1Setup
Intended use
The DT-RDX is intended to create new sounds for your synthesizer, It is
possible to play your connected Synth over midi when the DT-RDX is
attached. However this is not recommended and can result in unreliable
data or ‘sticky notes’
What is included
Please ensure that your DT-RTX includes the following:
•DT-RTX Programmer (in the main box)
•Mini Din Male-Male MIDI Cable (in the second box)
•Dual Male to Female Y Power Cable (in the second box)
Installation
Installation of the programmer onto the REFACE is simple and requires no
tools.
Carefully align the 4 little pins of the DT-RTX with the holes under the
reface body and slot them together with gentle pressure.
Be advised: the programmer and controller are loosely connected and
can easily come apart.

DTRONICS
DT-RDX
MANUAL
Connection
Connect one end of the small MIDI cable to the REFACE port of the DT-
RTX. Connect the other end to the MIDI port of the REFACE.
Connect the midi-splitter cable that came with your reface to the MIDI port
of the DT-RDX
Now connect one male end of the Y POWER CABLE to the
REFACE power port and the other end to the DT-RDX power port.
Connect your REFACE power supply to the female end of the Y POWER
CABLE. Both units share the same power supply.

DTRONICS
DT-RDX
MANUAL
2Operation
Powering On & Off
When you power the REFACE on or off, the programmer will automatically
wake up or go to sleep. No action is required to turn the programmer on or
off.
Firmware Version
The right 8 LEDS indicate the firmware version on power
up. This image shows version 1.2
Memory
All switch settings are automatically stored in memory and recalled. As
long as the power supply is present.

DTRONICS
DT-RDX
MANUAL
3Common Section
The left part of the control panel is the common section. Each knob of the
common section affects the REFACE at any time.
Init Function
Press the INIT button to reset the REFACE to an empty patch.
A nice feature to design a sound from scratch!

DTRONICS
DT-RDX
MANUAL
4Operator Section
The right part of the control panel is the operator section. It behaves
differently to the common section in that parameter changes only apply to
the selected operators.
Operator Select
Use the 4 OP SEL (Operator Select) buttons to select any of the 4
operators. Up to 4 operators can be selected at the same time. Now all
knobs of the operator section will affect to the selected operators.
Operator On/Off
Press the OP ON/OFF buttons to turn any operator On or Off.

DTRONICS
DT-RDX
MANUAL
5Backlight
You can switch the orange glow on the back on or off. This setting is stored
into memory.
Make sure the DT-RDX is connected to the RefaceDX and the power is ON.
wait until the programmer and reface have both completely finished their
startup.
Now turn off the refaced with its power button.
Turning the light off: PRESS and HOLD the OP SEL 1 switch. Turn on the
refaced with the power button.
Turning the light on: PRESS and HOLD the OP ON/OFF 1 switch. Turn on
the refaced with the power button.
