1 Hardware Overview 1.1 Features
[CONFIDENTIAL]Satellite C30-K/C40-K/C50-K Maintenance Manual
1-4
1.1 Features
The Dynabook Satellite C30-K/C40-K/C50-K is a full-size PC notebook equipped with an
Intel processor, providing high-speed processing capabilities and advanced features. The
computer employs a lithium ion battery that allows it to be battery-operated for long periods of
time. Thedisplay uses a 13.3-inch HD/FHD ; 14.0-inch HD/FHD ; 15.6-inch HD/FHD LCD
panel. Many features can be Built To Order (BTO) to customize the system for each user.
The computer has the following features:
Processor (BTO)
The computer is equipped with one of the following Intel
®
processors:
For Alder Lake platform
Intel® Core i7-1265U 2C/8c, 1.8G
Intel® Core i7-1255U 2C/8c, 1.7G
Intel® Core i5-1245U 2C/8c, 1.6G
Intel® Core i5-1235U 2C/8c, 1.3G
Intel® Core i3-1215U 2C/4c, 1.2G
Intel® Celeron 7305 1C/4c, 1.1G
Intel® Core i7-1260P 4C/8c, 2.1G
Intel® Core i5-1240P 4C/8c, 1.7G
Memory (BTO)
Two SODIMM slots which come standard with DDR-4 3200MHz 4GB/8GB/16GB,
accepting BTO customization for your memory requirements.
It can incorporate up to 32GB of main memory.
Battery Pack
The computer is powered by one 3 or 4-cell lithium ion battery pack with a capacity of
45Wh or 53Wh, which is rechargeable and removable.
Solid-State Drive (SSD) (BTO)
The computer accommodates a 2280 SSD with the followingstorage capacities:
PCIe SSD M.2 128GB/256GB/512GB
PCIe gen3/gen4 M.2 512GB/1TB

1-5 [CONFIDENTIAL]Satellite C30-K/C40-K/C50-K Maintenance Manual
1 Hardware Overview
1.1 Features
Display (BTO)
The LCD display comes with either one of the following non-touch panels.
13.3"W 16:9 HD (1366×768)
eDP 1.4b Non CSV LED display
13.3"W 16:9 FHD (1920×1080)
eDP 1.4b Non CSV LED display
14.0"W 16:9 HD (1366×768)
eDP 1.4b Non CSV LED display
14.0"W 16:9 FHD (1920×1080)
eDP 1.4b Non CSV LED display
15.6"W 16:9 HD (1366×768)
eDP 1.4b Non CSV LED display
15.6"W 16:9 FHD (1920×1080)
eDP 1.4b Non CSV LED display
Graphics (BTO)
Intel® Iris® Xe Graphics(i5/i7), Intel HD Graphics(others)
Keyboard (BTO)
13.3 inch - The keyboard which has 83(US)/ 84(UK/ 86(JPN), 1.4±0.2mm full stroke keys.
14 inch - The keyboard which has 83(US)/ 84(UK/ 86(JPN), 1.4±0.2mm full stroke keys.
15.6 inch - The keyboard which has 102(US)/ 103(UK/ 107(JPN), with number key. 1.4±0.2mm
full stroke keys.
Pointing Device
The integrated ClickPad performs finger touch and all the functions of a traditional
mouse. Allow control of the on-screen pointer and also supports multi-touch function
such as the scrolling of Windows.
Finger Print Device
A fingerprint sensor is an electronic device used to capture a digital image of the fingerprint pattern.
The captured image is called a live scan. This live scan is digitally processed to create a biometric
template (a collection of extracted features) which is stored and used for matching. Many
technologies have been used including Optical, Capacitive or CMOS, Ultrasound and Thermal
scanners.
Universal Serial Bus (USB) Ports
The computer has two(13-inch) or three(14/15-inch) USB 3.0 and one USB-C ports. It is
supported to daisy-chain a maximum of 127 USB devices. The USB3.0 serial data
transfer rate is up to 5 Gbps. The USB-C data transfer rate is up to 10Gbps. These ports
support PnP installation and hot plugging.

1 Hardware Overview 1.1 Features
[CONFIDENTIAL]Satellite C30-K/C40-K/C50-K Maintenance Manual
1-6
Bridge Media Slot
This slot allows you to insert an Micro SD memorycard. It supports high-speed SD.
UHS-I is also supported on SDXC up to SDR104. This model does not support CF or
Smart Media cards.
Sound system
Stereo Speaker (2 x speaker)
DTS Audio Processing for Japan model
Integrated Microphone
−2 x Mic
−Support Beam Forming, Noise Suppression
Support Cortana Near Field
Internal Camera
The computer has an internal camera it supports HD(0.9M) with camera shutter.
This camera module may come with the following types:
Webcam - HD: support capture still images/record video function
Webcam - HD & Face Authentication Sensor: support capture still images/record video/Facial
recognition(Windows Hello) function
Combo Audio Jack
This jack connects digital speakers, stereo headphones (16 ohm minimum), microphones, or
combo stereo headphone & earphone. When connected to digital speakers or headphones,
the internal speakers are automatically disabled.
It enables connection of a three-conductor microphone for monaural input and also enables
the connection of a stereo device for audio input.
HDMI Out Port
The HDMI 1.4b out port can connect with a Type A connector HDMI cable. The HDMI out
port can send up to 4K HDR video/audio signals.
Built-in LAN
The computer has built-in support for 10/100/1000M Gigabit. It employs a Realtek
RTL8111H controller.
It supports wake-up on LAN form S4/S5 boot support.

1-7 [CONFIDENTIAL]Satellite C30-K/C40-K/C50-K Maintenance Manual
1 Hardware Overview
1.1 Features
Wireless LAN (BTO)
The computer is equipped with a Wireless LAN (WLAN) card. This WLAN module may
come with the following types:
802.11AX＋BT-M.2(1×1)
802.11AX＋BT-M.2(2×2)

Intel 802.11 (a/b/g/n/ac/ax) AX201
Bluetooth (BTO)
Some computers in this series offer Bluetooth wireless communication function which
eliminates the need for cables between electronic devices such as computers and printers.
When implemented, Bluetooth provides wireless communication in a small space. This
module is Version 5.0 or later support (combo module with WLAN), and supports
Microsoft stack.

1 Hardware Overview 1.1 Features
[CONFIDENTIAL]Satellite C30-K/C40-K/C50-K Maintenance Manual
1-8
Figures 1-1 to 1-4 show the computer and its system unit configuration.
Figure 1-1 ID Parts Description Placement - Satellite C30-K
Figure 1-2 ID Parts Description Placement - Satellite C40-K
Figure 1-3 ID Parts Description Placement - Satellite C50-K

1-9 [CONFIDENTIAL]Satellite C30-K/C40-K/C50-K Maintenance Manual
1 Hardware Overview
1.1 Features
Figure 1-4 Block Diagram Description

1 Hardware Overview 1.1 Features
[CONFIDENTIAL]Satellite C30-K/C40-K/C50-K Maintenance Manual
1-10
The system unit of the computer consists of the following components:
Processor (BTO)
The computer is equipped with one of the following Intel
®
processors:
For Alder Lake platform
Intel® Core i7-1265U 2C/8c, 1.8G
Intel® Core i7-1255U 2C/8c, 1.7G
Intel® Core i5-1245U 2C/8c, 1.6G
Intel® Core i5-1235U 2C/8c, 1.3G
Intel® Core i3-1215U 2C/4c, 1.2G
Intel® Celeron 7305 1C/4c, 1.1G
Intel® Core i7-1260P 4C/8c, 2.1G
Intel® Core i5-1240P 4C/8c, 1.7G
Memory (BTO)
Two SODIMM slots which come standard with DDR-4 3200MHz 4GB/8GB/16GB,
accepting BTO customization for your memory requirements.
It can incorporate up to 32GB of main memory.
BIOS ROM (EEPROM)
The system BIOS uses one 16MB flash ROM(for BIOS) and one 8MB flash ROM(for
INTEL ME ). The flash utility can be used to program system and keyboard BIOS at the
same time.
System Controllers
Support SMBus specification V2.0
Hot keys for system control
Audio volume control
Battery status report and control
Power switch control
Support three independent devices
Internal Keyboard country selection
Wireless LAN on/off button

1-11 [CONFIDENTIAL]Satellite C30-K/C40-K/C50-K Maintenance Manual
1 Hardware Overview
1.1 Features
Graphics Controller (BTO)
Supported Display Device:
− Internal LCD
− RGB
− HDMI
DirectX11, AMD PowerXpress 5.5 (Muxless Switchable Graphics) supported
Audio Controller
Realtek Azalia ALC233
One Audio combo port
Synchronize to change sound output to HDMI
Software EQ support
Wireless LAN Controller (BTO)
Azurewave 802.11 (a/b/g/n/ac) RTL8821CE
Azurewave 802.11 (a/b/g/n/ac/ax) RTL8852BE

Intel 802.11 (a/b/g/n/ac/ax) AX201
KBC/EC (Keyboard Controller/Embedded Controller)
KBC
-Scan controller function
-Interface controller function
EC
- Power supply sequence control
- Overheat shutdown support
- LED control
- Device ON/OFF
- Cooling fan speed control
- Universal I/O port
- Battery capacity check
- Flash memory reprogramming function
- EC access interface
- I2C communication control

1.2 Solid State Drive (SSD)
1.3 Power Supply
1 Hardware Overview
1-12
[CONFIDENTIAL]Satellite C30-K/C40-K/C50-K Maintenance Manual
1.2 Solid State Drive (SSD)
1. Form factor: M.2 2280
2. Interface: NVMe-PCIe Gen3 or Gen4
3. Capacity: 128GB, 256GB, 512GB, 1TB
Table 1-1 SSD Device Comparison Table
Item Read Write Data transfer
rate LBA Bytes per
sector
M.2 PCIe Gen3 128G
SSD 3,100MB/s 1,200MB/s 128KB 250,069,680 512Bytes
M.2 PCIe Gen3/4 256G
SSD (DRAM less) 3,100MB/s 1,300MB/s 128KB 500,118,192 512Bytes
M.2 PCIe Gen3/4 512G
SSD (DRAM less) 3,100MB/s 1,800MB/s 128KB 1,000,215,216 512Byte
M.2 PCIe Gen4 512G
SSD 6,400MB/s 2,700MB/s 128KB 1,000,215,216 512Byte
M.2 PCIe Gen4 1TB
SSD 6,600MB/s 5,000MB/s 128KB 2,000,409,264 512Byte
1.3 Power Supply
The power supply unit provides constant voltage (19V) for the system board and performs the
following functions:
1. Power input monitor
Checks whether the AC adapter (DC power supply) is connected to the computer.
Checks whether the battery pack is connected to the computer.
Monitors the DC power supply input voltage (AC Adapter output voltage).
2. Power supply's internal control
Turns on and off the battery pack charging power supply.
Issues a charging current instruction to the PWM control IC of the battery pack charging
power supply.
Controls the supply of DC power supply input (AC Adapter output) to the power supply
unit.
Controls the supply of power to the system block (load/logic circuit side).
3. Logic circuit control
Instructs the gate array to enable/disable tuning the power on.
Controls power-on/off operation.

1.3 Power Supply
1 Hardware Overview
1-13 [CONFIDENTIAL] Satellite C30-K/C40-K/C50-K Maintenance Manual
4. Status display
Turns on the Power LED (in White).
DC-IN/Battery indicator (in White/Amber-Blink)
Camera indicator (in White)
5. External interface
Performs communication through the I2C bus (via the internal EC/KBC).
Transfers the power supply operation mode.
6. Output monitor
Monitors the voltage output to the system block (load/logic circuit side).
Monitors the voltage, over-voltage, input/output current of the battery pack.
Monitors the internal temperature of the battery pack.
Monitors the supply voltage from the AC adapter.

1-14
[CONFIDENTIAL]Satellite C30-K/C40-K/C50-K Maintenance Manual
1.4 Batteries
1 Hardware Overview
1.4 Batteries
The computer is powered by one 4-cell / 3-cell lithium ion main battery pack:
3cell (3S1P) of LI-ION 4050mAH polymer 467866 size with 45Wh
4cell (4S1P) of LI-ION 3550mAH polymer 476371 size with 53Wh
1.4.1 Main Battery
The main battery pack serves as the computer's main power source when the AC adapter is not
attached. The main battery maintains the state of the computer when the AC adapter is detached.
1.4.2 Battery Charging Control
Battery charging is controlled by ISL9538. When the AC adapter and battery pack are attached
tothe computer, the ISL9538 controls the charge on/off state and detects a full charge.
Battery Charge
When the AC adapter is attached, the battery is charged by off-state charge when the system
is powered off or by on-state charge when it is powered on.
Table 1-2 Quick/Normal Charging Time
State Charge Time
Off-State Charge
Battery pack (4050mAh, 3cell)
3 hours
Battery pack (3550mAh, 4cell)
4 hours
On-State Charge
Battery pack (4050mAh, 3cell) 12 hours
Battery pack (3550mAh, 4cell) 12 hours

1-15 [CONFIDENTIAL] Satellite C30-K/C40-K/C50-K Maintenance Manual
1.4 Batteries 1 Hardware Overview
Any of the following can stop the battery from charging:
1. The battery becomes fully charged.
2. The AC adapter or battery pack is removed.
3. The battery or AC adapter voltage is abnormal.
Detection of full charge
A full charge is detected only when the battery is being charged by quick or normal charge.
A full charge is detected when either of the following conditions are met:
1. The current in the battery charging circuit drops below the predetermined value.
2. The charging time exceeds the fixed limit.
NOTE: The time required for normal charge depends on the power consumption by the
system. Using a fluorescent lamp and frequently accessing the disk consumes more power and
lengthens the charge time.

Chapter 2
Troubleshooting Procedures
2
-
0

2 Troubleshooting Procedures
[CONFIDENTIAL]Satellite C30-K/C40-K/C50-K Maintenance Manual
Chapter 2 Contents
2.1 Troubleshooting Introduction .................................................................................. 2-3
2.2 Troubleshooting Flowchart........................................................................................ 2-6
2.3 Power Supply Troubleshooting.................................................................................. 2-9
2.4 Display Troubleshooting.......................................................................................... 2-13
2.5 Keyboard Troubleshooting ...................................................................................... 2-16
2.6 External USB Devices Troubleshooting...................................................................2-18
2.7 TouchPad Troubleshooting.......................................................................................2-20
2.8 Speaker Troubleshooting ..........................................................................................2-22
2.9 Wireless LAN Troubleshooting............................................................................... 2-24
2.10 Camera Troubleshooting........................................................................................... 2-26
2.11 Bluetooth Troubleshooting ...................................................................................... 2-28
2.12 SD Troubleshooting ..................................................................................................2-30
2.13 SSD Troubleshooting…............................................................................................2-32
2.14 HDMI Troubleshooting .......................................................................................... 2-34
2.15 MIC Troubleshooting............................................................................................... 2-36
2.16 TYPE C Troubleshooting .........................................................................................2-40
2.17 LAN Troubleshooting…...........................................................................................2-42
2.18 Battery Troubleshooting .......................................................................................... 2-44
2.19 LED Troubleshooting .............................................................................................. 2-46
2.20 FAN Troubleshooting ...............................................................................................2-48
2.21 Memory Troubleshooting…………………………………………………………..2-50
2.22 Finger Print Troubleshooting……………………………………………………….2-52
2
-
1
2
-
2
-
2
-
2
-
13
2
-
16
2
-
18
2
-
20
2
-
22
2
-
24
2
-
26
2
-
28
2
-
30
2
-
32
2
-
34
2
-
36
2
-
38
2
-
40
2
-
42
2
-
44
2
-
46
2
-
48
2
-
50

2 Troubleshooting Procedures
[CONFIDENTIAL]
Sate
llite
C30
-
K/C40
-
K/C50
-
K
Maintenance
Manual
Figures
Figure 2-1 Troubleshooting flowchart (2/1)........................................................................ 2-5
Figure 2-1 Troubleshooting flowchart (2/2)........................................................................ 2-6
Figure2-2 Power Supply Troubleshooting Process ............................................................ 2-9
Figure 2-3 Display troubleshooting process...................................................................... 2-13
Figure 2-4 Keyboard troubleshooting process ...................................................................2-16
Figure 2-5 External USB device troubleshooting process .................................................2-18
Figure 2-6 TouchPad troubleshooting process.................................................................. 2-20
Figure 2-7 Speaker troubleshooting process ..................................................................... 2-22
Figure 2-8 Wireless LAN troubleshooting process ............................................................ 2-24
Figure 2-9 Camera Troubleshooting process .....................................................................2-26
Figure 2-10 Bluetooth troubleshooting process ..................................................................2-28
Figure 2-11 SD card troubleshooting process ......................................................................2-30
Figure 2-12 SSD troubleshooting process........................................................................... 2-32
Figure 2-13 HDMI troubleshooting process.........................................................................2-34
Figure 2-14 MIC troubleshooting process............................................................................2-36
Figure 2-15 TYPE C troubleshooting process .................................................................... 2-40
Figure 2-16 LAN troubleshooting process........................................................................... 2-42
Figure 2-17 Battery troubleshooting process ........................................................................2-44
Figure 2-18 LED troubleshooting process ............................................................................2-46
Figure 2-19 FAN troubleshooting process ............................................................................ 2-48
Figure 2-20 Memory troubleshooting process ...................................................................... 2-50
Figure 2-21 Finger Print troubleshooting process.........................................................…… 2-52
Tables
Table 2-1 Battery LED ....................................................................................................... 2-10
Table 2-2 DC-IN LED ........................................................................................................ 2-11
2
-
2
2
-
5
2
-
2
-
2
-
13
2
-
16
2
-
18
2
-
20
2
-
22
2
-
24
2
-
26
2
-
28
2
-
30
2
-
32
2
-
34
2
-
36
2
-
38
2
-
40
2
-
42
2
-
44
2
-
46
2
-
48
2
-
50

[CONFIDENTIAL]Satellite C30-K/C40-K/C50-K Maintenance Manual
2.1 Troubleshooting Introduction
Chapter 2 describes how to determine if a Field Replaceable Unit (FRU) in the computer is
causing the computer to malfunction. The FRUs covered are:
1. Display 7. Wire LAN 13. USB3.0 19. Headphone
2. Keyboard 8. Camera 14. LAN 20. Memory
3. USB ports 9. Bluetooth 15.HDD/SSD 21. Finger Print
4. MIC 10. HDMI 16. Battery
5. Touch Pad 11. TYPE C 17. LED
6. Speaker 12. SD 18.FAN
The Diagnostics Disk operations are described in Chapter 3. Detailed replacement
procedures are given in Chapter 4.
The following tools are necessary for implementing the troubleshooting procedures:
1. Multi-meter
2. External monitor –HDMI
3. USB compatible keyboard
4. Multimedia sound system with line-in and line-out ports
5. Headphones
6. USB test module and USB cable
7. MIC module and MIC line
8. Audio loop back
9. USB3.0 HDD
10. HDMI
11. T&D for diagnostics program
2
-
3
2
Troubleshooting
Procedures
2.1 Troubleshooting Introduction

[CONFIDENTIAL]Satellite C30-K/C40-K/C50-K Maintenance Manual
2.2 Troubleshooting Flowchart
If you know the location of the malfunction, turn directly to the appropriate section of this
chapter. If the problem is unspecified, use the flowchart in Figure 2-1 as a guide for
determining which troubleshooting procedures to execute. Before performing any
troubleshooting procedures, verify the following:
Ask the user if a password is registered, if it is, ask him or her to enter the password.
Verify with the customer that Windows 11 is installed on the hard disk (SSD). Operating
systems that were not pre-installed by Dynabook can cause the computer to malfunction.
Make sure all optional equipment is removed from the computer
2
-
4
2
Troubleshooting
Procedures
2.2 Troubleshooting Flowchart
