Dynamobel CORONA User manual

Dynamobel S.A. • Ctra. Madrid, km.24 • 31350 Peralta Navarra Spain • T [phone] • F [phone]
[email protected]om • www.dynamobel.com
• 1 •
CORONA screen
1. Fitting for straight or angled connection from 90º to 180º
OPTIONAL FEATURES
The CORONA panel has 2 types of supports to adapt to any work environment. It will allow us die-
rent configurations through its linking elements. Its variety of finishes will provide us a total visual
contact through transparent tempered glass or cellular polycarbonate. But we can also have a privacy
environment with opaque finishes.
1. Straight Aor angled Bbase with lockable wheels or leveller.
2. Free-standing screen (2 feet).
3. Extension screen: when screens have a straight base, to form 90º joints use a foot + support with
leveller or foot + support with wheels (the angled base allows the screens to be joined at 90º).
FEATURES
1
1
1
A B

Dynamobel S.A. • Ctra. Madrid, km.24 • 31350 Peralta Navarra Spain • T [phone] • F [phone]
[email protected]om • www.dynamobel.com
• 2 •
CORONA screen
DESCRIPTION
STRUCTURE
Rectangular profiles of 44x24 mm made of extruded, powder-coated aluminium, joined together by
steel brackets at the corners.
PANELS
• 5 mm thick tempered glass.
• 10 mm thick transparent cellular polycarbonate.
• 10 mm thick laminated chipboard.
In all cases a plastic strip is placed between the panel and the aluminium frame.
BASES
Welded unit made of 0.8 mm steel plate and 20x20 mm square tube with powder coating finish.
The 20x20 tube is inserted into the vertical aluminium profile of the screen frame and screwed toge-
ther from the side.
The base can be fixed in two dierent positions to compensate for the dierence in height between a
screen with wheels and a screen with levellers.
FLOOR SUPPORTS
37mm diameter wheel
with lever brake
Leveller
STRAIGHT BASE
460 400
10001000
2000 2000
ANGLED BASE

Dynamobel S.A. • Ctra. Madrid, km.24 • 31350 Peralta Navarra Spain • T [phone] • F [phone]
[email protected]om • www.dynamobel.com
• 3 •
CORONA screen
1
3
5
2
4
SCREEN CONNECTION
The screens can be connected laterally by means of a fitting. This fitting can be integrated into the
screen itself or sold separately, depending on the product ordered. Therefore, depending on whether
you have integrated or external fittings, the steps to join screens will vary:
• INTEGRATED INTO THE SCREEN. In other words, the screen was ordered with the connecting
fittings. To join two screens, follow the instructions below from step 1 to 5.
• EXTERNAL TO THE SCREEN. If you have a screen and then need to attach it to another screen,
you just need to order the fitting. To assemble it, you should then just follow the instructions below
from step 3 to 5.
FITTING INTEGRATED INTO THE SCREEN
FITTING EXTERNAL TO THE SCREEN

Dynamobel S.A. • Ctra. Madrid, km.24 • 31350 Peralta Navarra Spain • T [phone] • F [phone]
[email protected]om • www.dynamobel.com
• 4 •
CORONA screen
GAMA
2000
2000
2000 2000
2000
2000
1000
1000
1000 1000
1000
1000
460
460
400 400
460
460
STRAIGHT BASE
ANGLED BASE
SUPPORT WITH WHEELS ON BOTH SIDES
SCREEN CONNECTION
SCREEN CONNECTION
SCREEN CONNECTION SCREEN CONNECTION
SCREEN CONNECTION
SCREEN CONNECTION
SUPPORT WITH LEVELLER ON BOTH SIDES
SUPPORT WITH LEVELLER + LEVELLER
SUPPORT WITH WHEELS ON BOTH SIDES SUPPORT WITH LEVELLER ON BOTH SIDES
SUPPORT WITH LEVELLER + WHEEL
