Durite ECE R65 User manual

ECE R65 Amber Lightbar 12/24V - 2FT (55cm/21.5”)
Part 0-443-05
0-443-05-LEAF
www.durite.co.uk
DIMENSIONAL DRAWING

www.durite.co.uk
UNPACKING
1) Check the box for damage in transit. If the box is damaged inform your designated
sales representative immediately. (If the consignment is not signed for as ‘damaged’ it
may affect whether the product can be repaired or replaced free of charge)
2) Carefully remove the lightbar from the box and place it on a at and stable surface,
taking extra care not to scratch the lenses.
3) Examine the lightbar for damage such as cracked or scratched lenses. Report any dam-
age to your designated sales representative.
MOUNTING
DURITE lightbars are available with a variety of xing methods. If the lightbar has a
different fixing method other than the standard universal footpack (shown below) please
contact your sales representative for further assistance.
0-443-05-LEAF

www.durite.co.uk
INSTALLATION
Quick-test procedure only applies to standard hardwired lightbars. If the lightbar is not a
standard build product please refer to Cables page.
PATTERN SELECT - MOMENTARY,
DIM - REDUCES TO 25% BRIGHTNESS,
SYNCRONISATIONTO MF PRODUCTS
0-443-05-LEAF

www.durite.co.uk
FUSE
The following table can be used as a guide to determine the maximum current from
standard builds: (24v vehicles will draw approximately half the current shown in the table
below. Installers should contact their sales representative if they are unfamiliar with fusing
requirements)
FLASH PATTERNS
To reset all controllers to ash pattern 1, hold brown cable to positive for 2 seconds.
0-443-05-LEAF
To use CAP 168 Flash Pattern hold brown cable to positive until flash pattern changes to
single CAP168 Flash Pattern (approx 5-10seconds). To return to normal flash patterns
repeat the process.

www.durite.co.uk
SYNCRONISATION
0-443-11-LEAF
CLEANING
Most DURITE products have been pre-programmed to include a synchronised ash rate.
Products can be synchronised by connecting their yellow cables. All LEDs can be perma-
nently illuminated (cruise light) by connecting the yellow cable to negative (Boost / 3 watt
mode only).

www.durite.co.uk 0-443-11-LEAF
CONDITIONS OF USE
1. The 0-443-05/0-443-11 Lightbar must only be tted to a vehicle and used in accordance
with this data sheet or any other terms and conditions of use as may appear upon DURITE’s
website www.durite.co.uk.
2.The use of the Product does not ensure that other road users will observe or react to the
emergency warning signal given by the product. Users of the Product should not take any
right of way upon the roads for granted. It is the user’s responsibility to ensure that the
user can proceed safely whilst driving and using the product.
3.The safety and the effectiveness of the product is dependent upon correct mounting and
wiring. It is the user’s obligation to ensure that the user follows these instructions within
this data sheet when either installing and/or using the product. Please ensure that the
projection of the product is not blocked by other components on the vehicle, or any other
form of obstruction.
4.The product is entitled for use by authorised personnel only who are legally permitted to
use the product as a warning device. It is the user’s sole responsibility to understand and
obey all laws regarding the use of such emergency warning devices.
5.The product should be installed in such a manner so as to not reduce the output perfor-
mance of the product, and all controls in relation to the use of the product should be placed
within the convenient reach of the driver/operator so that he/she can operate the product
safely and so as to continue to drive in a safe manner.
6.The product requires high electrical voltages and/or cu
rrents. The user should properly protect and use caution around live electrical connections,
both by the user and by any third party. Grounding or shorting of electrical connections
can cause high current arcing, which could cause personal injury and/or severe vehicle
damage.
7. All users of the product should ensure that they have been appropriately trained both in
relation to the use of the product and in relation to the use of emergency warning devices.
8. It is the user’s responsibility at all times to ensure that the product is used in a safe man-
ner and in accordance with this data sheet.
9. The user should ensure that the product is properly secured in line with this data sheet,
and that the user takes into account variations in the weather and environmental condi-
tions.
10. The product should be tested and checked on a regular basis both before use and during
use. The product should not be used if it appears to be defective and/or to have malfunc-
tioned.
11. The Supplier’s warranties and liabilities are fully detailed in the Supplier’s terms and con-
ditions in relation to sale of the Product and use of the Product by its customers (as therein
dened). In relation to use of the Product by any third party, the Supplier shall not be liable
to such third party whether in contract, tort (including negligence), breach of statutory duty
or otherwise (save for death or personal injury caused by the Supplier’s negligence).

www.durite.co.uk 0-443-05-LEAF
SPECIFICTAIONS
Type..............................................................LED Lightbar
Colour...........................................................Amber
Voltage.........................................................12V/24V
Current Draw...............................................3A @ both 12V/24V
Size...............................................................2Ft (55cm or 21.5”)
Flash Patterns..............................................6 Selectable (page 4)
LEDType.......................................................Osram
Number of LED modules............................8 (3 x 3W LED’s)
Power...........................................................72WTotal
Cable Length...............................................3 Metres
Fixing............................................................Universal Footpack
Lens..............................................................4mm Polycarbonate
Approval.......................................................E Marked: ECE R65 Approved (Class 1)
IP Rating.......................................................IP54 Ext/ IP67 Int
Dimensions..................................................(L) 305mm x (W) 546mm x (H) 117mm
Weight..........................................................4.85KG
Switch Panel................................................Not supplied
