Operation & Maintenance Manual

Table of Contents
1. Important Health & Safety Information ....................................................................4
1.1 Document Conventions...............................................................................................................................5
1.2 Health and Safety Information.................................................................................................................7
2. Specifi ations, Configu ations and Dimensions ..................................................11
Specifi ations....................................................................................................................................................... 12
XPW3000 Series Performance Curves....................................................................................................... 14
XPW5000 Series Performance Curves....................................................................................................... 15
XPW9000 Series Performance Curves....................................................................................................... 16
Wiring Diagrams................................................................................................................................................. 17
3. Installation and Commissioning ...............................................................................19
Basic Installation Information....................................................................................................................... 20
Installation Sequence....................................................................................................................................... 21
Commissioning ................................................................................................................................................... 23
4. Using the ScubaTANK ....................................................................................................24
User Controls ....................................................................................................................................................... 25
Starting and Running the ScubaTANK........................................................................................................ 28
Protection and Fault Alarms.......................................................................................................................... 31
Alert Messages and Possible Causes.......................................................................................................... 32
5. Troubleshooting...............................................................................................................36
General Troubleshooting................................................................................................................................. 37
6. Routine User Maintenance ..........................................................................................39
Routine Tank Maintenance............................................................................................................................. 40
Pressure Vessel Servicing................................................................................................................................ 42
Pump Servicing ................................................................................................................................................... 45
ScubaTANK WX

Appendix A: VASCO Pump Controller User Guide ....................................................48
ScubaTANK WX

1. Important Health & Safety
Information
ScubaTANK WX
Page 4ScubaTANK WX

1.1 Document Conventions
Throughout this manual, text may be accompanied by one of the following icons. Where these
occur the conventions shown below are applied.
In general these conventions will also apply to OEM Manufacture’s manuals that are included
within this User Guide, however variations may occur, but these will be redefined at the beginnin
of their manual.
PLEASE READ THE FOLLOWING INFORMATION WHICH IS PROVIDED FOR YOUR SAFETY
Danger: Denotes attention to the possibility of the risk of personal
injury or damage to adjacent property if the information is ignored.
Electric Shock: Denotes attention to the possibility of life-threatening
electric shock if the information is ignored.
Warning: Denotes attention to a condition that may result in under-
performance or damage to the equipment if the information is ignored.
ScubaTANK WX
Page 5ScubaTANK WX

Note: Denotes attention to an important factor applicable to the action
being performed.
ScubaTANK WX
Page 6ScubaTANK WX

1.2 Health and Safety Information
Basic safety warnings relating to all products.
United Kingdom Health & Safety at Work Act 1974
Dutypoint Responsibility
Section 6(a) of this Act requires manufacturers to advise their customers on the safety and the handling
precautions to be observed when installing, operating, maintaining and servicing their products. The user’s
attention is therefore drawn to the following:
• The appropriate sections of this manual must be read before working on the equipment.
• Installation, operating and maintenance must only be carried out by suitably trained/qualified personnel.
• Normal safety precautions must be taken and appropriate procedures observed to avoid accidents.
Refer to DUTYPOINT SYSTEMS for any technical advice or product information. 
Customer / Contractor Responsibility
It is the responsibility of the customer and/or the contractor: 
• To ensure that anyone working on the equipment is wearing all necessary protective gear/clothing.
• Is aware of appropriate health & safety warnings
• has read the information in this section of the manual.
ScubaTANK WX
Page 7ScubaTANK WX

Hand Control Mode
In the 'HAND' position the pump(s) controlled by the switch will normally run at full speed and completely
independently of any control devices, and can result in pump(s) running against a closed valve head if there is no
draw.
This can cause the system to be maintained at the maximum pressure produced by the pump plus any incoming
pressure and additional pressure caused by water surge and can potentially damage the pump and other parts of
the system.
The 'HAND' option should only be used with a competent operator in attendance, or when there is a
continued demand sufcient to provide constant ow through the pumps to maintain the running pressure
of the system to an acceptable level.
Pump Servicing
• Familiarise yourself with the relevant contents of this manual
• Installation, maintenance and repair work must only be carried out by trained, skilled and suitably
qualified personnel
• Disconnect or lock-out the power source to ensure that the pump(s) will remain inoperative. Locking out
the equipment by switching off the release mechanism or set value WILL NOT prevent accidental
starting of the motor.
• Allow the pump(s) to cool if over-heated.
•CLOSE the isolating valves on the suction and discharge connections of the affected pump(s).
•VENT the pump(s) slowly and cautiously – Refer to the relevant section of this manual.
•DRAIN the pump(s).
ScubaTANK WX
Page 8ScubaTANK WX

High Voltages
Especially applicable when Variable Speed Controllers (Inverters) are tted.
• When the inverter variable speed drive head is connected to the power supply the components of the power unit
– as well as certain components of the master control unit – are also connected to the power supply.
TOUCHING THESE COMPONENTS CAN SERIOUSLY ENDANGER LIFE!
• Before removing the frequency inverter cover, the system must be disconnected from the power supply. After
switching off the power supply wait at least 5 minutes before starting work on or in the inverter drive head – the
capacitors in the intermediate circuit must be given time to discharge completely via the discharge resistors.
Up to 800 volts can be present – if there are faults this can be higher.
• All work carried out when the frequency inverter is open must be performed only by suitably qualified an
properly authorised personnel.
When connecting external control wires care must be taken not to short circuit adjacent components. Bare cable
ends which are not in use must be insulated.
THE SYSTEM MUST ONLY BE OPERATED WHEN IT HAS BEEN CORRECTLY EARTHED AND PIPES BONDED TO
EARTH IN ACCORDANCE WITH IEE REGULATIONS
Electronic Safety Devices
• High voltage tests of the inverter or the motor may damage the electronic components. Bridge before
the incoming/outgoing terminals L-L2-L3 and U-V-W.
• To avoid incorrect metering by capacitors incorporated in the electronic circuits, isolate the motor from
the inverter drive head.
ScubaTANK WX
Page 9ScubaTANK WX

High voltage testing may damage electronic components
• High voltage tests of the inverter or the motor may damage the electronic components. Bridge before
the incoming/outgoing terminals L-L2-L3 and U-V-W.
• To avoid incorrect metering by capacitors incorporated in the electronic circuits, isolate the motor from
the inverter drive head.
ScubaTANK WX
Page 10ScubaTANK WX

2. Specications, Congurations
and Dimensions
ScubaTANK WX
Page 11ScubaTANK WX

Specications
Identifying Your ScubaTANK
Attached to each tank is a label that identies the type and specication.
Detailed Specications
Suitability Water with no gas or aggressive substances
Flow Range 1.2 - 3.1 litres/sec
Pressure Range 2.5 - 7.0 Bar
Liquid Temperature Max +23°C for domestic uses. Min +1°C to avoid icing.
Operating
Temperature +5 to +40°C for indoor installation. Relative humidity max 50% at +40°C
Controller Type Modus VASCO (x 2 for WX2 models)
Protection Low water level via probe control
Tank Construction
GRP construction
25mm insulation (HCFC and CFC free)
Base reinforced with encapsulated multi-ply board and fitted with security fixi
brackets
Tank Capacity 175l, 375l, 490l, 650l, 800l, 1050l, 1250l, 1650l, 2250l.
Dimensions Refer to drawings section.
Inlet Valve 1" high flow solenoid alve
ScubaTANK WX
Page 12ScubaTANK WX

Discharge (WX1)
1¼" BSP (2" available on request)
Screened vent and overflo
Discharge (WX2)
1½" BSP (2" available on request)
Screened vent and overflo
Pressure Vessel 12 litre; stainless steel construction
Pump Rating
Pump Type Motor Power (kW) Power Supply (V/ph/Hz) Full Load Current (A)
3040 XPW3040 0.55 230/1/50 4.1
3060 XPW3060 0.75 230/1/50 5.2
3080 XPW3080 1.10 230/1/50 7.4
5040 XPW5040 0.75 230/1/50 5.0
5060 XPW5060 1.10 230/1/50 7.4
5080 XPW5080 1.50 230/1/50 10.5
9040 XPW9040 1.50 230/1/50 10.5
9060 XPW9060 2.20 230/1/50 11.9
9070 XPW9070 3.0 400/3/50 7.9
Dimensional Drawings
Dimensional drawings vary according to the tank capacity and configu ation. Dimensional drawings for specifi
models are supplied with each unit and are available on our website at:
www.dutypoint.com/systems/
ScubaTANK WX
Page 13ScubaTANK WX

XPW3000 Series Performance Curves
WX1/2-3000 Series
~2900rpm, ISO 9006 - Annex A
ScubaTANK WX
Page 14ScubaTANK WX

XPW5000 Series Performance Curves
WX1/2-5000 Series
~2900 rpm, ISO 9906 - Annex A
ScubaTANK WX
Page 15ScubaTANK WX

XPW9000 Series Performance Curves
WX1/2-9000 Series
~2900rpm, ISO 9906 - Annex A
ScubaTANK WX
Page 16ScubaTANK WX

Wiring Diagrams
WX1 Wiring Diagram
ScubaTANK WX
Page 17ScubaTANK WX

WX2 Wiring Diagram
ScubaTANK WX
Page 18ScubaTANK WX

Page 18aScubaTANK WX
Volt-Free Contact Wiring Details
Probe Relay Wiring Details
Single Pump Probe Relay Wiring
Twin Pump Probe Relay Wiring

Page 18bScubaTANK WX
Level Probe Details
There are 5 terminals within the probe holder:
E1 – Solenoid cut-off probe – Shortest probe (300mm)
E2 – Solenoid cut-in probe – (400mm) this is 100mm longer than the cut out probe
E3 – Low level probe – this is 50mm shorter than the common probe.
E4 – Common probe – longest probe.
E5 – Not used on standard ScubaTANKs
E1
E2
E4
E3
E1 E2
E3
E4
E5
175, 800 375, 490, 650 1050, 1250, 1650, 2250
PR-6-890 - 890mm PR-6-1090 - 1090mm PR-6-1390 - 1390mm
PR-6-840 - 840mm PR-6-1040 - 1040mm PR-6-1340 - 1340mm
PR-6-400 - 400mm PR-6-400 - 400mm PR-6-400 - 400mm
PR-6-300 - 300mm PR-6-300 - 300mm PR-6-300 - 300mm
ScubaTANK Capacity (litres)
E4 Common Probe Length (mm)
E3 Low Level Probe Length (mm)
E2 Solenoid Cut-in Probe Length (mm)
E1 Solenoid Cut-out Probe Length (mm)
