DTS DTS170 User manual

QuickStart |
Set-up
•Unpack and check all parts
•Position and fasten the ballast weights
•Insert and fasten the handle
•Connect the power and control cables
Controls
•Push the thumb buttons forward for forward drive
•Push the thumb buttons backwards for reverse drive
•Adjust the drive speed with the speed control switch
•Stop the machine with the emergency stop
•Start and stop the stripping mechanism using the
switch on the main control box.
12
Blade installation
•Loosen the bolts
•Lift the blade fastener
•Insert the blade, aligning the slots
•Fasten each bolt
•V-blade –cuts and lifts the surfaces in strips,
suitable for vinyl and carpet
•U-blade –cuts the surface into strips,
suitable for vinyl
•Flat blade –universal blade, suitable for all surfaces
•Flat blade with bend –blade for tough situations,
only suitable for hard underfloor surfaces
Always remove the blade prior to transport
DTS170
3
Maintenance
•Lubricate all 3 bearings in the
stripping mechanism
•Remove any debris from within
the stripping mechanism
•Remove any debris from in
between the ballast weights
•Hand clean with a damp cloth,
do not use a water hose or
steam cleaner
•Replace the wheels as required
to ensure good traction
Safety first
•Always wear your PPE
•Check the area for hazards before working
•Inspect and replace any damaged parts
•Do not touch any moving parts
•Remove the blade during transport
Quick tips
•Work efficiently, create long strips
•Reduce tyre wear by preventing wheelspin
•Use the correct type of blade
•Use the free wheels for quick manoeuvering
•Regularly remove any debris from the stripping
mechanism and around the motors
•In case of drive motor failure, remove extension
cable and use a different power source
4
Dehaco B.V. • Kruisbaak 25 • 2165 AJ Lisserbroek (NL) • T [phone] • [e-mail] • www.dehaco.nl

Set-up
•Unpack and check all parts
•Position and hook from the transporter
brackets in the carry handle from the
rear ballast
•Fasten the transporter bracket
Using the transporter
•Position the transporter behind the DTS170 floor stripper
•Rotate the transporter forward and hook it over the brackets
mounted onto the ballast
•Pull on the transporter handle and push DTS170 handle forward to
lift it onto the transporter wheels
•Rotate the transporter and DTS170 until it is in balance on the
wheels. The floor stripper is now ready for transport.
QuickStart | DTS170 Transporter
