential if DSPM, Inc. field service assistance and cor-
respondence is required.







Following safety precautions is important when operating or servicing electrical equipment. Always heed these
precautions since they are essential to the safe operation and servicing of this product.
The symbols are used extensively
throughout this manual and are defined below. To ensure the safety of operating performance of this electrical
equipment, these instructions must be adhered too.
