Ducati MONSTER 696 User manual

Table of contents
Introduction 6
Safety guidelines 6
Warning symbols used in the manual 7
Intended use 8
Rider's obligations 8
Rider's training 10
Apparel 10
Safety “Best Practices” 11
Refuelling 13
Carrying the maximum load allowed 14
Dangerous products - warnings 15
Vehicle identification number 17
Engine identification number 18
Instrument panel (Dashboard) 19
Instrument panel 19
LCD - Main functions 23
LCD - How to set/display parameters 25
“Odometer” total mileage indicator 29
“Speed” indicator 30
“TRIP” mileage indicator 31
“TRIP FUEL” mileage on reserve indicator 32
Clock indicator 33
Air temperature indicator 34
Engine oil temperature indicator 35
Service indicator 38
Battery voltage indicator (BATT) 39
Engine idling setting (RPM) 41
Back-lighting setting 42
Lap timer display (LAP) 44
Saved data display (LAP Memory) 46
DDA data logger 48
Erase DDA 50
ABS disabling 52
Clock setup 53
Instrument panel diagnostics 55
Headlight “smart” switch-off 61
Headlight “smart” switch-on 61
The Immobilizer system 62
Keys 63
Code card 64
Immobilizer override procedure 65
3

Operation 68
Duplicate keys 69
Controls 72
Position of motorcycle controls 72
Key-operated ignition switch and steering lock 73
Left-hand switch 74
Clutch lever 75
Cold start lever 76
Right-hand switch 77
Throttle twistgrip 78
Front brake lever 79
Rear brake pedal 80
Gear change pedal 81
Adjusting the position of the gearchange and rear
brake pedals 82
Position on the vehicle 84
Tank filler plug 85
Seat lock 86
Helmet holder cable 87
Side stand 88
Rear shock absorber adjusters 90
Riding the motorcycle 92
Running-in recommendations 92
Pre-ride checks 94
Starting the engine 96
Moving off 99
Braking 100
Stopping the motorcycle 102
Refuelling 103
Parking 104
Tool kit and accessories 105
Main maintenance operations 106
Changing the air filter 106
Checking brake and clutch fluid level 106
Checking brake pads for wear 108
Lubricating joints 109
Adjusting the throttle cable 110
Charging and maintenance of the battery during
winter storage 111
Removing the battery 113
Refitting the battery 121
Checking drive chain tension 132
Chain lubrication 134
Replacing the bulbs 135
Beam setting 136
4
Main components and devices 84

Tyres 138
Check engine oil level 141
Cleaning and replacing the spark plugs 143
Cleaning the motorcycle 145
Storing the motorcycle 147
Important notes 147
Maintenance 148
Scheduled maintenance chart: operations to be
performed by the Dealer 148
Scheduled maintenance chart: operations to be
performed by the customer 151
Technical data 152
Weights 152
Overall dimensions (mm) 153
Engine 156
Timing system 156
Performance data 157
Spark plugs 157
Fuel system 157
Brakes 158
Transmission 159
Frame 160
Wheels 160
Tyres 160
Suspensions 160
Exhaust system 160
Available colours 161
Electrical system 162
Routine maintenance record 168
Routine maintenance record 168
5

Introduction
Safety guidelines
We would like to welcome you among Ducati
enthusiasts, and congratulate you on your excellent
choice of motorcycle. We think you will ride your
Ducati motorcycle for long journeys as well as short
daily trips. Ducati Motor Holding S.p.A. wishes you
smooth and enjoyable riding.
Your motorcycle is the result of Ducati Motor Holding
S.p.A.'s on-going research and development efforts.
It is important that you preserve its quality standard
by strictly observing the maintenance plan and using
genuine spare parts. This manual provides
instructions on minor maintenance operations. Major
maintenance operations are described in the Service
Manual available to Ducati Authorised Service
Centres.
In your own interest, for your safety and in order to
guarantee product reliability, you are strongly advised
to refer to our authorised Dealers and Service Centres
for any operations listed in the scheduled
maintenance chart, see page 148.
Our highly skilled staff have access to special
implements and appropriate equipment required to
perform any servicing job at best, and use Ducati
original spare parts only as the best guarantee for full
interchangeability, smooth running and long life.
All Ducati motorcycles come with a Warranty
Booklet.
The warranty does not apply to motorcycles used in
racing competitions.
Tampering with or altering any components, even
partially, will make the warranty null and void
effective immediately. Improper or poor
maintenance, using other than original spare parts or
parts not expressly approved by Ducati may invalidate
your warranty rights and lead to damage or loss of
performance.
6

Your safety and that of other road users are very
important. Ducati Motor Holding S.p.A. recommends
that you ride responsibly.
Before using your motorcycle for the first time, read
this entire manual carefully and closely follow the
guidelines outlined in it. The manual provides full
information on proper motorcycle operation and
maintenance. In case of any doubts, please call a
Dealer or Authorised Service Centre.
Warning symbols used in the manual
To alert you to potential hazards that could potentially
harm you or other persons, the following safety alerts
have been used:
- Safety labels on motorcycle;
-Safety messages preceded by a warning symbol
and the word WARNING or IMPORTANT.
Warning
Failure to comply with these instructions may
put you at risk and result in severe injury to rider or
other persons or even death.
Important
Possibility of damaging the motorcycle and/or
its components.
Note
Additional information concerning the job being
carried out.
The terms RIGHT and LEFT refer to the motorcycle
viewed from the riding position.
7

Intended use
This motorcycle must be used only on asphalted
roads or on level, regular pavement.
This motorcycle may not be used for riding on dirt
trails or for off-road riding.
Warning
Off-road riding may lead to loss of control,
resulting in severe damage to vehicle, injury or death.
Warning
This motorcycle may not be used to tow any
trailers or with a side-car attached; this can lead to
loss of control and result in an accident.
This motorcycle carries the rider and can carry a
passenger.
Warning
The total weight of the motorcycle in running
order including rider, passenger, luggage and
additional accessories should not exceed 390 kg/859
lb.
Rider's obligations
All riders must hold a valid licence.
Warning
Riding without a licence is illegal and is
prosecuted by law. Always make sure you have your
licence with you when riding. Do not let
inexperienced riders or who do not hold a valid
licence use your motorcycle.
Do not ride under the influence of alcohol and/or
drugs.
Warning
Riding under the influence of alcohol and/or
drugs is illegal and is prosecuted by law.
Do not take prescription or other drugs before riding
unless you have consulted your doctor about their
side effects.
8

Warning
Some medications and drugs may cause
drowsiness or other effects that slow down reaction
time and the rider's ability to control the motorcycle,
possibly leading to an accident.
Some states require vehicle insurance.
Warning
Check your state laws. Obtain insurance
coverage and keep your insurance document secure
with the other motorcycle documents.
To protect rider and passenger safety, some states
mandate the use of a certified helmet.
Warning
Check your state laws. Riding without a helmet
may be punishable by law.
Warning
Riders without helmets are more likely to suffer
severe bodily injury or die if they are in an accident.
Warning
Check that your helmet complies with safety
specifications, permits good vision, is the right size
for your head, and carries a certification label
indicating that it conforms to the standards in force in
your state. Traffic laws differ from state to state.
Learn about traffic laws in your state before riding and
always obey them.
9

Rider's training
Accidents are frequently due to inexperience. Driving
a motorcycle is different from driving other vehicles
and requires specific riding and braking techniques.
Warning
Poor training or improper operation of the
vehicle can lead to loss of control, death or severe
damage.
Apparel
Riding gear is very important for safety. Unlike cars,
a motorcycle offers no impact protection in an
accident.
Proper riding gear includes helmet, eye protection,
gloves, boots, long sleeve jacket and long pants.
-The helmet must have the requirements listed in
page 8; if your helmet does not have a visor, use
suitable eye wear;
- Use five-finger gloves made from leather or
abrasion-resistant material;
- Riding boots or shoes must have non-slip soles
and offer ankle protection;
- Jacket, pants or riding suit must be made from
leather or abrasion-resistant material and have
high-visibility colours and inserts;.
Important
Never wear loose clothing, items or accessories
that may become tangled in motorcycle parts.
Important
For your safety, always wear proper protective
gear, regardless of season and weather.
Important
Have your passenger wear proper protective
clothing.
10

Safety “Best Practices”
These few simple operations are critical to people
safety and to preserving the full performance of your
motorcycle. Never forget to perform them before,
while and after riding.
Important
During the whole running-in period, the
indications recommended in section "Riding the
Motorcycle" shall be observed carefully.
Failure to follow these instructions releases Ducati
Motor Holding S.p.A. from any liability whatsoever for
any engine damage or shorter engine life.
Warning
Before riding your motorcycle, become familiar
with the controls you will need to use when riding.
Perform the checks recommended in this manual
before each ride (see page 11).
Warning
Failure to carry out these checks before riding,
may lead to motorcycle damage and injury to rider
and/or passenger.
Warning
Start the engine outdoors or in a well ventilated
area. The engine should never be started or run
indoors.
Exhaust gases are poisonous and may lead to loss of
consciousness or even death within a short time.
Use proper body position while riding and ensure your
passenger does the same.
Important
Rider must hold the handlebars with both hands
AT ALL TIMES while riding.
Important
Both rider and passenger should keep their feet
on the footpegs when the motorcycle is in motion.
Important
The passenger should always hold on to the
grabhandles under the seat with both hands.
11

Important
Be very careful when tackling road junctions, or
when riding in the areas near exits from private
grounds, car parks or on slip roads to access
motorways.
Important
Be sure you are clearly visible and do not ride
within the blind spot of vehicles ahead.
Important
ALWAYS signal your intention to turn or pull to
the next lane in good time using the suitable turn
indicators.
Important
Park your motorcycle where no one is likely to
hit it and use the side stand. Never park on uneven or
soft ground or your motorcycle may fall over.
Important
Visually inspect the tyres at regular intervals for
cracks and cuts, especially on the side walls, and
bulges or large stains that indicate internal damage;
Replace them if badly damaged.
Remove any stones or other foreign bodies caught in
the tread.
Warning
The engine, exhaust pipes, and silencers stay
hot for a long time after the engine is stopped; take
special care not to touch the exhaust system with any
part of your body and do not park the motorcycle next
to inflammable material (wood, leaves, etc.).
Warning
Always remove the key when you leave your
motorcycle unattended and make sure it is not
accessible to persons not authorised to use the
motorcycle.
12

Refuelling
Refuel outdoors with the engine turned off.
Do not smoke or use open flames when refuelling.
Be extremely careful not to spill fuel on the engine or
on the exhaust pipe.
Never fill the tank completely. Fuel should never be
touching the rim of filler recess.
While refuelling, avoid inhaling fuel vapours and avoid
contact with eyes, skin or clothing.
Warning
The vehicle is only compatible with fuel having
a maximum content of ethanol of 10% (E10).
Using fuel with ethanol content over 10% is
forbidden. Using it could result in severe damage of
the engine and motorcycle components. Using fuel
with ethanol content over 10% will make the
warranty null and void.
Warning
In the event of illness after prolonged breathing
of fuel vapours, stay outdoors and seek medical
advice. In the event of contact with eyes, flush with
plenty of water. After contact with skin, wash
immediately with water and soap.
Warning
Fuel is highly inflammable. Clothing with spilled
fuel on it should be removed as possible.
13

Carrying the maximum load allowed
Your motorcycle is designed for long-distance riding,
carrying the maximum load allowed in full safety.
Even weight distribution is critical to preserving these
safety features and avoiding trouble when
performing sudden manoeuvres or riding on bumpy
roads.
Warning
Do not exceed the total permitted weight for the
motorcycle and pay attention to information provided
below regarding load capacity.
Information about carrying capacity
Important
Arrange your luggage or heavy accessories in
the lowest possible position and close to motorcycle
centre.
Important
Never fix bulky or heavy objects to the
handlebar or to the front mudguard as this would
affect stability and cause danger.
Important
Secure the luggage firmly to the motorcycle
structure Luggage incorrectly secured may cause the
motorcycle to become unstable.
Important
Do not insert any objects you may need to carry
into the gaps of the frame as these may foul moving
parts.
Warning
Make sure the tyres are inflated to the proper
pressure and that they are in good condition.
Please, refer to paragraph "Tyres" in page 138.
14

Dangerous products - warnings
Used engine oil
Warning
Prolonged or repeated contact with used engine
oil may cause skin cancer. If exposed to used engine
oil on a daily basis, make it a rule to wash your hands
thoroughly with soap immediately after use. Keep
away from children.
Brake lining debris
Never attempt to clean the brake assembly using
compressed air or a dry brush.
Brake fluid
Warning
Avoid spilling brake fluid onto plastic, rubber or
painted parts of the motorcycle to avoid the risk of
damage. Protect these parts with a clean shop cloth
before proceeding to service the motorcycle. Keep
away from children.
Warning
The brake fluid used in the brake system is
corrosive. In the event of accidental contact with eyes
or skin, wash the affected area with abundant running
water.
Coolant
Engine coolant contains ethylene glycol, which may
ignite under particular conditions, producing invisible
flames. Although the flames from burning ethylene
glycol are not visible, they are still capable of causing
severe burns.
Warning
Take care not to spill engine coolant on the
exhaust system or engine parts. These parts may be
hot and ignite the coolant, which will subsequently
burn with invisible flames. Coolant (ethylene glycol)
is an irritant and is poisonous when ingested. Keep
away from children. Never remove the radiator cap
when the engine is hot. The coolant will be scalding
hot and is under high pressure.
15

The cooling fan operates automatically: keep hands
well clear and make sure your clothing does not snag
on the fan.
Battery
Warning
The battery produces explosive gases; keep it
away from any source of ignition such as sparks,
flames and cigarettes. Charge the battery in a well-
ventilated area.
16

Vehicle identification number
Note
These numbers identify the motorcycle model
and should always be indicated when ordering spare
parts.
It is recommended to record the frame number of
your motorcycle in the space below.
Frame number
Fig. 1
17

Engine identification number
Note
These numbers identify the motorcycle model
and should always be indicated when ordering spare
parts.
It is recommended to record the number of your
motorcycle's engine in the space below.
Frame number
Fig. 2
18

Instrument panel (Dashboard)
Instrument panel
1) LCD.
2) REV COUNTER (rpm).
Shows the engine rotation speed/minute (rpm).
3) NEUTRAL LIGHT N (GREEN).
Comes on when in neutral position.
4) LOW FUEL LIGHT (AMBER YELLOW).
Comes on when fuel is low and there are about 3.5
litres of fuel left in the tank.
5) TURN INDICATOR LIGHTS (GREEN).
Illuminates and flashes when the turn indicator is in
operation.
If a turn signal does not work (ex. burnt out bulb) its
incorrect operation is signalled by making the light
flash twice as fast as in comparison to correct
operation.
5
2 4
3 1 6 7
10 9
8
Fig. 3
Important
If this light (6) stays on, stop the engine or it may
suffer severe damage.
6) ENGINE OIL PRESSURE LIGHT (RED).
Comes on when engine oil pressure is too low. This
light should come on when the ignition is switched to
ON and normally goes out a few seconds after engine
starts.
It may shortly come on when the engine is hot,
however, it should go out as the engine revs up.
19

7) HIGH BEAM LIGHT (BLUE) (Fig. 3).
Comes on when high beam is on.
8) "VEHICLE/ENGINE DIAGNOSIS - EOBD" LIGHT
(AMBER YELLOW) (Fig. 3).
It turns on in the case of an engine or motorcycle
error; in some cases the engine will be locked.
9) OVER REV LIMITER WARNING LIGHTS(Fig. 3).
It comes on steady when the first rev limiter
threshold (*) is reached. Starts flashing when the rev
limiter is reached.
20

10) ABS WARNING LIGHT (AMBER YELLOW) (for
ABS version only) (Fig. 3).
Engine off / speed below 5 Km/h
Light off Light flashing Light steady
- ABS disabled
with the menu
function “DISAB
ABS” (**)
ABS enabled but
not functioning
yet
Engine on / speed below 5 Km/h
Light off Light flashing Light steady
- ABS disabled
with the menu
function “DISAB
ABS”
ABS enabled but
not functioning
yet
Engine on / speed above 5 Km/h
Light off Light flashing Light steady
ABS enabled and
functioning
ABS disabled
with the menu
function “DISAB
ABS”
ABS disabled
and not function-
ing due to a prob-
lem
(*) depending on the model, each calibration of the
Engine Control Unit may have a different "setting" for
the thresholds that precede the rev limiter and
regarding the rev limiter itself.
(**) The ABS should be considered actually disabled
only if the light continues to flash after starting the
engine.
21
