SOL8SDR-P Quick Start Guide
Revision 1.0
Page 1
No
Item
Connection
1
Lemo 4-way jack
Connect 12V power via CA0002 or CA3172.
2
RJ45 8-way jack
Connect to a PC or network Ethernet port.
3
SMA 50 ohm jack
RF-A COFDM antenna.
4
SMA 50 ohm jack
RF-B COFDM antenna.
5
DIN 1.0/2.3 jack
SDI-1 video input. Connect CA2396 DIN 1.0/2.3 to BNC adaptor.
6
DIN 1.0/2.3 jack
SDI-2 video input. Connect CA2396 DIN 1.0/2.3 to BNC adaptor.

SOL8SDR-P Quick Start Guide
Revision 1.0
Page 2
The SOL8SDR-P IP address can be established using DTC’s Node Finder application.
If DHCP settings need to be disabled and a fixed address applied, right click on the device to reconfigure.
Double click the device on Node Finder to open web browser communications.
On authentication, leave the Username blank and enter the Password as Eastwood.
Go to the Configuration>Preset>Encoder tab and set the Video Source and Format to match the attached
camera. Click Apply at the bottom of the page to save the settings.
Go to the Configuration>Preset>Modulator tab and make the settings for your system, highlighted below.
Click Apply at the bottom of the page to save the settings. These settings must be matched at the receiver.
