dvblogic TF-MFD3 User manual

Version29.01.2013TF-MFD3
TV-Free
Video-in-motionInterface
TF-MFD3
for Volkswagen MFD3/RNS510,
SkodaColumbus
andSeatTrinax
navigationsystems
Legal Information
By law,watchingmovingpictureswhiledrivingisprohibited,thedriver mustnot be
distracted.We donotacceptany liabilityformaterial damage orpersonalinjury resulting,
directlyor indirectly,frominstallationor operationofthisproduct. This productshouldonly
beusedwhile standingortodisplay fixedmenusor rear-view-cameravideowhenthe
vehicle is moving, forexample theMP3menuforDVDupgrades.
Changes/updates of the vehicle’s software can cause malfunctions of the interface. We
offerfreesoftware-updates forourinterfacesforoneyearafterpurchase. Toreceive afree
update,theinterfacemust besentinatowncost.Laborcostforandotherexpenses
involvedwith thesoftware-updates will notberefunded.
www.eldibg.com
car integration, multimedia and security solutions

Version29.01.2013TF-MFD3
Page1
Contents
1. Priortoinstallation
1.1.Delivery contents
1.2.Checkcompatibilityof vehicle andaccessories
1.3.SettingtheDip-switchesoftheCAN-Box TV-500
1.4.Pin-assignments
2. Installation
3. Activationofthevideo-in-motionfunction
4. Specifications
5. Technical support
1. Priortoinstallation
Readthemanual priortoinstallation. Technical knowledgeis necessary forinstallation. The
place ofinstallationmustbefreeofmoistureandaway fromheatsources.
1.1. Deliverycontents
CAN-box TV-500
HW_____SW_____
Harness
TV-VW02
TakedowntheSW-versionandHW-versionoftheinterface boxes, and store this
manualfor support purposes.
www.eldibg.com
car integration, multimedia and security solutions

Version29.01.2013TF-MFD3
Page2
1.2. Check compatibility ofvehicleandaccessories
1.3. SettingtheDip-switchesoftheCan-BoxTV-500
Vehicle/navigation
Dip1
Dip2
Dip3
Dip4
Dip5
Dip6
Video-in-motion permanent
ON
OFF
OFF
OFF
OFF
OFF
Video-in-motion selective*
OFF
OFF
OFF
OFF
OFF
OFF
*Withdip1toOFFtheincludedgreencableis usedtoactivatethevideo-in-motionfunction.
Note:Dipswitchfunctionsof theTV-500
Dip1 –activation TV-free
Dip2 –nofunction
Dip3 –nofunction
Dip4 –nofunction
Dip5 –CAN-bustermination resistor onthevehicle side
Dip6 –CAN-bustermination resistor onthehead-unitside
1.4. Pin-assignments
Pin-assignmentvehicleconnector
Cablecolour
Assignment
Requirements
Vehicle Volkswagen, Seat, Skoda and BentleyContinental GT
Navigation MFD3/RNS510, Trinax or Columbus navigationsystems
www.eldibg.com
car integration, multimedia and security solutions

Version29.01.2013TF-MFD3
Page3
Pin-assignmentoftheCAN-BoxTV-500(Molex8pin)
Cablecolour
Pin-No.
Assignment
●Yellow
Pin4
CAN-HIGH –connectiontothehead-unit
●Blue
Pin3
CAN-LOW –connection tothehead-unit
●●Yellow/Black
Pin8
CAN-HIGH –connectiontothevehicle
●●Blue/Black
Pin7
CAN-LOW –connection tothevehicle
●Red
Pin1
+12Vpermanent
●Black
Pin5
Ground
●Green
Pin6
Activationofthevideo-in-motion function
(+12V=TV-freeactivated)
●White
Pin2
Trigger output(+12VDC500mA)
2. Installation
Switch off ignition and disconnect the vehicle’s battery! If according to factory rules
disconnectingthebatteryhastobeavoided,itisusuallysufficienttoputthevehicleis
sleep-mode.Incasethesleep-modedoes notshowsuccess,disconnectthebatterywitha
resistorlead.
InstructionforVWGolf 5,TouranwithMFD3/RNS510:
1. Removedecorative plasticpanels ofthenavigation
computercarefully, remove the4TORX screwsandpull the
navigation computerout ofthecentreconsolewith the
accordanttoolkit(not included).
2. DisconnectQuadlockconnectorfromthebacksideofthe
navigation computerand connectittoharness TV-VW02. If
theoriginalQuadlockconnector carries12pininserts,
disconnecttheinsertsandconnectthemtoharness TV-VW02.
ConnectTV-VW02tothenavigationcomputer.
www.eldibg.com
car integration, multimedia and security solutions

Version29.01.2013TF-MFD3
Page4
3. Activation of the video-in-motion function
Thevideo-in-motioncanbeactivatedand deactivatedbyDip1or alternatively by the
includedloose greencable inconnectionwithaswitch(notincludedindelivery).
Video-in-motion permanent
With dip1toONthevideo-in-motion functionisactivatedpermanentlywithout disturbing
thenavigation performance.
Video-in-motion selective
With dip1toOFFtheincludedgreencable isusedtoactivatethevideo-in-motionfunction.
Connectaswitchtothegreencable andconnectthegreencableto+12VACC.
●+12V= TV-Freeis activated
●0V = TV-Freeis notactivated
Note:Theloose whitecable is notrequiredandmustbeisolated.
4. Specifications
Operationvoltage10.5 –14.8V
Stand-bypowerdrain<2mA
Operationpower drain ~60mA
Powerconsumption~0,08W
Temperaturerange-30°C to+80°C
Weight44g
Measurements(box only) W xHxD76x27x54mm
