DynaVox T10 User manual

Part # 401438-B
DynaVox T10 User’s Guide
Copyright © 2013 DynaVox Systems LLC
All rights reserved. No part of this book may be reproduced, stored in a retrieval system, or transmitted in any form, by any means
(electronic, photocopying, recording, or otherwise) without the prior written permission of the publisher.
Copyright protection claimed includes all forms and matters of copyrightable material and information allowed by statutory or judicial
law or hereafter granted, including without limitation, material generated from the software programs which are displayed on the
screen such as screen displays, menus, etc.
Although every precaution has been taken in the preparation of this book, the publisher assumes no responsibility for errors or
omissions.
In North America:
For information, write to:
DynaVox Systems LLC
2100 Wharton Street, Suite 400
Pittsburgh, Pennsylvania 15203 USA
The European Authorized Representative is:DynaVox Systems Ltd.
Pure Offices Plato Close
Tachbrook Park
Leamington Spa
Warwickshire
United Kingdom
CV34 6WE
DynaVox® is a registered trademark of DynaVox Systems LLC.
DynaVoxT10™ is a registered trademark of DynaVox Systems LLC.
All other brand and product names mentioned are trademarks or registered trademarks of their respective holders.
Second Edition
Part Number 401438
Published October 2013
Created in the United States of America

DynaVox T10 User’s Guide
Part # 401438-B
Table of Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Resources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
myDynaVox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Additional Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Hardware Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Charging the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Temperature/Humidity/Atmospheric Pressure Ranges . . . . . . . . . . . . . . . . . . . . . . . .9
Mounting/Transporting Your T10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Product Cleaning/Handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Turning the T10 On For The First Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
The Tool Bar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
The Settings Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Open the Settings Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Page Browser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Page Creator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Vocabulary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Interface Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Access Method Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Toolbar Editor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Voice Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Rate Enhancement Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Camera Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Media Library . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Backup/Restore Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
Editing a Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
Cautions - Package Labeling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Important Information About Your DynaVox T10 . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
Intended Use of This Product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
Caution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45

DynaVox T10 User’s Guide 1
Part # 401438-B
Introduction
The DynaVox®T10 is an integrated hardware and software solution for AAC, which features
the DynaVox Compass™ communication software.
This User’s Guide provides an overview of the basic operation of your T10 Android 4.0.4
tablet. It points out key hardware features, briefly explains how to customize the pages and
their content, and describes the most frequently-used features and functions of your T10.
Resources
This User’s Guide is only a brief, introductory reference for your T10. Many other resources
are available.
NOTE
On your T10, open the Settings menu. Then select Help. A menu will open with links to
myDynaVox.com to access documentation, Help Videos, and the Knowledgebase.
myDynaVox
myDynaVox.com is your personal online storage and administration website that you can use
to manage the Compass software running on your T10. It is available to you from anywhere via
the web.
Go to www.myDynaVox.com to register for an account.
Your myDynaVox account integrates you with a community of clinicians, technical experts, and
your peers and provides you with a responsive community of help and support.
After you set up your account, you can access it from anywhere on the web to:
•Register your T10
•Upload, download, and share communication pages
•Receive software updates and new communication content
•Backup and restore user data
•Access implementation and therapy supports and tools
•View and participate in discussion forums
•Find technical support and documentation resources
•Search the Knowledgebase
•View help videos
•Manage your user profile

2
Additional Documentation
A Quick Start Guide was shipped with your DynaVox T10. This guide provides an overview of
your T10, walks you through starting up and customizing your new T10, and provides
information on resources available to you on both myDynaVox.com and through the Help
menu on your device.
Support
NOTE
Before you open a new case, write down the serial number of your T10. It can be found on the
bottom edge of your device - or select Help from the Settings menu, and select the Open button
next to About.
My T10 serial number is:______________________________
Technical Support
www.myDynaVox.com > Community & Support > myDynaVox Community
Visit the online library to access Knowledgebase articles, research product tips, and
perform custom searches, or visit the Community Q&A section.
Or - if you have a problem with your T10 device, start the repair process by opening a
new case.

DynaVox T10 User’s Guide 3
Part # 401438-B
Hardware Overview
BLOCK DIAGRAM

4
2 31 4
5
76
5
Front:
To p :

DynaVox T10 User’s Guide 5
Part # 401438-B
8
9 9
Back:
Bottom:
10
11
12
13
14
9 9

6
CAUTION
The LCD may show "image persistence" if the same image or page is displayed for four (4)
consecutivehoursorlonger.Thevisual artifactsmay ormay notbe noticeableordistracting.They
will not cause permanent damage to the LCD.
Front: 1Charging Indicator: Lit amber when the battery is charging. Turns
blue when the battery is fully charged.
2 Power Button: To turn the T10 on, press and hold until the splash
screen appears. Press and release to put to sleep. To shut down the
T10, press and hold until the shutdown menu appears.
3Front-facing Camera: Takes photographs of people and objects in
view of the T10 screen - for example, self portraits.
4 Ambient Light Sensor: Adjusts the screen brightness based on
the surrounding light.
Top 5Speakers: Dual speakers provide an extensive range of volume.
6 Volume Rocker Switch: Press on the + side of the switch to
increase volume. Press on the - side of the switch to decrease
volume.
Right Side 7Speaker/Headphone/External Microphone Jack: Connect an
external speaker, headphones for private audio, or an external
microphone.
Back 8 Rear-facing Camera: Use for taking custom photos to share with
others or to put on your communication pages.
9Lanyard connections: Provide attachment points for the T10 strap.
Bottom 10 Charger Port: Plug in the adapter/charger to charge the battery.
11 Micro USB Port: Connect to a micro-USB to full-size USB cable
adaptor. (DynaVox does NOT recommend the use of a USB hub.)
12 30-Pin Dock Connector: (for future use)
13 Micro HDMI Port: Connect an external monitor to your T10.
14 Built-in Microphone: Record speech and custom sounds.

DynaVox T10 User’s Guide 7
Part # 401438-B
Adapter
For safe and optimal performance, the adapter for the DynaVox T10 should be kept within the
following parameters:
Adapter Model: MTP451BX - 120300
DC Max Rating: 12V 3A
Adapter Voltage Range: 100-240V, 50/60Hz, 1.5A

8
Charging the Battery
When the battery charge is low, the T10 will emit an audible beep. You should plug in your T10
and recharge the battery immediately.
1. Plug the charger supplied with your T10 into a wall outlet.
2. Connect the charger to the charger port on the device (Page 5, #10).
The charging indicator (Page 4, #1) will glow amber while your T10 is charging. It will turn
blue when it is fully charged.
3. After your T10 is fully charged, disconnect the charger.
You can’t overcharge the battery. It is fine to charge the battery overnight.
You can use the T10 while the battery is charging.
The battery model is 5860103P/4000mAh/7.4V.
CAUTION
Because of internal chemical reactions, battery performance may deteriorate over time. In
addition, failure to keep the conditions of use (charge, discharge, ambient temperature, etc.)
withinspecifiedrangesmayshortenthebatterylifeexpectancy, ordamageyour T10.Ifthebattery
cannot maintain a charge for long periods of time, even when it is charged correctly, it may need
to be replaced.
CAUTION
For safe and proper operation of your DynaVox T10, use only chargers, batteries, and
accessories that have been approved by DynaVox Technologies.

DynaVox T10 User’s Guide 9
Part # 401438-B
Temperature/Humidity/Atmospheric Pressure
Ranges
For optimal device performance, the T10 should be kept within the following ranges:
NOTE
Run time will be shortened at the high and low ends of the temperature range.
Mounting/Transporting Your T10
If you use your T10 device while in a wheelchair, you should have it properly mounted for both
communication and transportation purposes. Wheelchair mounting systems are available
through DynaVox.
Protective and accessible carrying cases are also available. Consult the DynaVox website
(www.dynavoxtech.com) or your DynaVox sales consultant for more information.
Product Cleaning/Handling
To clean your T10, first turn it off and then wipe it gently with a damp cloth or soft paper towel.
You may dampen the towel with a mild window cleaner to remove fingerprints, food particles,
and dust.
Do not use tape or stickers on either the touch screen or the case, as they are difficult to
remove and may damage the device surface. Tape, stickers, and other sticky materials can
damage the touch screen and interfere with the operation of the device.
Be sure to avoid getting your T10 wet. Never submerge it in water (e.g., dishwasher). If your
unit accidentally gets wet, be sure to shut it down and allow it dry thoroughly. If after 24 hours
you find that the T10 seems to function normally, there is probably no damage. If it fails to
function or behaves abnormally, go to www.myDynaVox.com > Community & Support >
myDynaVox Community to start the repair process by creating a new case. You may need to
ship it to DynaVox for repairs.
Be careful not to drop it. Such treatment is not recommended and can shorten the life of your
T10. Do not use a sharp object to make selections on the touch panel, as this can cause
damage. Use a special capacitive stylus.
CAUTION
Never, under any circumstances, disassemble your T10. Doing so for any reason will void the
warranty, and you will be responsible for the cost of any required repairs.
Activity Temperature Range
Using the T10 32°F - 104°F (0°C - 40°C)
Charging the T10 battery 32°F - 113°F (0°C - 45°C)
Storing the T10 14°F - 113°F (-10°C - 45°C)
Relative humidity Up to 90%
Atmospheric pressure 80 - 106kPa

10
Turning the T10 On For The First Time
Press the Power button (Page 4, #2) to turn the T10 on. Select the DynaVox icon on your
desktop.
DYNAVOX ICON ON DESKTOP
The Setup Wizard screen will open.
SETUP WIZARD SCREEN
The Setup Wizard will walk you through the steps to create a new user and choose an
appropriate page set.
When setup is complete, a Congratulations screen will open.
CAUTION
If your device freezes or hangs or presents error messages, you may need to close programs or
reset the device to regain functionality.
CAUTION
Any system upgrade or installation must be done by a DynaVox technician. If you are not a
resident of North America, please call the dealer from whom you purchased thedevice. DynaVox
can provide the Standard Operating Procedure for the upgrade or installation of any DynaVox
system apps.

DynaVox T10 User’s Guide 11
Part # 401438-B
CONGRATULATIONS SCREEN
From the Congratulations screen, you can:
•View orientation videos. (The Orientation tab will, by default, be open. Select the video
thumbnail to launch the orientation videos.)
•Select the myDynaVox tab for information on the myDynaVox.com website. (See
myDynaVox.)
•Select the Resources tab for a list of resources available on the myDynaVox.com website
to support your use of the DynaVox Compass software.
When you have viewed the videos and learned about the myDynaVox.com website, select the
Start Communicating button. You are now ready to start communicating with your DynaVox
T10!

12
The Tool Bar
TOOLBAR (EXAMPLE)
Depending on the pageset you are using, a Toolbar may be
present on your screen. The Toolbar is designed to give you quick
access to your most-used tools and pagesets.
The appearance of the Toolbar may vary. It can be customized
and configured to your specifications - you can add or remove
buttons and folders, hide the Toolbar, and even move it from the
left side of the screen to the top, bottom, or right side of the
screen. (See Interface Settings.)
The Settings button in the Toolbar (circled in the illustration to the
left) opens the Settings menu, which provides you with easy
access to the tools you need to customize the DynaVox Compass
software. (See The Settings Menu below.)

DynaVox T10 User’s Guide 13
Part # 401438-B
The Settings Menu
The Settings menu gives you access to the Page Browser, Page Creator, Vocabulary, Interface
and Toolbar settings, Voice Settings, Rate Enhancement components, the camera and media
library, access method settings, backup and restore functions, as well as links to help
documentation and videos.
SETTINGS MENU

14
Open the Settings Menu
There are two methods of opening the Settings menu, depending on whether or not your
Toolbar is visible onscreen:
Open the Settings Menu if the Toolbar is Visible:
Simply select the Settings button on the Toolbar. The Settings menu will open.
Open the Settings Menu if the Toolbar is Not Visible
1. Select the Edit button in the top right corner of your screen.
EDIT BUTTON
If the Toolbar is hidden, a dialog will open presenting you with two options:
2. Select the Settings button. The Settings menu will open.
REFERENCE
When the Toolbar is enabled, the Settings button will always be visible on your screen. See
Interface Settings for instructions on enabling the Toolbar.

DynaVox T10 User’s Guide 15
Part # 401438-B
Settings
Page Browser
The Page Browser is the quickest way to open or edit a page. You can search for a page by
name, or look through the folders and see preview images of pages before opening them.
Open the Settings menu. (See Open the Settings Menu.)Then select Page Browser.
PAGE BROWSER (EXAMPLE)
The icons at the top right of the screen (circled in the illustration above) enable you to display
the pages and folders as a grid (default) or list.
Use the arrow button at the upper left of the screen (circled in the illustration above) to move
up through the layers of folders. Select a folder to open it and display the pages inside. Select
a page, and a large thumbnail of the page will open.
SELECTED PAGE IN PAGE BROWSER
Simply select Open to open the selected page or Editor to edit the page.

16
Page Creator
Create an entirely new page - either from a template, or based on the layout of an existing
page. You can customize your new pages with your own content - vocabulary, symbols, media
files, etc.
Open the Settings menu. (See Open the Settings Menu.)Then select Page Creator.
PAGE CREATOR
The icons at the top right of the screen (circled in the illustration above) enable you to display
the pages and folders as a grid (default) or list.
Select from a number of templates (blank or by activity type or instructional area) or select the
Like Page tab to create a new page using the layout of an existing page. You can also use the
Search text field to find a page you would like to use as a template.
Use the arrow button at the upper left of the screen (circled in the illustration above) to move
up through the layers of folders. Select a folder to open it and display the pages inside. Select
a page, and then select Create at the top right corner of the screen. A dialog will open - name
the page and browse for a location for it. You can then edit the page to your exact
specifications.

DynaVox T10 User’s Guide 17
Part # 401438-B
Vocabulary
Your vocabulary (your talk topic choices, word list, and phrases) was selected when you used
the Setup Wizard to set up your user account and is based on your input regarding your age,
gender, condition, and communication level.
Most vocabulary items are stored in folders. You can edit, copy, delete, change the order of
appearance onscreen, and add new vocabulary items using the Vocabulary menu.
Open the Settings menu. (See Open the Settings Menu.)Then select Vocabulary.
VOCABULARY MENU
Select the Word Lists, My Phrases, or Topics button.
VOCABULARY MENU - WORD LISTS (EXAMPLE)

18
Navigate through the folders (use the arrow button at the upper left of the screen - circled in
the illustration above) - to move up through the layers of folders. Select a folder to open it.
When you find the folder or item you wish to edit, select Manage at the top right corner of the
screen.
NOTE
If you are adding a new folder oritem, navigate to the level at which you want to add the folder or
item, then select Manage.
EDIT VOCABULARY MENU (EXAMPLE)
