Dual MWR15 Operating instructions

Marine Wired Remote Control
MWR15
IPX6 Waterproof UV Resistant Salt Resistant
INSTALLATION / OWNER'S MANUAL

Dimension
Control Locations
6
5
Ø50mm(2")
Ø61mm(2.4")
31.6mm
(1.2")
29.6mm(1.2") 250mm(9.8")
250mm(9.8")
4
1. Volume up: To adjust volume up
2. Mute: To silence the audio
3. Tune/Track up: To move radio frequency
up in tuner mode or track in CD, USB
mode etc. that the receiver supports
4. Band: To select band, FM, AM, or
weather band if device is supported
5. Tune/Track down: To move radio frequency
down in tuner mode or track in CD, USB
mode etc. that the receiver supports
6. Mode: To select one of the modes available
7. Volume down: To adjust volume down
NOTE: Remote operation can be subject to the functions on the radio being
controlled.
2
7
2
3
1
16mm(0.6")

Wiring
3
Extension Cable(1M)
Accessories Included
HEAD UNIT(not included)
Once the remote has been mounted, connect the extension cable to the remote
and head unit as shown in the diagram above. When routing the extension cable.
be sure to avoid sharp objects, tight corners, and places where it might get
pinched as this could affect performance and cause damage to the unit.
Extension Cable(included 1M)
3.5mm jack connects directly into SWC
(Steering Wheel Control) input of any receiver
Nuts(x6)
Plain Washer(x2)
Spring Washer(x2)
Stainless mounting bracket(x1) Rubber gasket(x1)
Bolts(x2)

Installation
Before You Start
* To test remote connection.
With the receiver turned off, plug the cable in to both the receiver and the
remote control. Turn on the receiver and test the functions of the remote control.
* Choose and prepare location.
MWR15 is designed to be mounted in a 2"(50mm) gauge cutout.
Mounting depth will vary, but at least 2.5" is needed to mount the remote control.
NOTE: Be sure to check behind the panel for wiring harnesses, steering cables,
hydraulic lines, fuel lines, gas tanks, etc. Also make sure you can get behind
the dash panel, bulkhead, etc. to to be able to attach the mounting bracket.
Do not mount the unit where it will be submerged.
4

Standard Gauge Cutout Mounting
Attach rubber gasket to the back of remote housing and insert into gauge hole
opening.
5
Fasten to the stainless mounting bracket with the included hardware.
2.0”

One-Year Limited Warranty
6

Surface Mounting Template
7
Scale: 100%

Dual Electronics Corp.
Toll Free: 1-866-382-5476
Monday-Friday, 9AM-5PM, EST
www.dualav.com
©2015 Dual Electronics Corp.
NSC-1115-V01
Details and specifications mentioned in this document may be updated
and subject to change without notice. To access the latest document,
please check the product website.
UV resistant ASTM D4329-057.2.2
Salt resistant ASTM B117-2011
IPX6 IEC 60529:2001
