4en | Important product information V Series
2024.01 | V03 | F.01U.402.248 Installation manual Dynacord
1 Important product information
1.1 Safety Information
1. Read and keep these safety instructions. Follow all instructions and heed all warnings.
2. Download the latest version of the applicable installation manual from
www.dynacord.com for installation instructions.
Information
Refer to the Installation Manual for instructions.
3. Follow all installation instructions and observe the following alert signs:
Notice! Containing additional information. Usually, not observing a notice does not
result in damage to the equipment or personal injuries.
!
Caution! The equipment or the property can be damaged, or persons can be injured
if the alert is not observed.
Warning! Risk of electric shock.
4. System installation and servicing by qualified personnel only, in accordance with
applicable local codes. No user-serviceable parts inside.
5. System installation for emergency sound (except for call stations and call station
extensions) in a Restricted Access Area only. Children may not get access to the
system.
6. For rack-mounting of system devices, make sure that the equipment rack is of suitable
quality to support the weight of the devices. Use caution when moving a rack to avoid
injury from tip over.
7. The apparatus shall not be exposed to dripping or splashing and no objects filled with
liquids, such as vases, shall be placed on the apparatus.
Warning! To reduce the risk of fire and electric shock, do not expose this apparatus
to rain or moisture.
8. Mains powered equipment shall be connected to a mains power outlet socket with a
protective earthing connection. An external, readily operable, mains plug or all‑pole
mains switch shall be installed.
9. Only replace the mains fuse of an apparatus with a fuse of the same type.
10. The protective ground connection of an apparatus shall be connected to protective
ground before the apparatus is connected to a power supply.
11. This unit has an autoranging input circuitry suitable for 100‑240Vac.
12. Amplifier outputs marked with

may carry audio output voltages up to 120VRMS.
Touching uninsulated terminals or wiring may result in an unpleasant sensation.
Amplifier outputs marked with or may carry audio output voltages above 120VRMS.
It requires a skilled person to strip and connect the loudspeaker wires in such a way
that the naked conductors are inaccessible.
13. To prevent hearing damage do not listen at high volume levels for long periods.

V Series Important product information | en 5
Dynacord Installation manual 2024.01 | V03 | F.01U.402.248
1.2 Disposal instructions
Old electrical and electronic appliances.
Electrical or electronic devices that are no longer serviceable must be collected
separately and sent for environmentally compatible recycling (in accordance with
the European Waste Electrical and Electronic Equipment Directive).
To dispose of old electrical or electronic devices, you should use the return and
collection systems put in place in the country concerned.
1.3 Class B Notice for FCC and ICES 003
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules and Canadian ICES‑003 requirements. These
limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the following
measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.

6en | About this manual V Series
2024.01 | V03 | F.01U.402.248 Installation manual Dynacord
2 About this manual
The purpose of this manual is to provide information required for installing, configuring,
operating and maintaining these products.
Read through this manual to familiarize yourself with the safety information, features, and
applications before you use it.
2.1 Digital document
This manual is available as a digital document in the Adobe Portable Document Format
(PDF).
You can find information about Dynacord products on the product related information at
www.dynacord.com.
2.2 Intended audience
This manual is intended for everyone who is authorized to install and use these products.
2.3 Copyright notice
Unless otherwise indicated, this publication is the copyright of Dynacord. All rights are
reserved.
2.4 Trademarks
Throughout this document trademark names may have been used. Rather than put a
trademark symbol in every occurrence of a trademark name, Dynacord states that the names
are used only in an editorial fashion and to the benefit of the trademark owner with no
intention of infringement of the trademark.
2.5 Notice of liability
While every effort has been taken to ensure the accuracy of this document, neither Dynacord
nor any of its official representatives shall have any liability to any person or entity with
respect to any liability, loss or damage caused or alleged to be caused directly or indirectly
by the information contained in this document.
Dynacord reserves the right to make changes to features and specifications at any time
without prior notification in the interest of ongoing product development and improvement.

V Series About this manual | en 7
Dynacord Installation manual 2024.01 | V03 | F.01U.402.248
2.6 Short information
The following table lists products in a family, with CTN (Commercial Type Number) and
identifying product name DESCRIPTION.
CTN Description
V600:4-EU Power amplifier, 600W, 4 channel, EU
V600:2-EU Power amplifier, 600W, 2 channel, EU
V600:4-US Power amplifier, 600W, 4 channel, US
V600:2-US Power amplifier, 600W, 2 channel, US
V600:4-CN Power amplifier, 600W, 4 channel, CN
V600:2-CN Power amplifier, 600W, 2 channel, CN
2.7 Document history
Release date Documentation version Reason
2022.02.01 V01 Release
2023.09.01 V02 Addition of V600:2

8en | Product introduction V Series
2024.01 | V03 | F.01U.402.248 Installation manual Dynacord
3 Product introduction
The V series power amplifiers are ideally suited to background music and clear voice
announcement applications such as:
– Bars and restaurants
– Retail outlets
– Education
– Houses of worship
– Museums and galleries
– Transport hubs
– Conference centers
The V600:4 is a 600W power amplifier with powerTANK technology that flexibly delivers the
total power over its 4 channels.
The V600:2 is a 600W power amplifier with powerTANK technology that flexibly delivers the
total power over its 2 channels.

V Series Product introduction | en 9
Dynacord Installation manual 2024.01 | V03 | F.01U.402.248
3.1 Features and functions
– 4‑channel amplifier (V600:4) / 2-channel (V600:2) amplifier with a total powerTANK
capacity of 600W.
powerTANK is a reservoir of available amplification power that is deployed flexibly across all
amplifier channels. There is no need to set up the powerTANK as it adapts to the
requirements of each zone or output without extra manual configuration of each individual
channel.
– Variable Load Drive (VLD) providing the same power into 4Ω, 8Ω, 70V or 100V
Variable Load Drive (VLD) ensures that the powerTANK capacity is utilized efficiently,
providing consistent power to any channel with different loads.
– dualCOOL convection cooling with additional intelligent fan in case of extreme thermal
conditions
The dualCOOL thermal design means that the amplifier typically operates as a convection
cooled amplifier, but in extreme thermal conditions the amplifier is also equipped with an
intelligent multi‑speed fan to ensure maximum performance and reliability in any
application.
– ecoRAIL and APD deliver significant reduction in power consumption
ecoRAIL’s power consumption is similar to a regular standby level, yet ecoRAIL still
produces audio output suitable for background music levels, and the Auto Power Down
(APD) mode can be engaged to further reduce power consumption to less than a watt when
there is no signal present for extended periods.
– Line input single cable solution for easy installation
The single cable installation feature is compatible with AES72‑1E (RJ45 connectors) wired
devices. This solution provides easy installation for all four channels of the V600:4 / both
channels of the V600:2 without needing to wire all the connections individually.
– Advanced Protection features and PFC to ensure reliability
Equipped with a PFC power supply and protection features usually reserved for the
professional power amplifiers, means that the amplifier resists complete shutdown
situations and will always perform at its best under all conditions.

10 en | General installation procedures V Series
2024.01 | V03 | F.01U.402.248 Installation manual Dynacord
4 General installation procedures
Before starting installation, ensure the following:
– You make use of manufacturer specified installation materials.
– No liquids can spill into or on the products.
– Installation is in a clean environment free of dust.
– The ventilation airflow of the 19" units is not obstructed.
– There is a mains power outlet of sufficient rating close to the intended location of the
products.
– Sufficient free space and access at the rear of the 19" units for connectors and wiring.
4.1 Unpacking
The products should be unpacked and handled with care. If an item appears to be damaged,
notify the shipper immediately. If any items are missing, notify your Dynacord
representative.
The original packaging is the safest container in which to transport products and can also be
used to return products for service, if necessary.
4.2 Parts included
V600:4 V600:2 Component
1 1 Power amplifier
1 1 Mains cord
1 1 Euroblock remote connector 5‑pole
2 1 Euroblock input connector 6‑pole
2 1 Euroblock output connector 4‑pole
4 4 Rubber feet
2 N/A 19"‑rack mounting brackets (pre‑mounted)
N/A 1 M3 screw
N/A 2 Short rack ears
N/A 1 Long rack ear
N/A 1 Connection plate
1 1 Quick Installation Guide
1 1 Safety information

V Series General installation procedures | en 11
Dynacord Installation manual 2024.01 | V03 | F.01U.402.248
4.3 Dimensions
V600:4

12 en | General installation procedures V Series
2024.01 | V03 | F.01U.402.248 Installation manual Dynacord
V600:2

V Series General installation procedures | en 13
Dynacord Installation manual 2024.01 | V03 | F.01U.402.248
4.4 Mounting and ventilation
i
Notice!
Before mounting the device, it is recommended to make the required settings. See
Indicators, controls and settings, page 25.
V600:4
19”-rack mounting
The V600:4 power amplifier has been designed for installation in a conventional
19”‑equipment rack. Attach the power amp with its frontal rack mount ears using four
screws and washers as shown in the illustration.
Figure4.1: Mounting the amplifier in a rack
Additionally securing the amplifier by rack rails might be necessary in case you intend to
transport the rack. Failure to do so may result in damage to the power amplifier as well as
to the rack case.

14 en | General installation procedures V Series
2024.01 | V03 | F.01U.402.248 Installation manual Dynacord
Tabletop use
If you want to use this device outside a 19”‑rack on a tabletop, dismount the rack mount
ears, reattach the screws back into the device and mount the four self‑adhesive rubber feet
on the bottom of the device.
Figure4.2: Dismounting the rack ears (top right) and attaching the rubber feet (bottom)

V Series General installation procedures | en 15
Dynacord Installation manual 2024.01 | V03 | F.01U.402.248
V600:2
The V600:2 amplifier has four mounting options.
Stand-alone mounting in a 19”-rack
Despite being half the size of the V600:4, the V600:2 power amplifier can be fitted alone in a
standard 19"-rack.
Mount one short rack ear to the preferred side of the amplifier using the built-in screws.
Unscrew the existent screws, attach the rack ear and screw them back in.
Mount the long rack ear (B) on the opposite side by unscrewing the existent screws on the
side of the amplifier, attaching the long ear and screwing them back in (1).
Attach the power amp with its frontal rack mount ears (short and long) (C) using four
screws and washers (2) as shown in the illustration.
I
B
C
x2
2
1
Figure4.3: Stand-alone mounting in a 19"-rack

16 en | General installation procedures V Series
2024.01 | V03 | F.01U.402.248 Installation manual Dynacord
Side-by-side mounting in a 19"-rack
If you intend to use the full 19"-rack, you can stack two V600:2 amplifiers in one rack slot.
To install both amplifiers in a side-by-side configuration:
1. Mount the one short rack ear to one side of one amplifier using the existent screws (C).
Unscrew the existent screws, attach the rack ear and screw them back in.
Do this for both amplifiers. The two short rack ears must be in opposite sides.
2. Mount the center connecting plate. Unscrew the four existent screws, attach the
connecting plate and screw them back in (D) as shown in the illustration.
II
C
D
x2
Figure4.4: Connecting the rack ears and the connecting plate
3. Once the connecting plate is attached to one amplifier, align the four holes in the side
of the amplifier with the four hooks (1) and slide the other amplifier until the two
amplifiers hook together (2). To prevent pushback of the amplifiers, screw in the
supplied M3 bolt (3) into the screw hole on the back of the amplifier as shown in the
illustration.

V Series General installation procedures | en 17
Dynacord Installation manual 2024.01 | V03 | F.01U.402.248
E
2
1
3
Figure4.5: Two amplifiers hooked together with connection plate mounted and M3 bolt to prevent
pushback
4. Attach the power amplifier with its frontal rack mount ears using four screws and
washers as shown in the illustration.

18 en | General installation procedures V Series
2024.01 | V03 | F.01U.402.248 Installation manual Dynacord
Figure4.6: Side-by-side mounting in a 19"-rack
Tabletop use (over and under the table)
You can use this device outside a 19”‑rack on a tabletop, mounted over or under the table.
For under the table mounting:
1. Stick the supplied rubber feet in the corners of the device top surface for more stability
with this type of installation (F).
Place the rubber feet in the edges of the lid so that they are not on top of the labels.
For the correct position, refer to the Quick installation guide of the product.
2. Align the short rack ears with the side screws of the amplifier (C). Unscrew the existent
screws, attach the rack ear and screw them back in (1).
3. Secure the device by screwing the rack ears to the table as shown in the illustration
(2).

V Series General installation procedures | en 19
Dynacord Installation manual 2024.01 | V03 | F.01U.402.248
III
F
x2
2
1
C
Figure4.7: Tabletop use - under the table
For tabletop mounting:
1. Stick the supplied rubber feet in the corners of the device bottom surface for more
stability with this type of installation (F).
For the correct position, refer to the Quick installation guide of the product.
2. Align the short rack ears with the side screws of the amplifier (C). Unscrew the existent
screws, attach the rack ear and screw them back in (1).
3. Secure the device by screwing the rack ears to the table as shown in the illustration
(2).

20 en | General installation procedures V Series
2024.01 | V03 | F.01U.402.248 Installation manual Dynacord
F
C
IV
1
x2
2
Figure4.8: Tabletop use - over the table
