DW DWC-XPZAWM User manual

Wall mount bracket for DWC-XPZA cameras
Quick Start Guide
Tel: [phone]
Technical Support Hours: 9:00AM – 8:00PM EST, Monday through Friday
digital-watchdog.com
NOTE: Download all your support materials and tools in one place.
1. Go to: http://www.digital-watchdog.com/resources
2. Search your product by entering the part number in the ‘Search by Product’ search bar. Results
for applicable part numbers will populate automatically based on the part number you enter.
3. Click ‘Search’. All supported materials, including manuals and quick start guide (QSGs) will
appear in the results.
WHAT’S IN THE BOX
1x Machine Screw, HM3 x 8 (Adapter Screw)
1x Silicon Cap (30 x 11mm)
1x O-Type Waterproof Ring (1.5 x 2mm)
1x Waterproof Mounting Pad (167 x 122 x 41.5mm)
4x Tapping Mounting Screws
1x Quick Setup Guide
DWC-XPZAWM

Accessories
4 x Machine screws, HM3 x 8
4 x Tapping Screws
1 x Silicon Cap Φ30 x 11mm
1 x O ring Φ1.5 x 2mm
1 x Silicone Pad 167 x 122 x 41.5mm
WALL BRACKET
Undecided. Evaluating how to mount the
camera to the wall mount bracket. Either
using junction box from Truen side or not.
Accessories
4 x Machine screws, HM3 x 8
4 x Tapping Screws
1 x Silicon Cap Φ30 x 11mm
1 x O ring Φ1.5 x 2mm
1 x Silicone Pad 167 x 122 x 41.5mm
WALL BRACKET
Undecided. Evaluating how to mount the
camera to the wall mount bracket. Either
using junction box from Truen side or not.
Quick Start Guide
Rev: 08/23
Copyright © Digital Watchdog. All rights reserved.
Specifications and pricing are subject to change without notice.
INSTALLATION
1Mark and drill the necessary holes on the mounting surface using the mounting bracket itself.
2Secure the mounting bracket to the mounting surface using the tapping screws included with the
mount. Use the waterproof mounting pad between the bracket’s arm and the mounting surface
as needed.
3Attach the bracket adapter included with the camera to the wall mount. Use the machine screw
included with the mount to secure the adapter to the mounting bracket. Place the O ring between
the wall mount and camera adapter to prevent moisture accessing the camera.
4
Secure the camera to the wall mount with the safety wire included with the camera.
5
Pass wires through and make all necessary connections. If you are running the cables from the
wall behind the mount, use the silicon cap to seal the pipe at the bottom of the mount.
6Secure the camera to the adapter using the screws included with the camera to complete the
installation.
Accessories
4 x Machine screws, HM3 x 8
4 x Tapping Screws
1 x Silicon Cap Φ30 x 11mm
1 x O ring Φ1.5 x 2mm
1 x Silicone Pad 167 x 122 x 41.5mm
WALL BRACKET
Undecided. Evaluating how to mount the
camera to the wall mount bracket. Either
using junction box from Truen side or not.
