The Series DW-WIFI Wireless Wi-Fi Data Logger measures and
records up to 1,000,000 temperature and/or humidity readings and
shares the data with any PC or server on the same Wi-Fi network.
Software settings allow the user to set the high and low alarms, the
sampling rate, and the temperature scale. If the Wi-Fi connection is lost,
the sensor will continue to store any records until it can regain
communication with the network. Stored data can be viewed at any time
after the communications have been restored. Each data logger includes
a wall bracket that allows the data logger to be mounted to any wall or
flat surface.
SOFTWARE INSTALLATION/LOGGER SET-U
Upon start-up, a reading may be displayed on the CD; however, the
product set-up must be completed in order to connect to a Wi-Fi network.
1. Before connecting the unit, download the free configuration and
logging software for this series, which is available on our website,
http://www.dwyer-inst.com/DW-USBSoftware.
2. After the software is installed, plug the data logger into the PC’s USB
port using the supplied cable and open the software.
3. Click on the “Set-Up Sensor” button.
4. Click on your Wi-Fi network and enter your password, if required.
Series DW-WIFI Wireless Wi-Fi Data Logger
Installation and Operating Instructions
Bulletin C-DW-WIFI
S ECIFICATIONS
Range:
Temperature:
DW-WIFI-T(-HA), DW-WIFI-TH(-HA): -4 to 140°F (-20 to 60°C);
DW-WIFI-TP(-HA): -40 to 257°F (-40 to 125°C);
DW-WIFI-TC:
Supplied K-Type Thermocouple: 32 to 752°F (0 to 400°C);
Full Range (Probe Dependent): -454 to 2372°F
(-270 to 1300°C);
Humidity (TH models only): 0 to 100%.
Accuracy (typ.):
Temperature:
DW-WIFI-T: ±1.0°F (±0.5°C) @ 14 to 122°F (-10 to 50°C);
DW-WIFI-TH: ±0.6°F (±0.3°C) @ 41 to 140°F (5 to 60°C);
DW-WIFI-TP: ±1.2°F (±0.6°C) @ 14 to 158°F (-10 to 70°C);
DW-WIFI-TC: ±3.0°F (1.5°C);
DW-WIFI-T-HA: ±0.2°F (±0.1°C) @ 14 to 140°F (-10 to 60°C);
DW-WIFI-TH-HA: ±0.4°F (±0.2°C) @ 41 to 140°F (5 to 60°C);
DW-WIFI-TP-HA: ±0.2°F (±0.1°C) @ 14 to 158°F (-10 to 70°C);
Humidity (TH models only):
DW-WIFI-TH: ±2.5% RH @ 20 to 80% RH;
DW-WIFI-TH-HA: ±2.5% RH @ 10 to 90% RH.
Display Resolution:
Temperature:
DW-WIFI-T, DW-WIFI-TP, DW-WIFI-TC: 0.1°F (0.1°C);
DW-WIFI-TH(-HA): 0.5°F (0.5°C);
DW-WIFI-T-HA, DW-WIFI-TP-HA: 0.01°F (0.01°C).
Humidity (TH models only): 1.0% RH.
Memory Size: 1,000,000 readings; 500,000 each for DW-WIFI-TH(-
HA).
Sampling Mode: Continuous recording.
Sampling Rate: Selectable from 10 s to 12 hrs.
Transmission Rate: Selectable from 1 min to 24 hrs.
Temperature Limits: -4 to 140°F (-20 to 60°C).
ower Requirements: 4.5 to 5.5 VDC; (1) 3.7 V rechargeable lithium
ion battery, installed functional, factory replaceable (cable for charging
included).
Alarms: Programmable high/low.
Interface: Wi-Fi connection.
robe Length:
DW-WIFI-TP: 11.8 in (30 cm);
DW-WIFI-TC: 59 in (150 cm).
Weight: 7.2 oz (204 g).
Agency Approvals: CE, RoHS.
ALL MODELS
3-7/8
[97.30]
1
[26.36]
2-3/4
[71.30]
DWYER INSTRUMENTS, INC. hone: 219/879-8000 www.dwyer-inst.com
.O. BOX 373 • MICHIGAN CITY, INDIANA 46360, U.S.A. Fax: [phone] e-mail: [email protected]
The logger will arrive partially charged, but for maximum
performance, charge it for 24 hours before the first use.
NOTICE

5. Name your logger and select the temperature scale, sample rate, and
transmission rate.
6. Set high and low alarms.
DIS LAY
On the home screen, the models show the current temperature and
humidity reading. Models DW-WIFI-T, DW-WIFI-TP, and DW-WIFI-TC
display the temperature only. DW-WIFI-TH displays temperature and
humidity on the same screen.
By pressing the button, the logger will cycle through the different
screens, which are:
1. Home Screen – Current temperature and/or humidity
2. Maximum Recorded Value
3. Minimum Recorded Value
4. Signal Strength
5. Data Syncing
To view detailed information and graphical data, open the configuration
software and click on the “View Sensors” icon.
Other icons shown on the home screen include network connection,
alarm, max/min, and battery.
Network Connection:
Not Displayed: The logger has not yet been set up and configured to a
Wi-Fi network.
Flashing: The logger is not communicating with the software.
Solid: The logger is successfully communicating with the software.
Max/Min:
Shown on their respective pages.
Both are displayed on home page.
Battery:
Not Displayed: Battery is okay.
Flashing: Battery is low.
Solid: Battery is charging.
CHANGING DATA LOGGER SETTINGS
Open the software package and click on the “View Sensors” icon. Select
the logger you would like to modify settings for and click on the “Adjust
Sensor Settings” icon. The software will guide you through the options
that can be altered.
RECHARGING THE BATTERY
When recharging the battery, connect the data logger to a PC or a 5V
power adapter via the provided USB cable. The battery icon will
disappear when the logger is fully charged.
RE LACING THE BATTERY
If the battery must be replaced, it is required that it be sent to the factory
for replacement. The battery must not be in the unit when it is sent back.
Please follow these directions to remove the battery.
1. Using a size T6 torx screwdriver, remove the four hex screws from
each corner.
2. Remove the back piece, being careful not to tear the white ribbon
connecting the circuit board to the back piece.
3. The battery is connected to the circuit board via a red and a black cord
that are plugged into CON1. Carefully disconnect the battery and
dispose as appropriate.
4. Reassemble the housing as before.
5. Contact customer service to receive a Return Goods Authorization
number before shipping the product back for battery replacement.
MAINTENANCE/RE AIR
Upon final installation of the Series DW-WIFI, no routine maintenance is
required. The Series DW-WIFI is not field serviceable and should be
returned if repair is needed. Field repair should not be attempted and
may void warranty.
WARRANTY/RETURN
Refer to “Terms and Conditions of Sale” in our catalog and on our
website. Contact customer service to receive a Return Goods
Authorization number before shipping the product back for repair. Be
sure to include a brief description of the problem plus any additional
application notes.
©Copyright 2014 Dwyer Instruments, Inc. Printed in U.S.A. 4/14 FR# R1-444114-00 Rev. 3
DWYER INSTRUMENTS, INC. hone: 219/879-8000 www.dwyer-inst.com
.O. BOX 373 • MICHIGAN CITY, INDIANA 46360, U.S.A. Fax: [phone] e-mail: [email protected]
Settings can be adjusted while connected to the PC or over
Wi-Fi.
NOTICE
Network
Connection
Alarm
Max and Min
Indicators
Battery
Indicator
