DUR-line SF 2500 Pro User manual

Ideal for realigning your satellite system
Extremely compact in size and weight
Easy installation and handling
Backlit signal display
Adjustable attenuation setting
Acoustic signal
Power supply via receiver
Scope of delivery
1
4
6
2
1 x SF 2500 Pro Satfinder
1 x FF cable
1 x instructions
Technical data
Input frequency: 950 - 2150 MHz
Input level min.: 68dBµV
Input level max.: 98dBµV
Input impedance: 75 Ohm
Output impedance: 75 Ohm
Power supply: 13 - 18 Volt DC
Disposal
Please consider the environment when you dispose of any packaging material.
This product consists of recyclable materials. Take an acve part in protecng the
environment by ensuring that your old device is disposed of in an environmentally
friendly manner.
Therefore, take your device to an ocial collecon or recycling point.
Your local government or city council will provide you with informaon about such
a collecon point near you.
Service Review product
Dear customer,
Thank you for choosing this
high-quality product.
Please do not assume that
the device is defective if
your product does not
immediately function as
you would expect.
Please do not immediately
return the device; please
send us an email instead!

The SF 2500 Pro microprocessor-controlled satellite finder with new and improved electronics enables
you to quickly and easily align your satellite system in a precise and reliable way. Accurate results are
provided via both the backlit display and an acoustic signal.
This device is very sensitive and can pick up even the weakest signals. Strong input signals (through
powerful satellites or large satellite antennas) can be easily attenuated using the “Attenuation +/-”
buttons and the lateral adjustment wheel. The device can be configured with all types of satellite
systems and produces highly accurate readings.
The satellite finder is powered through the LNB operating voltage by the receiver/TV or multiswitch
and does not require an additional power supply.
DURA-SAT GmbH & Co.KG
Unterer Dammweg 6/1
78050 Villingen-Schwenningen
WEEE reg. no.:
DE 88896400
www.durline.de
Subject to changes and prinng errors.
May only be copied and reproduced with
the permission of Dura-Sat GmbH.
Version dated 02/18
Installation instructions
see the reverse side 
5
33
DUR-line ® 
5
1LNB connector
2Receiver connector
3Gradually increase/reduce attenuation
4Switch background lighting on/off
5Switching buzzer on and off
6Infinitely variable attenuator
713 V = vertical/18 V = horizontal
822 k = high-band/0 Hz = low-band
9Attenuation stage -3 dB = brief flash
-6 dB = long flash
-9 dB = continuous
Overview
8 7 9

• Never open a product that has been connected to an electricity supply as there is a high risk
of electrocuon!
• Never work on the satellite system during thunderstorms.
• The product must be immediately isolated from the operang voltage if it has come into
contact with liquid.
• This device may only be opened and repaired by qualied personnel
who must observe the applicable regulaons.
NEW
Improved
electronics
developed by
DUR-line
®
Video tutorial (subtitle english):
A video tutorial is available to view on YouTube,
you can scan the adjacent QR code.
or
enter “DUR-line SF 2500 Pro” in the search eld in YouTube.
Manual available to download
in other languages:
www.durline.de/qr/manual/sf2500pro.html
Email to Support
Happy?
Review now
Instructions
see the reverse side

We always do our utmost to make sure

As such, we are always
happy to receive posive
feedback.
Share your experiences:
• Review our product
• Rate our product

Keep the signal level display region
at approx 50% by reducing or increasing the
aenuaon.
An increase or decrease in the level can thus
be idened.
If aenuaon is acvated,
“ATT” appears on the display.
The adjustment wheel is very sensive.
 In addion, use the “Aenuaon +/-”
buons.
 
 
The antenna is opmally aligned
when the signal strength cannot
be increased anymore.
It is oen possible to somewhat increase the
quality by turning the LNB in its retaining
clamp in small increments, known as skew
opmisaon (not necessary for Astra 19.2°).
1 Prepare the satellite dish
Region
Germany:
Azimuth
angle:

angle:

angle (skew):
North-west (Dortmund)
165° 30° -2°
North-east (Berlin) 173° 30° -2°
South-west (Stugart) 167° 33° -2°
South-east (Munich) 170° 34° -0°
1.1 Determine the angle for the
satellites
It is necessary to know the approximate
posion on the horizon in order to be able
to quickly align the
antenna on the correct
satellites. For this
purpose, use the easy
online calculator at
www.durline.de/tools/
satcalc.html
or scan the following QR code.
Or,
You can nd reference values for most
private and public channels as well as Sky
in the table below.

1.2 Roughly align your satellite dish
Now align the antenna in the posion in
the sky where you expect to nd the
satellite.
Azimuth angle: align by compass
(e.g. smartphone compass)
 Use the antenna
dial (back part).
 
3 Adjust the satellite dish more precisely
Antenna roughly aligned as described
 


 
3.1 Turn the satellite dish CAREFULLY
 
observe signal strength bar or buzzer
volume
If the antenna is roughly aligned,
the signal strength bar in the display
goes up.
The aim is to nd the point with the max.
signal level, but not to reach a certain
numerical value (such as 99%).
 

4.1 Check the picture of a number of channels on your TV (if necessary, start a channel search)
It is most likely that the satellite dish is aligned towards a different satellite, if no programmes or the
wrong programmes are received. Some satellites are in close proximity to each other.
Check the Azimuth angle and adjust again.

4.2 Switch off the receiver/power supply
Firstly, separate the receiver from the mains to avoid short circuiting.

4.3 Fasten the satellite dish crosswise and remove the satellite finder from the signal path.
Finally, connect the supply cable to the LNB - job completed!
Satellite: Astra 1KR/L/M/N (19.2° O)


Use the coaxial cable that was included with
the product – connect the “LNB” connector
to the LNB output.
2.2 Connect the receiver/power supply
 
Connect the (receiver) supply cable to the
connector that is labelled “Receiver”
2.3 Switch on the receiver/power supply
The receiver now supplies the power
to the satellite nder – the satellite nder
starts.
The satellite nder potenally displays a reading,
oen 99% or 0%
 Turn the adjustment wheel.

Depending on the LNB type and background
interference radiaon, the satellite nder may
already display a reading even though a satellite
is not being located.
Before beginning the alignment, you must
  
ground noise.
To do this, turn the lateral adjustment wheel or
press “Aenuaon” buons (ATT-), unl you
nd the threshold value and then adjust the
level to approx. 10%.
 
the satellite signals correctly.

-->
i
i
-->
100%
Signal level
0%
Threshold value
adjust

i

Use

(3 stages)
Keep signal level

Aenuaon
Receiver
LNB
turn
Video tutorial

SENSITIVE
i
i
LNB
Background
noise
Turn SLOWLY
Astra 19.2°
approx. 170°
1
Reduce LNB background noise

Astra 19.2°
approx. 30°
approx.
30°


 
->Thus, there remains enough “leeway in the display” when adjusng to idenfy whether the
recepon is geng beer or worse.
  
precisely.
2Azimuth:
