Dwyer Instruments HTDL-10 Supplement

Bulletin DA-HTDL-10
DWYER INSTRUMENTS, INC. Phone: [phone] www.dwyer-inst.com
P.O. BOX 373 • MICHIGAN CITY, INDIANA 46361, U.S.A. Fax: [phone] e-mail: [e-mail]
Specifications - Installation and Operating Instructions
Model HTDL-10 High Temperature Data Logger
The Model HTDL-10 is a high temperature data logger that can
handle being placed in conditions of extreme heat of up to 302°F
(150°C). This submersible and portable data logger can record
over 32,000 measurements and has a 2 inch rigid external probe
to ensure fast and accurate temperature readings. The easy to use
DL700 software makes retrieving data simple. The HTDL-10 can
easily be started and stopped from a PC or delayed to start up to
six months in advance.
SPECIFICATIONS
Range: -40 to 302°F (-40 to 150°C).
Memory Size: 32,767 readings.
Accuracy: ±0.9°F (±0.5°C).
Resolution: 0.1°F (0.05°C).
Sampling Method: Stop on memory full or continuous
recording.
Sampling Rate: Selectable from 1 sec to 12 hrs.
Computer Requirements: Windows® 95, Windows® 98, Windows®
2000, Windows® ME, Windows NT®, and Windows® XP operating
system, one free USB port.
Power Requirements: Factory replaceable, 3.9 V high-
temperature lithium battery.
Battery Life: 1 year (approx).
Interface: USB port (interface cable required).
Material: 316 Stainless Steel.
Weight: 8 oz (227 g).
Agency Approvals: CE.
Windows® and Windows NT® are registered trademarks of Microsoft.
3-3/64
[77.30]
1-11/32
[34.29]
1-3/64
[26.67]
29/64
[11.51]
Ø1-3/4
[44.45] Ø19/32
[15.24]
Ø7/64
[2.71]
Ø13/64
[5.25]
1/8˝ JACK FOR USB
INTERFACE CABLE
UNDER CAP
DA-HTDL-10:TEMPLATE 12/4/08 2:30 PM Page 1

©Copyright 2008 Dwyer Instruments, Inc. Printed in U.S.A. 9/08 FR# R6-443682-00
DWYER INSTRUMENTS, INC. Phone: [phone] www.dwyer-inst.com
P.O. BOX 373 • MICHIGAN CITY, INDIANA 46361, U.S.A. Fax: [phone] e-mail: [e-mail]
Before the device is submerged, screw on the cap tightly to make
sure that the logger is properly sealed.
SOFTWARE INSTALLATION
1. Insert installation CD and click Install Dwyer 2.00.
2. Follow onscreen instructions.
3. Next, click Install USB Interface Drivers on the CD Contents
screen.
4. Click Install.
A message may appear stating that the software has not passed
Windows Logo Testing. This software has been tested and works
properly. Click Continue anyway if this window appears.
CONNECT THE LOGGER
1. Remove the Warning sticker from the USB Data Logger
Interface converter to uncover the female end of the jack.
2. Insert one end of the jack into the USB Data Logger Interface
converter and the other end into the serial port in the data logger.
3. The serial port is located under the cap that is on the face of
the logger. Unscrew the cap and connect the cable.
4. Connect the DL700 USB cord to the PC and connect the other
end to the USB Data Logger Interface converter.
START THE LOGGER
1. To start the logger, from the Communication menu select Auto
Configure Port.
2. From the Device menu select Start Device and choose the
desired Reading Rate, the preferred method for starting the logger,
and the alarm settings.
3. Click the Start button.
Starting the device erases all data currently stored in the logger.
4. The logger will stop recording when the device is full or when
Stop Device is selected from the Device menu.
DOWNLOAD DATA
1. To download data, connect the logger to the PC.
2. From the Device menu select Read Device Data.
3. Data is then presented graphically.
**For more detailed information on using the DL700 software,
please consult the Software Manual.
BATTERIES
The battery is factory replaceable, and the typical battery life is 1
year. Fast logging will considerably shorten the battery life. To
preserve battery life, it is recommended to use the longest
practical sampling rate, and when the logger is not in use, select
Stop Device from the Device menu.
MAINTENANCE
Upon final installation of the Model HTDL-10 Data Logger, no
routine maintenance is required. The Model HTDL-10 is not field
serviceable and should be returned if repair is needed (field repair
should not be attempted and may void warranty). Be sure to
include a brief description of the problem plus any relevant
application notes. Contact customer service to receive a Return
Goods Authorization number before shipping.
