1-of-8 Control Console
DXE-EC-8
DXE-EC-8-INS-Revision 1
©DX Engineering 2012
P.O. Box 1491 ⋅Akron, OH 44309-1491 USA
Phone: [phone] ⋅Technical Support and International: [phone]
Fax: [phone] ⋅E-mail: [email protected]

- 2 -
Introduction
The DXE-EC-8 is a flexible 8 position controller used to control the DX Engineering RR8A series antenna
switches or any other product that uses a 12 to 24 Vdc 1-of-8 control format.
The DXE-EC-8 offers the following features:
•Stainless Steel Housing
•Non-Skid feet
•On-Off toggle switch
•Green LED indicates power is applied
•Filter capacitors on each line
•Internal automatic resettable fuse
•Includes a 2.1 mm power plug for DC power connection
Front and Rear Panels
On/Off toggle switch Control Wire Feed Through
Green LED Power Connection
8 Position Rotary Switch
The DC Input used in most applications will be +12 Vdc. You can input up to 24 Vdc if your
application requires 24 Vdc switching. A 2.1 mm power cord is supplied with unit. The wire with
the white stripes is the +12 Vdc.
Outer Connection is GROUND, Center Pin is +12 VDC.
If station power is used, it must be +12 Vdc at 1 amp (fused) minimum. An optional
DXE-PSW-12D1A 120 Vac 60 Hz to 12 Vdc 1 Amp, fused wall transformer supply is
available.
Tools Required
Phillips Head Screwdriver
Wire Stripper
Small Flat Blade Screwdriver
Overall Size
Interior Connections
1. Open the unit by removing the four (two per side) Phillips head screws to remove the cover.

- 3 -
2. Push the end of the cable through the control wire feed through on the rear of the unit.
3. Connections for the wire are made on header "H1". Loosen each terminal screw until it is near
flush with the top of the connector block as shown below.
4. Strip approximately 1/4" insulation from the 9 conductor wire ends
as shown to the right.
5. Connect each wire to a terminal by sliding the wire completely into the wire connection hole.
Using a small flat blade screwdriver, tighten the associated screw until the wire is firmly
gripped in place as shown below.
Take caution to ensure just the wire is clamped in place, not the wire's insulation which would cause an open
or intermittent connection. Do not over tighten the screw so much that the wire is cut instead of being firmly
gripped. Use the included Tye-Wrap on the inside of the unit to hold the cable from pulling outward as
shown above.
DXE-CW9S Shielded cable is recommended. The drain wire (bare wire) is used as the signal ground return.
Both of the "G" connections are internally tied together. When connecting the cable to the DXE-EC-8,
ensure your cable is wired the same way at the other end to avoid un-necessary troubleshooting. Use the
chart below to record which color wire is connected to each terminal connection. The selected position will
supply the DC voltage that is connected to the DXE-EC-8.
Connector Wire Reference Chart
G 1 2 3 4 5 6 7 8 G
Control lines (usually BCD ) can normally use good quality CAT5e cable (4 twisted pairs of 24
AWG wire) for runs up to 1000 feet. Typical DX Engineering BCD control lines requirements are
+12 VDC at 25 milliamps. Depending on the number of control lines needed (usually 3 or 4) you
can double up the twisted pairs of CAT5e cable, or use control wire that is at least 22 AWG,
allowing runs up to 1500 feet. If you use a cable with more conductors, it is a good idea to tie the

- 4 -
unused conductors to ground. For longer runs of control cable, use a line loss calculator to ensure
you supply the proper control levels needed.
Approximate BCD Control Line Lengths.
Minimum Copper
Wire Gage (AWG) Length
24 1,000 feet
22 1,500 feet
20 2,000 feet
Optional Items
DXE-CW9S - Shielded Control Wire, 9 conductor stranded, per foot
DXE-CW9S is a high quality shielded outdoor cable. It features 9 copper #24 AWG stranded conductors with
aluminum foil shielding plus a #24 stranded tinned copper drain wire. This gives you 8 switch positions plus
common ground - plus the separate shield. It has a gray PVC jacket. This cable is ideal for DX Engineering Remote
Antenna Switches and Four Square arrays, and should be considered for any low-current custom remote switching
application you have - such as receiving antenna arrays. Order by the foot in the length you require. Price shown is
per foot. A nice feature is the "rip cord", which allows for easy stripping of the heavy jacket without worry about nicking or
accidentally cutting the conductors.
AC Adapter 12VDC/1000mA - DXE-PSW-12D1A
The DXE-PSW-12D1A is an AC Wall Transformer Adapter to furnish 12 Volts DC at 1000 mA from 120 Vac 60 Hz
input, fused output. It features a standard 2.1 mm plug connection for 12 Vdc. Outer connection is GROUND Center
Pin is input for +12 VDC. Ideal separate power source for DX Engineering Antenna Switch and Transmit Four Square
Controllers, NCC-1, TVSU, DXE-MBV-ATU-1 Remote Antenna Tuner Kit and most MFJ automatic antenna tuners
