Rev. 10/98 1 949-1239-3
INSTRUCTIONS FORTHE
1600 SERIES
MICROPROCESSOR BASED
TEMPERATURE / PROCESS
CONTROL
INCLUDES FUZZY LOGIC OPTION
Dwyer Instruments, Incorporated
PO Box 338 Michigan City, IN 46361-0338
[phone] [phone] FAX [phone]
www.love-controls.com
❍❍
❍
LOVE CONTROLS DIVISION
®

949-1239-3 2 Rev. 10/98
TABLE OF CONTENTS
GETTING STARTED .............................................................................. 2
INSTALLATION.......................................................................................4
DIMENSIONS ......................................................................................... 5
INPUT SELECTION ................................................................................ 5
LOGIC JUMPER SELECTION................................................................ 6
WIRING...................................................................................................7
FRONT PANEL KEY FUNCTIONS.........................................................8
NOTATION CONVENTIONS FOR THE MENUS ................................. 10
THE HOME DISPLAY ........................................................................... 10
OPERATION OF SELF TUNE® FUNCTION ........................................ 11
Theory of Operation ..................................................................... 11
Program Setup and Operation .................................................... 12
METHOD FOR SET UP OF A HEAT / COOL CONTROL WITH SELF
TUNE .................................................................................................... 12
PROGRAMMING AND OPERATION FOR RAMP / SOAK FEATURE13
Theory of Operation ..................................................................... 13
Program Setup .............................................................................. 13
Ramp / Soak Operation ................................................................ 14
MENU SELECTIONS........................................................................... 15
PRIMARY MENU .................................................................................. 15
SECONDARY MENU ............................................................................ 15
SECURE MENU.................................................................................... 21
DIAGNOSTIC ERROR MESSAGES .................................................... 28
CONFIGURATION MENU .................................................................... 30
SPECIFICATIONS ................................................................................ 35
GETTING STARTED
1. Install the control as described on page 4.
2. Make sure that the Input DIP switch is set correctly for the input
you wish to use. Instructions on page 5.
3. If you wish to use the Logic (5 VDC) output, make sure that the
Logic jumper is in the correct position. See page 6 for details.
4. Wire your control following the drawing on page 7.
5. Make any programming changes necessary first in the Secure
Menu (page 21), next in the Secondary Menu (page 15), and
finallyinthePrimary Menu (page 15). DONOTmakechangesto
theConfigurationMenuunlessspecificallyinstructed. Ifyouneed
tobackupina menu,presstheINDEXand DOWNARROWkeys
together.

Rev. 10/98 3 949-1239-3
6. To quickly return to the HOME position, press the UP ARROW
and ENTER keys together, and then the INDEX and DOWN
ARROW keys.
Take the example of a Model 16010 that comes from the factory pro-
grammed for type J thermocouples. Suppose for this example you wish to
changetheinputto100ohmPlatinumDINRTD andlimitthesetpointrange
between 0° and 500° C.
First, change the input DIP switch as shown on page 5. For RTD inputs
switches 1, 3, and 4 are off, switch 2 is on.
Next,entertheSecuremenuasinstructedonpage8. PresstheINDEXkey
until the display shows Inp and press the DOWN ARROW until the display
shows P385. Don't forget to press the ENTER key to retain your setting.
Next,presstheINDEXkeytodisplayUnit. PresstheDOWNARROWuntil
the display shows C. Press ENTER.
Next, press the INDEX key until SPL is displayed (pass the dPt and InPt
selections). Press the UP ARROW until the display shows 0. Press
ENTER.
Finally, press INDEX key to display SPH. Press the DOWN ARROW until
the display shows 500. Press ENTER.
The necessary program changes are now complete. After 60 seconds the
display will switch back to the temperature reading. If you want to return
faster,presstheUPARROWandENTERkeys(atthesametime)andthen
pressthe DOWNARROWandINDEXkeys(againatthesametime). This
will'backout'ofthemenuandimmediatelydisplaythetemperaturereading.
If you want to use Self Tune®, Auto/Manual, or the Ramp/Soak Program-
mer features, see the special sections on these items. Page numbers for
these are in the Contents section on the previous page.

949-1239-3 4 Rev. 10/98
INSTALLATION
Mount the instrument in a location that will not be subject to excessive
temperature,shock,orvibration.Allmodelsaredesignedformountinginan
enclosed panel.
Selecttheposition desiredforthe instrumentonthepanel. Ifmorethan one
instrument is required, maintain the minimum of spacing requirements as
shownonthedrawingopposite. Closer spacing willstructurallyweakenthe
panel, and invalidate the IP66, UL type 4 rating of the panel.
Prepare the panel by cutting and deburring the required opening.
From the front of the panel, slide the housing through the cut out. The
housing gasket should be against the housing flange before installing.
From the rear of the panel slide
themountingcollaroverthehous-
ing. Hold the housing with one
hand and using the other hand,
pushthecollarevenlyagainstthe
panel until the spring loops are
slightly compressed. The ratch-
ets will hold the mounting collar
and housing in place.
MOUNTINGCOLLAR(SHOWNINPOSITION)
SLIDE COLLAR ONTO THE HOUSING
BEFORE WIRING THE REAR TERMINALS
SPRING LOOP
GASKET
PANEL
10mm (0.25")
MAX.
45mm
(1.77in) 19mm
(0.75in)
45mm
(1.77in) 45mm
(1.77in)
45mm
(1.77in)
Cut Out Cut Out
All Tolerances are -0.00 +0.60mm (-0.000 +0.020)
It is not necessary to remove the control chassis from
the housing for installation. If the control chassis is
removed from the housing, you must follow industry
standard practice for control and protection against
Electro-Static Discharge (ESD). Failure to exercise
good ESD practices may cause damage to the control.

Rev. 10/98 5 949-1239-3
INPUT SELECTION
Before removing the instrument from its housing, make sure you take
appropriate precautions to avoid electro-static discharge (ESD). See
caution on opposite page. To change the input type, remove the instru-
ment from its housing by grasping the front bezel sides and pulling
forward to release it from
the housing lock.
Locate the dip switch on
the right pcb. Determine
the input type desired and
change the dip switch
setting as shown at the
right.
Reinstall the instrument
into the housing.
After changing input selec-
tion with the DIP switches,
be sure to change the InP
menu item (page 11) in the
Secure Menu.
12 3 4
DIP SWITCH LOCATION
THERMOCOUPLE INPUTS
RTD INPUTS
CURRENT INPUT
VOLTAGE INPUT
12 (0.450) * 3 (0.125)
45
(1.760)
114 (4.475)
125 (4.925)
48 (1.880)
48
(1.880)
R
MADE IN USA
ENTER
AL AL
INDEX
˚C
˚F
SP2
AL
SP1
LOVE
RCONTROLS CORP.
PV
SV
(All dimensions in millimeters with inches in parenthesis.)
Panel cutout for all models is 45mm x 45mm (1.775 in x 1.775 in).
Allow for 13 mm (0.5 in) clearance at the rear of the instrument.
* Present for SSR outputs.
DIMENSIONS

949-1239-3 6 Rev. 10/98
LOGIC JUMPER SELECTION
Instruments with SSR or RELAY type outputs can be changed to and from a
LOGIC output in the field.
CAUTION: Damage to the instrument may result from an
incorrectly installed jumper strip. Follow the instructions
carefully. Damage to the instrument may also result from
improper handling. Use appropriate precautions to avoid
Electro-Static Discharge (ESD).
1. Remove the instrument from its housing. Grasp the front bezel sides and
pull forward to release it from the housing lock.
2. Locate the desired logic jumper strip on the left printed circuit board. The
OUTPUT A jumper
strip is always lo-
cated near the top
edge
3. To remove the logic
jumper strip, carefully
insert a small flat
blade screwdriver be-
tween the retaining
clip and the jumper
at one end of the
jumper strip. Apply slight pressure to
move the clip away from the jumper end
until it is released, then lift it up and out of
the clip.
4. To re-install the jumper strip, hold it with the spring contacts in the desired
position. Face springs up for SSR or RELAY outputs, or face springs down
for LOGIC outputs. Insert one end of the jumper strip under the retaining
clip and press the other end down until the remaining clip engages the
jumper.
5. To avoid any damage, recheck the jumper installation and the housing rear
terminal panel output wiring.
6. Replace the instrument into its housing.
OUTPUT A SET FOR LOGIC TYPE OUTPUT
OUTPUT B SET FOR SSR or RELAY TYPE OUTPUT
SLIGHT PRESSURE TO RELEASE
RETAINING CLIP
INSTALLING JUMPER FOR
LOGIC TYPE OUTPUT INSTALLING JUMPER FOR
SSR or RELAY TYPE
OUTPUT
SPRINGS UP
SPRINGS DOWN

Rev. 10/98 7 949-1239-3
936 +
-
B (+)
A (-)
992
RTD*
Current
Voltage
Thermocouple
+
-
* For 2-wire 1000 ΩRTD use terminals 1 & 3.
For 2-wire 100 ΩRTD use terminals 1 & 3, and
place a jumper wire between terminals 3 & 4.
F1
3/8 A @250 VAC
Medium Lag
INPUTS
Line Input See Rating
Label for details
AL1
ALARM OUTPUT
Terminals 4 & 5 are
Normally Open. See
Rating Label.
+
-
F1
}{
Relay**
N.O. Solid State Relay N.O. 5VDC Output 5V = On, 0V = Off
5VDC @
25mA
-
+
Current or
Voltage
+
-
}{ 5VDC @
25mA
-
+
+
-
0 to 10 VDC @ 25 mA
}{
}{
Output
A
Output
B
˚C˚F CURRENT
25 77 3.50
35 95 2.75
45 113 2.00
55 131 1.25
SSR Derating Chart For Relay or SSR
outputs use type MDA or
3AB 3.5A medium lag
fuse.
** R/C snubber is
recommended for driving
solenoid or contactor
loads.
INPUT WIRING: Do not run thermocouple of other signal wiring in the same conduit as power
leads. Use only the type of thermocouple or RTD probe for which the instrument has been
programmed. See Secure Menu for Input Programming.
For thermocouple input always use extension leads of the same type designated for your
thermocouple.
Outputs A and B may be logically swiched. See Secure Menu for details.
948
OPTIONS
WIRING

949-1239-3 8 Rev. 10/98
FRONT PANEL KEY FUNCTIONS
Set Point 1 Lamp Process Variable
Alarm Lamp
Set Point 2 Lamp Set Variable
°F Indicator
°C Indicator
INDEX: PressingtheINDEXkeyadvancesthedisplaytothe
next menu item. May also be used in conjunction with other
keys as noted below.
UP ARROW: Increments a value, changes a menu item, or
selects the item to ON in the upper display.
DOWN ARROW: Decrements a value, changes a menu
item, or selects the item to OFF in the upper display.
ENTER: Pressing ENTER stores the value or the item
changed.Ifnotpressed,thepreviouslystoredvalueoritemwill
be retained.
UPARROW&ENTER: Pressingthesekeyssimultaneouslybringsupthe
secondary menu starting at the auto/manual selection. Pressing these
keys for 5 seconds will bring up the secure menu.
INDEX&DOWN ARROW: Pressingthesekeys simultaneouslywillallow
backing up one menu item, or if at the first menu item they will cause the
display to return to the primary menu. If an alarm condition has occurred,
these keys may be used to reset the alarm.
INDEX & ENTER: Pressing these keys simultaneously and holding them
for 5 seconds allows recovery from the various error messages. The
following menu items will be reset:
LPbr: Loop break SEnC: Sensor rate of change
ALiH: Alarm inhibit OPEnInP:Openinputerrormessage
ArEA: Area error message bAd InP: Bad input error message
CHEC CAL: Check calibration error message
Correct the problems associated with the above conditions first before
using these reset keys. More than one error could be present. Caution is
advised since several items are reset at one time.

Rev. 10/98 9 949-1239-3
DISPLAYEDVALUE
WHENVIEWED
1
2
3
4
SECURITYLEVEL
MENU SECURITY
Primary Locked
Secondary Locked
Secure Locked
Primary Unlocked
Secondary Locked
Secure Locked
Primary Unlocked
Secondary Unlocked
Secure Locked
Primary Unlocked
Secondary Unlocked
Secure Unlocked
SECURITY LEVEL SELECTION
Four levels of security are provided. The display shows the current security
level.Tochangesecurity levels changethepasswordvalue using theUP &
DOWNARROWkeysandpressingtheENTERkey. Refertothepassword
table below for the correct value to enter for the security level desired. The
SECr menu item security level may be viewed or changed at any time
regardless of the present security level. The password values shown in the
table cannot be altered, so retain a copy of this page for future reference.
This will be the only reference made to password values in this instruction
book.
PASSWORD TABLE
PASSWORD
VALUE TO ENTER
1110
1101
1011
111
While in the Primary or Secondary menu, if no key is pressed for a period
of30seconds,thedisplaywillreturntotheHOMEpositiondisplayingthePV
andSVvalues.Thetimeisincreasedto1minutewhenintheSecuremenu.
NOTE: Tomovetotheprimarymenu quicklyfromanyothermenu,press
the UP ARROW &ENTER keys followed by pressing the INDEX & DOWN
ARROW keys.
NOTE: Program the Secure Menu first, the Secondary Menu second,
and the Primary Menu last.

949-1239-3 10 Rev. 10/98
NOTATION CONVENTIONS FOR THE MENUS
Because of the number of features available in this control, information is
includedthatmaynotapplytoyourspecificcontrol. All usablefeaturesare
included in this book, but may not be used in your process. To increase
clarity the following conventions are used:
1. Certainfeatures,MenuItems,andfunctionsshowninthis bookmayor
maynotappearonyourcontrol,depending onotherMenuItemselections.
At various places in the Menus there are notes identifying Menu Items that
"control" or "direct" other menu items. If you are looking for a particular
menu item and can't find it, check the menu item that is its "control" for
proper setting.
2. The "#" symbol is used in two ways. It is used inside a group of
characters to indicate which set point function (SP1 or SP2) is being
affected. It is also used before a group of characters of a menu item to
indicate that there may be more than one selection or value for that menu
item.
3. Features that apply only to Options will be printed in Italics.
THE HOME DISPLAY
The home display is the normal display while the control is operating. If no
errors or functions are active, the HOME display will indicate the Process
Variable(thetemperature,pressure,flow,RH,etc.,thatisbeingmeasured)
on the top display and the Set Variable (Set Point 1) on the bottom.
ItemsthatcanchangetheHOMEdisplayaretheAuto/Manualfunction,the
Prog function, the PctO function, and any error message. Description of
these special displays follow.
If Auto/Manual Menu Item is On, the home display is changed. The upper
displaycontinuestoshowtheProcessVariable (PV), but the lower display
changes to show the percentage of output in tenths of a percent to 99.9%
(0.0 to 99.9), or 100 if 100%. The display digit to the right of the number
showsaflashingletterotoindicatethatthevaluedisplayedisnolongerthe
SV, but percent output. The SP2 output is indicated by the use of an
overlineontheletterõ. AccesstotheSP2valueisdonebytheINDEXkey.
See Auto/Manual Operation on Page 13 for further information.
If Prog is turned On, the HOME display changes the SV display from SP1
to the Present Set Variable as calculated by the Ramp/Soak Programmer
function. WhenProgisOntheStAtMenuItemchangesthehHOMEdisplay
firther. WhenStAtisselectedOFF,theHOMEdisplayalternatelyindicates
the normal HOME and the Ramp/Soak partial status in the Lower Display.

Rev. 10/98 11 949-1239-3
The partial status display sequences with the set value showing the ramp
(S1rA)orsoak(S1So)segmentbeingprocessedatthatmoment.Itwillalso
show the Program output status if at Hold or OoFF.
When StAt is selected On, the HOME Display alternately indicates the
normal HOME and the Ramp/Soak full status in both the upper and lower
displays.Thefullstatusdisplaysequenceswiththesetvalue;Programrun,
Hold, or OoFF; and with the time remaining for the ramp S1rA or the soak
S1Sosegments.SeeProgrammingandOperationforRamp/SoakFeature
below for more information.
IfPctO (SecondaryMenu)isturnedOn,thelowerdisplaychangestoshow
the active percentage of output as required to maintain SP1. The display
issimilartotheAuto/Manualdisplayabove,exceptthattheletterindicators
donotflash,andtheoutputisdisplayedinwholepercentagesofoutput,not
intenthsofapercent. IfthecontrolhasbothSP1andSP2,thelowerdisplay
willalternatebetweentheSP1percent output and the SP2 percentoutput.
OPERATION OF SELF TUNE®FUNCTION
Self Tune®allows automatic selection of the necessary parameters to
achieve best control operation from your 1600 Series control. If you are
using the control output as a simple on-off function (S#Ot set for OnOF),
none of the following will apply.
Theory of Operation
The Self Tune function calculates the Pb1, rES, and rtE parameters under
thePIDtunEselectionasshownintheSecondaryMenu. Thesevaluesare
determined by measuring the response of the process connected to the
control. When Self Tune is started, the control temporarily acts as an on-
off control. While in this mode the control measures the overshoot and
undershootoftheprocess,andtheperiodoftheprocess(thetimefrompeak
value to the next peak value). These measurements are collected over a
period that lasts three periods of overshoot and undershoot. The data
collected over this time is then compared and calculated into final PID
values. The calculations for the PID values are the same as used in the
standardZiegler-Nicholsequationsthathavebeenrecognizedasstandard
for decades.
The only modification to the application of the Ziegler - Nichols equations is
controlled by the dFAC menu item. This menu item controls the amount of
rate(derivative)that is applied. AdFAC settingof 3(factorydefault)orless
allows for less damping. A dFAC setting of 4allows for critical damping as

949-1239-3 12 Rev. 10/98
set forth in Ziegler - Nichols. A dFAC setting of 5or more allows over
damping of the process.
Program Setup and Operation
In the secondary menu set tunE to SELF. Skip LErn and check to make
surethatdFAC isset tothedesired value. BackuptoLErnandsettoYES.
The control will begin the Self Tune function. While the Self Tune function
is active, the right hand decimal point on the lower display will blink. When
Self Tune is complete, the blinking will stop.
After the initial Self Tune is complete, the instrument will look at the LErn
menu item to determine if you wish to have the process continually tuned.
Setting LErn to Cont will allow the control to periodically check the tuning
parameters. Ifyouwishtohavethetuningvalueslockedin,setLerntoEnd.
If you wish at any time to view the PID values, change the tunE setting to
PID. Thisallowsexaminationand/ormodificationofthevaluescalculated.
We recommend that you do not change the calculated values unless you
haveafirmunderstandingoftheparametersinvolvedandtheirfunction. For
more information on PID tuning, please contact your supplier.
METHOD FOR SET UP OF A HEAT / COOL CONTROL WITH SELF
TUNE
Determine if the process is predominantly heating or cooling. An extruder,
for example, is predominantly cooling when running product. An environ-
mental chamber can be either heating or cooling.
Iftheprocessispredominantlycooling,setS1St todirand S2SttorE. Ifthe
process is predominantly heating, set S1St to rE and S2St to dir. Redirect
SP1 to output A or B as required by the hardware (see SP1o). Set S2t to
dE. Set SP2 for zero (no overlap of bands, no deadband). Set Pb2 to a
desired value (default is 12°F). Set tunE to SELF, Strt to YES, and LErn
to End.
Starttheprocessandwaitforittocometostability. Occasionallycheckthat
theSelfTunehascompletedthelearningprocessbyINDEXingtoStrtinthe
secondarymenu. IftheYESvaluehaschangedtono,thentheprocesshas
been learned. Once learning is complete, you may adjust SP2 to either
overlap the SP1 band (SP2 value less than zero), or add some separation
(or dead band) between them (SP2 greater than zero). Adjust SP2 as
required to optimize control.

Rev. 10/98 13 949-1239-3
PROGRAMMING AND OPERATION
FOR RAMP / SOAK FEATURE
Theramp/soakfeatureoffersagreatdealofflexibilitybyallowingchanges
in the set point to be made over a predetermined period of time.
Theory of Operation
The 1600 Series controls offer a very simple approach to programming a
ramp. Rather than requiring the operator to calculate an approach rate
(usually in degrees per minute), the 1600 does the calculation internally.
Thus, the operator only needs to program the target set point, the time
desiredto reachthatpoint,andthetimedesiredtoholdatthatpoint. When
therampsegmentisexecutedbythecontrol,itcalculatestheramprequired
to move the process from the starting value (current PV) to the desired
value (programmed SP) in the time allowed.
Care must be taken, however, that the process does actually reach the
soak value before the soak time starts. Make sure to test any program for
desired results before running production material.
Do not operate Self Tune while a ramp function is operating. The
ramp function will prevent the Self Tune from operating properly.
Make sure that all tuning is set up before operating Ramp / Soak.
Program Setup
The programming for the Ramp / Soak function is done in the Secondary
Menu.
In the Secondary Menu INDEX to Prog and make sure that Prog is set to
OFF.
Skip the StAt setting (this is discussed later) and press INDEX to 1rt.
Set 1rt to the amount of time you want for the ramp. This value is in time
units from 00.01 to 99.59 (hh,mm). Press INDEX.
Set 1St to the amount of time you want for the soak. This value is in time
units from 00.01 to 99.59 (hh,mm). Press INDEX.
Thelastmenuitemfortheramp/soakfunctionisPEnd. PEnddetermines
what the control does when the program has ended. You may choose to
Hold the set point (SP1), or turn the outputs off (OoFF).

949-1239-3 14 Rev. 10/98
Ramp / Soak Operation
Whenyouwishtostarttheprogram,entertheSecondaryMenuandsetthe
Prog menu item to On. Return to the HOME position by waiting for the
display to time out or by pressing the UP ARROW / ENTER keys and then
the DOWN ARROW / INDEX keys.
Changing the AUTO / MANUAL menu item to Auto OFF will also suspend
the program operation. This also puts the control into manual mode.
Auto / Manual Control
Manual Control is enabled through the Secondary Menu. When Auto is
turnedOn,thelowerdisplay in the HOMEpositionwilldisplaytheoutput in
percentforSP1or SP2,andisadjustable for eachfrom0.0to 100 percent.
SP1 appears first with a flashing “o”on the right hand corner of the lower
display to represent percent. Press INDEX to display SP2 output. A
flashing "õ" will appear on the right hand corner of the lower display to
represent percent.
When Manual is enabled, the present control outputs are held (bumpless
transfer) and displayed. The output for SP1 or SP2 can then be manually
adjusted while displayed by pressing the UP ARROW or DOWN ARROW
key to change the value, and then the ENTER key to activate.
The Upper display will normally indicate the Process Value. Since Manual
will override most fault messages the upper display could indicate a fault
message. Refer to the Diagnostic Error Message Section for further
explanation.

Rev. 10/98 15 949-1239-3
MENU SELECTIONS
PRIMARY MENU
Press INDEX to scan the Lower Display. Press UP ARROW or DOWN
ARROW to change the value in the upper display.
Inthefollowingthesymbol"#"willbeusedbeforealettertoindicatetheset
point value to be viewed and/or modified. (Applies to Option 948 only.)
#SP1 (948) or
SP1 Set Point 1, Main Control Point.
SP2 Set Point 2, if equipped.
SECONDARY MENU
Hold UP ARROW & ENTER. Press INDEX to scan the Lower Display.
Press UP ARROW or DOWN ARROW to change the value in the upper
display.
Auto Auto/Manual Control: Select On or OFF.
On Automatic Control
OFF Manual Control is enabled. The lower display in the
HOMEpositionwilldisplaytheoutputinpercentforSP1
or SP2, and is adjustable for each from 0.0 to 100
percent.SP1appearsfirstwithaflashing“o”ontheright
hand corner of the lower display to represent percent.
Press INDEX to display SP2 output. A flashing "õ" will
appear on the right hand corner of the lower display to
representpercent. WhenManualisenabled,thepresent
control outputs are held (bumpless transfer) and dis-
played.TheoutputforSP1orSP2canthenbemanually
adjusted while displayed by pressing the UP or DOWN
Arrow key to change the value, and then the ENTER
key. The Upper display will normally indicate the Pro-
cess Value. Since Manual will override most fault mes-
sagestheupperdisplaycouldindicateafaultmessage.
Refer to the Diagnostic Error Message Section for
further explanation.
ALLo AlarmLow:TheLowAlarmpointisusuallysetbelowtheMainSet
Pt.
ALHi Alarm High: The High Alarm Point is usually set above the Main
Set Pt.

949-1239-3 16 Rev. 10/98
SP Activesetpoint(948):Select1SP1,2SP1,3SP1,or4SP1. Allows
setting of the multiple stages of SP1, and SP1 tuning constants.
#SP1 Set Point Value # (948): Select desired value.
#tun (948) or
tunE Tuning Choice: Select SELF, Pid, SLO, nor, or FASt.
SELF The Controller will evaluate the Process and select the
PID values to maintain good control. Active for SP1
only.
Strt Select YES or no
YES Start Learning the Process. After the
process has been learned the menu
item will revert to no.
no Learning will stay in present mode.
LErn Select Cont or End
Cont ContinuouslyadjustthePIDvaluesto
maintain the best control. The Pro-
cessisbeingmonitoredatalltimesby
collecting and analyzing the data to
adjust the PID values. (adaptive con-
trol).
End The Process data is collected once
and then the PID values are saved,
tuning is stopped.
dFAC Damping factor, Select OFF, 1 to 7. Sets the
ratioofRateto ResetfortheSELF tunEmode.
7 = most Rate. Factory set to 3. For a fast
responseprocessthevalueshouldbelowered
(less Rate). For a slower process the value
should be increased (more Rate).
Pid Manually adjust the PID values. PID control consists of
three basic parameters, Proportional Band (Gain), Re-
set Time (Integral), and Rate Time (Derivative).
#Pb1 (948) or
Pb1 Proportional Band (Bandwidth). Select 6to
5000 °F, 3 to 2778 °C, or 6 to 9999 counts.
Pb2 Proportional Band (Bandwidth). Select 6to
5000 °F, 3 to 2778 °C, or 6 to 9999 counts.
(Appears after #rtE when Option 948 is se-
lected.)
#rES (948) or
rES AutomaticResetTime.SelectOFF,0.1to99.9
minutes. Select OFF to switch to OFS.
#OFS (948) or

Rev. 10/98 17 949-1239-3
OFS Manual Offset Correction Select OFF, 0.1 to
99.9%. Select OFF to switch to rES.
#rtE (948) or
rtE RateTime. SelectOFF,0.01 to99.99minutes,
Derivative.
SLO PID values are preset for a slow response process.
nor PID values are preset for a normal response process.
FASt PID values are preset for a fast response process.
Pid2 Linkage of PID parameters between SP1 and SP2: Select On or
OFF.
On Links SP2 to SP1 or #SP1 rEs and rtE terms for heat/
cool applications.
OFF Sp2 functions without rEs and rtE.
ArUP Anti- Reset Wind-up Feature: Select On or OFF.
On When ArUP is On the accumulated Reset Offset value
willbeclearedto0%whentheprocessinputisnotwithin
the Proportional Band.
OFF When ArUP is OFF, the accumulated Reset Offset
Value is retained in memory when the process input is
not within the Proportional Band.
ArtE Approach Rate Time: Select OFF, 0.01 to 99.99 minutes. The
function defines the amount of Rate applied when the input is
outside of the Proportional Band. The ArtE time and the rtE
time are independent and have no effect on each other. To
increase damping effect and reduce overshoot set the approach
rate time for a value greater than the natural rise time of the
process (natural rise time = process value time to set point).
Fint Fuzzy Logic Intensity(942): Select 0 to 100%. 0% is OFF
(disables Fuzzy Logic). The function defines the amount of
impact Fuzzy Logic will have on the output.
Fbnd Fuzzy Logic Error Band(942): Select 0 to 4000 °F, 0 to 2222°C,
or 0 to 4000 counts. Sets the bandwidth of the Fuzzy Logic. Set
Fbnd equal to PID proportional band (Pb1) for best results.
FrtE Fuzzy Logic Rate of Change(942): Select 0.00 to 99.99°F/sec.,
0.00 to 55.55°C/sec., or 0.00 to 99.99 counts/sec. For best initial
setting, find the degree/sec change of process value near set
point 1 with output ON 100%. Multiply this value by 3. Set FrtE
to this calculated value.

949-1239-3 18 Rev. 10/98
PEA Peak and Valley feature will remember the Highest (PEA) and
lowest (VAL) Input the Instrument has had since the last reset or
Power On. At Power On they are reset to the present input, and
VAL therefore may have to be manually reset. To manually reset
thevalue,PEAorVALmustbeinthelowerdisplayandthenpress
theENTER key.ThiswillcausetheItemtoberesettothepresent
input value.
Inthefollowingthesymbol"#"willbeusedfollowingletterstorefertoeither
anumber"1"ornumber"2". The "1" will relate to SP1functions,the"2"for
SP2. If your control is not equipped with a second set point, no SP2
functions will appear. The appearance of CY#,SP#d, or PUL# is
dependent upon the output type selected in the Secure Menu item S#Ot.
If time proportioning (cycle time) was selected, then CY# is adjustable. If
On-Offwasselected,thenSP#disadjustable.Ifpulsedtimeproportioning
was selected then PUL# is adjustable. If none of the above are selected
the menu indexes directly to S#Ot.
CY# Cycle Rate: Select 2 to 80 sec. Time Proportioning Control is
adjustable in 2 sec. steps. For best contact life, a time should be
selected as long as possible without causing the process to
wander.
SP#d Set Point On-Off Differential. Select 1 to 1999 deg. or counts.
When adjusting SP#d keep in mind that SPL and SPH have to be
considered to avoid a CHEC error message.
PUL# Pulsed Time Proportioning Output: Select 1to 7. 1 = Linear and
7 = most non-linear. Changes output linearty for use in cooling
applications or for an extremely fast response processes. At the
center of the proportional band, a pulse value of 1 provides an
outputofonesecondonandonesecondoff(50%output). Apulse
value of 2 provides an output of one second on and two seconds
off(33%output). Outputatcenterofbandequalsonesecondon,
2(pulse value-1) seconds off.
OUTPUT
0
REVERSE ACTING (S#St = rE)
(DOWNSCALE DIFFERENTIAL)
INPUT
SP# (DISPLAYED VALUE)
DIFF.
(SP#d)
OUTPUT
0 INPUT
SP# (DISPLAYED VALUE)
DIFF.
(SP#d)
DIRECT ACTING (S#St = dir)
(UPSCALE DIFFERENTIAL)

Rev. 10/98 19 949-1239-3
S#Ot Set Point Output Type. FT, Curr, or Volt.
Ft refers to Fast Time Proportioning, for Solid State Relay
or 5V Logic Outputs. Timing is fixed at 1 sec.
Curr refers to Proportional Current Output of 0 to 20 mA.
Volt refers to Proportional Voltage Output of 0 to 10 V.
BothCurr&VoltareselectedbytheHardware Configu-
ration Code and cannot be changed.
PctO Percent Output Feature: Select On or OFF.
On When selected On, the HOME lower display will indi-
cate the output of the controller in percent. An “o”will
appear in the right hand side of the lower display to
indicate percent output for SP1. An "õ" will appear on
the right hand corner of the lower display to represent
percent output for SP2. The display will alternate
between these values.
OFF Percent Output display is disabled.
Prog Ramp/Soak Feature: Select On or OFF
StAt Status Display in the HOME Position when Prog (above) is On:
Select On or OFF. When selected OFF, the HOME display will
alternatelyindicatethenormalHOMEandtheRamp/Soakpartial
statusintheLowerDisplay.Thepartialstatusdisplaysequences
with the set value showing the ramp (S1rA) or soak (S1So)
segment being processed at that moment. It will also show the
Program output status if at Hold or OoFF.
WhenselectedOn,theHOMEDisplaywillalternatelyindicatethe
normal HOME and the Ramp/Soak full status in both the upper
andlowerdisplays. The fullstatusdisplay sequences withtheset
value; Program run, Hold, or OoFF; and with the time remaining
for the ramp S1rA or the soak S1So segments.
1rt Ramp Time in Hours & Minutes: Select 0.00 to 99.59 (HH.MM).
1St Soak Time in Hours & Minutes: Select 0.00 to 99.59 (HH.MM).
PEnd End of Soak action: Select Hold or OoFF.
Hold Stay at the Present Set Pt.
OoFF Turn Off SP1 and SP2 Outputs at the End of the Soak.
InPC Input Correction: Select ±500 °F(±260 °C)or±1000 counts. This
feature allows the input value to be changed to agree with an
external reference or to compensate for sensor error. When
setting values having one or more decimal points, the lowest
negative value allowed is -199.9, -19.99, or -1.999. Note: InPC
