DUKANE
APPLICATION NOTE AN532
iQ Series
ULTRASONIC WELDING SYSTEM
43Q220-P-301
OPERATING A DUKANE
THRUSTER FROM A PLC
Dukane Ultrasonic Welders

AN532 (Rev. 00) © Dukane 2021. All Rights Reserved.
Page 2 of 5
DUKANE
APPLICATION NOTE AN532
CONNECTING A 43Q220-P-301 THRUSTER TO A PLC
Thruster Cable part number: 200-1413
The cable is provided with a connector on both ends. If desired cut the connector from one end to expose the individual
wires. Below are the pins used for thruster control. At minimum only 4 connections are needed. The Top of Stroke,
Trigger and Dual Pressure Valve connections are optional if additional functionality is desired.
Wire Color
Pin no#
Function
BLK/RED
1
22 Volts
BLK/GRN
3
Up Valve
BLK/BLU
5
Down Valve
BRN/BLK
9
Top of Stroke (relative to GND)
ORN/BLK
15
Trigger
BLU/RED
23
Trigger return
YEL/RED
20
Dual Pressure Valve
GRN/RED
24
GND
It is recommended that an E-stop be inserted between the 24 volt power supply and the cable connection. This will turn
both valves off, allowing the thruster to go to a neutral state. The 24 volt power supply should be capable of supplying
0.5 amps or more.















 





AN532 (Rev. 00) © Dukane 2021. All Rights Reserved.
Page 3 of 5
DUKANE
APPLICATION NOTE AN532
OPTIONAL TRIGGER SWITCH AND TOP OF STROKE SIGNALS
OPTIONAL DUAL PRESSURE VALVE
NOTE: These signals are not necessary for operation. These are only provided as optional if additional functionality is
required.






 
 

































