DVDO DVDO-Splitter-12-SE User manual

DVDO-Splitter-12-SE
1x2 HDMI 2.0 18Gbps Splitter
with Scaler / Audio Extraction
Version 1.0.0
User Manual

1
Thank you for purchasing this product
For optimum performance and safety, please read these
instructions carefully before connecting, operating or adjusting
this product. Please keep this manual for future reference.
Surge protection device recommended
This product contains sensitive electrical components that may
be damaged by electrical spikes, surges, electric shock, lighting
strikes, etc. Use of surge protection systems is highly
recommended in order to protect and extend the life of your
equipment.

2
Table of Contents
1. Introduction.................................................................... 3
2. Features.......................................................................... 3
3. Package Contents ............................................................ 4
4. Specifications .................................................................. 4
5.Operation Controls and Functions..................................... 6
5.1 Front Panel............................................................. 6
5.2 Rear Panel.............................................................. 8
6. Application Example........................................................ 9

3
1. Introduction
The 1x2 HDMI 2.0 Splitter simultaneously routes one HDMI
source to two HDMI displays. It supports resolutions up to
4K2K@60Hz (4:4:4) and HDCP 2.2. This product supports audio
extraction from HDMI source to optical and analog outputs. It
can operate in COPY, AUTO modes for EDID setting. Output
supports bypass and downscaling (4K->1080P ) functions.
2. Features
☆ HDMI 2.0b, HDCP2.2 / HDCP1.4 compliant.
☆ Supports HDMI resolutions up to 4K2K@50/60Hz (4:4:4)
☆ Extracts digital and analog audio from HDMI source.
☆ Supports output bypass and 4K->1080P downscaling
function via dial switch on panel.
☆ EDID can be set to COPY and AUTO modes via panel dial.
COPY: Copies OUT 1 port EDID setting to all output ports;
AUTO: Compares OUT 1 and OUT 2 EDID setting and outputs
the best resolution to all outputs).
☆ Supports HDMI audio formats LPCM, Dolby
Digital/Plus/EX, Dolby True HD, DTS, DTS-EX,DTS-96/24,
DTS High Res, DTS-HD Master Audio, DSD

7
INPUT LED
device with a HDMI cable.
3
HDMI
OUTPUT
LED
These blue LEDs will illuminate when the
HDMI OUT port has connected an active
display device with a HDMI cable.
4
SERVICE
port
Firmware update. (Manufacturer use only.)
5
EDID
AUTO: Compare OUT 1 and OUT 2 displays
EDID setting, then output the best resolution
to source device, the source will transmit the
signal again to all outputs.
COPY: Copy the HDMI OUT 1 port EDID setting
to source device, the source device will
transmit again the signal to all outputs.
6
Dial switch
(4K→
1080P)
OFF: When the dial switch is in‘OFF’
position, signal input and output is bypass
status.
ON: When the dial switch is in‘ON’position,
signal input will downscale (4k->1080P )
output.

9
6. Application Example
