DW Windsor KIRIUM ECO Series User manual

Kirium ECO
Installation Instructions
IMPORTANT
PRODUCT DETAILS
KIRIUM ECO MINI KIRIUM ECO MIDI
A 588mm 588mm
B 180mm 180mm
C 135mm 135mm
CxS 0.029m20.030m2
kg (PP cover) 3.8 4.1
kg (AL cover) 4.3 4.6
230VAC 50Hz
IP66 IK08
• DISCONNECT ELECTRICAL SUPPLY BEFORE INSTALLATION OR SERVICING.
• THIS PRODUCT MUST BE EARTHED.
• THIS PRODUCT IS DESIGNED TO OPERATE OUTDOORS. IF REQUIRED TO BE
USED INDOORS PLEASE CONSULT DW WINDSOR.
• DO NOT LOOK DIRECTLY AT LED LIGHT SOURCE
• THE LUMINAIRE SHOULD BE POSITIONED SO THAT PROLONGED STARING
INTO THE LUMINAIRE AT DISTANCE CLOSER THAN X M IS PREVENTED
135.3
587.8
179.5
135.3
587.8
179.5
587.7
180.0
135.2
587.7
180.0
135.2
A
B
C

POST TOP
12
3 4
SIDE ENTRY
REMOVE GRUB SCREWS AND NUTS, REVERSE AND
RE-INSERT SO THAT DRIVE HEX IS EXTERNAL
REVERSE SEQUENCE IF SWITCH
FROM SIDE ENTRY TO POST TOP

POST TOP
LOOSEN THE BOLTS UNTIL
TILTING IS POSSIBLE
DO NOT OVER LOOSEN RETIGHTEN TO REQUIRED TORQUE
SIDE ENTRY
TILT ADJUSTMENT
10°
10°
15°
-10°
7.5°
7.5°
12.5°
-7.5°
2.5°
2.5°
-2.5°
-2.5°
0°
0°
5°
5°
-5°
-5°
2 x
16Nm+1Nm
0Nm
8

POST TOP
16Nm +1Nm
0Nm
SIDE ENTRY
Due to continuous product development the details within this document
are subject to change at any time, please contact us for the most up-to-date
information or visit: www.dwwindsor.com
November 2016
DW Windsor
Pindar Road, Hoddesdon, Hertfordshire, EN11 ODX
T: [phone] | E: [e-mail]
www.dwwindsor.com
Sheet 2 of 4
2x
1
!
4x
1
45°
Step 1
Loosen and remove pre-attached 2x M10 screws and 4x disc spring
washers from lantern with 6mm allen key.
Step 2
Fit entry to lantern with supplied fasteners, tightening to 36Nm torque. 4x
Disc spring washers must be installed in the correct orientation.
Step 3
Undo quick-release side latches, and leave latches in open position.
Step 5
Loosen cable gland cap within base and feed through cable tail.
Step 4
Pivot lift-off head 45° away from base and remove. Store lift-off head in
safe area during base installation.
Note! Ensure entry is aligned to desired mounting angle.
Step 6
Wire cable to electrical disconnect with Philips Head Screwdriver. Tighten
gland cap to 6Nm to ensure IP sealing is maintained.
L N
3
Kirium Pro Installation Steps | Post Top Entry
The Kirium Pro Range
LED Road Light
Kirium Pro 1, 2 and 3
≥ 100mm ≥ 100mm
Ø 60-76mm
Ø 34-60mm
