Plasma Display Panel
Model P42A
Inputs are easily accessible on the side of panel
P42A
Only
3.5”
Wide Key Features
• 42 Inch display
• 853 x 480 resolution
• Outstanding image processing
• Built-in stereo amplifier
• Quiet operation
• 16:9 aspect ratio
• 160˚ viewing angle
• Portrait capability
24”
Tall
Video 1/ Video Out
Video 2
Video 3
Audio 1
Remote In/Out
DVD1/ HD1
Audio 2
RGB2 /DVD2/H
D2 Input
RGB1/ RGB Out
Audio 3
DVI
External Control

Dukane P42A plasma display panel draws your audi-
ence right into your message and commands their
attention. Super bright images, pure reds and saturated
colors combined with built-in stereo amplifier makes
sure your message is always loud and clear no matter
what your environment or angle. In areas with direct
lighting an anti-glare filter keeps images vibrant and
contrast high for a perfect image every time.
Advanced scan
conversion and
3/2 pull down pro-
cessing, delivers
smooth, lifelike
video. A patented
color filter ensures
realistic color.
Connect to multiple
sources from video to HD to RGB. Signal loop-through
capability allows a source to easily be looped from one
monitor to the next enabling you to connect 4 displays
without the use of an external DA*.
A sleek new design with cable management system,
programmable timer and portrait capability make the
P42A the perfect choice for any environment.
Dukane Corporation
Audio Visual Products Division
2900 Dukane Drive
St. Charles, Illinois 60174
800-676-2485 or 2486 toll-free
630-584-5156 fax
[email protected] e-mail
www.dukcorp/av.com
Plasma Display Panel P42A Specifications P42A
Display, diagonal 42 inches
Display, area 36.3" (H) x 20.4" (V)
Resolution, pixels 853 (H) x 480 (V), WVGA
Video Compatibility NTSC, PAL, SECAM, HDTV
1080i, 1035i, 720p, 625i/p,
540p, 525i/p, 480i/p
Aspect Ratio 16:9
Number of Colors 16.7 million
Contrast Ratio 1500:1
Brightness 400cd/sq m
Viewing Angle 160 degrees
Image Features Portrait/Landscape Mode, Zoom
Computer Compatibility VGA, SVGA, XGA, SXGA,
UXGA, WVGA, WXGA
Scanning Frequency fh 15.5-110 kHz, fv 50-120 Hz
Inputs, Computer 15-pin mini D-sub (shared)
5 BNC (RGB/HV)
29-pin DVI
Inputs, Video Composite BNC x 1
Composite RCA x 1
S-Video 4-pin DIN
RCA Component
(Y,Pb,Pr/Y,Cb,Cr)
BNC Component
(Y,Pb,Pr/Y,Cb,Cr)
Inputs, Audio RCA Stereo x 3
Output, Computer 15 PIN mini D-sub (shared)
Output, Video Composite BNC
Audio Internal Amplifier, 8W x 2 output
power
Control 9-pin mini D-Sub, RS232, Wired
remote(In/Out)
Operating Temperature 32-104 degrees F (0-40 degrees C)
(20-80% operating humidity)
Power 120V 50/60 Hz, 275W (typical),
0.9W (standby)
Weight 62.8 lbs.
Size (W x H x D) 40.1" x 24" x 3.5"
Shipping Weight 92 lbs.
Carton Size 16" x 33" x 51"
Safety FCC Class A, UL Approved
Accessories Included Power Cord, User Manual,
Remote Control, Batteries, Cable
Clamps
Optional Accessories Tabletop Stand (PX-ST1U),
Attachable Speakers (PX-42SP1U)
Terminal Cover (PX-CV1U)
Fixed Wall Mount (FWMK)
Tilt Wall Mount (TWMK)
Ceiling Mount (CMK)
Fixed Wall Mount for PC
(FWMKPC)
Tilt Wall Mount for PC (TWMKPC)
Ceiling Mount for PC (CMKPC)
Key features:
• 42 Inch display
• 853 x 480 resolution
• Outstanding image processing
• Built-in stereo amplifier
• Quiet operation
• 16:9 aspect ratio
• 160˚ viewing angle
• Low power consumption
• Portrait capability
• Cable management
• Programmable timer
One (1) year limited warranty on parts and labor in North America,
lamp excluded (for other locations, local warranties apply).
1YR
* Signal DA is required for sending a signal to more than 4 mon-
itors simultaneously.
