GigMAC PMC/PCI Controllers
Board and Driver Users Manual
(Includes models 5160, 5161, 6160 and 7160)
Version 1.12, P/N 131900
June 2002

GigMAC PMC and PCI Controller and Driver Users Manual
1. INTRODUCTION
Thank you for purchasing the DSS Networks GigMAC Gigabit Ethernet
Controller. The GigMac family of adapters is a high-performance, cost-effective
Ethernet solution for adding Gigabit Ethernet connectivity to any embedded
Network Appliance, Server or Access Device equipped with a PCI or PMC
Mezzanine slot and is ideal for both embedded PCI and CompactPCI systems.
The GigMac family includes optimized, high-performance driver support for
VxWorks, Linux and Windows. Instructions for Linux and Windows driver
installation are included in this manual. In addition, a companion document titled
“VxWorks Users Manual And Integration Guide” is provided for technical
assistance in integrating and testing the driver in an embedded VxWorks
environment.
1.1 SEE ALSO
Please also see the following documents on our website at
www.dssnetworks.com and also included in the OEM developers kit CD:
“Release Notes” -- where updated information is provided on new features,
compatibility, performance benchmarks, platform information and corrected
problems.
“VxWorks Users Manual and Integration Guide”, DSS Document part no
131901. Provides technical information on integrating and testing our controllers
and drivers into a VxWorks BSP and system board.
GIGFAQ.HTML – Also on website and included on OEM developer CD contains
many answers to commonly asked questions regarding Gigabit Ethernet and our
products including performance and system recommendations.
README.LINUX – Included on OEM developer CD contains latest driver
installation and usage instructions for Linux Operating System.
1.2 COMPATIBILITY
The GigMac family is fully compliant with the following standards:
 IEEE 802.3 (all sections applicable to 1000 Base T, 1000 Base SX, 1000
Base LX)
DSS NETWORKS, INC. Version: 1.12 Page: 2

GigMAC PMC and PCI Controller and Driver Users Manual
 IEEE 802.1D and IEEE 802.1Q as applicable for VLAN and priority
queuing support
 PCI 2.2 bus compliant
 PCI low-profile specification (as applicable for model)
 IEEE 1386.1 Draft 2.2
 Linux driver compatibility: Standard Linux 2.2 or 2.4 kernel level
Network driver module compiled and tested on Intel and PowerPC
architectures
 VxWorks driver compatibility: Standard Tornado 2.0.2, VxWorks 5.4
Enhanced Network Driver loadable module integrated and tested on
PowerPC, Intel and MIPS architectures
1.3 GigMAC MODEL NUMBERS
This user manual covers all Models of our GigMAC PMC and PCI cards
including:
 Model 5160 PMC Copper
 Model 5161 PMC Copper
 Model 7160 Fiber
 Model 6160 PCI
1.4 FEATURES
The GigMac adapter offers the following key features:
• Sustained throughput of 1.94 Gbps over PCI bus using PCI 64/66
• Sustained throughput of 110 Mbytes/sec over PCI bus using PCI 32/33
• Frame processing rate of over 500,000 frames per second
• Support for Copper and Fiber Interface Cards (Models 5160, 5161, 6160
and 7160)
• One adapter family for all common platforms with driver support for
vxWorks, Linux and Windows
• Both 64-bit PMC and 64-bit PCI low-profile card adapter form factors
• Supports 33 and 66 MHz, 32 and 64 bit PCI interfaces including PMC form
factor
• Installs in any PCI or CompactPCI system with a PMC or universal PCI
slot
DSS NETWORKS, INC. Version: 1.12 Page: 3

GigMAC PMC and PCI Controller and Driver Users Manual
• Ideal solution for CompactPCI and embedded 1U and 2U PC-based
systems
• Utilizes either 5 or 3.3 volt power supply and contains onboard power
regulators
• Full duplex Gigabit Ethernet Interface over standard CAT5 cabling
• Complies with all PCI revision 2.2 mechanical and electrical requirements
• Fully IEEE 802.3z, IEEE 802.3ab, 802.3u and IEEE 1386 compliant
• Compatible with all 10/100/1000BaseT hubs, switches and routers
• Burst rate of up to 256 dwords (1024 bytes) over PCI bus
• Optional jumbo packets, 802.3x full duplex flow control with automatic
pause and priority with multiple priority queues
1.5 OEM DEVELOPER KIT CONTENTS
An OEM developer kit is provided with the purchase of the Gigabit Ethernet
controllers which contains drivers, documentation and sample code including the
following:
 Specified mode of GigMAC PMC Mezzanine or PCI Adapter
 Users Manual (this document)
 VxWorks Users Manual and Integration Guide
 Drivers for VxWorks, Linux and Windows (as per ordered items)
 Driver Utility software
 Release Notes
 Datasheets
 README files
1.6 SYSTEM REQUIREMENTS
PC Requirements: (1000TA/TPC): Pentium III 700 MHZ or faster with PC100 or
PC133 SDRAM, 64-bit or 66MHZ PCI.
Recommended: PowerPC7400 series at 500MHZ or faster, Pentium3 or
Pentium4 at 1GHZ or faster, DDR or RDRAM based.
Operating system: Linux 2.2 or 2.4; Windows 2000 or Windows XP Embedded
Tornado II requirements: Tornado 2.0.2 with patch updates, VxWorks kernel
5.4 or later. PCI Configuration Library support (pciConfigLib). One available PMC
Mezzanine slot. PowerPC, Intel or MIPS based with a 450MHZ processor or
better, PC100 or PC133 SDRAM, DDR SDRAM or RDRAM based.
DSS NETWORKS, INC. Version: 1.12 Page: 4

GigMAC PMC and PCI Controller and Driver Users Manual
Recommended PowerPC7400 series at 500MHZ or better, Pentium3 or
Pentium4 at 1GHZ or better, DDR or RDRAM based.
DSS NETWORKS, INC. Version: 1.12 Page: 5

GigMAC PMC and PCI Controller and Driver Users Manual
1.7 BOARD LED INDICATORS
Models 5160, 5161, 6160 with RJ-45 connector
The front panel has onboard RJ-45 connectors that supports the connection of
Category 5 cabling with 6 LED indicators that provide the following as marked
with silkscreen nomenclature on front panels:
Three of the Yellow LEDs are used to indicate the link status and port speed
option: 10 Mb, 100 Mb (Fast Ethernet), and 1000 Mb (Gigabit Ethernet) modes.
The illuminated LED indicated that the link is up and established at the speed
indicated.
One yellow LED indicates Full-Duplex status if illuminated, else half-duplex.
The remaining two Green LEDs are used to indicate both transmit and receive
activity.
LED SUMMARY
Speed Link Activity Indicators
10 Mbps LED glows solid yellow
when link is detected
100 Mbps LED glows solid yellow
when link is detected
1000 Mbps LED glows solid yellow
when link is detected
Full-Duplex Link Activity Indicator
Full-Duplex LED illuminates solid yellow
to indicate full duplex status
Transmit and Receive Activity Indicators
Transmit and Receive LEDs are on solid or blinking green
to indicate activity on the link (solid shows constant activity, blinking shows
intermittent activity)
Model 7160 with SC or LC connector
The front panel has onboard fiber optic connectors that supports the connection
of fiber optic cabling using 50 or 62.5 micron multimode fiber, SC or LC type
DSS NETWORKS, INC. Version: 1.12 Page: 6

GigMAC PMC and PCI Controller and Driver Users Manual
connectors with 4 LED indicators that provide the following as marked with
silkscreen nomenclature on front panels:
Two of the Yellow LEDs are used to indicate Signal Detect (SD) and Link Status
(LNK). The Signal Detect indicates the physical layer connection is established
while the LNK indicates that the auto negotiation has completed and the link is
established at the MAC and driver level.
The remaining two Green LEDs are used to indicate both transmit and receive
activity. All ports function in the same manner as shown in the Table below:
LED SUMMARY
Signal “SD” detect Indicator
On solid yellow when hardware detects valid signal from Fiber
Link “LNK” Indicator
On solid yellow to indicate auto-negotiation complete and MAC and driver level
link is up
Transmit and Receive Activity Indicators
Transmit and Receive LEDs are solid or blinking green
to indicate activity on the link (solid shows constant activity, blinking shows
intermittent activity)
2. HARDWARE INSTALLATION
Before attempting to install the GigMac Gigabit adapter into your system, please
make sure of the following:
Shut off the power to the computer and any peripherals. It is important to remove
the power cable to the computer to reduce the possibility of residual power
remaining in the power supply.
Ground yourself. Many electronic components inside computer and on the
GigMac card can be severely damaged by receiving a shock of static electricity.
Before touching any electronic components or boards, discharge any static
electricity on your body by touching the bare metal case around the power supply
inside your computer. Avoid excessive movement during the installation, such as
walking across carpets, as this can generate static. If you must leave the
installation area before the installation is complete, be sure to ground yourself
again before continuing the installation.
DSS NETWORKS, INC. Version: 1.12 Page: 7

GigMAC PMC and PCI Controller and Driver Users Manual
Assess system power requirements. If you already have other PCI cards in
your Mac, make sure that your system is able to provide the necessary power to
support the addition of the GigMac adapter card. Check your computer's user
manual for power limitations.
2.1 INSTALLATION IN PC COMPUTER
There are many different styles and types of PC platforms that utilize PCI slots.
This section contains a generic installation procedure. Please refer to your User's
manual for more detailed instructions on installing the adapter in a PC.
The GigMAC PMC card requires a PMC-to-PCI Carrier adapter module in order
to be used in a standard PCI system. Please refer to section 2.2 below for
instructions on installing the GigMAC PMC adapter onto a mainboard carrier
adapter.
Step 1 - Shut down the power to the computer system and remove the power
cord and any peripheral cables.
Step 2 - Open the computer case. This will expose the interior of the case and
allow the adapter card to be installed. Consult your User's Manual for assistance
in opening your computer. The PCI card edge connector contains “key” notches
that correspond to dividers in the motherboard slot. It is very important to align
the key notches with the matching dividers in the slot. Failure to align the notches
correctly could cause the card or slot to be damaged.
Step 3 - Align the GigMac PCI edge connector and the system motherboard
socket as indicated in the diagram above. Once aligned, push down firmly on the
PCI card until it is completely seated in the slot. Once the GigMac adapter has
been successfully installed, close the PC case, re-attach the power cable and
any other cables that were removed for the hardware installation procedure.
Consult Section 2.3 for information on connecting the adapter to the network.
2.2 INSTALLATION IN AN EMBEDDED OR COMPACTPCI
SYSTEM
There are many different styles and types of Embedded System platforms that
utilize PMC Mezzanine slots. This section contains a generic installation
procedure. Please refer to your User's manual for more detailed instructions on
installing the adapter in an Embedded or CompactPCI system.
Step 1 - Shut down the power to the computer system and remove the power
cord and any peripheral cables.
DSS NETWORKS, INC. Version: 1.12 Page: 8

GigMAC PMC and PCI Controller and Driver Users Manual
Step 2 – Remove the CompactPCI or Embedded Mainboard controller from the
system, if necessary to access the PMC slot. This will allow the PMC adapter
card to be more easily installed. Consult your User's Manual for assistance in
opening and removing the mainboard. The PMC card has 3 connectors labeled
JN1, JN2 and JN3. JN1 and JN2 are required for all modes of operation while
JN3 is required only for 64-bit mode. Your CompactPCI mainboard or other PMC
carrier will also contain PMC card connectors labeled JN1 and JN2, and
optionally JN3 and JN4. JN4 is for optional user-defined I/O and is not used by
the GigMAC PMC adapter. Additionally, the mainboard may also contain either a
5 volt or 3.3 volt key to prevent voltage mismatches. Since the GigMAC PMC
card may operate from a 5 or 3.3 volt supply, it can be used in either a 5 or 3.3
volt keyed system. It is very important to align the connectors before pressing the
PMC card onto the mainboard to prevent damage to the card or slot.
Step 3 - Align the GigMac PMC connectors and the system motherboard
Connectors and push down firmly on the PMC card until it is completely seated in
the connectors on the mainboard. Once the GigMac adapter has been
successfully installed, re-install the mainboard. Re-attach the power cable and
any other cables that were removed for the hardware installation procedure.
2.3 CONNECTING THE CONTROLLER TO THE NETWORK
Connecting Copper RJ-45 Models 5160, 5161 and 6160
This section explains how to connect the GigMac controller to the external
network using the standard Category 5 cables. The maximum cable length is
typically 100 meters or 328 feet.
Insert the Category 5 or 5e cable into the RJ-45 connector until the self-locking
tab clicks into position. Connect the opposite end in to a 10/100 or 10/100/1000
Base T switch. Two types of cables are used when connecting the GigMac
controller to the network. A workstation or "straight through" cable is typically
used to connect Ethernet adapters to switches. A crossover cable may also be
used to connect adapters to adapters. This configuration is useful for diagnostic
purposes or when a hub or switch is not available. However, it is not
recommended for extended use, as it violates the IEEE specification for 10 Mbit,
100 Mbit and 1000 Mbit Ethernet networks.
Note: Our GigMAC Models 5160, 5161 and 6160 support “auto-MDIX” mode
where a crossover cable is not required when directly attaching two controllers.
RJ-45 pinouts for CAT5 cables are shown below.
DSS NETWORKS, INC. Version: 1.12 Page: 9

GigMAC PMC and PCI Controller and Driver Users Manual
Note:Cables used for Gigabit networks must use all 8 wires. In 10 and 100
modes, wires are dedicated for transmit or receive while in Gigabit mode, data is
transmitted and received over all 4-pairs.
Pin 10/100 Gigabit
# Signal Signal
1 Transmit+ Channel A+
2 Transmit- Channel A-
3 Receive+ Channel B+
4 Unused Channel C+
5 Unused Channel C-
6 Receive- Channel B-
7 Unused Channel D+
8 Unused Channel D-
Connecting Fiber optic Model 7160
This section explains how to connect the GigMac fiber controller to the external
network using standard fiber optic cables. Typically 50 or 62.5 micron multimode
fiber optic cables with LC or SC type connectors are used depending on the
connector option (see section on distance for Model 7160 toward end of this
document in Specifications).
Insert the fiber optic cable into the SC or LC type connector until the self-locking
tab clicks into position. Connect the opposite end in to a 1000 Base SX switch.
Two types of cables are used when connecting the GigMac fiber controller to the
network. A workstation or "straight through" cable is typically used to connect
Ethernet adapters to switches. A crossover cable may also be used to connect
adapters to adapters. This configuration is useful for diagnostic purposes or
when a switch is not available.
3. SOFTWAREW DRIVER INSTALLATION
The following sections explain how to install the driver software in VxWorks,
Linux and Windows based systems.
3.1 VXWORKS DRIVER INSTALLATION
Please see the vxWorks OEM Developers Guide p/n 131901 for vxWorks
software installation and integration.
DSS NETWORKS, INC. Version: 1.12 Page: 10

GigMAC PMC and PCI Controller and Driver Users Manual
3.2 LINUX DRIVER INSTALLATION
These instructions presume that you are running Red Hat Linux 6.x, 7.x or a
similar Linux OS. You should be using at least a kernel version 2.2.12 Installation
for any other Red Hat-based system will be similar. For Debian-based systems,
the location of some files may be slightly different.
Installing the driver
To install the driver, copy the driver files to an appropriate directory. You will to
make sure your CD is mounted.
$ mkdir GigMac
$ cd GigMac
$ cp /mnt/cdrom/linux/* .
$ tar vxf dpm-1.12.tar # replace with name on CD
To create a new driver object module:
$ make clean
$ make
Note: If you are installing the GigMac in an SMP machine, you should comment
out the standard CFLAGS line in the “Makefile” and uncomment the SMP version
of CFLAGS before compiling the driver.
To install the driver object module in the file system, become root and run:
# make install
# depmod –a
# insmod dpm.o
Configure the card using your preferred configuration tool, or edit the initialization
script for the interface directly. On Red Hat, the file /etc/sysconfig/network-
scripts/
ifcfg-eth0 might look something like this:
DEVICE=eth0
BOOTPROTO=static
IPADDR=192.168.1.10
NETMASK=255.255.255.0
You should also add the following line to /etc/conf.modules similar to this:
alias eth0 dpm
to ensure that the kernel loads the appropriate module.
DSS NETWORKS, INC. Version: 1.12 Page: 11

GigMAC PMC and PCI Controller and Driver Users Manual
Tuning the Installation
To try jumbo frames, the mtu size can be increased using the ifconfig utility, as
follows:
# ifconfig <interface-name> mtu <mtu-size>
eg: ifconfig eth0 mtu 3000
The BUF_SIZE_MAX value in nsm.h (Tunable parameter) should be changed to:
4096 if you enable jumbo frames.
<mtu-size> can be increased up to 4000 bytes for sane operation.
Please see the installation notes for information on functionality testing and
known driver problems.
Using dmUtil dpm driver utility
Examples:
dmUtil -s eth1 # get driver statistics for interface 1
dmUtil –p eth1 # get phy (transceiver) registers for interface 1
dmUtil –m eth1 # get MAC (PCI controller) registers for interface 1
dmUtil –t eth1 # get execution debug trace for interface1 (trace option must
be compiled in)
3.3 WINDOWS DRIVER INSTALLATION
This chapter describes the installation of the GigMac in Windows 2000/98/ME
environment. Before attempting to install the software, make sure your system
settings match the system requirements listed in Chapter 1.
The Hardware Wizard in Windows 98, and the Found New Hardware Wizards of
Windows 2000 and Windows Me makes the installation processes of these
programs very similar. Before installing the GigMac driver, make sure the
hardware has been installed properly, and the adapter is connected to the
network with the appropriate network cables. For information on connecting
network cables to the GigMac Ethernet adapter, please see the "Connecting to
the GigMac" section presented earlier in this manual.
DSS NETWORKS, INC. Version: 1.12 Page: 12

GigMAC PMC and PCI Controller and Driver Users Manual
Step 1 - Once the hardware is installed, reconnect the power and network cables
and turn on the power to the computer.
The Hardware Wizard will detect the card. Click the Next> button to continue
Installation and proceed to Step 2 below. If the Wizard does not detect the card,
please goto to Control Panel->Add/Remove Hardware. Click Next> and select
Add/Troubleshoot Device. At this point the system may find your device or you
may have to select it manually from the list. Then select Update Driver.
Step 2 - The Hardware Wizard will search for new software for the hardware it
has detected. Click Next> to continue installation.
Step 3 - The Hardware Wizard will ask you what you wish to do. Click Next> to
accept the Recommended option and continue installation.
Step 4 - The Hardware Wizard will ask where you wish to search for drivers.
Click the "Specify a location" option. Insert the DSS Networks GigMac Gigabit
Ethernet Adapter CD. Click Browse and select the CD. Select the appropriate
Windows directory and Click Next to continue.
Step 5 - The Hardware Wizard will find the driver and list the path to the INF file.
Click Next to continue installation. If the Wizard indicates more than 1 possible
driver, please make sure you have selected the one from the installation CD.
Step 6 - The Hardware Wizard will ask you to configure Advanced Features for
your adapter. For most users, the default settings are sufficient. Click OK to
accept the default settings.
Step 7 - The Hardware Wizard may ask you to insert your Windows 98,
Windows 2000 or Windows Me CD and then click OK. One Windows 2000, this
step may not be necessary as all of the necessary files may be on your hard
disk. If needed, insert the Windows CD and Click OK. The Hardware Wizard may
copy files from the Windows CD.
Step 8 - The Hardware Wizard will finish installing the adapter software. Click
Finish to continue the installation.
Step 9 - The Hardware Wizard may will ask you to restart your computer. Click
Yes to reboot your computer and complete your installation. The installation of
your DSS Networks GigMac Gigabit Ethernet Adapter is now complete.
4. TESTING AND VERIFICATION
There are several ways to test your adapter on vxWorks, Linux and Windows
platforms. This section provides suggestions on how you may test and verify your
DSS NETWORKS, INC. Version: 1.12 Page: 13

GigMAC PMC and PCI Controller and Driver Users Manual
installation. Before you can proceed with any of the suggested tests, you must
have previously configured your TCP/IP protocols and interfaces on your
computer. Please refer to your online help and User Manuals for your particular
system on instructions on setting up your TCP/IP environment.
 ICMP Ping. Ping is a simple verification method and it very useful for
verification of cabling, adapter configuration and system configuration of the
TCP/IP protocol software. You can also specify a “fast ping” and larger
message sizes in order to more effectively test the protocols and adapter
interface.
 FTP File Transfer. FTP is also an available method for testing your
installation. FTP allows you to test by transferring files of different sizes.
Using large file transfers is a good way to test medium transfer rates thru the
protocol stack.
 HTTP Web Browsing. Is a good means of testing the protocols and interface
to the adapter.
 Telnet. Using Telnet you can log into another system and invoke commands
to send a receive data. You can also test multiple connections within a single
Window by repetitively Telnet’ing back and forth between multiple systems.
 Windows Explorer. In a Windows environment, you can also use the
Windows explorer to access files on other systems within your Workgroup or
Domain.
 Blaster / blaster can be used to perform TCP throughput tests between
VxWorks, Linux and Windows platforms. These test programs are included on
the OEM developer CD.
5. SPECIFICATIONS
Connector (Models 5160, 5161, 6160): Gigabit Ethernet (1000BaseT,
100BaseTX, 10BaseT): RJ-45 CAT5
Connector (Model 7160 Fiber): SC or LC connector type for 50 and 62.5 micron
multimode fiber.
Drivers:
 Microsoft Windows 2000 Professional
 Microsoft XP Embedded
 Linux 2.2, 2.4
 VxWorks 5.4
DSS NETWORKS, INC. Version: 1.12 Page: 14

GigMAC PMC and PCI Controller and Driver Users Manual
Status Indicators (models 5150, 5161 and 6160): 1000 Mbps Link, 100 Mbps
Link, 10 Mbps link, Full-Duplex, Transmit and Receive Activity
Status Indicators (model 7160 fiber): Signal Detect, Link, Transmit and
Receive
Bus Interface: PCI v2.2 bus master, 32/64-bit, 33/66 MHz
Dimensions: (PMC Models 5160, 5161, 7160):
5.866” X 2.913
Dimensions: (PCI models 6160, 6162):
6.6” X 2.535”
Voltage: 5V or 3.3V (factory optioned)
Performance Throughput (PCI 64/66): 1.8 Gbps (full-duplex) sustained
Performance Throughput (PCI 32/33): 110 MB (880 Mbps full or half duplex)
sustained
Maximum frame rate: 500,000 frames per second sustained
Burst Rate: Up to 256 dwords (1024 bytes) over PCI bus
Host Offloading: IPv.4 checksum (UDP, TCP and IP) and optional statistics
gathering for RFC 1213 (MIB II), RFC 1398 (Ether-like MIB), IEEE
802.3 LME
Optional: Jumbo packets, 802.3x full duplex flow control with
automatic pause and priority with multiple priority queues
Link Quality Monitor: Continuously adapts to actual line conditions
by managing echo and crosstalk cancellation,
equalization, timing and skew compensation.
Automatic Gain Control maximizes signal strength
Environmental Range:
Operating Temperature: 32º to 131ºF (0º to 55ºC)
Relative Humidity: 10% to 90%, non-condensing
Power: Model 5161 – 3.3W @3.3V
Model 7160 – 2.6W @3.3V
Model 6160 – 4W @ 3.3V
Voltage: 5 or 3.3 volts
DSS NETWORKS, INC. Version: 1.12 Page: 15

GigMAC PMC and PCI Controller and Driver Users Manual
Standards Compliance (as applicable for model):
 FCC Part 15, Class B
 EN 55022; 1998 Class B
 EN 50082-1
 Network: IEEE 802.3u Auto Negotiation and parallel detection
 IEEE 802.3ab Gigabit Ethernet over 4 pairs of UTP Category 5
(1000BaseT) Gigabit
 IEEE 802.3z Gigabit Ethernet over 1000 Base SX multimode fiber
 IEEE 802.1D and 802.1Q as applicable for VLAN priority queuing
 Ethernet Cable or EIA/TIA-568A Category 5E recommended.
 IEEE 802.3u Fast Ethernet over 2 pairs of UTP Category 5 (100BaseTX).
 IEEE 802.3 Ethernet over 2 pairs of UTP Category 3 (10BaseT).
 IEEE 1386 Draft 2.2 PMC Mezzanine Standard
Distance (Models 5160, 5161 and 6160 copper): Recommended maximum
distance is 328 feet (100 meters).
Full Duplex: Support for 10/100/1000 Mbps data rates on all copper models
(fiber models Gigabit mode only)
Virtual Network: Virtual LAN (VLAN) tag support
Distance (Model 7160, 850nm Multimode fiber)
1000BASE-SX (850 nm Laser)
Fiber Core
Diameter Type
Fiber
Bandwidth
Mhz* km
Distance
62.5 um multi-mode 160 Mhz * km 2 to 220 m
62.5 um multi-mode 200 Mhz * km 2 to 275 m
50.0 um multi-mode 400 Mhz * km 2 to 500 m
50.0 um multi-mode 500 Mhz * km 2 to 550 m
DSS NETWORKS, INC. Version: 1.12 Page: 16

GigMAC PMC and PCI Controller and Driver Users Manual
Technical Support and Warranty:
Telephone technical support (8AM to 6PM, MST), 24-hour support via web
1 year product warranty on controller hardware
Contacting Us
You may contact DSS Networks in one of several ways: via the Web, e-mail, fax
or telephone.
Technical Support
Send all technical support queries to [email protected] or visit the DSS
Networks website at www.dssnetworks.com. The DSS Networks website
contains technical as well as sales literature for all of our products.
Technical Support-Worldwide
+1.888.506.7651
Technical Support-Fax
+1.949.727.2498
Main Corporate Telephone Numbers
949-727-2490
DSS NETWORKS, INC. Version: 1.12 Page: 17
