1) Introduction
The DYN-PM-10 is designed to provide dynamic force excitation for
vibration and shock testing of small sized mechanical structures.
The DYN-PM-10 is a compact, lightweight and powerful general purpose
electrodynamic shaker providing up to 10 N peak sine force.
2) General Information
2.1) Unpacking and Inspection
DynaLabs products provide adequate protection for undamaged products to
be transported. Document the damages that occur indirectly during the
transport and contact the customer representative. Check all components of
the shaker. If there is a defect, please contact us.
2.2) System Components
DYN-PM-10 has the following components:
-Electrodynamic Shaker Body
- Amplifier (DYN-SA-150)
-Power Adapter
-Signal Cable
-Ground Cable
-User Manual

All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors.
5
2.3) Theory of Operation
DYN-PM-10 is an electromagnetic actuator. Electromagnetic actuators are
basically a voice coil consisting of magnet and coil. The moving element can
be a coil or magnet depending on the design requirements. The moving
element is usually suspended by an elastic spring. DYN-PM-10 has a
stationary coil (drive coil) whose current is controlled to produce vibration.
The stationary magnetic field is produced by a magnet.
Item
Description
1
External Signal Input
2
GND
3
Signal Output
4
GND
5
DC Power Input
6
Sine Frequency Generator
7
Gain Knob
8
External Signal Input
9
LCD Display

All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors.
6
2.4) Specifications
Parameters
Specifications
Excitation Type
Vertical or Horizontal
Output Force (Sinus)
10 N
Frequency
10-10000 Hz
Displacement (Peak to Peak)
4 mm
Shaker Weight
Shaker body (1 kg) + outer frame (0.3
kg)
Suspension
Carbon Fiber
Cooling System
Natural Convection
Operating Temperature Range
5-35 °C
Maximum Input Current
4A (RMS)
AMPLIFIER
EXTERNAL
Amplifier Weight
0.65 kg
Power Supply Voltage
19V DC
Power Supply Current
4.74 A
External Signal Voltage Level
1 VAC(PEAK)

All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors.
7
2.5) Outline Drawing
The dimensional properties of DYN-PM-10 shakers are given below. All
dimensions are in mm.
It can be used by removing the outer frame and the shaker body.

All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors.
8

All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors.
9
3) Operation and Installation
3.1) General
The general shaker connector configuration is given below.
The Gain Knob is a push-pull and rotational switch. The amplifier is in
External Signal Mode when the Gain Knob is pushed in and the amplifier is
in Internal Signal Mode when it is pulled out.
In order to protect the amplifier from electrical problems, it is advised to turn
the Gain Knob counter clockwise to the lowest gain position before
connecting the external signal cable or before changing operational modes.

All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors.
10
3.1.1-) External Signal Mode:
Connect DC power source and drive signal to shaker power input and signal
input respectively. Start the external signal source. Adjust the Gain of the
amplifier by turning the Gain Knob clockwise.
3.1.2-) Internal Signal Mode:
The amplifier can generate sine signal from 1Hz to 15kHz with 1 Hz
increments that the user can adjust with the Sine Frequency Generator
Switch. Connect DC power source and drive signal to shaker power input.
Pull the Gain Knob out.

All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors.
11
Raise or lower the Sine Frequency Generator Switch to the desired Sine
frequency. Adjust the Gain of the amplifier by turning the Gain Knob
clockwise. The frequency of the generated sine signal will be visible on the
LCD Screen.
3.2) Power Requirements
DYN-PM-10 has an external power amplifier which is powered by its power
adaptor. Please note the output voltage and current ratings of the adaptor if
a replacement adaptor is to be used.
3.3) Cooling
DYN-PM-10 does not require forced cooling. Air convection cooling is
sufficient for the force levels given in the specifications.

All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors.
12
3.4) Frequency Response
The following figure shows the acceleration levels/Input voltage versus
frequency of the shaker.
3.5) Mounting Interface

All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors.
13
4) Maintenance and Troubleshooting
The DYN-PM-10 shaker is a sealed device requiring no maintenance if the
operating instructions described in this manual are followed. Repair of the
coil, exciter body or magnet core should not be attempted. Please return the
shaker to DynaLabs for proper repair.
5) Safety
Please ensure that this manual section is reviewed and understood prior to
installation, operation or maintenance of the equipment. The danger of
electrical shock or fire always exists in electrical equipment.
The DYN-PM-10 Shaker is designed for safe operation. Safety features
such as electrical insulation on outer surfaces are provided for the safe
operation of the shaker system. Always monitor the applied voltage to the
amplifier and shut down the shaker if the temperature of the shaker body
rises drastically or smoke is observed from the shaker due to high voltage
levels applied.

All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors.
14
5.1) Grounding
The shaker is internally grounded via the power adapter. However, if further
grounding is necessary a grounding socket is available on the shaker as shown.
Appropriate grounding cable is also supplied with the shaker.

All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors.
15
6) Declaration of Conformity
