Dyna-glo Ra100ngdgd Instructions for use

—

Printed in China

Unpacking

1. Unpack all materials used to protect

the heater inside of carton. Retain

plastic caps attached to exposed

fittings for use during storage.

2. Remove heater, accessories and all

hardware from carton.

3. Inspect all items for damage that may

have occurred during shipment.

General Safety Information

Make sure you read and thoroughly

understand these safety and operating

instructions. Keep these instructions for

future reference. They are your guides

to safe and proper operation of this

heater.

Safety information appears throughout

this manual. Pay close attention to

them. Below are definitions for the

safety information listed throughout

this manual.

Indicates an

imminently

hazardous situation which, if not

avoided, WILL result in death or serious

injury.

Indicates a poten-

tially hazardous

situation which, if not avoided, COULD

result in death or serious injury.

Indicates a poten-

tially hazardous

situation which, if not avoided, MAY

result in minor or moderate injury.

Not for home

or recreational

vehicle use.

GENERAL

HAZARD

WARNING:Failure to comply with the

precautions and instructions provided

with this heater can result in death,

serious bodily injury, and property loss,

or damage from hazards of fire,

explosion, burn, asphyxiation, carbon

monoxide poisoning, and/or electrical

shock. Only persons who can

understand and follow these

instructions should use or service this

heater. If you need assistance or heater

information such as an instruction

manual, labels, etc., contact your local

manufacturer.

Consumer: Retain this manual for

future reference.

Dyna-Glo®Delux Natural

Gas Radiant Heaters

Operating Instructions & Parts Manual RA100NGDGD and RA250NGDGD

Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described. Protect yourself and

others by observing all safety information. Failure to comply with instructions could result in personal injury and/or property damage! Retain instructions for

future reference.

Description

Dyna-Glo Delux Models RA100NGDGD and RA250NGDGD heaters are 50,000 to

100,000 and 250,000 BTU/Hr construction heaters. These heaters use natural gas for

combustion. They are primarily intended for temporary heating of well-ventilated

buildings under construction, alteration or repair. These heaters should be utilized

in sheltered, well-ventilated areas, but never in occupied dwellings.

Fuel Consumption Min. Gas Max. Gas Manifold Ignitor Size

Model BTU/Hr Maximum Supply Pressure Supply Pressure Pressure Gap Weight (Lbs) L x W x H (in.)

RA100NGDGD 50,000 to 5.1 lbs 8” W.C. 14” W.C. 7.5” W.C. 0.19“ 18.7 (heater) 16.3 x 16.3 x 29.8

100,000

RA250NGDGD 250,000 12.8 lbs 10 PSI 250 PSI 6 PSI 0.19” 30.8 (heater) 14.7 x 14.7 x 44.3

Fuel Type – Natural Gas Only Ignition Type – Piezo (RA100NGDGD) Minimum Operating Temp. – -20°F (-29°C)

Pilot (RA250NGDGD)

Specifications

GHP Group, Inc.

6440 W Howard St

Niles, IL 60714

ANS Z83.7b-2009 CSA 2.14b-2009 Construction Heater

C US

Figure 1 – Models RA100NGDGD / RA250NGDGD

PROFESSIONAL GRADE

Rev. 2013-06-13

General Safety Information

(Continued)

GENERAL HAZARD

WARNING: Failure

to comply with the precautions and

instructions provided with this heater can

result in death, serious bodily injury, and

property loss, or damage from hazards of

ﬁre, explosion, burn, asphyxiation, carbon

monoxide poisoning, and/ or electrical

shock. Only persons who can understand

and follow these instructions should use or

service this heater. If you need assistance

or heater information such as an

instruction manual, labels, etc. contact the

manufacturer.

FIRE, BURN,

INHALATION AND

EXPLOSION HAZARD: Keep solid

combustibles such as building materials,

paper, or cardboard, at a safe distance

away from heater

as recommended by the instructions.

Never use the heater in spaces which do

or may contain volatile or airborne com-

bustibles or products such as gasoline,

solvents, paint thinner, dust particles, or

unknown chemicals.

Not for home or

recreational vehicle

use.

This heater has been designed as a

construction heater in accordance with

ANS Z83.7 CSA 2.14. Other standards

govern the use of fuel gases and heating

products for specific uses. Your local

authority can inform you of these. The

primary purpose of these construction

heaters are to provide temporary

heating of building under construction,

alteration, or repair. When properly

used, the heater provides safe

economical

heating. Products of combustion are vented

into the heated area.

- For either indoor or outdoor use.

Adequate ventilation must be

provided.

Combustible

byproducts produced

when using this product contain carbon

monoxide, a chemical known to the State of

California to cause cancer, birth defects, or

other reproductive harm.

IMPORTANT: Every possible

circumstance that might involve a

hazard cannot be anticipated. The

warnings in this manual on tags or

decals affixed to the unit are not all

inclusive. If a procedure, work method,

or operating technique not specifically

recommended by Dayton is used, you

must make sure it is safe for you and

others. You should also ensure that

equipment will not be damaged or

be made unsafe by the operating or

maintenance method you use.

Carbon Monoxide

poisoning may lead to

death! Some people are more affected by

Carbon Monoxide than others. Early signs

of carbon monoxide poisoning resemble

the flu, with headaches, dizziness, and/or

nausea. If you have these signs, the

heater may not be operating properly or

the area may not be sufficiently

ventilated. Get fresh air at once! Have

heater serviced.

Carefully install and

always use great care

when operating this heater. Be sure to

research and follow all local ordinances

and codes. In the absence of local codes,

with the Standard for the Storage and

Handling of Liquefied Petroleum Gases,

ANSI/NFPA 58 and the Natural Gas and

Propane Installation Code CSA B149.1.

Natural Gas: Natural gas has a very

distinctive odor that will help you

detect a leak. However, this odor

may fade in time. Natural gas may be

present in the area even though no

odor is detected.

– Use only natural gas. Do not attempt

to use propane gas. Use only factory

preset regulator provided on heater.

– Provide adequate ventilation. Before

using heater, provide at least a 3

square foot opening of fresh, outside

air for every 100,000 BTU/Hr rating.

California

Proposition 65

Warning: Fuels used in gas or oil ﬁred

appliances and the products of

combustion of such fuels, contain

chemicals known to the State of

California to cause cancer, birth defects

or other reproductive harm. This product

contains chemicals, including lead and

lead compounds, known to the state of

California to cause cancer, birth defects

or other reproductive harm. Wash hands

after handling.

– This heater should be utilized in

sheltered, well-ventilated areas, but

never in occupied dwellings.

– Do not use heater in occupied

dwellings, in living or sleeping areas.

– Do not use heater in basement or

below ground levels. If a leak occurs,

gas may accumulate to hazardous

amounts.

– Keep appliance clear and free from

combustible materials, gasoline, paint

thinner, and other flammable vapors

and liquids. Dust is combustible. Do

not use heaters in areas with high

dust content.

Dyna-Glo®Delux Natural Gas

Radiant Heaters

RA100NGDGD and RA250NGDGD

Dyna-Glo Delux Operating Instructions and Parts Manual

For Technical Support or Troubleshooting, Call: 1-877-447-4768, 8:00 am - 5:00 pm CST www.ghpgroupinc.com

NEVER LEAVE THE HEATER

UNATTENDED WHILE BURNING!

General Safety Information

(Continued)

– Check heater for damage before each

use. Do not use damaged heater.

Minimum heater clearance from

combustibles:

Sides: 6 feet Top: 5 feet

Floor: Combustible - Not for use

on finished floors

– The heater, other than a heater with

integral propane gas container, must

be located at least 6 feet (in Canada,

distance must be 10 feet) from any

propane gas container.

– Blower or radiant type heaters shall

not be directed toward any propane

gas container within 20 feet (6 m).

– Check hose before each use of heater.

Do not use if hose is cut or damaged.

Replace with hose specified by

manufacturer.

– Always be sure to place the heater on

a stable and level surface while the

heater is in operation.

– The heater is not intended for use

on finished floors. Warping or other

damage may occur.

– Place heater away from any breezes

or drafts. Keep away from dripping

water or rain.

– Keep small children and animals away

from the heater.

– Never handle, move or service a hot or

operating heater. Wait 20 minutes after

turning heater off before touching the

heater. Severe burns can result.

– Always wear gloves when handling

the heater to prevent injury.

– Never attach ductwork to heater.

– Do not alter heater. Keep heater in its

original state.

– Do not use heater if altered.

– Turn off gas supply to heater when

not in use.

– Use only original replacement parts.

This heater must use design specific

parts. Do not substitute or use generic

parts. Improper replacement parts

could cause serious or fatal injury.

Assembly

MODEL RA100NGDGD

1. Provide natural gas supply system.

2. Install plumbing to a low pressure

natural gas source to heater. The

source must be regulated to 1/2 PSI,

maximum 3/4 inch I.D. pipe or flexible

connector, not longer than 10 feet.

3. Be sure to use thread sealing

compound when connecting the hose

to the heater at the 1/2 NPT fitting at

the regulator inlet. Tighten all fittings

with a wrench.

4. Open natural gas supply valve

SLOWLY.

5. Check all connections for leaks.

Never use an open

flame to check for a

leak. Apply 50/50 mixture of liquid soap

and water to all joints. Bubbles forming

show a leak. Correct all leaks at once.

6. Close natural gas supply valve.

MODEL RA250NGDGD

1. Insert AA battery (included)

into ignition by turning

COUNTERCLOCKWISE and

unscrewing ignition cap.

2. Provide natural gas supply system.

3. Install plumbing to a low pressure

natural gas source to heater.

4. Connect gas supply to heater using

minimum 3/8” ID pipe. Maximum

pipe length is 10 feet.

5. Connect hose or plumbing to 1/2”

NPT flare fitting at the valve inlet.

Tighten all fittings with a wrench.

6. Open natural gas supply valve

SLOWLY. Check all connections for

leaks. Never use an open flame to

check for leaks.

7. Close natural gas supply valve.

NOTE: Keep hands and face away from

outlet (around top of shelf) of heater

while attempting to start heater.

Models RA100NGDGD and RA250NGDGD

Dyna-Glo Delux Operating Instructions and Parts Manual

Figure 2 – Pipe and Valve Inlet

Figure 3 – Heater Control Knob –

RA100NGDGD

PROFESSIONAL GRADE

For Technical Support or Troubleshooting, Call: 1-877-447-4768, 8:00 am - 5:00 pm CST www.ghpgroupinc.com

NEVER LEAVE THE HEATER

UNATTENDED WHILE BURNING!

Operation

Hot while in

operation. Do not

touch. Keep children, clothing, furniture,

gasoline, and other liquids having

flammable vapors away.

The gas supply attaches to the heater by

a minimum 3/8 inch I.D. pipe or flexible

connector. User must supply pipe or

flexible connector. The length should be

no more than 10 feet. The natural gas

moves through the regulator and out

the nozzle.

Ignition System: The ignitor initiates

a spark which ignites the gas from the

main burner.

Automatic Control System: This

system causes the heater to turn off if

the flame is extinguished.

TO START HEATER (RA100NGDGD)

1. Follow all of the safety, ventilation

and installation instructions

previously noted in this manual.

2. Always be sure to place the heater on

a stable and level surface while the

heater is in operation. Be sure that no

strong winds blow into the ends of

the heater.

3. Turn control knob CLOCKWISE

to “OFF” position.

4. Turn natural gas supply valve on.

5. Depress heater control knob and turn

counterclockwise to “(IGN) LOW”

position to light burner (see Figure 3).

6. If burner does not light, turn heater

control knob to “OFF” position and

repeat step 5. Keep control knob

depressed for approximately 10 to 15

seconds, then release control knob.

7. If burner flame goes out, wait 5

minutes then repeat steps 5 and 6.

8. With burner operating, the control

knob may be turned counter-

clockwise to desired heating level

between “LOW,” “MED,” and

“HIGH.”

TO SHUT DOWN HEATER

1. Shut off the main burner valve, being

sure to wear a glove for protection.

Turn the control knob to the “OFF”

position.

2. Firmly close the natural gas supply

valve.

TO RESTART HEATER

1. Wait five minutes for heater to cool.

2. Follow steps in TO START HEATER

section.

TO START HEATER (RA250NGDGD)

1. Follow all of the safety, ventilation

and installation instructions

previously noted in this manual.

2. Always be sure to place the heater on

a stable and level surface while the

heater is in operation. Be sure that no

strong winds blow into the ends of

the heater.

3. SLOWLY open the gas valve.

4. Push in and hold the automatic

control button (see Figure 4). Push

ignitor button (see Figure 4). You

may need to repeat pushing the

ignitor button several times before

the pilot will light.

NOTE: The gas line may have air in it.

Press in the automatic control button

for about 15 seconds for the air to

pass out of the system. Then push the

ignitor button once again. Once the

pilot lights, keep the automatic control

button pressed in. Release after at least

15 seconds.

5. If pilot does not light, repeat Step 4.

6. When pilot stays lit, fully open the

main burner valve by turning the

handle of the burner valve counter-

clockwise until it stops all the way to

the ON position.

Dyna-Glo®Delux Natural Gas

Radiant Heaters

RA100NGDGD and RA250NGDGD

Dyna-Glo Delux Operating Instructions and Parts Manual

Figure 4 – RA250NGDGD Part Identification

Shell

Emitter

Regulator

Base Chamber

Upper Base

Tubing Outlet Assembly

Control Valve Assembly

Lower Base

Tubing Inlet Assembly

Ignitor

Tubing Pilot Assembly

Pilot Assembly

Nozzle Bracket

Main

Nozzle Flame

Shield

Insulation Ring

Base Shield

Tip Over Switch

Automatic Control Button

For Technical Support or Troubleshooting, Call: 1-877-447-4768, 8:00 am - 5:00 pm CST www.ghpgroupinc.com

NEVER LEAVE THE HEATER

UNATTENDED WHILE BURNING!

Operation (Continued)

NOTE: Arrows on main burner valve

handle show directions for ON and OFF.

TO SHUT DOWN HEATER

1. Firmly close the natural gas supply

valve.

2. Shut off the main burner valve, being

sure to wear a glove for protection.

Turn the main burner handle

CLOCKWISE until it stops all

the way to the “OFF” position.

TO RESTART HEATER

1. Wait five minutes for heater to cool.

2. Follow steps in TO START HEATER

section.

Running heater

below specified gas

pressure may cause flashback. During

flashback, the burner flame is mostly

yellow. The flame will burn inside the

burner tube causing a roaring noise. If

flashback occurs, turn heater off. After

burner tube cools off, restart heater.

NATURAL GAS SUPPLY

You must provide the natural gas supply

along with all pipe and fittings. The

gas supply must be regulated down

to a maximum of 1/2 PSI, and to a

minimum of 6 inches water column.

The supply system must supply 8” WC

min. (RA100NGDGD) for each heater

connected to the system.

Check with your local gas supplier to

properly size all of your supply lines. Be

sure to follow all local codes, or refer to

the Natural Fuel Gas Code Handbook –

NFPA54/ANSI Z223.1, or the Natural Gas

Installation Code – CAN/CSA B149.1.

VENTILATION

A three square foot

opening of fresh

outside air for each 100,000 BTU/Hr of

heater output must be provided to

operate each heater safely. If the proper

ventilation air is not provided, carbon

monoxide poisoning can occur.

Always be sure that the proper

ventilation is being provided before

starting this heater.

FRESH OUTSIDE AIR OPENING

REQUIREMENTS

Heater size Square foot opening

100,000 BTU 3.0

250,000 BTU 7.5

Read and understand

all of the warnings in

the General Safety Information pages of this

manual. They are essential to the safe

operation of this heater. Be sure to follow

all local codes when operating this heater.

Be sure to leak test all

fittings and pipe

connections after installation or repairs. Use

a 50/50 mixture of liquid dish soap and

water. Bubbles forming reveal a leak. You

must repair all leaks at once!

Models RA100NGDGD and RA250NGDGD

Dyna-Glo Delux Operating Instructions and Parts Manual

Figure 5 – RA100NGDGD Part Identification

Shell

Emitter

Spark Plug

Thermocouple

Nozzle Burner

Tubing Outlet Assembly

Flame Shield

Nozzle Burner Bracket

Regulator

Base

Knob

PROFESSIONAL GRADE

For Technical Support or Troubleshooting, Call: 1-877-447-4768, 8:00 am - 5:00 pm CST www.ghpgroupinc.com

NEVER LEAVE THE HEATER

UNATTENDED WHILE BURNING!

Maintenance

Never attempt to

service heater while

it is connected to natural gas supply,

operating, or hot. Severe burns can occur.

1. Always keep heater clean.

2. Inspect heater before each use.

Check connections for leaks. Apply

a 50/50 solution of dish soap and

water. Bubbles forming show a leak

that must be corrected. Correct leaks

at once.

3. Inspect regulator hose assembly

before each use. If hose is highly

worn or cut, replace with hose

specified by manufacturer.

4. Keep appliance area clear and free

from combustible materials, gasoline,

and other flammable vapors and

liquids.

5. Have heater inspected yearly by a

qualified service person.

6. The flow of combustion and

ventilation air cannot be obstructed.

STORAGE

Disconnect heater

from natural gas

supply.

1. Place plastic cover over brass fitting

on inlet connector.

2. Store in a dry, clean, safe place.

3. When taking the heater out of

storage, always check inside the

heater. Small animals or insects may

place foreign objects in the heater.

Keep heater free from foreign objects

and combustible materials.

Dyna-Glo®Delux Natural Gas

Radiant Heaters

RA100NGDGD and RA250NGDGD

Dyna-Glo Delux Operating Instructions and Parts Manual

Symptom Possible Cause(s) Corrective Action

Burner fails to light

Burner lights but goes out

when automatic control

valve button is released

Burn rate is low, emitter

does not glow

Flames are extremely high

and coming from emitter

1. More warm-up time needed

2. Gas pressure is low

3. Thermocouple loose or in need of

replacement

4. Automatic control valve in need of

replacement

1. Main burner valve not completely open

2. Clogged gas orifice

3. Low gas pressure

4. Low gas supply

1. Main burner valve not fully open

2. Plugged gas orifices

3. Low gas pressure

4. Low fuel supply

Unit has been connected to a propane gas

supply instead of natural gas

1. Relight, holding control valve button in for

45 seconds

2. Inspect natural gas supply

3. Tighten, reconnect or replace

thermocouple

4. Replace automatic control valve

1. Completely open main burner valve by

turning control knob to HIGH position

2. Replace gas orifice

3. Check gas supply, regulator function

4. Contact gas supplier

1. Fully open main burner valve by turning

control knob towards HIGH position until it

stops

2. Replace gas orifice

3. Check gas supply, regulator output

4. Consult gas supplier

Check gas source and replace with natural gas

supply

Troubleshooting Chart

NEVER LEAVE THE HEATER

UNATTENDED WHILE BURNING!

RA100NGDGD

Dyna-Glo Delux Operating Instructions and Parts Manual

For Repair Parts, call 1-877-447-4768

Please provide following information:

-Model number

-Serial number (if any)

-Part description and number as shown in parts list

Figure 6 – Repair Parts Illustration for Natural Gas Radiant Heater RA100NGDGD

14 15

NEVER LEAVE THE HEATER

UNATTENDED WHILE BURNING!

Model RA100NGDGD

Dyna-Glo Delux Operating Instructions and Parts Manual

Repair Parts List for Natural Gas Radiant Heater RA100NGDGD

1 Top Cover 5002854 1

2 Guard 2315528 1

3 Emitter 2315519 1

4 Nozzle 2315521 1

5 Nozzle Connector 2315545 1

6 Nozzle Nut 2315546 1

7 Main Gas Tubing Assy (NG) 2315523 1

8 Nozzle Bracket 2315517 1

9 Flame Shield 2315516 2

10 Thermocouple 2201584 1

11 Spark Plug 2201583 1

12 Thermocouple Holder 2315520 1

13 Base 5002851 1

14 Control Knob 2101451 1

15 Control Valve 5050651 1

16 Fitting 2304948 2

17 Tubing Inlet Assy 2315524 1

18 Fitting-Regulator to Tubing Inlet 2315547 1

19 Regulator 2315555 1

20 Regulator Bracket 2315518 1

Reference Part Number for Model:

Number Description RA100NGDGD Quantity

PROFESSIONAL GRADE

For Technical Support or Troubleshooting, Call: 1-877-447-4768, 8:00 am - 5:00 pm CST www.ghpgroupinc.com

NEVER LEAVE THE HEATER

UNATTENDED WHILE BURNING!

Use only original

replacement parts. This

Heater must use design-specific parts. Do

not substitute or use generic parts. Improper

replacement parts could cause serious or

fatal injuries.

WARNING

Figure 7 – Repair Parts Illustration for Natural Gas Radiant Heater RA250NGDGD

RA250NGDGD

Dyna-Glo Delux Operating Instructions and Parts Manual

For Technical Support or Troubleshooting, Call: 1-877-447-4768, 8:00 am - 5:00 pm CST www.ghpgroupinc.com

For Repair Parts, call 1-877-447-4768

Please provide following information:

-Model number

-Serial number (if any)

-Part description and number as shown in parts list

NEVER LEAVE THE HEATER

UNATTENDED WHILE BURNING!

Model RA250NGDGD

Dyna-Glo Delux Operating Instructions and Parts Manual

Repair Parts List for Natural Gas Radiant Heater RA250NGDGD

1 Top Cover 5002854 1

2 Guard 2315554 1

3 Emitter 2315537 1

4 Upper Base 5002853 1

5 Base Cover 2315532 1

6 Lead Wire 2315643 1

7 Tilt Switch 2300186 1

8 Lower Base 5002852 1

9 Blanket 2315539 1

10 Insulation 2315544 1

11 Flame Shield 2315540 1

12 Thermocouple 2201591 1

13 Spark Plug 2201583 1

14 Spark Plug Bracket 2315609 1

15 Bracket 2315520 1

16 Box for Lead Wire 2315535 1

17 Pilot Assy GL250.39 1

18 Pilot Bracket 2315608 1

19 Wind Box 2315610 1

20 Ignition Wire 2201585 1

21 Battery 2300481 1

22 Ignition 2201220 1

23 Regulator 2315513 1

24 Regulator Holder 2315536 1

25 Regulator Connector 2315547 1

26 Inlet Tubing Assy 2315542 1

27 Connector 2315549 1

28 Control Valve 5001423 1

29 Contol Valve Fixing Nut 2305687 1

30 Contol Valve Bracket 2315538 1

31 Ball Valve 2304630 1

32 Ball Valve Connector 2305391 1

33 Pilot Connector 2315548 1

34 Main Tubing Assy 2315550 1

35 Pilot Tubing 2001402 1

36 Base Shield 2315541 1

37 Rubber Ring for Wire 2315543 1

38 Nozzle Bracket 2315533 1

39 Nut 2101008 1

40 Nozzle Connector 2315534 1

41 Nozzle 2315546 1

Reference Part Number for Model:

Number Description RA250NGDGD Quantity

PROFESSIONAL GRADE

For Technical Support or Troubleshooting, Call: 1-877-447-4768, 8:00 am - 5:00 pm CST www.ghpgroupinc.com

NEVER LEAVE THE HEATER

UNATTENDED WHILE BURNING!

Use only original

replacement parts. This

Heater must use design-specific parts. Do

not substitute or use generic parts. Improper

replacement parts could cause serious or

fatal injuries.

WARNING

RA100NGDGD and RA250NGDGD

Dyna-Glo Delux Operating Instructions and Parts Manual

LIMITED WARRANTY:

This limited warranty is extended to the original retail purchaser of this Forced Air/Convection/Radiant Heater and warrants against any

defect in materials and workmanship for a period of one (1) year from the date of retail sale. GHP Group, Inc., at it’s option, will either

provide replacement parts or replace or repair the unit, when properly returned to the retailer where purchased or one of our service centers

as directed by GHP Group, Inc., within one (1) year of retail purchase. (Shipping costs, labour costs, etc. are the responsibility of the purchaser.)

DUTIES OF THE OWNER:

This heating appliance must be operated in accordance with the written instructions furnished with this heater. This warranty shall not excuse

the owner from properly maintaining this heater in accordance with the written instructions furnished with this heater. A bill of sale, canceled

check or payment record must be kept to verify purchase date and establish warranty period. Original carton should be kept in case of warranty

return of unit.

WHAT IS NOT COVERED:

1. Damage resulting from use of improper fuel.

2. Damage caused by misuse or use contrary to the owners manual and safety guidelines.

3. Damage caused byalack of normal maintenance.

4. Fuses

5. Use of non-standard parts or accessories.

6. Damage caused in transit. Freight charges on warranty parts or heaters to and from the factory shall be the responsibility of the owner.

This warranty does not imply or assume any responsibility for consequential damages that may result from the use, misuse, or the lack of

routine maintenance of this heating appliance.Acleaning fee and the cost of parts may be charged for appliance failures resulting from lack of

maintenance. This warranty does not cover claims which do not involve defective workmanship or materials. FAILURE TO PERFORM

GENERAL MAINTENANCE (INCLUDING CLEANING) WILL VOID THIS WARRANTY.

THIS LIMITED WARRANTY IS GIVEN TO THE PURCHASER IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED,

INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY OF FITNESS FORAPARTICULAR PURPOSE. THE

REMEDY PROVIDED IN THIS WARRANTY IS EXCLUSIVE AND IS GRANTED IN LIEU OF ALL OTHER REMEDIES. IN NO EVENT WILL

GHP GROUP, INC. BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES.

Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you. Some states do not

allow the exclusion or limitation of incidental or consequential damages so the above limitation or exclusion may not apply to you.

CLAIMS HANDLED AS FOLLOWS:

1. Contact your retailer and explain the problem.

2. If the retailer is unable to resolve the problem, contact our Customer Service Dept. detailing the heater model, the problem, and proof

of date of purchase.

3. A representative will contact you. DO NOT RETURN THE HEATER TO GHP GROUP,INC. unless instructed by our Representative.

This warranty gives you specific legal rights and you may also have other rights which vary from state to state.

TO REGISTER THE WARRANTY ON YOUR HEATER, PLEASE FILL OUT THIS CARD COMPLETELY

AND MAIL WITHIN 14 DAYS FROM DATE OF PURCHASE OR REGISTER ON-LINE AT www.ghpgroupinc.com

NAME: ______________________________________ PHONE: ( ) __________________ EMAIL: ____________________________

ADDRESS: _________________________________ CITY: ______________________________ STATE: __________ ZIP: ____________

MODEL: ____________________ SERIAL #: _______________________________________ DATE PURCHASED: __________________

DEALER PURCHASED FROM: ____________________________________________ TYPE OF STORE: __________________________

CITY & STATE WHERE PURCHASED: ______________________________________________ PRICE PAID: _______________________

Please TakeaMinute To Give Us Your Answers To The Following Questions.

All Responses Are Used Solely For Market Research And Are Held In Strict Confidence.

Who primarily decided this purchase? Male Female 18-24 25-39 40-59 60 and over

Purpose of Purchase? _______________________________________________________________________________________________

Do you own any other portable heaters? Yes No If yes, type____________________________brand_____________________

How do you intend to use your new heater? Construction Site Farm Warehouse/Commercial Garage/Outbuilding Other

How did you become aware of this heater? In-Store Display Newspaper Ad Magazine Ad Friend/Relative

TV Commercial Store Salesperson Other ___________________________

What made you select this heater? Style Size/Portability Price Package Brand Other ___________________

Do you: own rent Would you recommend this heater toafriend? Yes No

Please give us your comments:________________________________________________________________________________________

THANK YOU FOR COMPLETING THIS FORM!

Information will be held confidential.

Warranty
