Dynalabs DYN-P-5000 User manual

Model DYN-P-5000
Range [g]: 100, 200, 500, 2000, 6000
Product Manual

All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors.
2
Product Support
If at any time you have questions or problems with the DYN-P-5000 sensors,
please contact a Dynalabs engineer at:
Phone: [phone] (9 a.m. to 5 p.m., UTC +3)
E-mail: [email protected]
Warranty
Our products are warranted against defective materials and workmanship for one
year. Defects arising from user errors are not covered by the warranty.
Copyright
All copyrights of this manual belonging to Dynalabs products are reserved. It
cannot be reproduced without written consent.
Disclaimer
Dynalabs Ltd. provides this publication "as is" without warranty of any kind,
express or implied, including but not limited to, the implied warranties of
merchantability or fitness for a particular purpose. This document is subject to
change without notice, and should not be construed as a commitment or
representation by Dynalabs Ltd.
This publication may contain inaccuracies or typographical errors. Dynalabs Ltd.
will periodically update the material for inclusion in new editions. Changes and
improvements to the product described in this manual may be made at any time.

All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors.
3
Table of Contents
1) Introduction......................................................................................................4
2) General Information.........................................................................................4
2.1) Unpacking and Inspection..........................................................................4
2.2) System Components...................................................................................4
2.3) Specifications.............................................................................................5
2.4) Outline Drawing ........................................................................................6
3) Operation and Installation................................................................................7
3.1) General.......................................................................................................7
4) Sensor Static Calibration Verification..............................................................7
5) Declaration of Conformity...............................................................................8

All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors.
4
1)Introduction
The piezoresistive accelerometers are based on micro-electro-mechanical systems
(MEMS) technology. Piezoresistive accelerometers are used for high impact
applications in automotive industry such as crash testing. 5000 Series Dynalabs
triaxial accelerometers feature a wide range up to 5,000 Hz and excellent shock
resistance up to 10,000 g. 5000 series accelerometers are lightweight. They have
reliable aluminum housing with IP68 protection class. These sensors have
integrated cable with configurable length and connection options.
DYN-P-5000 sensors offer the following options;
• Custom Cable Length (5m standard cable)
• Custom Housing Material
• Custom Connector
• Base plate
2) General Information
2.1) Unpacking and Inspection
Dynalabs products provide adequate protection for undamaged products to be
transported. Document the damages that occur indirectly during the transport
and contact the customer representative.
2.2) System Components
The DYN-P-5000 has the following components:
- MEMS Sensor
- Calibration Certificate
-Product Manual

All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors.
5
2.3) Specifications
Table 1: Specifications datasheet
Full scale
acceleration
(g)
5010
±100
5020
±200
5050
±500
5200
±2000
5600
±6000
Sensitivity
(@10V
excitation)
(mV/g)
1.2
1.2
0.6
0.3
0.3
Frequency range
(±5%)
(Hz)
1,200
1,400
2,000
4,500
5,000
Non-linearity
(full scale)
(%)
1
1
1
1
2
Shock
survivability
(g)
5,000
5,000
5,000
5,000
10,000
Transverse
Sensitivity
%
<3
<3
<3
<3
<3
Damping Ratio
0.9
0.6
0.6
0.3
0.3
Zero
Acceleration
Output
(mV)
±25
±25
±25
±25
±25
Environmental
Table 2 Environmental specifications datasheet
Protection Level
IP 68
Operating Voltage
10V –40 V
Operating Temperature
-40 °C to +100 °C
Operating Current Consumption mA
<12 mA
Isolation
Case isolated

All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors.
6
Physical
Table 3 Physical specifications datasheet
Sensing Element
MEMS Piezoresistive
Housing Material
Aluminum
Connector (Optional)
D-Sub 9 or 15 pin, Lemo, Binder
Mounting
Adhesive or screw mount
Base plate (Optional)
Aluminum
Weight (without cable)
20g
2.4) Outline Drawing
The dimensional properties of DYN-P-5000 sensors are given below.

All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors.
7
3) Operation and Installation
3.1) General
The general sensor connector configuration is given below;
Cable Code/Pin Configuration:
• Red : V + Power supply voltage +10 V to +40 VDC
• Black : Ground Power GND
• X-Axis: Yellow : Signal(+) Positive, analog output voltage signal
Purple : Signal(-) Negative, analog output voltage signal
• Y-Axis: Blue : Signal(+) Positive, analog output voltage signal
Green : Signal(-) Negative, analog output voltage signal
• Z-Axis: White : Signal(+) Positive, analog output voltage signal
Orange : Signal(-) Negative, analog output voltage signal
WARNING
Never connect the power supply and/or the power ground to yellow, purple, blue, green,
white, and/or orange cables.
Never connect the power supply to the power ground. Always use a clean power source
and check the voltage range.
4) Sensor Static Calibration Verification
Using gravity, voltage values are measured in the + and - directions, providing a value of 1 g.
The measurement should be made as follows;
When the acceleration value of 5000 series sensors is entered into the data
acquisition system, the sensor shows +1 g with the effect of gravity, which is
in the direction of the axis to be calibrated.
When the sensor is positioned in the opposite direction to the axis to be
calibrated, the arrow shows -1g as shown below under the effect of gravity.
Using gravity, the voltage values that provide 1 g in the + and - directions
are measured and compared with the catalog value. The calibration value
should be close to the catalog value with a 10% tolerance. Sensor catalog
sensitivity values are given in Table 1.

All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors.
8
5) Declaration of Conformity
This declaration of conformity is issued under the sole responsibility of the manufacturer.
The product(s) are developed, produced and tested according to following EC- directives:
•2014/35/EU –Low Voltage Directive (LVD)
•2006/42/EU –Machinery Safety Directive
•2015/863/EU –RoHS Directive
Applied standards:
• EN 61010-1:2010
• EN ISO 12100:2010
• MIL-STD-810-H-2019 (Test Methods: 501.7 - High Temperature, 502.7 - Low
Temperature, 514.8 - Vibration, 516.8 –Shock)
DYNALABS MÜHENDİSLİK SANAYİ TİCARET LİMİTED ŞİRKETİ declares
that above mentioned products meet all the requirements of the above mentioned
standards and regulations.
Canan Karadeniz, General Manager
Ankara, 15.07.2021
