Dynasound DS1404 User manual

Dynasound, Inc. 6439 Atlantic Blvd. Norcross, GA. 30071 800.989.6275
DS1404 4-Ch. PC programmable
soundmasking level controller
ver. 1.0 1/15/08

3
Dynasound, Inc. 6439 Atlantic Blvd. Norcross, GA. 30071 800.989.6275
Contents
About the DS1404
Installing the DS1404 Controller
Creating Attenuation Schedules
Connecting your PC to the DS1404
Downloading Schedules to the DS1404
Setting Options for the DS1404
Creating Weekly Schedules
Creating Individual Weekly Events
Creating a Transition Schedule
Creating Date Events
Date and Time
Daylight Saving Time Options
Soft-Start Option
Modifying Weekly Schedules
Downloading Weekly Schedules
Downloading Date Events
Establishing Communications
Installing the DS1404 Control Software
Included CD Rom
Updates via www.soundmasking.com
Physical Connections
Physical Connections
Bypass Switches
5
4
5
5
5
5
6
8
7
15
14
13
8
9
10
11
11
Warranty and Repair 17
Specifications 16

4
Dynasound, Inc. 6439 Atlantic Blvd. Norcross, GA. 30071 800.989.6275
About the DS1404
The DS1404 is a four channel, PC programmable, line-level attenuator used primarily to control soundmasking
levels based on date and time-of-day. The DS1404 can also be used to provide attenuation schedules for
background music or paging signals. Highly configurable custom schedules can be created and downloaded to
the DS1404 using the provided Windows based software.
The front of the unit provides buttons used for minor changes, such as adjusting the time of day. The front panel
buttons are also used to toggle the display between channels 1-2 and 3-4. The rear panel provides line level input
and output connections via industry standard Phoenix™ connectors, a com port for PC connections and bypass
controls.
The front of the unit provides buttons used for minor changes, such as adjusting the time of day. The front panel
buttons are also used to toggle the display between channels 1-2 and 3-4.
serial port
line level outputs line level inputs
bypass
normal
1
120 v. 60 Hz
1234
2341234
bypass controls
No user servicable parts inside.
Refer servicing to qualified
personnel. Do not expose to moisture.
Replace fuse with same value only.
DS1404 programmable level control.
Made in USA
Align text with cutouts as indicated.
File at full scale. Drawing printed @ print to fit page.
All text black .
The rear panel provides line level input and output connections via industry standard Phoenix™ connectors, a
com port for PC connections and bypass controls.

5
Dynasound, Inc. 6439 Atlantic Blvd. Norcross, GA. 30071 800.989.6275
Installing the DS1404 Control Software
Installing the DS1404 Controller
The DS1404 is shipped with a CD containing the DS1404 control software. Insert the CD and run the included
program called “setup.exe” and follow the prompts.
Updated versions of the DS1404 software are available for download at www.soundmasking.com/support.
This software allows configuration of each channel of the DS1404 and provides several system wide options such
as soft start on power-up, holiday schedules and Daylight Saving Time settings.
The DS1404 is designed to be installed into any standard 19” wide equipment rack. Typically, the inputs of the
DS1404 will be connected to the outputs of a soundmasking generator and the outputs of the DS1404 will provide
signal to the soundmasking system amplifier input(s).
It is important to note that the inputs and outputs of the DS1404 share a “common” terminal which is on the right
side (when facing the rear of the unit) of each Phoenix™ connector. “Common” and “Positive” terminals must not be
interchanged or the DS1404 will not properly attenuate signals.
TherearpanelBypass switchesare usedto passsignals throughthe clockinputs andoutputs withoutany attenuation.
In bypass mode, signals are passed through even if the DS1404 is unpowered. No DS1404 features, such as soft-
start are active when in Bypass mode.
Connecting your PC to the DS1404
Connection from the PC to the DS1404 is made through your PC’s com. port. If your PC does not have a standard
9 pin, RS-232, communications port you must use a USB to Com adaptor in order to connect the DS1404 to your
PC’s USB port.
Using the cable supplied with the DS1404, connect your PC’s com port (or USB adaptor) to the port labeled serial port
on the back of the DS1404. See the following sections for activating the connection and configuring the DS1404.

6
Dynasound, Inc. 6439 Atlantic Blvd. Norcross, GA. 30071 800.989.6275
If you are not sure which port is used on your computer you may need to check Windows device manager or your
USB adaptor software to determine the correct port setting.
Start the DS1404 control software. After installing the software there will be a Dynasound section in your programs
menu. Click the Start button, go to the “All Programs” list and navigate to the Dynasound menu. Select DS1404
and click to start the program.
When the program starts, use the menu to select “Settings > Communications”. the screen should appear as
below. You must select the correct com port based on your PC. The PC and DS1404 cannot communicate if the
correct port is not chosen.
Establishing Communications with the DS1404
The DS1404 is factory configured to provide a standard Monday through Friday attenuation schedule without need
for further configuration. See the section on “Specifications” for details of the provided schedule.
To create a custom attenuation schedule you must connect the DS1404 to your PC using the provided cable. The
following steps describe connecting your PC to the DS1404 and using the provided software to create custom
soundmasking schedules.
communication settings window

7
Dynasound, Inc. 6439 Atlantic Blvd. Norcross, GA. 30071 800.989.6275
After selecting the correct port settings, use the main menu to select “ File > Connect”. The screen shown below
should appear.
CommunicationsfromtheDS1404tothePCareshownnearthebottomofthiswindow labeled“Controller Response”.
When this window appears, it is important to observe the controller response to see if a connection has been made.
Each time this window is opened the PC based control software attempts to communicate with the DS1404. If, after
a few seconds, the controller response still shows off-line status then close and reopen the window to initate another
connection attempt.
It is important to understand that when creating soundmasking schedules, that you are programming the amount of
attenuation that will be introduced by the DS1404, not the actual final volume levels of the sound system. In other
words, a setting of 15 would produce the most attenuation of the system (the least volume); a setting of 0 would
introduce no attenuation (the most volume).
The DS1404 can be configured to provide from 0dB to 15 dB attenuation per channel and stores an attenuation value
for each minute of the week. Weekly attenuation schedules are easily created with just a few clicks by using the
“Create Weekly Schedule” feature of the control software.
main configuration window - channel one shown
Creating Attenuation Schedules

8
Dynasound, Inc. 6439 Atlantic Blvd. Norcross, GA. 30071 800.989.6275
For example, let’s assume you need to create a soundmasking attenuation schedule for a company having typical
Monday thru Friday 9am to 5pm hours. Let’s also assume that you would like the soundmasking to lower by
10 decibels each night, taking one hour duration to transition from full volume (0 db attenuation) to 10 dB of
attenuation.
In the “Create Weekly Schedule” portion of the window you are given options for weekdays (Mon-Fri, Mon-Sat,
Mon-Sun.), Start andEnd times,Attenuation (0-15dB) and Duration (0-120). Fortheabovementioned schedule
you would select Mon-Fri, 8:00 AM to 5:00 PM, 10 dB attenuation and 60 (minutes) duration. 8:00 AM was chosen
as a start time assuming that we wanted the soundmasking to be “ramped up” by 9:00 AM and the ramp-time or
“Duration” was set to 60 minutes. The parameters must be separately configured for each of the four channels.
Note that each time any of these options are changed the weekly schedule is updated and displayed on the Weekly
Schedule chart.
Schedules must be balanced in terms of attenuation increases and decreases. Using the options in the “Create
Weekly Schedule” section insures that increases and decreases are balanced, as it creates matching events.
While it’s very simple to create a schedule that works for most situations, with just a few clicks, there will be
situations that require a more complex schedule. For example, perhaps the weekly schedule is fine except that
the company hours are shorter on Fridays. One can still create the weekly schedule and then modify an individual
event by right-clicking the event and changing the required parameters. Other needs may be, for example, raising
the soundmasking more slowly (longer duration) in the morning and faster ramp down(shorter duration) in the
evening. As you can see there are endless variations.
Creating Attenuation Schedules - continued
The example to the left shows
the Ramp-down time being modi-
fied for every Tuesday evening.
Modifying Weekly Schedules

9
Dynasound, Inc. 6439 Atlantic Blvd. Norcross, GA. 30071 800.989.6275
In addition to storing a routine weekly schedule for each channel the DS1404 can be programmed for holiday or
non working days. Date “events” such as Holidays may be programmed as one-time or reoccurring events.
The most flexible, and potentially confusing, way to create schedules is to use the “Create Single Event” portion of
thewindow.Thisfeaturecan create“singleevents”forindividual ormultipledaysbutdoes notcreatea“matching”or
“counter-acting” event. In this mode the user is responsible for balancing the attenuation increases and decreases
over the course of a week. While its seldom the best method to create an entire weekly schedule, this feature can
be used to insert “ups” and “downs” inside a workday for lunch periods or breaks.
Keep in mind that you are always working on one-channel at a time, based on which tab you are viewing in the
configuration window. Each tab is a channel specific schedule. The last tab is for date specific events that are
applied to all channels.
Creating Date Events
Creating Attenuation Schedules - continued

10
Dynasound, Inc. 6439 Atlantic Blvd. Norcross, GA. 30071 800.989.6275
Creating Date Events - continued
To create a One-Time Event, select “Apply as One-Time Holiday” on the list box as shown. Next select the desired
date on the calendar. Select the amount of attenuation for the one time event and click Apply. The information will
be added to the One Time Events list.
The process to create a Reoccurring Event is very similiar excpet that “Apply as Reoccurring Holiday is selected
instead of One Time Holiday. The reoccurring event will be added to the Reoccurring Events table.
One time or reoccurring events can be removed by clicking on the row pointer of the line you want to remove and
pressing the PC’s delete key.

11
Dynasound, Inc. 6439 Atlantic Blvd. Norcross, GA. 30071 800.989.6275
Creating a Transition Schedule
The process to create a transition schedule, basically creates a series of One-Time Events in order to gradually
transition the soundmasking. One-Time Holidays cannot be scheduled on the same day as a Transition Schedule
date.
A Transition schedule is used to slowly increment a newly installed soundmasking system into an existing facility.
You can choose a 5, 10, or 20 day period.

12
Dynasound, Inc. 6439 Atlantic Blvd. Norcross, GA. 30071 800.989.6275
Downloading Weekly Schedules to the DS1404
Any change to a channels attenuation schedule requires a complete erasure, download and memory verification
for that channel. While this process is very easy, it does take several minutes and cannot be interrupted. To
download a schedule into a particular channel, be on the selected channel’s tab and click Download Schedule
to Conroller as shown below. General progress status will be displayed in the controller response area. A more
detailed progress status may be observed on the LCD of the DS1404.
Downloading Date Events to the DS1404
Any change to date events requires a complete erasure and download. While this process is very easy, it does
take several minutes and cannot be interrupted. To download date or holiday information into the DS1404, have
selected the Date Events tab and click the menu as shown above. General progress status will be displayed in the
controller response area. A more detailed progress status may be observed on the LCD of the DS1404.

13
Dynasound, Inc. 6439 Atlantic Blvd. Norcross, GA. 30071 800.989.6275
Setting Current Date and Time
While communicating with the DS1404, you may sync the time on the DS1404 Contoller to that of your PC by
selecting the menu item shown above. You will receive a confirmation response back from the controller, verifying
the change.
The time of day may be set using the front panel buttons, allowing minor adjustments without need for a PC
connection. The “Mode” button toggles between Hours and Minutes and the Set button increments the respective
value. Date changes must be made with a PC connection using the DS1404 software. After setting the hours or
minutes, the Mode button must be pressed until the display returns to normal operating mode. In normal operating
mode, the date, time and attenuation levels are displayed. The DS1404 cannot operate if left in “Set Hours” or
“Set Minutes” mode.
Setting Current Time with Front Panel Buttons

14
Dynasound, Inc. 6439 Atlantic Blvd. Norcross, GA. 30071 800.989.6275
Setting Daylight Saving Time Option
The DS1404 can adjust for Daylight Saving Time if properly configured. While communicating wiith the DS404,
select your preference as shown above. This parameter will be automatically saved to the DS1404. You should
receive a confirmation reponse from the DS1404.
The Download DST Dates option should not be required unless the current DST starting and ending dates are
changed through legislation, or the current date is beyond 2026. The factory downloaded dates are shown on the
Date Functions tab of the DS1404 software and can be modified and downloaded into the DS1404 if a change or
update is needed.

15
Dynasound, Inc. 6439 Atlantic Blvd. Norcross, GA. 30071 800.989.6275
Setting Soft-Start Option
The DS1404 can ease system starts by gradually increasing the soundmasking over a 15 to 20 second period.
If this feature is activated, upon power up, the DS1404 will wait 10 seconds to let other system amplifiers go
through a power up sequence. The DS1404 then slowly ramps up the soundmasking. While communicating with
the DS1404, select your preference as shown above. This parameter will be automatically saved to non-volatile
memory in the DS1404. You should receive a confirmation reponse from the DS1404.
If the Soft Start feature is activated at night, or while any given channel is attenuated, the DS1404 will soft start
from 20 dB attenuation and slowly ramp to the correct level based on the programmed schedule.

16
Dynasound, Inc. 6439 Atlantic Blvd. Norcross, GA. 30071 800.989.6275
Specifications
serial port
line level outputs line level inputs
bypass
normal
1
120 v. 60 Hz
1234
2341234
bypass controls
No user servicable parts inside.
Refer servicing to qualified
personnel. Do not expose to moisture.
Replace fuse with same value only.
DS1404 programmable level control.
Made in USA
Align text with cutouts as indicated.
File at full scale. Drawing printed @ print to fit page.
All text black .
front panel
rear panel
Dimensions:
Weight:
Power Consumption:
Channels:
PC Interface:
Default Schedule:
18” wide , 1.75” tall (one rack space) and 8” deep
4 channel
RS232 Com Port 9 pin
8 lbs.
Monday 05:00 PM 10dB decrease 60 minute duration
Tuesday 07:00 AM 10dB increase 60 minute duration
Tuesday 05:00 PM 10dB decrease 60 minute duration
Wednesday 07:00 AM 10dB increase 60 minute duration
Wednesday 05:00 PM 10dB decrease 60 minute duration
Monday 07:00 AM 10dB increase 60 minute duration
Thursday 07:00 AM 10dB increase 60 minute duration
Thursday 05:00 PM 10dB decrease 60 minute duration
Friday 07:00 AM 10dB increase 60 minute duration
Friday 05:00 PM 10dB decrease 60 minute duration
0.2 Amps

17
Dynasound, Inc. 6439 Atlantic Blvd. Norcross, GA. 30071 800.989.6275
Warranty & Service
DYNASOUND IS PLEASED TO EXTEND THE FOLLOWING 5-YEAR LIMITED WARRANTY
TO THE ORIGINAL PURCHASER OF THE PROFESSIONAL SOUNDMASKING EQUIP-
MENT DESCRIBED IN THIS MANUAL.
DYNASOUND expressly warrants this product to be free from
defects in material and workmanship for a period of 5 YEARS from
the date of purchase as a new product from an authorized DYNA-
SOUND dealer under the following conditions.
1. In the event the warranted DYNASOUND product requires ser-
vice during the warranty period, DYNASOUND will repair or replace,
at its option, defective materials, provided that the original purchas-
er attains a Return To Manufacturer Authorization (RMA) number by
contacting DYNASOUND, then shipping or transporting the unit to
the manufacturer at the address below. Transportation and insur-
ance charges to the DYNASOUND factory for warranted products
or components thereof to obtain repairs shall be the responsibility of
the purchaser. DYNASOUND will return ship the product at factory
expense in the same manner received.
2. This warranty will be VOIDED if the serial number has been
removed or defaced; or if the product has been subjected to acci-
dental damage, abuse, rental usage, alterations, or attempted repair
by any person not authorized by DYNASOUND to make repairs; or
if the product has been installed contrary to DYNASOUND System’s
recommendations.
3. Electro-mechanical fans, electrolytic capacitors, and the normal
wear and tear of appearance items such as paint, knobs, handles,
and covers are not covered under this warranty.
4. DYNASOUND shall not in any event be liable for special, inci-
dental, or consequential damages, including lost profits, loss of use,
property damage, injury to goodwill, or other economic loss of any
sort. Except as expressly provided herein, DYNASOUND disclaims
all other liability to purchaser or any other persons arising out of use
or performance of the product, including liability for negligence or
strict liability in tort.
5. This warranty is in lieu of all other warranties expressed or
implied. DYNASOUND expressly disclaims all implied warranties of
merchantability and fitness for a particular purpose. The remedies
set forth herein shall be the purchaser’s sole and exclusive remedies
with respect to any defective product. The agents, employees, dis-
tributors, and dealers of DYNASOUND products are not authorized
to modify this warranty or to make additional warranties binding on
DYNASOUND systems. Accordingly, additional statements such as
dealer advertisements or representations do not constitute warran-
ties by DYNASOUND.
6. No action for breach of this warranty may be commenced more
than one year after the expiration of this warranty.
Dynasound, Inc.
6439 Atlantic Boulevard
Norcross, Georgia 30071
Nationwide [phone]
In Georgia [phone]
www.soundmasking.com
