DRIVENET 1664
2

TECHNICAL SPECIFICATIONS
DTS Product codes:
03.LA.198 DRIVENET 1664 Screw terminal outputs
Input voltage/frequency range: 180-240Vac 50-60Hz (Voltage not compatible in: USA, Canada,
Mexico, Venezuela, Colombia, Ecuador, Central America and Carribean area, Japan, Taiwan, Libia)
Output channels: 64 (4 channels x 16 groups)
Output current: 700mA max (per channel)
Ouput voltage: 48Vdc
Max power: 2200W
Max projectors distance: 50 m
Output connections: Screw terminal connectors
Mains connections: PowerCON male panel connector
DMX connections: XLR 5-pole and 3-pole panel connectors
Display: Touch-screen color display
Control: DMX 512 / RDM / Art-Net (optional)
DMX channels: 64 (default), 128 ch, 10 ch, 14 ch, 160 ch, 224 ch, 96 ch, 1 ch
IP protection degree: IP20
Operating temperature: -10° / 40°
Rack units: 3-rack units
Weight: 11.4 Kg
International certifications
CE certification
Accessories included
1 x PowerCON female cable connector (code 0520P014)
1 x XLR 5 pins male cable connector (code 0508B148)
1 x XLR 5 pins female cable connector (code 0508B147)
Accessories on request
Art-Net interface PCB (code 0514T027)
DTS Dongle Firmware Uploader (code 03.LA.206)
3 DRIVENET 1664

DIMENSIONS
4 DRIVENET 1664

IMPORTANT SAFETY INFORMATION
Fire prevention:
It is permissible to place the unit on normally flammable surfaces.
Suitable for mounting on normally flammable materials surfaces greater than 200°C with some
combustion time lag.
Replace any blown or damaged fuse only with one of identical value (15AT).
Prevention from electric shock:
High voltage is present inside the unit.
Unplug the unit prior to performing any operation which involves touching the inside of the unit.
This equipment must be grounded, do not connect to non-grounded supplies.
The use of a thermal magnetic circuit breaker is recommended for each DRIVENET 1664.
Use only AC supplies 180-240V 50-60Hz (Voltage not compatible in: USA, Canada, Mexico, Venezuela,
Colombia, Ecuador, Central America and Carribean area, Japan, Taiwan, Libia).
The unit should never be located in position exposed to rain or in areas of extreme humidity.
A good air ventilation is essential for proper equipment work.
Safety:
Never install the unit in an enclosed area lacking sufficient air flow.
The ambient temperature should not exceed 40°C and should not be lower than -10°C.
CONNECTIONS PANEL
5
MAINS IN
180-240Vac 50-60 Hz*
PowerCON male
panel connector
FUSE
15AT
Art-Net IN
RJ45 female
panel connector
(optional)
DMX IN / OUT
XLR 5-pole and 3-pole
panel connectors
16 LED OUTPUTS
8-pole screw terminal connectors
1234
5678
9 10 11 12
13 14 15 16
* Voltage not compatible in: USA, Canada, Mexico, Venezuela, Colombia, Ecuador, Central America and
Carribean area, Japan, Taiwan, Libia.
DRIVENET 1664

DMX SIGNAL CONNECTION:
The unit operates using a digital DMX 512 signal. Connection between the controller and the unit or
between units must be carried out using a two pair screened ø 0.5 mm cable and a CANNON XLR 5 pins
connector.
Ensure that the conductors do not touch each other. Do not connect the cable ground to the XLR
chassis. The plug housing must be isolated. Connect the mixer signal to the DMX IN of the Z8 plug and
connect it to the next unit by connecting the DMX OUT plug on the first Z8 to the DMX IN plug of the
second one.
This way, all the projectors are cascade connected.
P.S: If the display showing the DMX address flashes, then one of the following errors has occurred:
- DMX signal not present
- DMX reception problem
For Installations where long distance DMX cable connections are needed, we suggest to use a DMX
terminator.
The DMX terminator is a male XLR 3-5 pins connector with a 120 ohm resistor Between pin 2 and 3.
The DMX terminator must be plugged into the last unit (DMX out panel connector) of the DMX line.
1
2
3
5
4
OUT
120 ohm
PIN 3
PIN 2
PLACE A 120 OHM RESISTOR BETWEEN PIN 2
AND 3 OF A MALE XRL CONNECTOR AND PLUG IT
INTO THE DMX OUT PANEL CONNECTOR OF THE
LAST UNIT CONNECTED TO THE DMX LINE
6
Standard
DMX 512
controller
5
3
4 2
11=GND
2=DATA-
3=DATA+
OUT
IN
OUT
IN
OUT
DRIVENET 1664

DMX ADDRESS
DRIVENET 1664 can be used in 9 DMX modes: 64 ch (default), 128 ch, 10 ch, 14 ch, 160 ch,
224 ch, 96 ch or 1 ch mode.
If you want to use the DRIVENET 1664 in 64 channels mode, select the “ ” mode Full Type 8 bit 64ch
from the DMX MODE menu under DMX SETUP and set the following addresses on the mixer:
Projector 1 A001
Projector 2 A065 If you want to select the next projector, just add “64”
Projector 3 A129
….. A….
projector 6 A321
If you want to use the DRIVENET 1664 in 10 channels mode, select the “ 10ch” mode Z1 Type 8 bit
from the DMX MODE menu under DMX SETUP and set the following addresses on the mixer:
Projector 1 A001
Projector 2 A011 If you want to select the next projector, just add “10”
Projector 3 A021
….. A….
projector 6 A051
Selecting the DMX address
1) Press the UP-DOWN key until you reach the required DMX address. The numbers on the display will
start flashing (but the new DMX address hasn't yet been set).
2) Press ENTER to confirm your selection. The numbers on the display will stop flashing and the
projector is now controlled by the new DMX address.
TIPS: if you keep pushed the UP or DOWN keys, the channels are calculated more quickly and you get a
faster selection.
7 DRIVENET 1664

RDM FUNCTIONS
DRIVENET 1664 do accept the following RDM commands:
8 DRIVENET 1664
NOTE: Between Identify ON and Identify OFF packets, the DMX is Ignored.
When “INDEPENDENT UNIT ADDRESS” is eneabled on unit display, the RDM controller
do have access to DMX of the first output group.
FIRMWARE UPDATING
DRIVENET 1664To update the firmware release of the you need:
- DTS Dongle Firmware Uploader (code 03.LA.206).
- “DTS Firmware Upgrade Utility v.2.02” program installed on PC.
- Latest firmware release available for unit.DRIVENET 1664
Updating the firmware release.
Please follow the procedure below to perform the update:
1. Connect the DTS Dongle Firmware Uploader to a spare USB port on the PC.
2. Connect the unit DMX input to the DTS Dongle Firmware Uploader DMX output with a
standard DMX cable and turn ON the unit.
3. Send the new firmware release into the unit by using “DTS Firmware Upgrade
Utility v.2.02” program. At the end of the procedure, the unit will reset.
For more information please refer to an authorised DTS service centre.

MENU
DISPLAY
ENTER DOWN UP
MENU ENTER DOWN UP
A001
DISPLAY FUNCTIONS
ENTER DOWN
UP
MENU
DISPLAY FUNCTIONS
The DRIVENET 1664 24Vdc display panel shows all the available functions.
Using these functions, it is possible to change some of the parameters and add some functions.
Changing the DTS setting can vary the functions of the unit so that it does not respond to the DMX 512
signal used to control it.
Carefully follow the instructions below before carrying out any variations or selections.
NOTE: the symbol shows which key has to be pushed to obtain the desired function.
FIRMWARE RELEASE: 1.19
RDM Device Model ID: 0x0D21/2E
DMX Personality ID (default): 0x01 “FULL TYPE 8 BIT 64 ch”
9
TOUCH-SCREEN
COLOR DISPLAY
POSITION
AA
Menu
DISPLAY POSITION
Reverses display's reading depending on
the mounting position
(on the ground or suspended).
DISPLAY STANDBY
To turn off the display (after 30 seconds) or
Leave it always on.
Up-Down Display ENTER Up-Down DISPLAY POSITION
ON THE GROUND (Default)
SUSPENDED
DISPLAY STANDBY
OFF = Display standby disabled (default)
ON = Display goes off after 30 seconds
ENTER
ENTER
ARTNET 512CH
UNIVERSE #001
DRIVENET 1664

DMX Setup DMX MODE MAP
Full Type 8 bit 64ch = 64 DMX ch (default)
= RGBW 4 ch each output: 1-Red, 2-Green, 3-
Blue, 4-White.
Full Type 16 bit 128ch = 128 DMX ch mode
= RGBW 2 ch each colour; 8 ch each output:
1-Red 8 bit, 2-Red 16 bit, 3-Green 8 bit,
4-Green 16 bit, 5-Blue 8 bit, 6-Blue 16 bit,
7-White 8 bit, 8-White 16 bit
Z1 Type 8 bit 10ch = 10 DMX ch mode with all
the outputs automatically set on DMX starting
channel 1:
1=Shutter, 2=Dimmer, 3=Red, 4=Green,
5=Blue, 6=White, 7=White pre-programmed,
8=CTC, 9=Macro, 10=Function
Z1 Type 16 bit 14ch = 14 DMX ch mode with
Dimmer and RGBW channels with 16 bit control
and all outputs automatically set on DMX
starting address 1:
1=Shutter, 2=Dimmer, 3=Red 8 bit, 4=Red 16
bit,5=Green 8 bit, 6=Green 16 bit, 7=Blue 8 bit,
8=Blue 16 bit, 9=White 8 bit, 10=White 16 bit,
11=White pre-programmed, 12=CTC, 13=Macro,
14=Function
Z1 Full 8 bit 160 ch = (10x16) 160 DMX ch
mode same as Z1 Type 8 bit 10ch but each
output with independent DMX control:
Output 1=DMX 1, Output 2= DMX 11, Output
3= DMX 21 ...
Z1 Full 16 bit 224ch = (14x16) 224 DMX ch
mode same as Z1 Type 16 bit 14ch but each
output with independent DMX control:
Output 1 = DMX 1, Output 2 = DMX 15,
Output 3 = DMX 29...
Z1 Short Full 8 bit 96ch = (6x16) 96 DMX ch
mode with Dimmer, Shutter and RGBW 8 bit
channels and each output with independent DMX
control
Output 1 = DMX 1, Output 2 = DMX 7,
Output 3 = DMX 13...
Z1 Short Full 16 bit 160ch = (10x16) 160
DMX ch mode with RGBW 16 bit each colour and
each output with independent DMX control
Output 1 = DMX 1, Output 2 = DMX 11,
Output 3 = DMX 21...
1-Dimmer, 2-Shutter, 3-Red 8 bit, 4-Red
16 bit, 5-Green 8 bit, 6-Green 16 bit,
7-Blue 8 bit, 8-Blue 16 bit, 9-White 8 bit,
10-White 16 bit
1ch Full Mode = 1 DMX channel
Menu Up-Down ENTER Up-Down ENTER
DMX MODE
To select DMX mode:
Full Type 8 bit 64 ch
Full Type 16 bit 128 ch
Z1 Type 8 bit 10 ch
Z1 Type 16 bit 14 ch (for Chase and Cue
recording).
Z1 Full 8 bit 10x16 = 160 ch
Z1 Full 16 bit 14x16 = 224 ch
Z1 Short Full 8 bit 6x16 = 96 ch
Z1 Short Full 16 bit 10x16 = 160 ch
1 ch Full Mode = 1 ch
INDEPENDENT UNIT ADDRESS
Allows independent DMX patch each
group for the following DMX modes:
Full Type 8 bit 64 ch
Full Type 16 bit 128 ch
Z1 Full 8 bit 10x16 = 160 ch
Z1 Short Full 8 bit 6x16 = 96 ch
Z1 Short Full 16 bit 10x16 = 160 ch
Default = OFF
MACRO
Standard = default
Extended = enable rainbow effects on
MACRO channel
10
MENU
DMX SETUP
ENTER DOWN UP
DMX MODE
Full Type 8 bit 64ch
MENU
DMX SETUP
ENTER DOWN UP
MACRO
STANDARD
MENU
DMX SETUP
ENTER DOWN UP
INDEPENDENT UNIT ADDRS
OFF
DRIVENET 1664
