e-bike vision Power Pack Quick start guide

Manual for Power Pack compatible for Bosch* Classic (+) drive system
* Bosch is a trademark of the Robert Bosch GmbH Page 1of 9
Manual / Safety notes
for your E-Bike Vision Power Pack, compatible with
Bosch* Classic (+) drive system with 36 V
Power information:
13 Ah / 468 Wh Battery downtube and carrier version
17 Ah / 612 Wh Battery downtube and carrier version
Dimensions downtube version 13 and 17 Ah: 295,8 x 85,0 x 129,7 mm
Dimensions carrier version 13 and 17 Ah: 392,5 x 124,0 x 77,0 mm
Date: February 2018
Version: 05
E-Bike Vision GmbH
Friedenstraße 17
D-63814 Mainaschaff
fon: +49 (0) 6021 / 3289 - 288
fax: [phone] / 3289 - 286
mail: [e-mail]
web: www.e-bike-vision.de
www.facebook.com/ebikevision

Manual for Power Pack compatible for Bosch* Classic (+) drive system
* Bosch is a trademark of the Robert Bosch GmbH Page 2of 9
Read manual carefully before use!
This manual is integral part of the product. It contains important information and
safety notes. Keep it in range and give it away with the product to third party.
Introduction
We are glad, that you choose a Lithium battery of our Power Pack range.
Please take some time to read this manual carefully. It contains detailled information about
handling of your battery, it’s functions and it’s care, as well as the usage of the E-Bike Vision
fast charger.
For further questions, do not hesitate to contact your dealer or get in contact with us via our
homepage.
Enjoy your new Power Pack and thank you for your confidence.
Your E-Bike Vision Team
Disclaimer
The E-Bike Vision GmbH assumes no responsibility for any loss, damages or costs arising
from incorrect use and operation of the product, or related.
The obligation to pay any compensation, regardless of the legal reason, is limited to the
directly involved E-Bike Vision products invoiced value, as far as this is permitted by law.
This does not apply, if a liability according to binding legal rules due to intent or gross
negligencem has to be respected. Furthermore, the E-Bike Vision GmbH assumes no
responsibility for the completeness and accuracy of the documents that come with the
battery, due to its‘ different distribution channels.
Guarantee
For our battery products, we accept the legally applicable guarantee beyond a 24 months
warranty. To qualify for the 24 months guarantee, submission of the purchase receipt is
required.
Please contact your dealer from whom you purchased the product, in guarantee cases.
Excluded from the guarantee are malfunctions caused by:
- improper operations, e.g. overheating, incorrect connection, short-circuit or reverse polarity,
immersion in water, cleaning with high pressure or steam cleaners, deep discharge, wrong
polarity or drop
- use of non-approved accessories by the E-Bike Vision GmbH
- accidental or deliberate damages
- defectives due to normal tear
- operation outside the technical specifications
- damages that will not appear directly on the device, for which we assume the guarantee
- grease the contacts with contact spray or similar
- changes / repairs / modifications / installations or upgrades that have not be performed by
the E-Bike Vision service center use only our service center for repairs
- optical damages that justify no functional damages or which can be remedied by cleaning
- the costs for rental batteries
Removal of the performace label leads to loss of warranty claim.

Manual for Power Pack compatible for Bosch* Classic (+) drive system
* Bosch is a trademark of the Robert Bosch GmbH Page 3of 9
CE declaration of conformity
The evaluation of the device was carried out by European harmonized directives.
You therefore have a product that is related to it’s construction meets the safety
objectives of the European Community to the safe operation of equipment. The
detailed CE declaration of conformity can be obtained from our service center.
Technical information
Li-Ionen battery
13 Ah
17 Ah
Nominal voltage
36 V
36 V
Nominal capacity
13 Ah
17 Ah
Energy
468 Wh
612 Wh
Operating
temperature
-10 up to 60°C
-10 up to 60°C
Charge temperature
0 up to 45°C
0 up to 45°C
Storing temperature
~ 17°C
~ 17°C
Weight
approx. 3 kg
approx. 3 kg
Safety class
dust- and splash water approved
Care and storage
- Use only a soft cloth and a little water or a neutral detergent for cleaning
- Never clean with a high pressure or steam cleaner!
- Do not immerse in any liquids!
- Do not use any cleaning agents as gasoline, alcohol or other liquids.
- Abrasive cleaning agents can lead to detachment of the painting, discoloration,
deformation, scratechs or similar defects.
- Store your battery at room temperature (18° to 23° C).
- For longer periods, store it at temperatures around 17° C.
- Humidity should be in the range of 0 to 80 %.
- Ideal charging state in not use is about 70 % charged capacity.
- Check the state of charge by prolonged non-use regularly and charge your battery if
necessary.
Accessories
- E-Bike Vision fast charger for power packs with 36 V and a charge current of 7A.
- E-Bike Vision charger for power packs with 36 V and a charge current of 4A.
These allows easy charging directly on the eBike in no time.

Manual for Power Pack compatible for Bosch* Classic (+) drive system
* Bosch is a trademark of the Robert Bosch GmbH Page 4of 9
Common safety notes for Power Packs
Please read this manual carefully! Please consider the safety notes!
- Power Packs are no toys. Keep them away from children!
- Don’t change anything on the battery. Especially, consider that you are not allowed to open
the battery, or rather modify it, otherwise you loose your warranty claim.
- By mishandling (heating, e.g. solar irridation or store on radiators, open fire, dipping into
water, cleaning with pressure washer or steam cleaner, short circuit, over charging, deep
discharging, inverse polarity or droping) or situations, that lead to not-proper operation, that
can heart people or catch the battery fire.
- Power Pack batteries are products which may not release any substances under normal
and reasonably foreseeable conditions of use.
- Howerver, should any liquids or gas eject from the battery, avoid any contact with it and
also do not breathe it. If contact occurs randomly, wash the affected skin with water.
- In case of burns or on contact of the eyes with one of these fluids or by respiratory irritation,
please consult a doctor!
- In extreme cases, seal batteries airtight and add dry sand, chalk powder (CACO3) or
vermiculite.
- Do not use damaged batteries or chargers. In any doubt, contact your dealer.
- Do not use battery and/or charger for other purposes.
- You must use Power Packs only in the designated eBikes.
- Use only the appropriate chargers.
- Contacts should not be treated with lubricants.
- The battery connectors at the eBike must be dry and clean before contacting!
- The covers of charge/discharge connectors must be replaced immediately on loss,
otherwise warranty void.
That way, you do have the maximum saftey!

Manual for Power Pack compatible for Bosch* Classic (+) drive system
* Bosch is a trademark of the Robert Bosch GmbH Page 5of 9
Safety notes for charging
Please pay particular attention to the following points when charging:
- Connect the charger only to a suitable mains supply.
- Do not charge NiCd, NiMh or primary cells!
- Use the charger only with the appropriate Power Packs of E-Bike Vision!
- When not using for a longer period, disconnect the mains supply and also connected
batteries.
- The charging time varies depending on the battery’s capacity and charger type.
- Do not charge the battery below 0° and not above 45° C. The battery management system
will not allow to start the charging process.
- Please charge your Power Packs only under supervision and on a non-combustible surface
(both battery and charger).
- The charger is designed for operation in ventilated, dry and dust-free environment. Never
expose to rain or extreme heat. Allow adequate air circulation.
- Do not cover the charger, nor the battery.
- Ensure that that the plugs and sockets of the charger are not damp or contaminated.
- Do not touch plugs and sockets of the charger with wet hands.
- Do not try to convert or disassemble the charger.
- Before the charger is connected to the mains, please ensure that line voltage matches to
the supply voltage of the charger. The charger’s needed voltage is indicated on it‘s
nameplate on the backside.
- A charger with a damaged power supply cord or plug must not be connected to the
electrical grid and must promptly replaced or repaired by the E-Bike service center.
- Penetration of water and moisture into the charger must be avoided in any case. Should
this have happened, power off the charger (by turning off the fuse) immediately. Disconnect
the charger from the mains and let it be checked by the E-Bike Vision service center.
- A sudden temperature change from cold to hot, there could be condensation water on and
in the charger. In this case, wait for connecting to the mains until the charger is as warm as
the room. Try to avoid this case by storing the charger where you use it.
For maximum life of your battery, charge it only within 10° and 30° C temperature range.

Manual for Power Pack compatible for Bosch* Classic (+) drive system
* Bosch is a trademark of the Robert Bosch GmbH Page 6of 9
The Charging
The charging outside the pedelec is started by unlocking the lock, that way you can remove
the battery as usual and charge it in your appartement or garage in your presence.
Turn off the drive system and wait until the LEDs of the battery expire. Only now, you unlock
the lock with the key counter-clockwise to the left.
When using the E-Bike Vision charger you are able to charge your battery in or outside the
battery.
The drive system must be turned off.
Simply open the cap.
Under the cap, the 4pin connector for the E-Bike Vision charger is located.
Start of charging process with E-Bike Vision charger
- Connect the charger to the mains.
- Turn on the charger and wait until the green LED flashes slowly.
- Make sure that none of the battery LEDs are lighting when it’s not mounted in the
eBike.
- Now plug in the charging connector of the charger to the battery.
- In the charging socket of the battery and in the charging plug of the charger, there are
guide slots to prevent the charging plug to be inserted incorrectly. Please turn the
charging plug slightly, when you plug it in the socket of the battery, until it is in it’s right
position. This manifests itself by a slight snap. Now, the charging plug can be inserted
with light pressure. Please do not try to push the charging plug into the charging socket
with too much force, otherwise you could damage the battery or the charger.
- Charging process starts and the fan turns on. The LEDs of the battery corresponding to
it’s current state of charge begins to flash.
- If the battery is almost fully charged (4 LEDs are lighting and the 5th is flashing),
the fan will not start turning under certain circumstances, because the charger
switches immediately into the so-called constant voltage mode. Within this mode,
the power consumption of the charger is that low that the running of the fan is not
necessary.
Furthermore, the fan will also turn off towards the end of charging process, as it is
no longer needed in constant voltage mode.

Manual for Power Pack compatible for Bosch* Classic (+) drive system
* Bosch is a trademark of the Robert Bosch GmbH Page 7of 9
- Do not take remove the HMI during charging process!
Once you remove the HMI of your eBike during charging, the capacity indication
LEDs turn off. The charging process is continued indeed, but even if you install the
HMI again, you will not see the capacity indication LEDs again.
During charging, the capacity is indicated by lighting and flashing of the battery’s
LEDs as follows:
LED 1 flashing: 0 –20 % charged capacity
LED 1 lighting and LED 2 flashing: 21 –40 % charged capacity
LED 1,2 lighting and LED 3 flashing: 41 –60 % charged capacity
LED 1,2,3 lighting and LED 4 flashing: 61 –80 % charged capacity
LED 1,2,3,4 lighting and LED 5 flashing: 81 –99 % charged capacity
LED 1,2,3,4 and 5 lighting: 100 % charged capacity
Break up of charging process
- To complete the charging, switch off the charger and unplug the charging plug of the
battery. Reattach the cap of the charging socket and pull the power plug of the charger from
the wall socket.
- If you charged your battery within your eBike, so please turn off and on your drive system,
so that it can calculate the range.
Charging with your original charger is completed, as soon as all LEDs are lighting
permanently.
With the E-Bike Vision fast charger, charging is completed, as soon as all LEDs of the
battery are lighting and charger LED is lighting solid green or red.
If the charger’s LED lights red, this is no cause for concerns. This can signalise for
example, that the battery management system has finished charging for balancing the
individual cell voltages of the installed cells. This ensures the lifetime and the safety
of your battery.
Charging time
The battery with a capacity of 13 Ah requires about 4 hours to be fully charged with the
standard charger and about 2 hours with our fast charger.
The battery with a capacity of 17 Ah requires about 5 hours to be fully charged with the
standard charger and about 3 hours with our fast charger.
Of course, you can continue to use your old charger. Please proceed as described
within the manufacturer’s manual.
ATTENTION: Charge your Power Pack always with minimum 4A charge current (that is
called the so called rapid charging)!
If you own the first generation charger (metallic housing), please make sure that you charge
in the rapid charge mode (indicated by the flashing charger LED).

Manual for Power Pack compatible for Bosch* Classic (+) drive system
* Bosch is a trademark of the Robert Bosch GmbH Page 8of 9
Battery usage
Please consider the safety instruction given earlier during usage of your E-Bike Vision Power
Pack.
Your Power Pack will enter automatically into sleep-mode (if it is not installed in the
eBike) after 3 seconds to prevent itself of self-discharging. Also, it will shut down the
drive system after 10 minutes of no use of the eBike. It is irrelevant whether the lights
are enabled or not!
Take care, that the battery is in it’s correct position, before inserting. If not, you can
damage the battery’s housing.
Before each use of Power Pack, it must be activated by pushing the capacity indicator
button or by pushing the ON / OFF switch of the HMI.
Do not press the capacity indicator button several times in quick succession, this
activates and deactivates the battery once again.
You installed your new E-Bike Vision Power Pack correctly in your eBike and locked it (do
not forget to remove the key)? Then turn on the drive system by the capacity indication
button or via the ON /OFF switch of your HMI. The drive system now read the current
capacity of the battery and will calculate the approximated range, based on your previous
driving profile. The drive system is ready for use as soon as the speed is displayed.
Capacity is indicated during use as folows:
LED 1 flashing: 0 –5 % charged capacity
LED 1 lighting: 6 –20 % charged capacity
LED 1 and 2 lighting: 21 –40 % charged capacity
LED 1,2 and 3 lighting: 41 –60 % charged capacity
LED 1,2,3 and 4 lighting: 61 –80 % charged capacity
LED 1,2,3,4 and 5 lighting: 81 –100 % charged capacity
Do not remove your battery off the eBike, as long as the drive system is on. Turn it off
before!
Your new Power Pack owns the latest and most safely battery management system
technology and protects itself from incorrect operation. Before the cells would be completely
discharged, the battery switches off the motor. However, there will remain enough power
within the battery, to drive safe home with activated lights, if you are powering the lights via
the drive battery.

Manual for Power Pack compatible for Bosch* Classic (+) drive system
* Bosch is a trademark of the Robert Bosch GmbH Page 9of 9
Maintenance
The life span of your Power Pack depends mainly of your carefully usage.
Never use the complete capacity, but use it regular and store it at 17° C. That way, your
battery will thank you will longer life span.
With increasing aging your battery will loose capacity, anyway.
Do not try to refresh or exchange the cells on your own!
Get in contact with our service department. They can also rate and exchange single
components after the warranty time.
An essential shorte usage time after fully charged the battery indicates that the battery is
dissipated, however. Replace it!
Troubleshooting
If your drive system can not be activated, please check the contacts of the discharge plug to
make sure that they are clean, straight and undamaged and that there is a safe contact
between battery and connector box.
If the drive system can still not be activated, please try to charge your battery.
If charging does not start, please check the polarity of the charge plug.
Please test the battery by pushing the capacity indicator button.
Is the power cord of the charger connected properly and performs the wallet socket?
Is the green LED of the charger flashing? If this is flashing red, there can be a short circuit.
Charger and battery must be returned to the E-Bike Vision service center.
If the battery is damaged, defective or exits any liquids or smell? Please do not use your
Power Pack further and contact your dealer or our service center.
Recycling
Do not dispose lithium batteries in the household waste!
Return defective or used batteries to the battery dealers or to the municipal waste
collection centers. Turn back the battery in discharged state. Also prevent short-
circuits by covering the terminals.
With the proper disposal of your battery, you make an important contribution to protect our
environment.
