DynaMetric TLP-124HS User manual

Instructions
TLP-124HS Logger Patch for
Cell Phones & Cordless Phones
FOR LEGAL USE ONLY 12-1-06
www.DynaMetric.com Page 1 of 2 ©DynaMetric 2001 Doc 44409
The TLP-124HS Logger Patch adapts most cordless and cell phones that use a headset
with a 2.5mm plug, to a tape recorder, sound card, or other audio device. It provides a
clear audio signal containing both sides of the phone conversation. The TLP-124HS
connects to the cell phone via the 2.5mm headset connector. See the diagram and
installation instructions below.
INSTALLATION INSTRUCTIONS
1 Unplug the 2.5mm headset plug from the cell phone and plug it into the jack on the
TLP-124HS.
2 Plug the black cable with the 2.5mm plug on the TLP-124HS into the cell phone
where the headset was plugged.
3 Plug the cable with the 3.5mm plug (gray, larger plug, longer cable) on the TLP-
124HS into the tape recorder, or MIC Input of a sound card or other audio device.

Instructions
TLP-124HS Logger Patch for
Cell Phones & Cordless Phones
FOR LEGAL USE ONLY 12-1-06
www.DynaMetric.com Page 2 of 2 ©DynaMetric 2001 Doc 44409
