Ducati Multistrada 950S 2019 User manual

Owner’s manual

Owner’s manual ENGLISH
1

This manual forms an integral  of the motorcycle and must be kept with it for its whole service life.
If the motorcycle is resold, the manual must always be handed over to the new owner.
This manual must be preserved with care. If it is lost or becomes damaged, contact a Ducati Dealer or
authorised Service Centre without delay to obtain a new copy of the manual.
The quality standards and safety of Ducati motorcycles are steadily improved as new design solutions,
equipment and accessories are developed. While the information contained in this manual is current at the
time of going to print, Ducati Motor Holding S.p.A. reserves the right to make changes at any time without
notice and without any obligations. For this reason, the illustrations in this manual might  from your
motorcycle.
Any and all reproduction or spreading of the contents herein in whole or in  is forbidden. All rights
reserved to Ducati Motor Holding S.p.A. Any request for  authorisation shall be addressed to this
company, specifying the reasons for request.
Enjoy your ride!
2

Table of contents
Introduction 8
Safety guidelines 8
Warning symbols used in the manual 9
Intended use 10
Rider's obligations 12
Rider's training 13
Apparel 14
Safety "Best Practices" 15
Refuelling 17
Carrying the maximum load allowed 18
Information about carrying capacity 18
Dangerous products - warnings 19
Vehicle identification number 21
Engine identification number 22
Option kits / Customisations 23
Instrument panel (Dashboard) 32
Instrument panel 32
Acronyms and abbreviations used in the
Manual 36
Technological Dictionary 36
Information statement on UE directive
2014/53/UE 39
Function  42
Parameter  44
Main and auxiliary functions 56
Engine rpm indication (RPM) 58
Motorcycle speed 60
Fuel level 61
Engine Coolant temperature 62
Clock 63
Riding Mode 64
ABS 70
DTC 77
DQS 83
Motorcycle setup 85
DSS 88
Gear 93
Odometer (TOT) 94
Menu Functions 95
Residual range (RANGE) 97
3

Average Fuel Consumption (CONS. AVG
1) 98
Trip meter 1 (TRIP 1) 100
Trip time (TRIP TIME 1) 101
Average speed (SPEED AVG 1) 102
Trip meter 2 (TRIP 2) 104
Instantaneous fuel consumption
(CONS.) 105
Ambient air temperature (T-AIR) 106
TRIP MASTER 107
Player management (PLAYER) 109
Call management (LAST CALLS) 110
Tyre deflation pressure indication (TIRE
PRESSURE) - accessory 111
ABS enabling/disabling 113
 menu (SETTING MENU) 115
Customising the Riding Mode 118
Customising the Riding Mode: Engine
 121
Customising the Riding Mode: DTC level
 123
Customising the Riding Mode: ABS
 126
Customising the Riding Mode: DQS enabling/
disabling 129
Customising the Riding Mode: DSS
suspension  132
Customising the Riding Mode: Motorcycle
Load Mode 136
Customising the Riding Mode: Reset to
default  (DEFAULT) 140
Customising the Riding Mode: Reset to
default  (ALL DEFAULT) 142
Display mode  (Info Mode) 143
Pin Code 145
Changing the PIN CODE 150
LAP 156
Backlighting  (Backlight) 162
Date  (Date and Clock) 164
Clock  (Date and Clock) 167
Unit of measurement  (Units) 170
Service thresholds display (Service) 175
Tyre  and drive ratio (Tyre
Calibration) 176
 motorcycle Load Mode 180
Bluetooth device  (Bluetooth) 182
 the tyre sensor reference deflation
pressure (Tyre Pressures) - accessory 191
Turn indicator automatic  feature
(Turn indicators  195
Information (Info) 197
4

Infotainment 199
LAP time 209
Cruise Control 212
Vehicle Hold Control (VHC) 214
Service indication (SERVICE) 215
OIL SERVICE zero warning 216
OIL SERVICE or SERVICE DATE or DESMO
SERVICE indication 217
OIL SERVICE or SERVICE DATE or DESMO
SERVICE countdown indication 218
Warnings/Alarms 219
Error warnings 235
Heated handgrips 236
Side stand warning 238
Light control 239
Fog lights 247
Immobilizer system 248
Keys 249
Replacing the  in the active key 252
Duplicate keys 256
Restoring motorcycle operation via the PIN
CODE 257
Controls 259
Position of motorcycle controls 259
"Hands free" system 260
 switch 274
Clutch lever 278
Right-hand switch 279
 twistgrip 281
Front brake lever 282
Rear brake pedal 283
Gear change pedal 284
Adjusting the position of the gearchange
pedal and rear brake pedal 285
Main components and devices 287
Position on the vehicle 287
Tank filler plug 288
Seat lock 290
Seat height adjustment 293
Side stand 296
Bluetooth control unit 298
Power outlet 300
Centre stand 302
Assembling the Ducati side panniers 303
Using the side panniers 308
USB connection 312
Adjusting windscreen height 313
Adjusting the front fork 314
5

Adjusting the rear shock absorber 315
Motorcycle track alignment variation 316
Riding the motorcycle 317
Running-in recommendations 317
Pre-ride checks 319
ABS device 321
Engine  322
Moving  327
Braking 328
Stopping the motorcycle 330
Parking 331
Refuelling 332
Tool kit and accessories 334
Main use and maintenance
operations 335
Checking coolant level and topping up, if
necessary 335
Checking brake and clutch fluid level 337
Checking brake pads for wear 339
Charging the  340
Checking drive chain tension 344
Lubricating the drive chain 346
Number plate light 351
Aligning the headlight 352
Adjusting the rear-view mirrors 354
Tubeless tyres 355
Check engine oil level 358
Cleaning and replacing the spark plugs 360
Cleaning the motorcycle 361
Storing the motorcycle 363
 notes 363
Scheduled maintenance  364
Scheduled maintenance  operations to
be carried out by the dealer 364
Scheduled maintenance  operations to
be carried out by the Customer 368
Technical data 369
Weights 369
Dimensions 371
Fuel, lubricants and other fluids 373
Engine 375
Timing system 376
 data 377
Spark plugs 377
6

Fuel system 377
Brakes 377
Transmission 378
Frame 379
Wheels 379
Tyres 379
Suspension 380
Exhaust system 380
Available colours 380
Electric system 382
Routine maintenance record 388
Routine maintenance record 388
7

Introduction
Safety guidelines
We would like to welcome you among Ducati
enthusiasts, and congratulate you on your excellent
choice of motorcycle. We think you will ride your
Ducati motorcycle for long journeys as well as 
daily trips. Ducati Motor Holding S.p.A. wishes you
smooth and enjoyable riding.
Your motorcycle is the result of Ducati Motor
Holding S.p.A.'s on-going research and
development  It is  that you
preserve its quality standard by strictly observing
the maintenance plan and using genuine spare
 This manual provides instructions on minor
maintenance operations. Major maintenance
operations are described in the Workshop Manual
available to Ducati Authorised Service Centres.
In your own interest, for your safety and in order to
guarantee product reliability, you are strongly
advised to refer to our authorised Dealers and
Service Centres for any operations listed in the
scheduled maintenance  see page 0 .
Our highly skilled  have access to special
implements and appropriate equipment required to
 any servicing job at best, and use Ducati
original spare  only as the best guarantee for
full interchangeability, smooth running and long life.
All Ducati motorcycles come with a Warranty Card.
The warranty does not apply to motorcycles used in
racing competitions.
Tampering with or altering any components, even
 will make the warranty null and void
 immediately. Improper or poor
maintenance, using other than original spare 
or  not expressly approved by Ducati may
invalidate your warranty rights and lead to damage
or loss of 
Your safety and that of other road users are very
 Ducati Motor Holding S.p.A.
recommends that you ride responsibly.
Before using your motorcycle for the first time, read
this entire manual carefully and closely follow the
guidelines outlined in it. The manual provides full
information on proper motorcycle operation and
8

maintenance. In case of any doubts, please contact a
Dealer or Authorised Service Centre.
Warning symbols used in the manual
Several kinds of warnings are used as an  of the
possible hazards for you or other persons such as:
- Safety labels on the motorcycle;
- Safety messages preceded by a warning symbol
and either WARNING or IMPORTANT.

Failure to comply with these instructions may
put you at risk, and could lead to severe injury or even
death of the rider or other persons.

Possibility of damaging the motorcycle and/or
its components.
Note
Additional information about the current
operation.
The terms RIGHT and LEFT are referred to the
motorcycle viewed from the riding position.
9

Intended use

This motorcycle was designed for both road use
and for light  and  road use. Heavy duty
 use is not advised and can result in the rider
losing control of the vehicle, thereby increasing the
risk of accidents.

This motorcycle may not be used to tow any
trailers or with a side-car  this can lead to
loss of control and result in an accident.
This motorcycle carries the rider and can carry a
passenger.

The total weight of the motorcycle in running
order with rider, passenger, baggage and additional
accessories must not exceed 465 kg / 1025.15 lb.

The maximum weight  for the side
panniers, top case and the tank bag must never
exceed 30 kg (66 lb), divided as follows:
10 kg (22lb) max. per side pannier;
5 kg (11 lb) max. for the top case;
5 kg (11 lb) max. for the tank bag.

The maximum speed  with the side
panniers, the top case and the tank bag  must
not exceed 180 km/h (112 mph) and at any rate it
must comply with the applicable statutory speed
limits.
10


Using the motorcycle under extreme
conditions, such as very damp and muddy roads or
dusty and dry environment, could cause above-
average wear of components like the drive system,
the brakes or the air filter. If the air filter is  the
engine could get damaged. Therefore, this might
translate in required service or replacement of the
wear  earlier than specified in the scheduled
maintenance 
11

Rider's obligations
All riders must hold a valid licence.

Riding without a licence is illegal and is
prosecuted by law. Always make sure you have your
licence with you when riding. Do not let
inexperienced riders or persons without a valid
licence use your motorcycle.
Do not ride under the influence of alcohol and/or
drugs.

Riding under the influence of alcohol and/or
drugs is illegal and is prosecuted by law.
Do not take prescription or other drugs before riding
unless you have consulted your doctor about their
side 

Some medications and drugs may cause
drowsiness or other  that slow down reaction
time and the rider's ability to control the motorcycle,
possibly leading to an accident.
Some states require vehicle insurance.

Check your state laws. Obtain insurance
coverage and keep your insurance document secure
with the other motorcycle documents.
To protect rider and passenger safety, some states
mandate the use of a  helmet.

Check your state laws. Riding without a helmet
may be punishable by law.

Riders without helmets are more likely to 
severe bodily injury or die if they are in an accident.
12


Check that your helmet complies with safety
specifications, permits good vision, is the right size
for your head, and carries a  label
indicating that it conforms to the standards in force
in your state. Road  laws  from state to
state. Learn about  laws in your state before
riding and always obey them.
Rider's training
Accidents are frequently due to inexperience.
Riding, manoeuvres and braking must be 
in a  way than on the other vehicles.

Untrained riders or a wrong use of the vehicle
may lead to loss of control, serious injuries or even
death.
13

Apparel
Riding gear is very  for safety. Unlike cars,
a motorcycle  no impact protection in an
accident.
Proper riding gear includes helmet, eye protection,
gloves, boots, long sleeve jacket and long trousers.
- The helmet must meet the requirements listed
at "Rider's obligations"; if your helmet does not
have a visor, use suitable eye wear;
- Use five-finger gloves made from leather or
abrasion-resistant material;
- Riding boots or shoes must have non-slip soles
and  ankle protection;
- Jacket, trousers or riding suit must be made
from leather or abrasion-resistant material and
have high-visibility colours and 

Never wear loose clothing, items or accessories
that may become tangled in motorcycle 

For your safety, always wear suitable protective
gear, regardless of season and weather.

Have your passenger wear proper protective
clothing.
14

Safety "Best Practices"
These few simple operations are critical to people
safety and to preserving the full  of your
motorcycle. Never forget to  them before,
while and  riding.

Closely follow the indications provided at
chapter "Riding the motorcycle" during the running-
in period.
Failure to follow these instructions releases Ducati
Motor Holding S.p.A. from any liability whatsoever
for any engine damage or  engine life.

Before riding your motorcycle, become familiar
with the controls you will need to use when riding.
 the checks recommended in this manual
(see “Checks before riding”) before each ride.

Failure to carry out these checks before riding
may lead to motorcycle damage and injury to rider
and/or passenger.

 the engine outdoors or in a well
ventilated area. The engine should never be 
or run indoors.
Exhaust gases are poisonous and may lead to loss of
consciousness or even death within a  time.
Use proper body position while riding and ensure
your passenger does the same.

Rider must hold the handlebar with both hands
at ALL TIMES while riding.

Both rider and passenger should keep their
feet on the footpegs when the motorcycle is in
motion.

The passenger should always hold on to the
grab handles under the seat with both hands.
15


Be very careful when tackling road junctions, or
when riding in areas near exits from private grounds,
car parks or on slip roads to access motorways.

Be sure you are clearly visible and do not ride
within the blind spot of vehicles ahead.

ALWAYS signal your intention to turn or pull to
the next lane in good time using the suitable turn
indicators.

Park your motorcycle where no one is likely to
knock against it, and use the side stand. Never park
on uneven or  ground, or your motorcycle may
fall over.

Visually inspect the tyres at regular intervals
for detecting cracks and cuts, especially on the side
walls, bulges or large spots that are indicative of
internal damage. Replace them if badly damaged.
Remove any stones or other foreign bodies caught in
the tread.

Engine, exhaust pipes and silencers stay hot
long  the engine is switched  pay 
 not to touch the exhaust system with any
body  and do not park the vehicle next to
flammable material (wood, leaves etc.).
16

Refuelling
Fuel label
Fuel identification label
Refuel outdoors with engine 
Do not smoke or use open flames while refuelling.
Be careful not to spill fuel on engine or exhaust pipe.
Never completely fill the tank when refuelling. Fuel
should never be touching the rim of filler recess.
When refuelling, avoid breathing the fuel vapours
and prevent fuel from reaching your eyes, skin or
clothes.

The motorcycle is only compatible with fuel
having a maximum content of ethanol of 10% (E10).
Using fuel with ethanol content over 10% is
forbidden. Using it could result in severe damage of
the engine and motorcycle components. Using fuel
with ethanol content over 10% will make the
warranty null and void.

In case of indisposition caused by breathing
fuel vapours for a long time, stay in the open air and
contact your doctor. In case of contact with eyes,
thoroughly flush with water; in case of contact with
skin, immediately clean with water and soap.

Fuel is highly flammable, in case of accidental
spillage of fuel on your clothes it is necessary to
change into clean clothes.
Fig 1
17

Carrying the maximum load allowed
Your motorcycle is designed for long-distance riding,
carrying the maximum load allowed in full safety.
Even weight distribution is critical to preserving
these safety features and avoiding trouble when
 sudden manoeuvres or riding on bumpy
roads.

The maximum speed  with the side
panniers, the top case and the tank bag  must
not exceed 180 km/h (112 mph) and at any rate it
must comply with the applicable statutory speed
limits.

Do not exceed the total  weight for
the motorcycle and pay  to information
provided below regarding load capacity.
Information about carrying capacity

Arrange your luggage or heavy accessories in
the lowest possible position and close to motorcycle
centre.

Never fix bulky or heavy objects to the
handlebar or to the front mudguard as this would
 stability and cause danger.

Be sure to secure the luggage to the 
provided on the motorcycle as firmly as possible.
Improperly secured luggage may  stability.

Do not  any objects you may need to carry
into the gaps of the frame as these may foul moving


Make sure the tyres are inflated to the proper
pressure and that they are in good condition.
18

Refer to paragraph "Tyres".

If you install the side panniers (available on
request from Ducati  service),  out luggage
and accessories according to their weight and
arrange them in the side panniers to evenly
distribute the weight. Close the side panniers with
the relevant key locks.
Dangerous products - warnings
Used engine oil

Prolonged or repeated contact with used
engine oil may cause skin cancer. If working with
engine oil on a daily basis, we recommend washing
your hands thoroughly with soap immediately
 Keep away from children.
Brake dust
Never clean the brake assembly using compressed
air or a dry brush.
Brake fluid

Spilling brake fluid onto plastic, rubber or
painted  of the motorcycle may cause damages.
Protect these  with a clean shop cloth before
proceeding to service the system. Keep away from
children.

The fluid used in the brake system is corrosive.
In the event of accidental contact with eyes or skin,
wash the  area with abundant running water.
Coolant
Engine coolant contains ethylene glycol, which may
ignite under  conditions, producing
invisible flames. Although the flames from burning
ethylene glycol are not visible, they are still capable
of causing severe burns.

Take care not to spill engine coolant on the
exhaust system or engine 
19
