Dynex DX-AC9013 User manual

Dynex Laptop AC Power
Adapter
DX-AC9013
User Guide
DX-AC9013 11-1024_MAN_V1.fm Page 1 Thursday, November 3, 2011 12:15 PM

2Contents
Dynex DX-AC9013
Laptop AC Power Adapter
Contents
Introduction .............................................................2
Safety information ...................................................3
Features ....................................................................3
Using the AC power adapter .....................................4
FAQ for Dynex Adapters ............................................6
Specifications ...........................................................8
Legal notices .............................................................9
Three-year limited warranty ...................................11
Introduction
Thank you for purchasing a Dynex universal laptop power adapter. This
adapter plugs into any AC power outlet anywhere in the world, and
provides a reliable power source to run your laptop computer and charge
its internal battery. This adapter provides a reliable power source to run
your laptop computer and charge its internal battery.
NOTE: A physical adapter plug may be necessary to plug into some AC
power outlets outside of the United States.
This adapter comes with a variety of numbered tips which connect to the
output cable of the adapter and control the output voltage. To make sure
that the proper voltage is delivered to your laptop, you must always make
sure that you are using the correct tip for your specific laptop model. Read
the following instructions and refer to the Tip Compatibility Guide
included with this adapter to make sure you select the correct tip for your
laptop. You can also go to the Tip Wizard at www.dynexproducts.com for
a complete listing of compatible models.
CAUTION: This AC power adapter is not compatible with Mac
computers or laptops requiring more than 90 watts of power.
DX-AC9013 11-1024_MAN_V1.fm Page 2 Thursday, November 3, 2011 12:15 PM

Safety information 3
Safety information
• Do not expose the power adapter to rain, moisture, or excessive
dust. It may cause shock hazards.
• Do not operate the adapter in direct sunlight.
• Operate the adapter in a well ventilated area. Maximum ambient
temperature around the power adapter must not exceed 105°
Fahrenheit (40° Celsius).
• Do not open the power adapter under any circumstances. The
power adapter is not intended to be repaired in case of failure or
component defect. There are no internal serviceable parts.
• Discontinue use and contact our toll free help line for assistance
[phone] if any of the following should occur:
• The adapter shuts down when it is plugged into the
device (LED turns off).
• The adapter's LED light blinks when the adapter is
plugged into an AC power outlet.
• A cord or plug is damaged or frayed.
• Do not use with laptops that require more than 90 watts of
power.
• Make sure to use the correct tip for your laptop listed in the Tip
Compatibility Guide. You can also go to the Tip Wizard at
www.dynexproducts.com for a complete listing of compatible
models. Do not use a tip that is not listed for your laptop.
• Keep away from children.
Features
• Provides up to 90 watts of power
• Includes over-voltage, over-temperature, and short circuit
protection
• Powers 19V laptops using a standard AC wall outlet
• Can be used anywhere in the world - no voltage converter
needed (an adapter plug may be necessary)
DX-AC9013 11-1024_MAN_V1.fm Page 3 Thursday, November 3, 2011 12:15 PM

4Using the AC power adapter
Package contents
• Dynex Laptop AC power adapter
• Seven tips
•ACpowercord
• Tip Compatibility Guide
• User Guide
Using the AC power adapter
To use the AC power adapter:
1Locate your laptop manufacturer and model from the Tip
Compatibility Guide, or go to www.dynexproducts.com and go to
DX-AC9013 to find the Tip Wizard.
2Identify the correct tip number for your laptop model.
DC input
jack
Tip
Output
cable
AC adapter AC cord
AC
power
outlet
LED
DX-AC9013 11-1024_MAN_V1.fm Page 4 Thursday, November 3, 2011 12:15 PM

Using the AC power adapter 5
CAUTION: The use of an incorrect tip may damage your laptop. Do
not use this product if you cannot locate your laptop model in the Tip
Compatibility Guide included with this AC adapter or by using the Tip
Wizard at www.dynexproducts.com. If you still have questions,
contact our toll-free help line for assistance at [phone].
This AC power adapter is not compatible with Mac computers or
laptops requiring more than 90 watts of power.
NOTE: If the compatible tip for your device is not included in the
adapter package, one free tip can be ordered through the Tip Wizard
at www.dynexproducts.com. Use the Tip Wizard to locate the
manufacturer and model and you can order your complementary tip.
If you are unable to locate your laptop on the Tip Wizard or need
assistance please contact Dynex customer service at [phone].
3Locate the specified tip from the tip bundle provided. Each tip is
clearly numbered.
4Connect the selected tip to the end of the output cable, making
sure that the pins on the tip are aligned with the holes in the
cable. The ridge on the inside of the tip should align with the
groove in the output cable connector. Make sure that the tip is
pushed all the way into the output cable's connector.
DX-AC9013 11-1024_MAN_V1.fm Page 5 Thursday, November 3, 2011 12:15 PM

6FAQ for Dynex Adapters
5Connect the AC cord to the socket on the AC adapter.
6Plug the AC cord into an AC power outlet. The LED on the adapter
turns on, indicating that the adapter is powered and ready.
IMPORTANT: If the adapter's LED does not turn on, or if it blinks,
discontinue use and contact our toll free help line for assistance at
[phone].
7Plug the tip connected to the output cable into the DC input jack
on the side or back of your laptop. The adapter powers the laptop
and charges its battery.
FAQ for Dynex Adapters
What tip should I use for my laptop?
You can determine the correct tip for your laptop by referencing the Tip
Compatibility Guide included with the adapter or by visiting the Tip
Wizard at www.dynexproducts.com. Locate your laptop manufacturer
and model and the correct tip will be listed.
If you cannot find your specific laptop model please contact Dynex
customer service at [phone] for additional assistance.
My tip is not included, how do I order a new one?
First review the included Tip Compatibility Guide to locate the correct tip
for your specific laptop. You can also go to the Tip Wizard at
www.dynexproducts.com for a complete listing of compatible models. If
the compatible tip for your laptop is not included in the adapter package,
one free tip can be ordered through the Tip Wizard at
www.dynexproducts.com. Use the Tip Wizard to locate your laptop
manufacturer and model and you can order your complimentary tip. If
you are unable to locate your laptop in the Tip Wizard please contact
Dynex customer service at [phone].
DX-AC9013 11-1024_MAN_V1.fm Page 6 Thursday, November 3, 2011 12:15 PM

FAQ for Dynex Adapters 7
How do I connect the tip to the adapter cable?
After you have selected the correct tip for your laptop, connect the tip to
the output cable, making sure that the ridge on the inside of the tip aligns
properly with the groove in the output cable connector. Additionally, the
pins on the inside of the tip should be in line with the holes in the output
cable. The tip should be pushed firmly onto the cable until the tip and
cable meet and there is no gap.
What other laptops can I use this adapter for?
The Dynex Laptop AC Power Adapter is compatible with thousands of
laptop models. A complete list of compatible laptops can be viewed
through the Tip Wizard at www.dynexproducts.com.
Why doesn't the tip fit into my laptop?
If the tip does not appear to fit into your laptop you may have selected the
incorrect tip for your laptop. The tip should fit snugly inside the DC input
jack on the side or back of your laptop. If the tip does not fit into the jack,
do not force the tip. Confirm you have selected the correct tip for your
laptop by referencing the included Tip Compatibility Guide or visiting the
Tip Wizard at www.dynexproducts.com. If you need additional assistance
please contact Dynex customer service at [phone].
Will using an incorrect tip damage my laptop?
The tips are designed to be used with specific laptops and so you should
only use the tip that is designated specifically for your laptop. The correct
tip can be identified by using the online Tip Wizard at
www.dynexproducts.com or by locating your specific laptop in the
included Tip Compatibility Guide.
The use of an incorrect tip may cause performance issues, including the
inability to charge the internal battery or power the laptop, or the display
of an error message on the laptop screen. It is also possible that the use of
an incorrect tip could damage your laptop. For these reasons, it is
necessary to use the tip designed specifically for your laptop.
DX-AC9013 11-1024_MAN_V1.fm Page 7 Thursday, November 3, 2011 12:15 PM

8Specifications
My laptop is less than 90 watts (e.g. 65 watts). Will this
adapter damage my laptop?
No, using this power adapter will not damage your laptop. This adapter
only supplies as much power as required by the laptop, up to a maximum
of 90 watts.
My laptop is more than 90 watts (e.g. 120 watts). Will
this adapter damage my laptop?
This is a 90 watt adapter and it should NOT be used with laptops that
require more than 90 watts of power.
I notice that the adapter is warm when I use it. Is this a
problem?
During standard operation the adapter body may feel warm, and this is
normal. The adapter should always be placed in a ventilated area in order
to prevent over-heating.
How long is the cord from the wall to the laptop?
The AC input cord is 6 feet (172 cm) and the DC output cord is 3.8 feet
(116 cm).
Specifications
AC wall socket input cable 6’ (172 cm)
DC power output cable 3.8’ (116 cm)
AC input voltage 100~240V AC, 50-60Hz ~2.5 A
DC output voltage 19 Volts DC
Output current 4.7 Amps
Output power 90 W maximum (AC)
Adapter Weight 8 oz. (228 g)
Adapter Dimensions (LxWxH) 3.94 x 2.76 x 0.77 inches
(100 x 70 x 20 mm)
DX-AC9013 11-1024_MAN_V1.fm Page 8 Thursday, November 3, 2011 12:15 PM

Legal notices 9
Legal notices
FCC Part 15
This device complies with Part 15 of the FCC Rules. Operation of this
product is subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired
operation.
This equipment has been tested and found to comply within the limits for
a class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced technician for help.
FCC warning
Changes or modifications not expressly approved by the party responsible
for compliance with the FCC Rules could void the user’s authority to
operate this equipment.
Copyright
© 2011 Dynex. Dynex is a trademark of BBY Solutions, Inc. Other brands
and product names are trademarks or registered trademarks of their
respective holders. Specifications and features are subject to change
without notice or obligation.
For service and support call [phone].
DX-AC9013 11-1024_MAN_V1.fm Page 9 Thursday, November 3, 2011 12:15 PM

10 Legal notices
This page intentionally left blank.
DX-AC9013 11-1024_MAN_V1.fm Page 10 Thursday, November 3, 2011 12:15 PM

Legal notices 11
Three-year limited warranty
Dynex Products (“Dynex”) warrants to you, the original purchaser of this new
DX-AC9013 (“Product”), that the Product shall be free of defects in the original
manufacture of the material or workmanship for three (3) years from the
purchase of the Product (“Warranty Period”). This Product must be purchased
from an authorized dealer of Dynex brand products and packaged with this
warranty statement. This warranty does not cover refurbished Product. If you
notify Dynex during the Warranty Period of a defect covered by this warranty that
requires service, terms of this warranty apply.
How long does the coverage last?
The Warranty Period lasts for three years (1095 days), beginning on the date you
purchased the Product. The purchase date is printed on the receipt you received
with the product.
What does this warranty cover?
During the Warranty Period, if the original manufacture of the material or
workmanship of the Product is determined to be defective by an authorized
Dynex repair center or store personnel, Dynex will (at its sole option): (1) repair
the Product with new or rebuilt parts; or (2) replace the Product at no charge with
new or rebuilt comparable products or parts. Products and parts replaced under
this warranty become the property of Dynex and are not returned to you. If service
of Products and parts are required after the Warranty Period expires, you must pay
all labor and parts charges. This warranty lasts as long as you own your Dynex
Product during the Warranty Period. Warranty coverage terminates if you sell or
otherwise transfer the Product.
How to obtain warranty service?
If you purchased the Product at a retail store location, take your original receipt
and the Product to the store you purchased it from. Make sure that you place the
Product in its original packaging or packaging that provides the same amount of
protection as the original packaging. If you purchased the Product from an online
web site, mail your original receipt and the Product to the address listed on the
web site. Make sure that you put the Product in its original packaging or
packaging that provides the same amount of protection as the original packaging.
Where is the warranty valid?
This warranty is valid only to the original purchaser of the Product in the United
States, Canada, and Mexico.
DX-AC9013 11-1024_MAN_V1.fm Page 11 Thursday, November 3, 2011 12:15 PM

12 Legal notices
What does the warranty not cover?
This warranty does not cover:
• Customer instruction
•Installation
•Setupadjustments
• Cosmetic damage
• Damage due to acts of God, such as lightning strikes
•Accident
•Misuse
•Abuse
•Negligence
•Commercialuse
• Modification of any part of the Product, including the antenna
This warranty also does not cover:
• Damage due to incorrect operation or maintenance
• Connection to an incorrect voltage supply
• Attempted repair by anyone other than a facility authorized by Dynex to
service the Product
• Products sold as is or with all faults
• Consumables, such as fuses or batteries
• Products where the factory applied serial number has been altered or
removed
REPAIR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS YOUR
EXCLUSIVE REMEDY. DYNEX SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES FOR THE BREACH OF ANY EXPRESS OR IMPLIED
WARRANTY ON THIS PRODUCT, INCLUDING, BUT NOT LIMITED TO, LOST
DATA, LOSS OF USE OF YOUR PRODUCT, LOST BUSINESS OR LOST PROFITS.
DYNEX PRODUCTS MAKES NO OTHER EXPRESS WARRANTIES WITH RESPECT
TO THE PRODUCT, ALL EXPRESS AND IMPLIED WARRANTIES FOR THE
PRODUCT, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTIES OF
AND CONDITIONS OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE, ARE LIMITED IN DURATION TO THE WARRANTY PERIOD SET
FORTH ABOVE AND NO WARRANTIES, WHETHER EXPRESS OR IMPLIED,
WILL APPLY AFTER THE WARRANTY PERIOD. SOME STATES, PROVINCES
AND JURISDICTIONS DO NOT ALLOW LIMITATIONS ON HOW LONG AN
IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO
DX-AC9013 11-1024_MAN_V1.fm Page 12 Thursday, November 3, 2011 12:15 PM

Legal notices 13
YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY
ALSO HAVE OTHER RIGHTS, WHICH VARY FROM STATE TO STATE OR
PROVINCE TO PROVINCE.
Contact Dynex:
For customer service please call 1-800-305-2204
www.dynexproducts.com
Distributed by Best Buy Purchasing, LLC
7601 Penn Avenue South, Richfield, Minnesota, U.S.A. 55423-3645
© 2011 BBY Solutions, Inc.
All rights reserved. DYNEX is a trademark of BBY Solutions, Inc. Registered
in some countries. All other products and brand names are trademarks of
their respective owners.
DX-AC9013 11-1024_MAN_V1.fm Page 13 Thursday, November 3, 2011 12:15 PM

www.dynexproducts.com [phone]
Distributed by Best Buy Purchasing, LLC
7601 Penn Ave. South, Richfield, MN 55423 U.S.A.
© 2011 BBY Solutions, Inc. All rights reserved.
DYNEX is a trademark of BBY Solutions, Inc. Registered in some countries.
All other products and brand names are trademarks of their respective owners.
11-1024
ENGLISH
DX-AC9013 11-1024_MAN_V1.fm Page 16 Thursday, November 3, 2011 12:15 PM
