Sonoff Lampini iFan03 User manual

User manual V1.2
iFan03
· FCC Warning------------ 43
· 中 文 -----------------------1-6
· Deutsch --------------- - 13-18
· Français----------------- 25-30
· Русский язык----------37-42
· English--------------------7-12
· Español---------------- -19-24
· Italiano---------------- 31-36
Wi-Fi Fan & Light Controller

SONOFF TECHNOLOGIES CO., LTD.
7
ON OF F
ON OF F
ON OF F
ON OF F
100-240V AC
N
L
N
LIGHT
FAN
English
Operating Instruction
1. Power off
To avoid electric shocks, please consult the dealer or a qualified professional for
help when installing and repairing!
2. Wiring instruction
Please install protection devices before connecting the live wire. (e.g. fuses or air
switches).
Make sure the neutral wire and live wire connection is correct.

SONOFF TECHNOLOGIES CO., LTD.
8
English
4.Power on
3. Download the eWeLink APP
eWeLink
eWeLink
Android™ & iOS
After powering on, the device will enter the quick pairing mode (Touch) during the
first use, then the fan makes two short beeps and one long beep.
If not paired within 3mins, the device will exit the quick pairing mode (Touch). If
you need enter again, long press the “pairing button” on the controller or
“Wi-Fi pairing button” on the RM433 remote controller and hold 5s until the fan
makes two short and one long “bi” sound and release.
5. Add the device
Tap “+” and select “Quick Pairing”, then operate following the prompt on the APP.
Sou nd P air in g
Add dev ice in th is mode i f your
devic e s uppor t this fe atur e.
Sca n QR c ode
GSM dev ices an d devic es with Q R co
de can be a dded in t his mod e.
Quick Pairing
WIF I devic es can be a dded in t his mo
de( make su re the de vice is i n pairi ng
mod e) .
Add D evice

SONOFF TECHNOLOGIES CO., LTD.
9
English
<RM433
Wi-Fi
iFan03
100-240V AC 50/60Hz 5A
IEEE 802.11 b/g/n 2.4GHz
PC V0
Android & iOS
-10℃~40℃
RF 433.92MHz
116x55x26mm
Pairing method for the device and SONOFF RM433
remote controller:
Please press any button within 5s after powering on again untilthe ceiling fan makes
a sound “di”, and pairing is successful.
The device can pair with up to 10 remote controllers and the 11th remote controller
data will cover the 1th.
Specifications
Model
Input
Output
Material
Dimension
Operating systems
Working temperature
Light: 100-240V AC 50/60Hz 3A
Tungsten lamp: 660W/220V Max
LED: 300W/220V Max
Fan: 100-240V AC 50/60Hz 2A Max

SONOFF TECHNOLOGIES CO., LTD.
10
English
Product Introduction
Pairing button
On/Off (light)
RF antenna
Wi-Fi antenna
Features
Remotely turn on/off the device, schedule it on/off or share it with your family to
control together.
Smart Scene Sync Status LAN Control
Remote Control Single/Countdown
Timing
Share Control Voice Control
433MHz Remote
Control
The device weight is less than 1 kg.
The installation height of less than 2 m is recommended.

SONOFF TECHNOLOGIES CO., LTD.
11
English
RM433
433.92MHz
PC V0
86x45x12.5mm
Switch Network
If you need to change the network, Long press the “pairing button” on the controller
or “Wi-Fi pairing button” on the RM433 remote controller and hold 5s until the fan
makes two short and one long “bi” sound and release., then the device enters quick
pairing mode and you can pair again.
Deleting the device on the eWeLink app indicates you restore it to factory setting.
Factory Reset
RM433 remote controller
Before operating the product, please press andpush down the back cover until it
removes, thenpress the battery and pull out the insulation sheet.
Model
RF
Remote controller size
Power supply
Material
12V removable battery (Model: 27A)

SONOFF TECHNOLOGIES CO., LTD.
12
English
In quick pairing mode, you can short press any button on the remote controller
to exit this mode.
Mute
Wi-Fi pairing(long press)
Medium speed
Low speed
On/Off (light)
High speed
Off (fan)
RF clearing(long press)
The iFan03 supports the remote controller with 433.92MHz frequency brand to turn
on/off, after pairing with one button, all buttons can control the connected device,
which is local short-range wireless control not Wi-Fi control.
Long press for 5s until the ceiling fan makes two sounds “di di” to clear the code
successfully.
Long press for 5s until the fan makes two short and one long "bi" sound to enter the
quick pairing mode (Touch). then you can add the light on eWeLink APP.
Wi-Fi pairing method:
RF clearing method:
Q: Why my device stays “Offline”?
A: The newly added device needs 1 - 2mins to connect Wi-Fi and network. If it stays
offline for a long time, Please judge the problem according to the following
methods:
Common Problems
① Maybe you have entered a wrong Wi-Fi password.
② Maybe there's too much distance between the switch your router or the
environment causes interference, consider getting close to the router. If failed,
please add it again.
③ The 5G Wi-Fi network is not supported and only supports the 2.4GHz wireless
network.
④ Maybe the MAC address filtering is open. Please turn it off.
⑤ Ensure steady enough network.
⑥ If none of the above methods solved the problem, you can open the mobile data
network on your phone to create a Wi-Fi hotspot, then add the device again.

FCC Radiation Exposure Statement:
FCC Warning
Changes or modifications not expressly approved by the party responsible for
compliance could avoid the user’s authority to operate the equipment.
Note:
— Reorient or relocate the receiving antenna.
— Increase the separation between the equipment and receiver.
— Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
— Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause
undesired operation.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum
distance20cm between the radiator & your body. This transmitter must not be
co-located or operating in conjunction with any other antenna or transmitter.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
43
SONOFF TECHNOLOGIES CO., LTD. FCC Warning

https://sonoff.tech/usermanuals
Hereby, Shenzhen Sonoff Technologies Co., Ltd. declares that the radio equipment
type iFan03 is in compliance with Directive 2014/53/EU.The full text of the EU
declaration of conformity is available at the following internet address:
Shenzhen Sonoff Technologies Co., Ltd.
MADE IN CHINA
1001, BLDG8, Lianhua Industrial Park, shenzhen, GD, China
ZIP code: 518000 Website: sonoff.tech
TX Frequency:
WiFi: 2412-2472MHz
RX Frequency:
WiFi: 2412-2472MHz SRD: 433.92MHz
Output Power:
14.35dBm(802.11b), 13.61dBm(802.11g), 13.37dBm(802.11n20)
