Duplo EX-2000 User manual

Provided By
http://www.MyBinding.com
http://www.MyBindingBlog.com
Duplo Express
Sealer EX-2000
Service Manual

1
Introduction
Symbols and Notations in this manual
Safety precautions
Various symbols and pictures are used in this manual and on the stickers affixed to the machine. These symbols
and pictures provide warnings and instructions to prevent danger to you or other personnel, and to prevent
damage to office property. The meanings of these symbols and pictures are explained below.
WARNING
Indicates a high degree of potential danger. Ignoring the warning may result in death or
serious injury of personnel.
CAUTION
Indicates a medium degree of potential danger. Ignoring the caution may result in injury of
personnel or damage to properties.
Examples of pictorial symbols
A circle with a line through it indicates a prohibited action. The particular act
prohibited is indicated by a picture inside the circle. ( In the example on the right
indicates ‘disassembly is prohibited.’
● A black disc indicates an instruction , or sometimes a prohibited action. The
instruction itself is indicated by pictorial symbols drawn in white on the disc. ( In the
example on the right indicates ‘Remove the plug from the outlet.’
Other Notations
IMPORTANT Notes on faulty operation/maintenance which can damage products or disturb
its performance.
REF. Information in regards to the performance of the product, operation or maintenance.

2

3

4
Introduction ････････････････････････････････････････････････････････････････････････ 1
1. Specifications ･････････････････････････････････････････････････････････････････････ 5
2. Parts names and their functions ･･････････････････････････････････････････････････ 6
3. Paper flow and operating principle････････････････････････････････････････････････ 7
4. Operating sequence･･･････････････････････････････････････････････････････････････ 8
5. Circuits and their operation ･･･････････････････････････････････････････････････････ 8
6. Maintenance and adjustments ････････････････････････････････････････････････････ 11
7. HELP mode････････････････････････････････････････････････････････････････････････ 20
8. Error message displays ･･･････････････････････････････････････････････････････････ 23
9. Electrical parts･････････････････････････････････････････････････････････････････････ 26
Contents

5
1. Specifications
No. Item Specification Remarks
1 Type Desktop
2 Model name EX-2000
３Paper size Length：279.4ｍｍ (11”) - 355.6mm (14”)
Width ：210mm - 215.9mm (8.5”)
４Finished size Length： 93.1mm - １48.5mm
Width ： 210mm - 215.9mm (8.5”)
24lb（90g/㎡） - 32lb（120g/㎡）
５Paper type Envelop paper with pressure sensitive adhesive along
the edges of the front
* Do not use envelop paper with pressure sensitive
adhesive applied overall.
7000 sheets/hour （FAST）
６Processing speed 8.5”×11”
Z-fold envelop 5000 sheets/hour （SLOW）Under operating
temperature
７Feed system Friction feed system based on rubber rollers and paper
separation plate
８Feed capacity 200 Z-fold (accordion fold) envelopes (thickness: 28lb)
９Fold types V-fold, C-fold, Z-fold, EZ-fold, EC-fold
1st panel 60mm - 266.7mm
10 Fold size 2nd panel 60mm – 118.5mm
11 Stacker type Gravity stacker
12 Stacker capacity 200 Z-fold (accordion fold) envelopes (thickness: 28lb)
１３ Functions & safety
system
Test operation
Paper detection
JAM detection for all paper paths
Cover interlock
Manual feed
Double feed detection
Speed selection
Batch count
１4 Dimensions [In use] 756mm（D）×701ｍｍ（W）×533（H）
[Folded] 633ｍｍ（D）×465ｍｍ（W）×403（H）
１5 Weight 54kg (folder: 22.5kg, sealer: 31.5kg)
１6 Power source AC115Ｖ（±10％） 60Hz 3A
１7 Power consumption 330W
18 Operating
temperature 10 – 30℃
19 Operating humidity 40 – 70% (No condensation)
Notice: Specifications are subject to change for improvement without notice.

6
2. Parts names and their functions
No. Name Function
1 Feed pressure
adjuster lever Adjusts feed pressure according to paper thickness. Normally set to “Standard”.
2 Paper feed guides Makes smooth paper transport by adjusting the guides to the paper size.
3 Double feed detection
adjuster knob Adjusts double feed detection according to paper thickness.
4 Paper set lever Lower this lever before loading paper and raise it to start operation.
5 Control panel Use keys for operation. The display shows the current operational status.
6 Power switch Press the “I” to turn on and “○” to turn off.
7 Folding tray 1 Used for all foldings (Z-fold, C-fold, V-fold)
8 Folding tray 2 Used for Z-fold and C-fold. Install the turn guide for V-fold.
9 Support tray Used when setting paper.
10 Handle slot Insert the handle to remove jammed paper or clean the rubber rollers.
11 Stacker stopper Adjust this stopper according to ejected paper.
12 Stacker guide Adjust these guides according to ejected paper.
13 Safety cover Open this cover to adjust the transport guide or to remove jammed paper.
1
12
7
3
2
4
8
10
6
5
13
11
９

7
PPS sensor 1
Paper
tray
Paper
3. Paper flow and operating principle
3-1 Folding section
1．Papers loaded on the feed tray are separated to 1
sheet by the separator unit when being fed by the
paper feed ring.
(The timing for feeding the paper is controlled by the
PPS 1 which senses paper flow.)
2． In the double feed detecting section, the paper presses
up the upper double feed detection roller when it passes
between the rollers. When the upper roller is pressed
up higher than reference position, double feed is detected
and the machine stops.
(Error message ‘DOUBLE FEED’ will appear in the display.)
3．The paper passed through the double feed detection
section is fed to the folding tray 1 by the folding rollers
1 and 2, and stops at the stopper. The stopped paper
sags and is fed to the path between the folding rollers
2 and 3, and then is fed to the folding tray 2.
Support tray Paper feed ring
Paper tray
PPS sensor 1
(light receiving)
Paper separator unit
PPS sensor 1
(light emitting)）
Double feed
detection roller
Folding roller 1
Folding roller 2
Folding tray 1
Folding tray 2
Folding roller 4
Folding roller 3
PPS sensor 2
(light receiving)
PPS sensor 2
(light emitting)
Ejection
roller
Parts name
Double feed
detection roller
Stopper
Folding roller 3
Folding roller 1
Folding tray 1
Folding roller 2

8
4．The paper fed to the folding tray 2 sags by bumping
the stopper as well as the flow in the folding tray 1,
and is fed to the path between the folding rollers 3
and 4, and then is fed to the sealer section by the
ejection roller.
(When V-fold is executed, the paper is fed directly
to the path between the folding rollers 3 and 4 from
the folding tray 1 by leading with the turn guide.)
3-2 Sealer section
1. The paper fed to the sealer section touches the stopper,
and is fed to the pressure roller section by the feed
rollers and roller.
2. The temporary sealed part in the folding section of the
paper fed is peeled off by the bracket F (upper and lower)
installed adjacent to the feed roller, and then is fed to the
pressure roller section.
3. The paper is applied by strong pressure between the
pressure rollers, and pressure sensitive adhesive
parts are adhered.
Folding tray 2
Folding roller 2
Stopper Folding roller 4
Stopper
PPS sensor 3
(light receiving)
PPS sensor 3
(
li
g
ht emittin
g)
Feed roller
Pressure roller (lower)
Pressure roller (upper)
Bracket F (lower)
Bracket F (upper)
Parts names
Roller
Feed roller
Roller Pressure
roller
(
u
pp
er
)
Pressure roller
(lower)
Folding
roller 3
Bracket F (upper)
Bracket F (lower)
