Dynon SkyView Classic User manual

SkyView Classic Pilot’s User Guide – Revision Z i
SkyView Classic
SkyView Touch
Pilot’s User Guide
Document 101321-025, Revision Z
For use with software version 15.3
March 2018
Copyright © 2009-2018 by Dynon Avionics, Inc.
Permission to print this manual is granted to third parties

SkyView Classic Pilot’s User Guide – Revision Z ii
Contact Information
Dynon Avionics, Inc.
19825 141st Place NE
Woodinville, WA 98072
Phone: [phone] - 8:00 AM –5:00 PM (Pacific Time) Monday –Friday
Dynon Technical Support available 7:00 AM–4:00 PM (Pacific Time) Monday –Friday
Email: [e-mail]
Fax: [phone]
Dynon Avionics offers online sales, extensive support, and frequently updated information on its products via its
Internet sites:
•www.dynonavionics.com –Dynon Avionics primary web site; including:
•docs.dynonavionics.com –Current and archival documentation.
•downloads.dynonavionics.com –Software downloads.
•support.dynonavionics.com –Support resources.
•store.dynonavionics.com –Dynon Avionics’ secure online store for purchasing all Dynon products 24 hours a
day.
•forum.dynonavionics.com –Dynon Avionics’ Internet forum where Dynon customers can interact with each
other and Dynon Avionics. A key feature of the forum is that it allows the exchange of diagrams, photos, and
other types of files.
•newsletter.dynonavionics.com –Dynon Avionics’ email newsletter.
•preflight.dynonavionics.com –A collection of educational articles, tips, news, and “behind the panel”
information about Dynon and its products.
•register.dynonavionics.com –Register your Dynon Avionics product.
•license.dynonavionics.com –Redeem certificates for Navigation Mapping Software, Synthetic Vision, and
other features for license codes that add new functionality to your SkyView system.
Copyright
2008-2018 Dynon Avionics, Inc. All rights reserved. No part of this manual may be reproduced, copied,
transmitted, disseminated or stored in any storage medium, for any purpose without the express written
permission of Dynon Avionics. Dynon Avionics hereby grants permission to download a single copy of this manual
and of any revision to this manual onto a hard drive or other electronic storage medium to be viewed for personal
use, provided that such electronic or printed copy of this manual or revision must contain the complete text of this
copyright notice and provided further that any unauthorized commercial distribution of this manual or any revision
hereto is strictly prohibited.
Information in this document is subject to change without notice. Dynon Avionics reserves the right to change or
improve its products and to make changes in the content without obligation to notify any person or organization of
such changes. Visit the Dynon Avionics website (www.dynonavionics.com) for current updates and supplemental
information concerning the use and operation of this and other Dynon Avionics products.

SkyView Classic Pilot’s User Guide – Revision Z iii
Limited Warranty
Dynon Avionics warrants this product to be free from defects in materials and workmanship for three years from
date of shipment. Dynon Avionics will, at its sole option, repair or replace any components that fail in normal use.
Such repairs or replacement will be made at no charge to the customer for parts or labor performed by Dynon
Avionics. The customer is, however, responsible for any transportation cost and any costs that are incurred while
removing, reinstalling, or troubleshooting the product. This warranty does not cover failures due to abuse, misuse,
accident, improper installation or unauthorized alteration or repairs.
THE WARRANTIES AND REMEDIES CONTAINED HEREIN ARE EXCLUSIVE, AND IN LIEU OF ALL OTHER WARRANTIES
EXPRESSED OR IMPLIED, INCLUDING ANY LIABILITY ARISING UNDER WARRANTY OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE, STATUTORY OR OTHERWISE. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS,
WHICH MAY VARY FROM STATE TO STATE AND IN COUNTRIES OTHER THAN THE USA.
IN NO EVENT SHALL DYNON AVIONICS BE LIABLE FOR ANY INCIDENTAL, SPECIAL, INDIRECT OR CONSEQUENTIAL
DAMAGES, WHETHER RESULTING FROM THE USE, MISUSE OR INABILITY TO USE THIS PRODUCT OR FROM DEFECTS
IN THE PRODUCT. SOME STATES AND COUNTRIES DO NOT ALLOW THE EXCLUSION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS MAY NOT APPLY TO YOU.
Dynon Avionics retains the exclusive right to repair or replace the instrument or firmware or offer a full refund of
the purchase price at its sole discretion. SUCH REMEDY SHALL BE YOUR SOLE AND EXCLUSIVE REMEDY FOR ANY
BREACH OF WARRANTY.
These instruments are not intended for use in type certificated aircraft at this time. Dynon Avionics makes no claim
as to the suitability of its products in connection with FAR 91.205.
Dynon Avionics’ products incorporate a variety of precise, sensitive electronics. SkyView products do not contain
any field/user-serviceable parts. Units found to have been taken apart may not be eligible for repair under
warranty. Additionally, once a Dynon Avionics unit is opened up, it is not considered airworthy and must be
serviced at the factory.

SkyView Classic Pilot’s User Guide – Revision Z iv
Revision History
Revision
Revision Date
Description
A
December 2009
Initial release
B
March 2010
Document number changed to 101321-001.
Minor style, grammar, and cross reference changes and corrections.
Added information regarding Autopilot servos in applicable sections.
Addressed screen synchronization in applicable sections.
SV-D700 and SV-D1000 Operation Chapter updates:
•Added the Menu Navigation Section
•Clarified the How to Turn the System On or Off Section
•Expanded the How to Manually Adjust the Backlight Brightness
or Dim Level Section
•Expanded the How to Enter the Joystick Function Menu
Section
•Added the How to Check Installed Database Statuses Section
•Added the How to Configure the Top Bar Section
PFD Operation Chapter updates:
•Added the ADAHRS Source Section
•Added the GPS Source Section
•Added “push to synchronize” instructions for applicable bugs
Moving Map Operation Chapter updates:
•Added an important note regarding Moving Map requirements
•Added the GPS Source Section
•Added the Terrain Data Section
•Added the Aviation Data Section
Corrected the Onscreen Alerts Section in the Alerts Chapter.
C
May 2010
Document number changed to 101321-002.
Minor style and grammar changes and corrections.
Updated the guide to include HSI operation information.
Updated the guide to include Autopilot operation information.
Updated the guide with more Moving Map content.
D
June 2010
Document number changed to 101321-003.
Clarified intended use of Synthetic Vision.
Added information about Synthetic Vision depictions of runways and
obstacles.
Added EMS menu, lean mode, engine timers, and fuel computer
information.
Clarified map Magnetic North pointer.
Added Navigation Mapping Software information.
Added Trial Navigation Mapping Software information and operation
instructions.
Added external alarm light behavior.

SkyView Classic Pilot’s User Guide – Revision Z v
E
October 2010
Added information about User Waypoint power user feature that is
fully documented on wiki web page.
Added information about menu changes that may be present in SLSA
and other aircraft that SkyView is integrated into as an OEM
component.
Added transponder operation information and specifications.
Added traffic display information for both MAP and PFD pages.
Added a better description of the combined EGT/CHT gauge.
Added Synthetic Vision licensing information.
Added Navigation Mapping Software Licensing and updated operation
information.
G
March 2011
Revision F skipped to obtain version parity between Installation Guide
and Pilot’s User Guide.
Added description of GPS Steering control of Autopilot.
Pitch Trim Indicator behavior and performance expectations clarified.
Added servo weights.
Added product registration information.
Described improved loss of external power with backup battery
connected behavior.
Added information about G Meter.
Added information about new/improved Navigation Mapping Software
purchase, licensing, and operation.
H
May 2011
Added description of enabling/disabling extreme pitch warning
indicators and Flight Path Marker.
Updated screen layout button labeling and figures
Added information on Flight Planning.
Updated several of the figures that were no longer valid due to button
and screen changes.
Changes made for new style of heading bug and heading readout.
Screen Hardware changed to Display Hardware.
Added section on autopilot safety features.
Added additional information about airport graphics.
Added additional information to SV-ADAHRS-20X Instruments and
Sensors table.
I
September 2011
Added description of improved bug window outlining (when selected)
and cyan highlighting (when being adjusted).
Added “Show VOR Directions As” menu item description.
Added Vertical Power VP-X information.
Clarified SV-BAT-320 charging behavior; Clarified which devices and
modules the SV-BAT-320 is capable of powering.
Added permission to print the manual.
Added map panning information.
Remove erroneous checkmark in AOA column in winds row in
“Instruments and Sensors “ table.
Improved HSI information.

SkyView Classic Pilot’s User Guide – Revision Z vi
J
March 2012
Clarified that Jeppesen data must be transferred to USB stick via the
Jeppesen JSUM program.
Added PocketFMS information.
Clarified bearing sources and limitations (SBY bearings from some NAV
radios and no availability of bearings from LOCs).
Clarified EMS timers.
Added special Rotax 912 tachometer and oil temp behavior when
configured.
Added altitude alerter information.
Refreshed Messages and Alerts section to reflect feature
improvements.
Added Audio Alert information.
Updated map instructions to reflect UI refresh, improved info items
support, user waypoints, and visual reporting points support.
K
July 2012
Clarified engaging the Autopilot with the Disengage/CWS Button.
Added information about when airspeed indication comes alive.
Added SkyView Network redundancy information.
Added ADAHRS cross-checking information.
Updated Navigation Mapping Software to incorporate base map
support and airspace improvements.
L
December 2012
Updated Screen Layout Configuration section to add information about
display swap mode and reversion mode.
Added information about DA calculation.
Added engine alert inhibit information.
Added information about normal display artifacts on power on.
Updated recommendation to have servos powered whenever SkyView
is powered on.
Added description of take-off position marking for trim widget.
Added information about attitude rate limit indications.
Rearranged PFD Operation section for better information flow.
Added SV-XPNDR-26X, SV-ADSB-470/472 information to system
overview.
Added ADS-B and Flarm traffic information.
User waypoint altitude information now displayed on their Info pages.
Added information about the AUTO transponder setting when
automatic ALT/GND mode changes are enabled (only available with
transponder firmware version 2.02 or above).
Detailed improvements to ENGINE > FUEL UI.
Added information about weather features and usage via SV-ADSB-
470/472.
M
January 2013
Added information about Data Logging.
Added information about Stadium TFRs.
Added TACAN and Outer Marker symbols.
Clarified information about the AIRSPACES BELOW feature in the Map
Menu.

SkyView Classic Pilot’s User Guide – Revision Z vii
N
June 2013
Added MDA bug information.
Updated PFD Bugs section with new bug names.
Updated information regarding how the Flight Path Marker is displayed.
Revised GPS 0 position source information, now labeled SkyView.
Added Map Trial Mode –Trial Expired description.
Added Map Aviation Database Expired description.
Added Garmin GTX 330ES transponder support for activating ADS-B
traffic.
Revised “Show Airspaces Below” description.
Added Traffic Fail announcement description.
Added Battery status/test information.
Revised Autopilot chapter to reflect new Simplified and Expert
Autopilot Control schemes.
Added COM Radio Chapter.
Revised Messages, Alerts, and Audio Alert Details.
Added information about Backup Battery status information and testing
capabilities.
O
September 2013
Center click can now be used to pull up, set, and sync (by holding) the
PFD joystick functions menus (bugs, baro, crs, etc.).
Added new Up/Down Timers feature.
Added new Fuel Tank Reminder alert.
Added Geo-referenced Approach/Departure Charts and Airport
Diagrams feature for US Data.
Updated Navigation Mapping Software chapter to reflect refined direct-
to and flight planning behaviors. Minor changes.
Added new Map Pointer selection features.
Clarified new shortcut of using Nose Up and Nose Down buttons to
immediately start a climb/descent from Alt Hold mode in Expert
Autopilot.
Added audio alert inhibition upon SkyView startup information.
P
November 2013
Added Geo-referenced Approach/Departure Charts and Airport
Diagrams feature for Europe data.
Added procedure for downloading Europe Chart data.
Added information about ICAO and FAA flight plan codes in the
Transponder Operation section.
Modified procedure chart FOLLOW behavior description (follow mode
now default s to on for airport diagrams).

SkyView Classic Pilot’s User Guide – Revision Z viii
Q
March 2014
Added: Information about SV-INTERCOM-2S
Added: Support for SkyView Touch.
Added: Enroute charts, including VFR, IFR LO and HI. US support via
existing Seattle Avionics Subscriptions at release.
Clarified: GPS assist in Attitude Calculation
Clarified: magnetic heading is not used to aid attitude determination
Added: Support for dual engine monitoring by using two SV-EMS-22X
modules.
Added: Support to monitor up to 28 total EGT and/or CHTs by using a
second SV-EMS-22X module.
Clarified: Navigation Mapping Software required to view charts on
SkyView
Clarified: SV-COM-C25 product description
Added: Support for SV-KNOB-PANEL dedicated knob control panel.
Added: Support for SV-AP-PANEL dedicated autopilot control panel.
Clarified: Top Bar status area configuration
Added: 60% PFD Screen layout option when paired with 40% Map
Added: Vertical Speed Required to destination Info Item on map and
PFD VSI displays the current VS required to set up at a specified point at
or before and above your final destination waypoint.
Improved: GPS waypoints now displayed in HSI info area for ARINC
navigators such as the GNS and GTN.
Improved: External GPS and nav radios can now be named with a user-
configurable 7 character “friendly name” to aid in identifying sources
on the HSI display.
Moved: Synthetic Vision description within the PFD Chapter
Added: Conventional analog “six-pack” display mode for primary flight
instruments.
Changed: PFD menu now includes MODE button to select between EFIS
or Analog presentation and to toggle SynVis on or off
Added: HSI Source Button is duplicated in the Autopilot Menu for
convenience.
Added: Support for showing Flight plans from ARINC IFR GPS navigators
such as the GNS and GTN series both on SkyView’s map (including holds
and other procedure turns) and on SkyView’s flight plan display.
Improved: Timer expiration in top bar changed from yellow to white
Improved: All EMS widgets that have assignable color ranges
(red/yellow/green/black) now have additional color options: blue,
white, purple, cyan, and orange.
Changed: All EMS timers that formerly had “flight” or “flt” in their
names are now called “air” timers. The underlying behavior of these
timers has not changed.
Improved: Fuel Tank Switch Reminder is now based on Flight Time and
not engine Run Time.
Improved: Press and holding knob/joystick center-click from within the
FPL menu brings up the insert waypoint function.
Improved: When the map pointer is selecting a single item, range is still
enabled by turning the map joystick knob (if two or more items are
under the pointer, turning the knob chooses which one is selected).
Improved: Yellow/red terrain alert coloration disabled on the map page
when not in flight.

SkyView Classic Pilot’s User Guide – Revision Z ix
Fixed: “Show Airspaces Below” feature did not always properly exclude
airspaces whose altitudes were defined by flight levels (primarily in
non-US data).
Added: Support for MGL V6 and V10 Com radios.
Added: Support for the Trig TY91 Com radio.
Added: Support for Val NAV 2000 nav radio.
Improved: Radios such as the Icom A210 that can receive frequencies
but do not output status now need not cause the top bar radio status
area to show a “red x”. Added DISPLAY COM IN TOP BAR option to
configure this behavior.
Fixed: Fuel Tank Switch Reminder is now a message, not a caution alert.
Added: Touch Panel Fault Alert
Added: Special alert behavior for Dual Engine monitoring
Added: “Check gear” and “gear overspeed” audio alerts for retractable
gear aircraft that are tied to both landing gear status and airspeeds.
Added: “Gear up for water landing” and “gear down for runway
landing” audio alerts for amphibious aircraft that are annunciated as a
selected airspeed is transitioned through.
Added: Tail numbers for ADS-B equipped traffic will be shown below
traffic targets when available. Only available for aircraft equipped with
Dynon Avionics’ ADS-B receiver, and will only be shown for target
aircraft that are ADS-B OUT equipped.
Improved: Radios such as the Icom A210 that can receive frequencies
but do not output status now need not cause the top bar radio status
area to show a “red x”. Added DISPLAY COM IN TOP BAR option to
configure this behavior.
Fixed: Warning, caution, and message alerts that do not have their own
dedicated audio phrases were not annunciating the generic “warning”,
“caution”, and “message” audio phrases they should have been. This
bug is present in SkyView 7.0-7.1. It worked properly previously and is
fixed with 10.0.
Fixed: Items that shouldn’t be appearing on the map per the “map
items” zoom/range declutter settings were appearing when the map
was very zoomed in.
New: Support for speed-scheduling of the trim control in the SV-AP-
PANEL.
Improved: HSI courses are now remembered for each HSI source. This is
especially helpful when switching between VOR and ILS or GPS and ILS
sources.

SkyView Classic Pilot’s User Guide – Revision Z x
R
August 2014
New: Support for SV-COM-X83 8.33 kHz COM radio.
New: Support for Video Input Adapter. Allows display of video via NTSC
and PAL S-Video and composite connections. Note: Only compatible
with SkyView Touch and newer SkyView SV-D1000 (s/n >= 6000) and
SV-D700 (s/n >= 4000) displays.
New: Virtual-DME (non-certified) distance to VORs via GPS when the
VOR identifier is known. Magenta distance is displayed on HSI info area
on PFD.
New: SHOW AIRSPACES WITHIN XXXX FT option to declutter airspaces
that aren’t a factor at the current aircraft altitude.
New: Wide field of view option for Synthetic Vision under PFD > MODE
> WIDE. Setting also proportionately scales the pitch ladder.
New: Vne can now be set as TAS.
New: Option to turn on color-coded weather “dots” at airports with
METARS via MAP MENU > WEATHER OPTIONS > METAR ICONS (SV-
ADSB-470/472 required).
New: BARO sync will now obtain either the nearest METAR (when ADS-
B is available in-flight), set to 29.92 (when at/above 18k feet or no ADS-
B on board), or to make the altimeter match GPS altitude (when on the
ground).
Added: Alert when engine sensor definitions do not match across
multiple displays in a SkyView system.
Added: Caution alert if transponder hex code is not set.
Added: Option to alert the pilot when the current BARO setting and the
nearest METAR-based altimeter setting are significantly different
(requires SV-ADSB-470/472).
Added: Audible “AUTOPILOT” callout when the autopilot is engaged.
Added: Alerts when SV-AP-PANEL, or SV-KNOB-PANEL go offline.
Added: Alert when an external Level button is connected and detected
stuck at boot.
Added: GPS-based distances to bearing sources in HSI info area (when
only one bearing source is displayed).
Added: Alert for detectable audio subsystem failures.
Added: MAP MENU > FLIGHT PLAN OPTIONS > PLAN GROUND SPEED
lets SkyView perform ETE, ETA, and other speed-dependent calculations
at a user-specified ground speed when not flying.
Improved: Traffic service/device reception quality indicator on map
page.
Improved: Additional failure detection and annunciation of rate
sensors, accelerometers, and pressure transducers in the SV-ADAHRS-
20X.
Improved: Alert that annunciates when there is no high-res terrain
available for the current aircraft location (usually because a different
world region is loaded).
Improved: Joystick knob menu now annunciates successful sync of any
bug or BARO setting when you press/hold the joystick knob.
Improved: Bugs can now be turned on and off per display via
PFD>BUGS. The presence of an autopilot no longer forces all bugs to be
shown on all displays.
Improved: Display dimming algorithm and menu control scheme
improved to disallow brightness settings that would result in an illegible
(too dim) display.

SkyView Classic Pilot’s User Guide – Revision Z xi
Improved: Airport identifiers on MAP are now white to improve
legibility.
Improved: PFD>XPNDR menu no longer has a time-out that
automatically backs out of menu.
Improved: ROP/LOP EMS info widget now says “PK?” instead of “UND”
when calculation is out of range or not possible for the configuration.
S
January 2015
New: Autopilot Auto-Trim. The SkyView AutoPilot can automatically re-
trim the aircraft as it flies under autopilot control. This feature requires
that the aircraft has an SV-AP-PANEL and is using its integrated trim
controller for trim servo actuation.
New: OBS Mode that allows pilots easily set and adjust an inbound
course to any navigable point on the map. That inbound course may
then be easily adjusted with the HSI CRS knob, similar to how one
would with a VOR. This is useful to approach an airport from a specific
direction, for example, without having to create a second waypoint to
create a full flight plan leg.
New: Aircraft icon displayed on the Map and in the HSI PFD can be
changed to one of over a dozen types of aircraft.
Added: Alerts that let the pilot know if the CPU within SkyView's display
is overheating due to failure of SkyView's thermal dissipation features.
Added: New option under MAP MENU > MAP ITEMS > TFR OPACITY
that allows pilots to change the opacity of TFRs. This can be used to
tune the visibility of co-located TFRs and underlying map features.
Added: Support for sending/receiving frequencies to the Garmin GTR-
200. This does not include the ability to send aviation database
information to the GTR-200.
Fixed: When a USB stick containing expired chart data is removed, on-
screen alerts about that expired data are no longer displayed.
Fixed: User alert data logs sometimes had corrupt values in them.
Fixed: Traffic vector length now correct for ADS-B targets.
Fixed: Not all data from Garmin portable GPS products was being
passed along to compatible Garmin radios as if they were directly
connected.
T
February 2015
New: Support for the Wi-Fi Adapter for SkyView. The Wi-Fi Adapter
allows supported devices to interface to SkyView. ForeFlight Mobile on
iOS devices is supported on release.
New: Tablet connectivity with ForeFlight Mobile. ForeFlight Mobile
customers (US and Canadian markets only) can send and receive flight
plans from their iOS devices and SkyView. SkyView can also transmit its
GPS position and ADAHRS information to ForeFlight for use within the
ForeFlight app. This feature requires one Wi-Fi Adapter for SkyView for
each display in the aircraft.

SkyView Classic Pilot’s User Guide – Revision Z xii
U
April 2015
New: Support for SV-MAG-236 Remote Magnetometer for SkyView.
New: Transponder firmware update to version 2.6 to support ADS-B+
format from capable Garmin IFR navigators. Using ADS-B+ format is a
requirement for having an FAA ADS-B rule compliant installation in
2020 and beyond. Note that the transponder firmware update must be
manually initiated and does not happen automatically during a SkyView
software update.
New: Tablet connectivity with PocketFMS EasyVFR. PocketFMS
customers can send and receive flight plans from their devices and
SkyView over Wi-Fi.
Improved: SkyView now remembers the last two hours of ADS-B
weather and all active/upcoming TFRs after when SkyView is power
cycled. This gives the pilot access to weather and TFR information that
is still valid when SkyView is turned on and acquires time via GPS lock.
Updated: US Stadium TFRs now provided via database file after the
ADS-B FIS-B service ceased transmitting them.
Fixed: User data logs' time stamps were off by one day.
Fixed: SkyView did not recognize more than 20 GPX files on a USB
memory stick.
Fixed: Permanent Disney TFR shown as upcoming instead of active.
Fixed: Filtering for 912iS fuel pressure improved. For best results also
update to the latest engine sensor definitions.
Fixed: SkyView would restart for some customers after exporting data
logs.
Improved: Fuel computer no longer compares fuel computer totals to
measured fuel in aircraft that do not have in-tank fuel level sensors.
V
July 2015
Improved: Single autopilot disconnect switch press leaves the flight
director on. A double press will turn off the flight director and clear the
lateral and vertical autopilot modes.
New: Added multi-language support. SkyView Pilot’s User Guide is only
available in English at this time.
New: A new warning message is displayed if the transponder detects an
anomaly.
New: A new message is displayed if the D1000 or D700 detects a
potential anomaly.
Improved: Chart data formats have changed resulting in improved
rendering time and better enroute chart graphics. The correct format
must be selected in the Seattle Avionics loader software. In addition,
one may notice that the map layer buttons might change location
and/or names when displaying Seattle Avionics charts.
Improved: Synthetic vision can highlight terrain that is immediately a
threat.
Improved: Added new widgets to support Rotax 912iS throttle position
and ECO mode.

SkyView Classic Pilot’s User Guide – Revision Z xiii
W
January 2016
Changed: Transponder warnings are now messages not warnings.
Changed: XPNDR GPS IN OFFLINE is now NO ADS-B OUT: GPS LOST
Changed: SkyView now displays DATABASE NO LONGER CURRENT
PRESS MAP > ACCEPT to clarify what action should be taken.
Improved: New caution messages for Rotax engines with CAN bus EMS
monitoring (limit flight ops and land aircraft).
New: Added checklists to TOOLS. SkyView now supports user
configurable checklists.
New: SkyView map can show a circle on the map that represents the
area to which the aircraft can glide. The glide ring is based on current
calculated wind, AGL and programmed sink rate and best glide speed.
X
October 2016
Name of this guide changed to SkyView Classic Pilot’s User Guide
System Software version 15.0
New: Extended runway indications
New: Sequenced NEXRAD
New: Weight and balance
New: Vertical navigation mode
New: Maintenance Log
New: Wi-Fi “streaming data” includes weather and traffic data
New: Highway In The Sky (HITS)
New: Airports and flight plan waypoints are shown with flags on
synthetic vision
New: Airspace Proximity indicates airspace type around the aircraft
Y
November 2017
System Software version 15.1 and 15.2
New: SV-ADSB-472 operational documentation
Changed: Vertical Guidance documentation
Changed: Checklist items are scrolled with the cursor
Changed: Airport flags are selectable
Changed: Weight and balance supports metric
Changed: Weight and balance displays zero-fuel calculations
Changed: Estimated time elapse (ETE) to waypoint uses minutes and
seconds
New: Detailed 912iS fault list
Changed: Com panel ATC button ignores on-ground/in-air
Changed: Six pack altimeter has 1000 and 10000 indicators
Changed: Autopilot disconnect button behavior in expert mode
Changed: HITS vertical guidance
Changed: Transponder auto mode defaults to ALT
Changed: Autopilot operation on back course
Changed: OAT out of range displays ---
New: Yaw damper

SkyView Classic Pilot’s User Guide – Revision Z xiv
Z
January 2018
Minor style, grammar, and cross reference changes and corrections.
Reformatted Document.
Updated Figures: 25, 26, 30, 31, 32, 33, 91, 127, 128, 129, 130.
Updated Header information.
Added page numbers, by chapter.
Changed: Bearing pointers in the HSI are now blue.
Changed: SV-KNOB-PANEL synchronization is now a click.
Changed: MDA bug is now labelled MIN.
Changed: Vertical Speed Required (VSR) index line is now an arrow on
the VS tape.
Changed: The north arrow on the map is now gray.
Changed: Servo failures are now white messages.
Changed: Transponder failures are now white messages.
Changed: GPS ASSIST warning is now CHECK PITOT HEAT.
Changed: Autopilot audio messages changed to Trim Nose Up/Down
and Autopilot Roll/Pitch Disconnect.
New: Traffic coasting updates ADS-B targets.

SkyView Classic Pilot’s User Guide – Revision Z xv
Table of Contents
Copyright ....................................................................................................................................................................... ii
Limited Warranty.......................................................................................................................................................... iii
Revision History ............................................................................................................................................................ iv
1. Introduction 1-1
Before You Fly.............................................................................................................................................................1-1
Warning ......................................................................................................................................................................1-1
Video and In-person Training .....................................................................................................................................1-1
About this Guide.........................................................................................................................................................1-1
Dynon Avionics Product Registration .........................................................................................................................1-2
2. System Overview 2-1
SV-D700, SV-D1000 and SV-D1000T...........................................................................................................................2-1
SV-ADAHRS-20X..........................................................................................................................................................2-4
SV-MAG-236 ...............................................................................................................................................................2-5
SV-EMS-22X ................................................................................................................................................................2-5
SV-GPS-250 .................................................................................................................................................................2-5
SV-GPS-2020 ...............................................................................................................................................................2-6
SV-BAT-320 Backup Battery........................................................................................................................................2-6
Autopilot Servos .........................................................................................................................................................2-6
Navigation Mapping Software (SV-MAP-270) ............................................................................................................2-6
SV-XPNDR-26X ............................................................................................................................................................2-6
SV-ADSB-470/472 .......................................................................................................................................................2-6
SV-COM-C25 ...............................................................................................................................................................2-7
SV-COM-X83 ...............................................................................................................................................................2-7
SV-INTERCOM-2S........................................................................................................................................................2-7
SV-KNOB-PANEL..........................................................................................................................................................2-7
SV-AP-PANEL...............................................................................................................................................................2-7
Video Input Adapter for SkyView ...............................................................................................................................2-7
Wi-Fi Adapter for SkyView..........................................................................................................................................2-8
3. SV-D700, SV-D1000 and SV-D1000T Operation 3-1
Screen Synchronization ..............................................................................................................................................3-1
Display Bezel Layout ...................................................................................................................................................3-1
Joystick and Button Operation ...................................................................................................................................3-3
Menu Navigation ........................................................................................................................................................3-4
Basic Display Operation Procedures...........................................................................................................................3-6
Screen Layout Configuration ......................................................................................................................................3-9
Backup Battery Charging and Testing.......................................................................................................................3-11
4. PFD Operation 4-1
PFD Page Layout .........................................................................................................................................................4-1
PFD Symbology ...........................................................................................................................................................4-2
ADAHRS (Flight Instrument) Redundancy and Cross-Checking ................................................................................4-27
PFD Menu .................................................................................................................................................................4-31
Top Bar......................................................................................................................................................................4-33
Checklists ..................................................................................................................................................................4-34
SkyView Knob Control Panel Operation ...................................................................................................................4-38
5. EMS Operation 5-1

SkyView Classic Pilot’s User Guide – Revision Z xvi
Engine Page Layout.....................................................................................................................................................5-1
Rotax 912 Behavior.....................................................................................................................................................5-2
Rotax 912iS .................................................................................................................................................................5-4
Engine Menu...............................................................................................................................................................5-4
Timers .........................................................................................................................................................................5-6
Fuel Computer ............................................................................................................................................................5-7
Dual Engine Monitoring..............................................................................................................................................5-9
VP-X Operation .........................................................................................................................................................5-10
6. Transponder Operation 6-1
Transponder Status ....................................................................................................................................................6-1
Transponder Menu .....................................................................................................................................................6-2
Reported Pressure Altitude ........................................................................................................................................6-4
ADS-B OUT Transmissions ..........................................................................................................................................6-4
Flight Plan Codes ........................................................................................................................................................6-5
7. SV-MAP-270 Navigation Mapping Software 7-1
License Information ....................................................................................................................................................7-1
Databases and Charts .................................................................................................................................................7-3
Geo-Referenced Procedure Charts and Airport Diagrams .........................................................................................7-7
GPS Source................................................................................................................................................................7-11
Moving Map Page Layout .........................................................................................................................................7-12
Moving Map Symbology ...........................................................................................................................................7-13
MAP Menu................................................................................................................................................................7-34
Navigation and Flight Planning .................................................................................................................................7-37
Weather and TFR Information..................................................................................................................................7-79
Glide Ring..................................................................................................................................................................7-89
8. Autopilot Operation 8-1
Autopilot Safety Features ...........................................................................................................................................8-1
Simplified or Expert Controls......................................................................................................................................8-2
Top Bar Autopilot Status Area ....................................................................................................................................8-2
Other Autopilot Status Information ...........................................................................................................................8-3
Auto-Trim....................................................................................................................................................................8-6
Yaw Damper ...............................................................................................................................................................8-7
Simplified Autopilot Operation and Controls .............................................................................................................8-7
Expert Autopilot Operation and Controls.................................................................................................................8-13
Missed Approach (Go around)..................................................................................................................................8-27
SkyView Autopilot Control Panel Operation.............................................................................................................8-28
9. SkyView Touch (SV-D1000T) Operation 9-1
Menu Operations........................................................................................................................................................9-1
Top Bar Operations.....................................................................................................................................................9-1
PFD Operations...........................................................................................................................................................9-2
Engine Operations ......................................................................................................................................................9-3
Map Operations..........................................................................................................................................................9-3
10. Video Input Operation 10-1
11. COM Radio Operation 11-1
COM Control Panel Overview...................................................................................................................................11-1
SkyView Top Bar COM Radio Status Overview .........................................................................................................11-2
Using your COM Radio..............................................................................................................................................11-2

SkyView Classic Pilot’s User Guide – Revision Z xvii
Loading Airports to the SkyView Com Radio ............................................................................................................11-7
Using the TWR, ATIS, GND, and ATC Buttons .........................................................................................................11-10
Other Status Information .......................................................................................................................................11-11
External Flip/Flop....................................................................................................................................................11-13
Dual COM Radios ....................................................................................................................................................11-13
12. Messages and Alerts 12-1
Loss of Information...................................................................................................................................................12-1
Message, Caution, and Warning Alerting System.....................................................................................................12-1
Prompts Requiring Interaction .................................................................................................................................12-5
Audio Alerts ..............................................................................................................................................................12-5
Inhibited Alerts .........................................................................................................................................................12-5
Messages, Alerts, and Audio Alert Details................................................................................................................12-5
13. Appendix A: SkyView System Specifications 13-1
14. Appendix B: License Information 1

Introduction
SkyView Classic Pilot’s User Guide – Revision Z
1-1
1. Introduction
Thank you for purchasing the Dynon Avionics SkyView system.
This chapter provides some important cautionary information and general usage instructions
for this guide.
The printed version of this guide is in grayscale. Some figures and diagrams contain important
color information. Reference the electronic version of this guide to view it in color.
Before You Fly
We strongly recommended that you read this entire guide before attempting to use SkyView in
an actual flying situation. Additionally, we encourage you to spend time on the ground
familiarizing yourself with the operation of the system. While first learning to use the system in
the air, we recommend you have a backup pilot with you in the aircraft. Finally, we encourage
you to keep this guide in the aircraft with you at all times. This document is designed to give
you quick access to information that might be needed in flight. In a flying situation, it is the
pilot’s responsibility to use the system and the guide prudently.
Warning
Dynon Avionics’products incorporate a variety of precise, sensitive electronics. SkyView
products do not contain any field/user-serviceable parts. Units found to have been taken apart
may not be eligible for repair under warranty. Additionally, once a Dynon Avionics unit is
opened up, it is not considered airworthy and must be serviced at the factory.
Video and In-person Training
This guide is intended to familiarize a new SkyView pilot with the basics of operating a SkyView
system. No printed (or electronic) guide, such as this, can substitute for “seeing it in action,”
and thus Dynon Avionics provides an online collection of instructional videos; including a
complete SkyView operations course - see www.dynonavionics.com/videos. These videos help
new owners quickly learn the basics so they can safely start flying with the system. Also, current
SkyView owners can gain in-depth knowledge of many of the more advanced or complex
features.
Dynon Avionics provides hands-on training classes to help you in your transition to new
SkyView system. These are typically half-day courses, sitting in front of live SkyView displays
combined with in-depth instruction on how to operate SkyView. Visit our training page at
www.dynonavionics.com/training for details on upcoming classes.

Introduction
SkyView Classic Pilot’s User Guide – Revision Z 1-2
About this Guide
This guide helps you configure and get acquainted with SkyView Classic‘s many functions and
facilitates quick access to vital information. If you have a SkyView SE, or SkyView HDX system,
this is not the correct guide for those products –each has its own dedicated user’s guide
available at docs.dynonavionics.com. For detailed technical and installation information, refer
to the Installation Guide, also available at docs.dynonavionics.com.
This guide is revised, at a minimum, several times per year, usually coinciding with the release
of a new version of SkyView software, or the introduction of new SkyView-related products
from Dynon Avionics or partner companies. This revision reflects the features available as part
of the software version stated on the cover page. If your SkyView Classic system currently has
an earlier software version, some features may not be available for use on your SkyView system
(until you update its software).
Printing This Guide
To reduce waste and confusion resulting from outdated information in print, Dynon Avionics no
longer provides this guide in printed form. The latest, most up-to-date, most complete version
of this guide (and all Dynon Avionics documentation) is always available at
docs.dynonavionics.com. Rather than printing this guide on a home printer (typically, with
relatively expensive inkjet printing) we recommend that you take the PDF file of this guide to be
printed at a large office supply retailer that provides printing services. The statement on the
cover of this guide: Permission to print this manual is granted to third parties. should be
sufficient permission to do so.
It is also handy to have the electronic version on your tablet computer as reference, as you can
perform keyword searches, and the electronic version includes figures and diagrams that
contain important color information. We have found that the free “iBooks” application that can
be installed on Apple iPad tablet computers can import this guide’s PDF file for easy reference.
In the electronic (.PDF) version of this guide, page and section references in the Table of
Contents and elsewhere act as hyperlinks, taking you to the relevant location in the guide. The
latest electronic version (.PDF) of this guide may be downloaded from our website at
docs.dynonavionics.com.
This guide discusses the most common operation scenarios. If you have an operational issue
that is not discussed in this guide, you can find additional operational information on Dynon
Avionics’ internet sites:
•forum.dynonavionics.com –Dynon Avionics’ Online Customer Forum is a resource for
Dynon Avionics customers to discuss installation and operational issues relating to
Dynon Avionics products. The Forum is especially useful for pilots with uncommon
aircraft or unusual installation issues. For customers that cannot call Dynon Technical
Support during our normal business hours, the Forum is a convenient way to interact
with Dynon Avionics Technical Support. The Forum allows online sharing of wiring
diagrams, photos, and other types of electronic files.

Introduction
SkyView Classic Pilot’s User Guide – Revision Z 1-3
Dynon Avionics Product Registration
Please take a moment to register your Dynon Avionics SkyView system at
register.dynonavionics.com. Registering your product with Dynon ensures that your contact
information is up-to-date. This helps verify product ownership, can expedite warranty claims,
and allows us to notify you in the event a service bulletin is published for your product. You can
also optionally sign up to receive other Dynon news and product announcements. Dynon will
not share your contact information with third parties or send you announcements without your
explicit consent.
The following icons are used in this guide.
This icon denotes information that merits special attention.
This icon denotes a helpful tip.
